slide-1
SLIDE 1

GeoPrisma GeoPrisma

Boreal Boreal Information Strategies Inc. Information Strategies Inc. Mapgears Inc. Mapgears Inc.

slide-2
SLIDE 2

GeoSpatial data over the Web GeoSpatial data over the Web

GeoSpatial data Web

slide-3
SLIDE 3

Need : access control Need : access control

?

slide-4
SLIDE 4

Sample : GMap Sample : GMap

slide-5
SLIDE 5

Several single applications Several single applications

slide-6
SLIDE 6

x x applications = hard to maintain applications = hard to maintain

slide-7
SLIDE 7

GeoPrisma GeoPrisma Solution

A web mapping application A web mapping application featuring access control to featuring access control to geospatial data with dynamic user geospatial data with dynamic user interfaces. interfaces.

slide-8
SLIDE 8

GeoPrisma features GeoPrisma features

Built on OpenSource libraries Architecture Access controlled data (proxy) Integration with any authentication libraries Integration with any geospatial services Links to external applications Dynamic User Interface (UI) Custom template i18n support Access controlled functionality (widgets)

slide-9
SLIDE 9

Built on OpenSource libraries

OpenLayers OpenLayers MapFish MapFish GeoExt GeoExt ExtJS ExtJS FeatureServer FeatureServer MapServer MapServer TileCache TileCache etc. etc.

slide-10
SLIDE 10

Under the hood Under the hood

WMS WMS WPS WPS FeatureServer FeatureServer TileCache TileCache

Scribble

MapFishServer MapFishServer

slide-11
SLIDE 11

Standard architecture Standard architecture

Web browser Application

OpenLayers OpenLayers MapFish MapFish GeoExt GeoExt

Services

WMS WMS WFS WFS FeatureServer FeatureServer TileCache TileCache

Data

slide-12
SLIDE 12

Architecture with GeoPrisma Architecture with GeoPrisma

Web browser Application

OpenLayers OpenLayers MapFish MapFish GeoExt GeoExt

Services

WMS WMS WFS WFS FeatureServer FeatureServer TileCache TileCache

Data

GeoPrisma GeoPrisma

slide-13
SLIDE 13

Access control by a proxy Access control by a proxy

wms tiles

feature

etc. .

GetMap request GetMap request Response Users GeoPrisma (Proxy) GeoSpatial services UI

slide-14
SLIDE 14

Proxy Proxy

Authentication Access control list Data filtering

Components

slide-15
SLIDE 15

LDAP JOSSO DataBase XML Yours...

Integration with any authentication libraries

Proxy Proxy

slide-16
SLIDE 16

WMS FeatureServer TileCache GYMO Any...

Proxy Proxy

Integration with any geospatial service

slide-17
SLIDE 17

Proxy Proxy

Your application !

Links to external applications

slide-18
SLIDE 18

Architecture with GeoPrisma Architecture with GeoPrisma

Web browser

GeoPrisma GeoPrisma

Application

OpenLayers OpenLayers MapFish MapFish GeoExt GeoExt

Services

WMS WMS WFS WFS FeatureServer FeatureServer TileCache TileCache

Data

GeoPrisma GeoPrisma

slide-19
SLIDE 19

Dynamic User Interface Dynamic User Interface

Custom UI templates

slide-20
SLIDE 20

i18n support

Dynamic User Interface Dynamic User Interface

English

slide-21
SLIDE 21

i18n support

Dynamic User Interface Dynamic User Interface

French

slide-22
SLIDE 22

i18n support

Dynamic User Interface Dynamic User Interface

Non roman languages

slide-23
SLIDE 23

Dynamic User Interface Dynamic User Interface

Widgets automatically added if access granted

slide-24
SLIDE 24

Widgets automatically added if access granted

Dynamic User Interface Dynamic User Interface

slide-25
SLIDE 25

Widgets

Map MapPanel Toolbar ZoomSlider Query FeaturePanel Editing tools InitialView Merge Split Scale MousePosition MeasureTool LayerTree Recenter ...

Dynamic User Interface Dynamic User Interface

Built with OpenLayers, MapFish, GeoExt, ExtJS, etc.

slide-26
SLIDE 26

Review : GMap sample

Dynamic User Interface Dynamic User Interface

C Create reate R Read ead U Update pdate D Delete elete

slide-27
SLIDE 27
slide-28
SLIDE 28
slide-29
SLIDE 29
slide-30
SLIDE 30
slide-31
SLIDE 31
slide-32
SLIDE 32

Contributors

Boreal Information Strategies Inc. Boreal Information Strategies Inc. Mapgears Inc. Mapgears Inc. Nippour Geomatik Nippour Geomatik

slide-33
SLIDE 33

Conclusion

We want your feedback ! We want your feedback ! http://geoprisma.org/download http://geoprisma.org/download

slide-34
SLIDE 34

1

GeoPrisma GeoPrisma

Boreal Boreal Information Strategies Inc. Information Strategies Inc. Mapgears Inc. Mapgears Inc.

Borealis MapGears

slide-35
SLIDE 35

2

GeoSpatial data over the Web GeoSpatial data over the Web

GeoSpatial data Web

A common problem today is to bring geospatial data

  • ver the web.

This has been solved already in the past; we won't bore you with that.

slide-36
SLIDE 36

3

Need : access control Need : access control

?

But what about access control ? What if you want to bring your data over to the web, but not to everyone?

slide-37
SLIDE 37

4

Sample : GMap Sample : GMap

The easiest way to demonstrate the need is with an example. Here's the Gmap demo. Let's apply some access control to it.

slide-38
SLIDE 38

5

Several single applications Several single applications

Without an access control tool, you would have to create several individual applications and apply security to each one.

slide-39
SLIDE 39

6

x x applications = hard to maintain applications = hard to maintain

Several applications to maintain is counterproductive.

slide-40
SLIDE 40

7

GeoPrisma GeoPrisma Solution

A web mapping application A web mapping application featuring access control to featuring access control to geospatial data with dynamic user geospatial data with dynamic user interfaces. interfaces.

Our solution : GeoPrisma A web mapping application featuring access control to geospatial data and dynamic user interfaces.

slide-41
SLIDE 41

8

GeoPrisma features GeoPrisma features

Built on OpenSource libraries Architecture Access controlled data (proxy) Integration with any authentication libraries Integration with any geospatial services Links to external applications Dynamic User Interface (UI) Custom template i18n support Access controlled functionality (widgets)

Now let's take a closer look at it. There are 2 main features to GeoPrisma: a proxy and a dynamic UI. But first let's present Geoprisma.

slide-42
SLIDE 42

9

Built on OpenSource libraries

OpenLayers OpenLayers MapFish MapFish GeoExt GeoExt ExtJS ExtJS FeatureServer FeatureServer MapServer MapServer TileCache TileCache etc. etc.

First of all, GeoPrisma does not reinvent the wheel. We use existing and proven Open Source components such as OpenLayers, MapServer, MapFish and others...

slide-43
SLIDE 43

10

Under the hood Under the hood

WMS WMS WPS WPS FeatureServer FeatureServer TileCache TileCache

Scribble

MapFishServer MapFishServer

Under the hood the concept is quite simple. Access control on the data is configured in an XML file. Multiple services can be defined, WMS, FeatureServer, TileCache and soon MapFishServer or WPS. All those services can serve the same layer. In GeoPrisma we regroup all those services under a component we call resource. And it's on the resource that we apply access control.

slide-44
SLIDE 44

11

Standard architecture Standard architecture

Web browser Application

OpenLayers OpenLayers MapFish MapFish GeoExt GeoExt

Services

WMS WMS WFS WFS FeatureServer FeatureServer TileCache TileCache

Data

To illustrate what we are saying, here's a typical web mapping architecture, composed of a client browser running JavaScript applications (like OpenLayers) connecting with services on a server (WMS, WFS, TileCache).

slide-45
SLIDE 45

12

Architecture with GeoPrisma Architecture with GeoPrisma

Web browser Application

OpenLayers OpenLayers MapFish MapFish GeoExt GeoExt

Services

WMS WMS WFS WFS FeatureServer FeatureServer TileCache TileCache

Data

GeoPrisma GeoPrisma

GeoPrisma provides an access control layer that fits in between the client and the services.

slide-46
SLIDE 46

13

Access control by a proxy Access control by a proxy

wms tiles

feature

etc. .

GetMap request GetMap request Response Users GeoPrisma (Proxy) GeoSpatial services UI

Here's a simple example. When a user tries to connect to a WMS service, GeoPrisma checks if she has access to it and sends the request to the server to get a map If the user doesn't have access then the request is denied

slide-47
SLIDE 47

14

Proxy Proxy

Authentication Access control list Data filtering

Components

You may ask yourself: what.s so special with GeoPrisma? I can do that in PHP or Python or whatever. Sure, but our proxy can integrate with any authentication library and connect to any geospatial service.

slide-48
SLIDE 48

15

LDAP JOSSO DataBase XML Yours...

Integration with any authentication libraries

Proxy Proxy

We currently have drivers to use LDAP, JOSSO, PostgreSQL DB, XML files for authentication. And it's easy to make more : extend a PHP class !

slide-49
SLIDE 49

16

WMS FeatureServer TileCache GYMO Any...

Proxy Proxy

Integration with any geospatial service

Arbitrary services can be configured to work with GeoPrisma, not just OGC web services You can see the list of currently supported services and ... It's easy to make more : extend a PHP class !.

slide-50
SLIDE 50

17

Proxy Proxy

Your application !

Links to external applications

GeoPrisma can also connect to external applications. We already did it with GeoNetwork and with an application you can see in the presentation at 11:30 in Parkside G04.

slide-51
SLIDE 51

18

Architecture with GeoPrisma Architecture with GeoPrisma

Web browser

GeoPrisma GeoPrisma

Application

OpenLayers OpenLayers MapFish MapFish GeoExt GeoExt

Services

WMS WMS WFS WFS FeatureServer FeatureServer TileCache TileCache

Data

GeoPrisma GeoPrisma

The second big strength of GeoPrisma is its user interface generation capabilities. In a GeoPrisma application, the UI is always automatically generated based on the user permissions. That means that GeoPrisma generates a user interface based on specific user access. The tools can be „secured”.

slide-52
SLIDE 52

19

Dynamic User Interface Dynamic User Interface

Custom UI templates

The UI is generated using a templating system, currently XSLT. The same application can have a different look for different clients or users.

slide-53
SLIDE 53

20

i18n support

Dynamic User Interface Dynamic User Interface

English

Also, GeoPrisma was built with internationalisation support from the start. GeoPrisma's widgetry is currently available in English and French.

slide-54
SLIDE 54

21

i18n support

Dynamic User Interface Dynamic User Interface

French

French You can see the layer tree and tooltips text changing

slide-55
SLIDE 55

22

i18n support

Dynamic User Interface Dynamic User Interface

Non roman languages

Even a non roman language ! Well, that's more a mixture of characters, but it shows right-to-left language support. BTW, the maps you just saw are from a real world application using GeoPrisma deployed at the end of the summer.

slide-56
SLIDE 56

23

Dynamic User Interface Dynamic User Interface

Widgets automatically added if access granted

But let's come back to one of the main reasons you want to use GeoPrisma: the automatically generated user interface. The tools (also known as widgets) in your application will be included only if you have the right access to the data they operate on.

slide-57
SLIDE 57

24

Widgets automatically added if access granted

Dynamic User Interface Dynamic User Interface

It's true for all the elements in the interface : the layers in the map and the legend of course But also for more specific tools like the query button

  • r the online editing features.
slide-58
SLIDE 58

25

Widgets

Map MapPanel Toolbar ZoomSlider Query FeaturePanel Editing tools InitialView Merge Split Scale MousePosition MeasureTool LayerTree Recenter ...

Dynamic User Interface Dynamic User Interface

Built with OpenLayers, MapFish, GeoExt, ExtJS, etc.

There's a nice library of widgets already included and it's growing fast. Most of them are simply the tools from OpenLayers, MapFish and GeoExt. That's one of the key ingredients of GeoPrisma : We don't reinvent the wheel When something is already available, we reuse it. If it's not, we do it and contribute it back to the right

  • project. We try to not have any custom tools in our

system.

slide-59
SLIDE 59

26

Review : GMap sample

Dynamic User Interface Dynamic User Interface

C Create reate R Read ead U Update pdate D Delete elete

Let's see GeoPrisma in pseudo-action (a 20-minute presentation doesn't allow for a live demo ;-) ) There will be 5 users with different access. Some will have read-only access and some will have read and write.

slide-60
SLIDE 60

27

This first user, the secretary, has read-only access to most features. The basic tools are included.

slide-61
SLIDE 61

28

Now if we look at the gardener, you can immediately see that with less access there are fewer layers available, but also fewer tools. Note how the gardener has the 'i' button working

  • nly for the parks. The roads are not there anymore.
slide-62
SLIDE 62

29

The civil engineer now, has write access to the roads, so there are new tools in the application. Notice the editing tools and the layer tree that now contains new layers.

slide-63
SLIDE 63

30

The settler can edit the cities as we can see. It's important to note that as the UI is built with limited tools, the transaction on the server is also secured to make sure that the queries are not hacked.

slide-64
SLIDE 64

31

Finally the Superadmin has: Full access Full layers Full widgetry

slide-65
SLIDE 65

32

Contributors

Boreal Information Strategies Inc. Boreal Information Strategies Inc. Mapgears Inc. Mapgears Inc. Nippour Geomatik Nippour Geomatik

There are three contributors right now. The project was an initiative from Boreal-IS and was developed with the help of Mapgears. Nippour Geomatik joined later on and used GeoPrisma to build a mapping portal.

slide-66
SLIDE 66

33

Conclusion

We want your feedback ! We want your feedback ! http://geoprisma.org/download http://geoprisma.org/download

Boreal-IS contributed the code from GeoPrisma and it's now an Open Source project (BSD licenced). Simply go to geoprisma.org to get more information and download the zip on a web directory for a test drive. This presentation is actually part of the official launch

  • f the project. The same presentation is also given at

around the same time in Montreal, Canada. On the

  • ther side of the planet. That's geo-diversity! :-)
