FOTOGRAFISKA NEW YORK LANDMARKS PRESERVATION COMMISSION LPC PUBLIC HEARING 281 PARK AVE SOUTH NEW YORK 19 JUNE, 2018 281 Park Avenue South 19 JUNE 2018 PAGE: 1 OF 18 E.22ND ST. E.21ST ST. SITE PLAN 281 PARK AVENUE SOUTH EXISTING

slide-1
SLIDE 1

281 Park Avenue South

PAGE: 1 OF 18 19 JUNE 2018

FOTOGRAFISKA NEW YORK

LANDMARKS PRESERVATION COMMISSION

281 PARK AVE SOUTH NEW YORK LPC PUBLIC HEARING

19 JUNE, 2018

slide-2
SLIDE 2

281 Park Avenue South

PAGE: 2 OF 30 19 JUNE 2018

EXISTING CONDITIONS

281 PARK AVENUE SOUTH SITE PLAN

E.22ND ST. E.21ST ST.

slide-3
SLIDE 3

281 Park Avenue South

PAGE: 3 OF 30 19 JUNE 2018

1905 1940’S 1894

HISTORIC IMAGES

1979

slide-4
SLIDE 4

281 Park Avenue South

PAGE: 4 OF 30 19 JUNE 2018

HISTORIC PLAN & EXISTING CONDITIONS

slide-5
SLIDE 5

281 Park Avenue South

PAGE: 5 OF 30 19 JUNE 2018

EXISTING AND PROPOSED AXONOMETRIC

EXISTING- PHASE 1 PROPOSED- PHASE 2

slide-6
SLIDE 6

281 Park Avenue South

PAGE: 6 OF 30 19 JUNE 2018

EXISTING AND PROPOSED ROOF LAYOUT

EXISTING PROPOSED

RD RD RD

CLOSED ACCESS TO ROOF BUILDING PROPERTY LINE BELOW EXISTING CHIMNEY NEW SLAB ABOVE PROPOSED ELEVATOR SHAFT NEW PORTION OF EXIST. EXTERIOR STAIR EXISTING PORTION OF EXTERIOR STAIR EXISTING BULKHEAD PROPOSED RETURN AIR FAN PROPSED EXHAUST FAN PROPOSED EXHAUST FAN PROPOSED MAKE-UP AIR FAN PROPOSED MAKE-UP AIR FAN PROPOSED CONSDENSING UNIT, TYP. PROPOSED CATWALK GRATING WITH STAIR OVER DUNNAGE FOR ACCESS

DN

RD RD RD SLOPE DN SLOPE DN SLOPE DN SLOPE DN SLOPE DN SLOPE DN

  • EXIST. BULKHEAD

CLOSED ACCESS TO ROOF EXISTING DUCTWORK AND DUNNAGE BUILDING PROPERTY LINE BELOW EXISTING CHIMNEY AND DUCT EXISTING MECH. EQUIPMENT

  • EXHAUST FAN

EXISTING METAL ROOFING OVER PATHWAY EXISTING MECH. EQUIPMENT EXISTING MECH. EQUIPMENT EXISTING METAL RAILING EXISTING METAL RAILING

N

PARK AVE. SOUTH EAST 22ND STREET PARK AVE. SOUTH EAST 22ND STREET

slide-7
SLIDE 7

281 Park Avenue South

PAGE: 7 OF 30 19 JUNE 2018

EAST ELEVATION

EXISTING PROPOSED

GROUND FLOOR - TOS 0' - 0" 2ND FLOOR - TOS 16' - 5" 3RD FLOOR - TOS 37' - 9" 4TH FLOOR - TOS 50' - 9" 5TH FLOOR - TOS 63' - 9" 6TH FLOOR - TOS 76' - 1" ATTIC - TOS 90' - 4" ROOF - TOS 95' - 0" CELLAR - TOS

  • 11' - 5"

T.O. EXISTING PARAPET 96' - 8 9/32"

EXISTING STEEL STAIR & RAILING EXISTING METAL ROOFING ABOVE PATHWAY & EXISTING STAIR EXISTING METAL ROOFING AT STAIR EXISTING LOUVERS ON OPENINGS EXISTING DUCTWORK EXISTING COOLING TOWER EXISTING BULKHEAD EXISTING SLOPED ROOF EXISTING CHIMNEY EXISTING MECH. EQUIPMENT

GROUND FLOOR - TOS 0' - 0" 2ND FLOOR - TOS 16' - 5" 3RD FLOOR - TOS 37' - 9" 4TH FLOOR - TOS 50' - 9" 5TH FLOOR - TOS 63' - 9" 6TH FLOOR - TOS 76' - 2 29/32" ATTIC - TOS 90' - 5 15/16" ROOF - TOS 95' - 0" CELLAR - TOS

  • 11' - 5"

FLOOR 2 LANDING 28' - 11" T.O. EXISTING PARAPET 96' - 8 9/32" 277 - FLOOR 1 3' - 0"

EXISTING CHIMNEY EXISTING BULKHEAD EXISTING SLOPED ROOF BEYOND PROPOSED DUCTWORK 5' - 6" 8' - 0" 11' - 11" PROPOSED FAN UNIT PROPOSED CONDENISING UNITS TYP. PROPOSED FAN UNIT EXISTING BUILDING EXISTING EXHAUST FAN PROPOSED DUCTWORK PROPOSED ELEVATOR HOISTWAY PROPOSED ADDTION TO EXTERIOR STAIRS PROPOSED DUCTWORK EXISTING RAILING 8' - 0" ELEVATOR PIT 8' - 0" SUMP PIT BEYOND ELEVATOR CAB 12' - 0" 10' - 5 1/2" HOIST BEAM

277 PARK AVE SOUTH 277 PARK AVE SOUTH 281 PARK AVE SOUTH 281 PARK AVE SOUTH

slide-8
SLIDE 8

281 Park Avenue South

PAGE: 8 OF 30 19 JUNE 2018

EXISTING ROOFTOP- EAST ELEVATION PROPOSED ROOFTOP- EAST ELEVATION

EXISTING AND PROPOSED ROOF PLAN DIAGRAM

PARK AVE SOUTH

281 PARK 277 PARK

E 22nd ST

6TH FLOOR - TOS 76' - 2 29/32" ATTIC - TOS 90' - 5 15/16" ROOF - TOS 95' - 0" T.O. EXISTING PARAPET 96' - 8 9/32"

EXISTING CHIMNEY EXISTING BULKHEAD EXISTING SLOPED ROOF BEYOND PROPOSED DUCTWORK 5' - 6" 8' - 0" 11' - 11" PROPOSED FAN UNIT PROPOSED CONDENISING UNITS TYP. PROPOSED FAN UNIT EXISTING BUILDING EXISTING EXHAUST FAN PROPOSED DUCTWORK PROPOSED ELEVATOR HOISTWAY PROPOSED ADDTION TO EXTERIOR STAIRS PROPOSED DUCTWORK EXISTING RAILING

6TH FLOOR - TOS 76' - 1" ATTIC - TOS 90' - 4" ROOF - TOS 95' - 0" T.O. EXISTING PARAPET 96' - 8 9/32"

EXISTING STEEL STAIR & RAILING EXISTING METAL ROOFING ABOVE PATHWAY & EXISTING STAIR EXISTING METAL ROOFING AT STAIR EXISTING LOUVERS ON OPENINGS EXISTING DUCTWORK EXISTING COOLING TOWER EXISTING BULKHEAD EXISTING SLOPED ROOF EXISTING CHIMNEY EXISTING MECH. EQUIPMENT EXISTING EXHAUST FAN 19' - 5 1/4" 7' - 2 3/4" 8' - 2" EXISTING RAILING EXISTING BUILDING

N

slide-9
SLIDE 9

281 Park Avenue South

PAGE: 9 OF 30 19 JUNE 2018

EXISTING AND PROPOSED 2ND FLOOR LAYOUT

EXISTING PROPOSED

PE-1 PE-2 UP DN UP DN EXISTING ELEVATORS
  • EXIST. STAIR A
EXIST. STAIR C PROPERTY LINE
  • EXIST. EXTERIOR STAIR
ELEVATOR / STAIR VESTIBULE RESTROOM EXISTING STAINED GLASS WINDOWS TO REMAIN EXISTING STAINED GLASS WINDOWS TO REMAIN EXISTING STAINED GLASS WINDOWS TO REMAIN EXISTING STAINED GLASS WINDOWS TO REMAIN EXISTING STAINED GLASS TO BE REMOVED AND RELOCATED. MEP CLOSET MEP CLOSET

N

PARK AVE. SOUTH EAST 22ND STREET PARK AVE. SOUTH EAST 22ND STREET

STAINED GLASS SCOPE OF WORK: Existing stained-glass window to be carefully removed from east wall and transported

  • ff-site for restoration. All stained glass and wood frame elements to be catalogued, inspected, cleaned and restored in kind.

Stained-glass window to be returned to the site and installed in the center of the second-fl

  • or restaurant space.
slide-10
SLIDE 10

281 Park Avenue South

PAGE: 10 OF 30 19 JUNE 2018

ENLARGED PLAN & WINDOW ELEVATION

slide-11
SLIDE 11

281 Park Avenue South

PAGE: 11 OF 30 19 JUNE 2018

WINDOW SECTION & EXISTING CONDITIONS

slide-12
SLIDE 12

281 Park Avenue South

PAGE: 12 OF 30 19 JUNE 2018

VIEW TOWARDS DINING ROOM

HISTORIC WINDOW FLANKED BY TWO NEW PLASTER ARCHES, WITH SAME SPRINT POINT AS ARCHED WINDOWS EXISTING STAINED GLASS WINDOW AT SOUTH FACADE LOCATION OF HISTORIC WINDOW, CENTERED OPPOSITE OF EXISTING ARCHED WINDOW

slide-13
SLIDE 13

281 Park Avenue South

PAGE: 13 OF 30 19 JUNE 2018

EXISTING CONDITIONS

  • A. VIEW OF EXISTING REAR YARD-

EAST FACADE

  • B. VIEW OF EXISTING REAR YARD-

SOUTH FACADE

PARK AVE SOUTH

281 PARK 277 PARK

E 22nd ST

A B

slide-14
SLIDE 14

281 Park Avenue South

PAGE: 14 OF 30 19 JUNE 2018

EXISTING CONDITIONS OF STAINED GLASS WINDOW

EXTERIOR INTERIOR

slide-15
SLIDE 15

281 Park Avenue South

PAGE: 15 OF 30 19 JUNE 2018

ELEVATION AND SECTION OF STAINED GLASS WINDOW

ELEVATION SCALE: 1/2”=1’-0” SECTION SCALE: 1/2”=1’-0”

VIF 13' - 6 1/2" VIF (M.O.) 14' - 7 3/8" VIF 14' - 11" STAINED GLASS WINDOW TO BE REMOVED AND RESTORED EXISTING MULLIONS TO BE REMOVED AND RESTORED WINDOW SILL VIF 5 1/2" 12' - 11 3/4" VIF 5 1/2" VIF 11 3/8" VIF 1 1/4" VIF 6' - 7 1/2" VIF 1 1/4" VIF 5' - 2 1/2" VIF 13' - 6 1/2" INTERIOR EXTERIOR EXISTING EXTERIOR WALL (TYP.) VIF 1' - 10" 2 3/8" VIF 1' - 10" 2 3/8" VIF 1' - 10" 2 3/8" VIF 2' - 2 5/8" 2 3/8" VIF 1' - 10" 2 3/8" VIF 1' - 10" 2 3/8" VIF 1' - 10"

slide-16
SLIDE 16

281 Park Avenue South

PAGE: 16 OF 30 19 JUNE 2018

EXISTING VIEW MOCK-UP VIEW PROPOSED- 3D MODEL

EXISTING AND PROPOSED VISIBILITY MOCKUP

slide-17
SLIDE 17

281 Park Avenue South

PAGE: 17 OF 30 19 JUNE 2018

EXISTING AND PROPOSED VISIBILITY MOCKUP

EXISTING VIEW MOCK-UP VIEW PROPOSED- 3D MODEL

slide-18
SLIDE 18

281 Park Avenue South

PAGE: 18 OF 30 19 JUNE 2018

EXISTING AND PROPOSED VISIBILITY MOCKUP

EXISTING VIEW MOCK-UP VIEW NO VISIBILITY PROPOSED- 3D MODEL

slide-19
SLIDE 19

281 Park Avenue South

PAGE: 19 OF 30 19 JUNE 2018

EXISTING AND PROPOSED VISIBILITY MOCKUP

EXISTING VIEW MOCK-UP VIEW- NO VISIBILITY PROPOSED- 3D MODEL

slide-20
SLIDE 20

281 Park Avenue South

19 JUNE 2018 PAGE: 20 OF 30

EXISTING AND PROPOSED VISIBILITY MOCKUP

EXISTING VIEW MOCK-UP VIEW PROPOSED- 3D MODEL

slide-21
SLIDE 21

281 Park Avenue South

PAGE: 21 OF 30 19 JUNE 2018

EXISTING AND PROPOSED VISIBILITY MOCKUP

EXISTING VIEW MOCK-UP VIEW- NO VISIBILITY

slide-22
SLIDE 22

281 Park Avenue South

19 JUNE 2018 PAGE: 22 OF 30

EXISTING AND PROPOSED VISIBILITY MOCKUP

EXISTING VIEW MOCK-UP VIEW PROPOSED- 3D MODEL

slide-23
SLIDE 23

281 Park Avenue South

PAGE: 23 OF 30 19 JUNE 2018

EXISTING AND PROPOSED VISIBILITY MOCKUP

EXISTING VIEW MOCK-UP VIEW PROPOSED- 3D MODEL

slide-24
SLIDE 24

281 Park Avenue South

19 JUNE 2018 PAGE: 24 OF 30

EXISTING AND PROPOSED VISIBILITY MOCKUP

EXISTING VIEW MOCK-UP VIEW PROPOSED- 3D MODEL

slide-25
SLIDE 25

281 Park Avenue South

19 JUNE 2018 PAGE: 25 OF 30

PROPOSED EXTERIOR LIGHTING

1 4 3 2 5 WEST FACADE- PARK AVE SOUTH 2 3 4 5 NORTH FACADE- EAST 22ND STREET 1

slide-26
SLIDE 26

281 Park Avenue South

19 JUNE 2018 PAGE: 26 OF 30

EXTERIOR LIGHTING DETAILS

DEATIL SECTION (KC) SECTION LIGHTING (KC) LIGHTING PLAN (KC) SCALE: 1”=1’-0” SCALE: 1/4”=1’-0” SCALE: 1/16”=1’-0”

INTERIOR EXTERIOR

P L

CONCRETE EMBEDED ELECTRICAL CONDUIT 2-3/8" DIA. STAINLESS STEEL THREADED RODS EMBEDS 3-1/2" MIN. ATTACHED W/POWER RAWL AC-100+COLD ADHESIVE OR APP EQUAL (PER MANUFACTURER) CONCRETE EMBEDED ELECTRICAL CONDUIT BLOCKING KC - IN GROUND LIGHTING EMBEDED METAL HOUSING EXISTING SIDEWALK CAULK AND SEALANT EXISTING FACADE BEYOND EXISTING DOOR ENTRANCE GROUND FLOOR - TOS 0'-0" 1' - 11 1/4" 8" MAX

PE-1 PE-2
  • PE-1
PE-2
  • PE-1
PE-2
  • PARK AVENUE SOUTH ENTRANCE

KC - IN GROUND LIGHTING EXISTING FACADE PROPERTY LINE STAIR TO SUBWAY 9" 9"

EAST 22ND STREET

NOTE: CONCEPT DETAILS ASSUME PROPER INSTALLATION OF ALL PROPOSED FIXTURES IS POSSIBLE, PENDING COMPLETE FIELD CONDITION SURVEY INFORMATION. SAME CONCEPT OF WEST FACADE WILL APPLY TO NORTH FACADE.

TYPICAL IN-GRADE UPLIGHTING (LT-KC) 1

IN-GRADE UP-LIGHT

  • HIGHLIGHTS RUSTICATION AND ARCHITECTURAL ELEMENTS
  • DRAWS THE EYE UPWARDS TO CELEBRATE VERTICALITY
slide-27
SLIDE 27

281 Park Avenue South

19 JUNE 2018 PAGE: 27 OF 30

FACADE ELEVATION (KB) DETAIL SECTION (KB) FACADE PLAN (KB) SCALE: 1/4”=1’-0” SCALE: 1 1/2”=1’-0” SCALE: 1/4”=1’-0”

EXTERIOR LIGHTING DETAILS

TYPICAL WINDOW LIGHTING (LT-KB) 2

KB - LIGHT FIXTURE CONTINUOUS METAL BAFFLE FINISH TO MATCH EXISTING STONE FACADE CAULK AND SEAL METAL PLATE ATTACHED TO WINDOW SILL FRAME. FINISH TO MATCH EXISTING STONE FACADE EXISTING WINDOW 1' - 3 1/4" 5 5/8" 1' - 2 1/8" PRESSURE TREATED WOOD BLOCKING

1/8" / 1'-0"

RUN ALL CONDUIT OF FIXTURE THROUGH CAULK JOINT BETWEEN WINDOW FRAME AND STONE AT ABOUT 1" ABOVE EDGE OF WINDOW FRAME EXTERIOR INTERIOR VIF 5 3/8" VIF 6" VIF 2' - 11" 4 1/8" EXISTING LEDGE TO REMAIN LT-KA BEYOND ATTACH BLOCKING TO STONE WITH 5/16" D. STAINLESS STEEL THREADED RODS @ 24" O.C. EMBED 2" MIN. IN 3/8" D HOLES, ATTACHE WITH BONSTONE M80 ANCHOR SETTING MORTART OR APPROVED EQUAL LT-KA TYP. RUN ALL CONDUIT OF FIXTURE THROUGH CAULK JOINT BETWEEN WINDOW FRAME AND STONE AT ABOUT 1” ABOVE EDGE OF WINDOW FRAME. J-BOX LOCATED AT INTERIOR OF WINDOW. LT-KB TYP.

NOTE: CONCEPT DETAILS ASSUME PROPER INSTALLATION OF ALL PROPOSED FIXTURES IS POSSIBLE, PENDING COMPLETE FIELD CONDITION SURVEY INFORMATION. SAME CONCEPT OF WEST FACADE WILL APPLY TO NORTH FACADE.

LINEAR WINDOW SILL UP-LIGHT

  • CELEBRATES THE DEEP ARCHITECTURAL DETAILS IN

WINDOWS

slide-28
SLIDE 28

281 Park Avenue South

19 JUNE 2018 PAGE: 28 OF 30

KA - LIGHT FIXTURE, FINISH TO MATCH EXISTING STONE FACADE PRESSURE TREATED WOOD BLOCKING ATTACH BLOCKING TO STONE WITH 5/16" D. STAINLESS STEEL THREADED RODS @ 24" O.C. EMBED 2" MIN. IN 3/8" D HOLES, ATTACHE WITH BONSTONE M80 ANCHOR SETTING MORTART OR APPROVED EQUAL EXISTING WINDOW 9 5/8" 2' - 1 1/4" RUN ALL CONDUIT OF FIXTURE THROUGH CAULK JOINT BETWEEN WINDOW FRAME AND STONE AT ABOUT 1" ABOVE EDGE OF WINDOW FRAME. V.I.F. EXTERIOR INTERIOR VIF 5 3/8" VIF 6" VIF 2' - 11" EXISTING LEDGE TO REMAIN 6 5/8" CAULK AND SEAL

1 / 8 " / 1 '

  • "

TYPICAL COLUMN LIGHTING (LT-KA) 3

EXTERIOR LIGHTING DETAILS

DETAIL SECTION (KA) SCALE: 1 1/2”=1’-0”

NOTE: CONCEPT DETAILS ASSUME PROPER INSTALLATION OF ALL PROPOSED FIXTURES IS POSSIBLE, PENDING COMPLETE FIELD CONDITION SURVEY INFORMATION. SAME CONCEPT OF WEST FACADE WILL APPLY TO NORTH FACADE.

FACADE ELEVATION (KA) FACADE PLAN (KA) SCALE: 1/4”=1’-0” SCALE: 1/4”=1’-0”

LT-KA TYP. RUN ALL CONDUIT OF FIXTURE THROUGH CAULK JOINT BETWEEN WINDOW FRAME AND STONE AT ABOUT 1” ABOVE EDGE OF WINDOW FRAME. J-BOX LOCATED AT INTERIOR OF WINDOW. LT-KB TYP.

MINIATURE POINT SOURCE UP-LIGHT AT COLUMNS

  • VERY SMALL FIXTURES PLACED AT THE SIDES OF

EACH WINDOW PROVIDE SHARP “FLAMES” OF LIGHT THAT ACCENTUATE VERTICALITY

  • FINSIH TO MATCH ADJACENT STONE
slide-29
SLIDE 29

281 Park Avenue South

19 JUNE 2018 PAGE: 29 OF 30

TYPICAL BALUSTRADE LIGHTING (LT-KD) 4

EXTERIOR LIGHTING DETAILS

DETAIL SECTION (KD) FACADE ELEVATION (KD) FACADE PLAN (KD) SCALE: 1 1/2”=1’-0” SCALE: 1”=1’-0” SCALE: 1”=1’-0”

NOTE: CONCEPT DETAILS ASSUME PROPER INSTALLATION OF ALL PROPOSED FIXTURES IS POSSIBLE, PENDING COMPLETE FIELD CONDITION SURVEY INFORMATION. SAME CONCEPT OF WEST FACADE WILL APPLY TO NORTH FACADE.

3RD FLOOR - TOS 37' - 9"

KD - LIGHT FIXTURE METAL BAFFLE. FINISH TO MATCH STONE FACADE BLOCKING STRUCTUALLAY ADHERE TO LEDGE. CAULK & SEALANT 2" LEADER CABLE SECURED AROUND BALUSTRADES W/STRUCTURAL ADHESIVE. COLOR TO MATCH STONE EXTERIOR INTERIOR VIF 7 3/8" EQ EQ BLOCKING STRUCTUALLY ADHERE TO LEDGE. EXISTING EXTERIOR WALL ASH FILL OR SLEEPERS 1" DIA. MAX. ELECTRICAL CONDUIT THROUGH EXISTING

  • FACADE. ONE CONDUIT PER BAY.

PROVIDE WATERPROOFING SEALANT AROUND OPENINGS. EXISTING STRUCTURAL BACKUP TO BE VERIFIED IN FIELD BEFORE ANY PENETRATION THROUGH FACADE IS DONE. FACADE EXISTING STONE V.I.F. WALL CAVITY F.F.E. EQ EQ METAL BAFFLE. FINISH COLOR TO MATCH STONE PROPERTY LINE EXISTING EXTERIOR STONE FACADE KD - LIGHT FIXTURE. STRUCTURALLY ADHERE TO LEDGE. EQ EQ LEADER CABLE SECURED AROUND BALUSTRADES. COLOR TO MATCH STONE 1" DIA. MAX. ELECTRICAL CONDUIT THROUGH EXISTING FACADE. PROVIDE WATERPROOFING SEALANT AROUND OPENINGS. V.I.F. WALL CAVITY

3RD FLOOR - TOS 37' - 9"

EQ EQ EQ V.I.F. KD - LIGHT FIXTURE EXISTING EXTERIOR BALUSTRADE EXISTING EXTERIOR UPPER FACADE LEDGE LEADER CABLE SECURED AROUND BALUSTRADES. COLOR TO MATCH STONE

BALUSTRADE POINT SOURCE UP-LIGHT

  • TINY “LIGHT FLAMES” PLACED BETWEEN EACH BALUSTRADE ELEMENT CELEBRATE

THE ARCHITETURE WHILE MAINTAINING VERTICALITY

slide-30
SLIDE 30

281 Park Avenue South

19 JUNE 2018 PAGE: 30 OF 30

TYPICAL LANTERN LIGHTING (LT-KE) 5

EXTERIOR LIGHTING DETAILS

EQ EQ EQ EQ EQ EQ KE PENDANT LIGHT FIXTURE, TENSION CABLE OR STEM. MOUNTING PENDING FIELD SURVEY EXISTING STONE STRUCTURE TO REMAIN KE PENDANT LIGHT FIXTURE, TENSION CABLE OR STEM. MOUNTING PENDING FIELD SURVEY LEADER CABLE, SURFACE MOUNTED ALONG THE INSIDE 5/16" DIA. STAINLESS STEEL EYEBOLT, TURN VERT., EMBEDED 2-1/2"

  • MIN. INTO STONE. ATTACH

W/M80 BY BONSTONE COOR APP. EQ. 5/16" DIA STAINLESS STEEL CABLE KE PENDANT LIGHT FIXTURE, TENSION CABLE OR STEM. MOUNTING PENDING FIELD SURVEY KE PENDANT LIGHT FIXTURE, TENSION CABLE OR STEM. MOUNTING PENDING FIELD SURVEY 5/16" DIA. STAINLESS STEEL EYEBOLT, TURN VERT., EMBEDED 2-1/2"

  • MIN. INTO STONE. ATTACH

W/M80 BY BONSTONE COOR APP. EQ. 5/16" DIA. STAINLESS STEEL CABLE 3' - 9 7/8"

EXTERIOR GLOBE PENDANT

  • “GLOWING LANTERN” LIGHT

NOTE: CONCEPT DETAILS ASSUME PROPER INSTALLATION OF ALL PROPOSED FIXTURES IS POSSIBLE, PENDING COMPLETE FIELD CONDITION SURVEY INFORMATION. SAME CONCEPT OF WEST FACADE WILL APPLY TO NORTH FACADE.

FACADE ELEVATION (KE) DETAIL SECTION (KE) DETAIL PLAN (KE) SCALE: 3/8”=1’-0” SCALE: 3/8”=1’-0” SCALE: 3/8”=1’-0”
