Greetings Started in 1983 in Gardner, MA with three employees 30 years later in Gardner MA, our new facility Please visit our new facility Manufacturing Facility Company History 30 years of Growth and Experience Privately owned and

slide-1
SLIDE 1

Greetings

slide-2
SLIDE 2

Please visit our new facility

Started in 1983 in Gardner, MA with three employees 30 years later in Gardner MA, our new facility

slide-3
SLIDE 3

Manufacturing Facility

slide-4
SLIDE 4

Company History

  • 30 years of Growth and Experience
  • Privately owned and operated
  • December 1983 – Data Guide Cable was incorporated
  • 2010 – Moved to Sherman St., Gardner Massachusetts
slide-5
SLIDE 5

Cables for every application

 Audio Cables  Broadcast and Studio Cables  Breather Tubes  Bus Drop Cables  Chemical and Solvent Resistant Cables  Control Cables - (2010-600V – 3015-1000V)  Deep Well Submersible Cables  Direct Burial Cables  Electronic – Interconnect Cables  Extreme Low Temperature Cables  Fungus Resistant Cables  Gasoline and Oil Resistant  Guitar/Instrument Cables  IMSA Cables  Instrumentation Cables - (TC-600V – PLTC-300V)  Irrigation Cables  Load Cell Cables  Low Smoke Zero Halogen Cables  Marine Data Cables  Non –Power Limited Cables  Power Limited Cables  Riser Cables  Robotic Control and Sensing Sables  Rodent Resistant Cables  Severe Abrasion Resistant Cables  Simultaneous Transmission Cables  Water Recovery System Cables  Weather and Sunlight Resistant Cables  Well-Drilling Instrumentation Cables
slide-6
SLIDE 6

Application break down

  • Tray Applications needing ER approval
  • TC-ER for use with cable trays without conduit
  • Machine Tools
  • Machine and plant construction
  • HVAC
  • Assembly and production lines
  • Industrial applications
———————————————————————————————————
  • Multi-conductor VFD and Motor Applications to connect power from drives to
motors plus one control pair.
  • Designed for harsh industrial environments and operating conditions with
voltage spikes and high noise levels. ———————————————————————————————————
  • Machine Builder - motor and control cables
  • Markets: bottling, control panels, paper converting, conveyor systems,
food processing, machine tools, packaging, robotics
slide-7
SLIDE 7

How many years has Data Guide Cable been in business?

slide-8
SLIDE 8

Capabilities

CONDUCTOR RANGE
  • Sizes 28 AWG through 2 AWG
INSULATION CAPABILITIES
  • Polyvinyl Chloride (PVC)
  • Polyethylene (PE)
  • Polypropylene (PP)
  • Hytrel
  • Foamed PE & Foamed PP
  • With or Without PVC Skins
  • Thermal Plastic Rubber (TPR)
  • Plenum PVC Alloy
  • PVC/Nylon Tandem
  • Low Smoke Zero Halogen
CABLING METHODS
  • Cabling
  • Twinning
  • Bunching
  • Planetary Cablers
SHIELDING
  • Foil and Drain
  • Copper Tapes
  • Spiral Wire Shields
  • Braid Shields: 16 & 24 carrier Braided Armor:
Steel, Aluminum, Bronze JACKETS to 1.50” DIAMETER NON-PLENUM
  • Polyvinyl Chloride (PVC)
  • Low Density Polyethylene (LDPE)
  • High Density Polyethylene (HDPE)
  • Polyurethane
  • Thermal Plastic Rubber (TPR)
  • Low Smoke Zero Halogen
PLENUM
  • Polymer-Alloy
  • Kynar
slide-9
SLIDE 9

Approvals

 UL Type TC-ER  UL/CSA/CE  UL AWM  (UL) Type MTW or DP-1  WTTC  Class 1, Div. 2 per NEC  Art. 336,392,501  C(UL) TC  CIC FT4  UL 1277  Oil Res I / II  RoHS  Compliant with NFPA 79

.

slide-10
SLIDE 10

Certifications

slide-11
SLIDE 11

We do NOT manufacture

X ETFE X PVDF X Neoprene X Kynar Hi-Temperature cables X Not a coax house, we make a select few X Not a coil cord house X Not a cord house – unless it is a special X We do not manufacture continuous corrugated armor

X

slide-12
SLIDE 12

Thank You!
