FOCUS Series Optical Closures

Outside Plant Enclosures

• Single Circuit, Single element & Mass splicing solutions
• 3 different sizes of round closures
• 2 different sizes of flat closures
• Cold seals and heat-shrink seals
• Multi-cable seals for smaller diameters
• Base with 2 oval ports available
• High density trays available
• Carrier class specifications

In this presentation

• Types of organizer trays
• Sealing
• Cold applied seals
• Heat shrink seals
• Types of closures
• ODC: Optical Distribution Closure
• CODC: Compact Optical Distribution Closure
• MSC: Mass Splicing Closure
• Closure capacities
• Accessories

SAM splice array modules

Cold Applied Sealing Kits

• Each seal is re-accessible and allow easy and fast

installation of any cable even when other cables are pre-installed in the same port.

• Whatever the construction of the cable is, all

sealing kits allow to terminate either the aramid yarns or the strength member in order to provide a good resistance to accidental forces.

• Depending on the size of the cable, each sealing

kit permits the entrance of one or more cables in the same port even in different sequences.

• The sealing (IEC529 and IP68) in all circumstances

is always guaranteed.

Cold Applied Oval port sealing kits

2500963 Oval port, cold applied cable seal kit for 1 continous looped cable with dia. 5mm ~ ≤10mm + 2 drop cables with same diameter 2500970 Oval port, cold applied cable seal kit for 1 continous looped cable with dia. 10mm ~ ≤20mm

Cold Applied Round port sealing kits

2500981 Round port cold applied sealing kit for max 8 cable with dia. ≤ 6mm 2500962 Round port cold applied sealing kit for max 6 cables with dia. 4mm ~ ≤ 8mm 2500981 Round port cold applied sealing kit for max 2 cables with dia. 6mm ~ ≤ 12mm

2500984 Round port cold applied sealing kit for max 16 cables with dia. ≤ 3mm 2500980 Round port cold applied sealing kit for max 1 cable with dia. 12mm ~ ≤ 20mm

Cold Applied Round port sealing kits

Heat Shrinkable sealing kits

• The sealing kits consist of heat shrinkable tubing

made from high performance cross linked polyolefin coated internally with hot melt adhesive to give high mechanical and environmental protection.

• When heated with a standard gas torch, or similar

heat source, the tubing shrinks to follow the shape of the outlets and cables to be protected.

• The hot melt adhesives or sealant flows to fill any

cavities or surfaces to guarantee IP68 level of

• protection. Inside every kit are all the components to

prepare and terminate all type of cables with different constructions

2500951 Heat-shrinkable sealing oval port kit 2500952 Heat-shrinkable sealing port A kit 2500953 Heat-shrinkable sealing two port B kit

Heat Shrinkable sealing kits

Heat Shrinkable sealing kits

2500960 Heat-shrinkable sealing port A kit and second cable pre-arranging kit 2500954 Heat-shrinkable sealing second cable kit

FOCUS – ODC

FOCUS – ODC features

• Sealed single-ended closure
• Splicing and passive component integration
• Acc. IEC 529, IP68
• Use with FOCUS-SAM and FOCUS-HD modules and/or passive device sub-

assemblies.

• Equipped for all cable termination and sealing requirements.
• One or two oval entry ports for looped (uncut) cable
• Six, eight or eighteen round ports for drop cables entry/exit
• Uncut loose buffer tube storage space is available between the two stacks.
• Trays flip up and stay in position (no need for tray wedge)
• Cold seals have the same sealing performance as heat shrink
• Fibers cross in tray (not in groove) to increase installer friendliness
• Easy guiding system for cable tubes
• High-Density trays increase capacity
• Standard delivered with valve

FOCUS – ODC capasity

FOCUS – CODC

FOCUS – CODC features

• Sealed single-ended closure
• Splicing and passive component integration
• Acc. IEC 529, IP68
• The flat rectangular shape guarantees installation in restricted environment
• Use with FOCUS-SAM and FOCUS-HD modules and/or passive device sub-

assemblies.

• Equipped for all cable termination and sealing requirements.
• One oval entry ports for looped (uncut) cable
• Eight round ports for drop cables entry/exit
• Uncut loose buffer tube storage space behind the splice tray stack.
• Trays flip up and stay in position (no need for tray wedge)
• Cold seals have the same sealing performance as heat shrink
• Fibers cross in tray (not in groove) to increase installer friendliness
• Easy guiding system for cable tubes
• High-Density trays increase capacity
• Standard delivered with valve

FOCUS – CODC capasity

FOCUS - MSC

• Single-ended mass-splicing
• Up to 8 hinged FOCUS Mass Splice Trays (MST)
• Until 768 splices (up to 12 splices in each holder)
• Possibility to store and protect passive components

(splitters, WDMs, optical circuits) in a separate area

• n the tray
• Basket to store loose buffer tubes (can be mounted

with the window opening facing inside or outside)

• Acc. IEC 529, IP68
• 1 oval cable entry port 88 x 41mm
• 6 round cable entry ports Ø 32mm

Accessories

2500950 Bracket for mounting ODC/MSC closures on a wall 2500949 Bracket for mounting CODC closures on a wall 2500979 Bracket for cables or pipes fixing 2500956 Bracket for mounting ODC/MSC closures on a pole 3197640 Pole storage bracket
