SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030 - - PowerPoint PPT Presentation

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 1 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC HISTORIC VIEW OF THE PRIVATE ALLEYWAY “THE KING MODEL HOUSES” RECORD & GUIDE PUBLICATION (pub. 1892)

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 2 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC EXISTING VIEW OF THE PRIVATE ALLEYWAY

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 3 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC NEIGHBORHOOD PLOT PLAN VISUAL POINTS OF REFERENCE FROM PUBLIC SIDEWALK(S) + INSIDE PRIVATE ALLEY LEGEND: 1 STORY STRUCTURE....................................................................................... 2 STORY STRUCTURE....................................................................................... 4 STORY STRUCTURE OR MORE....................................................................... NOTE: ALL PUBLIC POINTS OF REFERENCE DO NOT ALLOW FOR ANY VISIBILITY INTO THE REAR PORTION OF THE PROPERTY IN QUESTION. ONLY WITHIN THE PRIVATE EASEMENT ALLEYWAY CAN YOU SEE THE REAR PORTION OF THE PROPERTY.

FREDERICK D O U G L A S B L V D . W E S T 1 3 8 T H S T R E E T W E S T 1 3 9 T H S T R E E T

269 W 263 W 259 W 251 W 257 W 253 W 271 W 241 W 273 W 255 W 245 W 247 W 227 W 239 W 225 W 266 W 237 W 229 W 264 W 223 W 250 W 262 W 260 W 236 W 258 W 246 W

234 W

244 W 226 W 230 W 228 W 232 W 240 W 224 W 220 W 261 W 249 W 248 W 238 W

AREA OF PROPOSED WORK: 234 W 139TH STREET

265 W 235 W 267 W 256 W 243 W 221 W 231 W 222 W 233 W 254 W 242 W 252 W 272 W 270 W 268 W 202 W 214 W 216 W 208 W 206 W 212 W 218 W 210 W 204 W 219 W 217 W 215 W 213 W 211 W 209 W 207 W 205 W 203 W 200 W

2 3 6 2 A D A M C L A Y T O N B L V D .

2360 ADAM CLAYTON BLVD.

2 3 6 4 A D A M C L A Y T O N B L V D . 2 3 6 6 A D A M C L A Y T O N B L V D . 2 3 7 A D A M C L A Y T O N B L V D . 2372 ADAM CLAYTON BLVD. 2374 ADAM CLAYTON BLVD. 2376 ADAM CLAYTON BLVD. 2 3 6 8 A D A M C L A Y T O N B L V D .

ADAM C. POWELL B L V D .

PRIVATE GATE PRIVATE G A T E PRIVATE GATE PRIVATE GATE PRIVATE GATE PRIVATE G A T E

PRIVATE ALLEY PRIVATE ALLEY

LEGEND:

1 3 4 2 5 6

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 4 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC NORTH VIEW FROM 138TH STREET BETWEEN 219 W. & 221 W. 138TH STREET PRIVATE ALLEY ENTRANCE

NOTE: REAR PORTION OF THE PROPERTY IS NOT VISIBLE VIA PUBLIC SIDEWALK POINTS OF REFERENCE.

NORTH VIEW FROM 138TH STREET BETWEEN 251 W. & 253 W. 138TH STREET PRIVATE ALLEY ENTRANCE 1 2

F R E D E R I C K DOUGLAS BLVD. W E S T 1 3 8 T H S T R E E T WEST 139TH STREET

AREA OF PROPOSED WORK: 234 W 139TH STREET

ADAM C. POWELL BLVD.

PRIVATE ALLEY PRIVATE ALLEY

LEGEND: 1 2

KEY PLOT PLAN

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 5 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC

NOTE: REAR PORTION OF THE PROPERTY IS NOT VISIBLE VIA PUBLIC SIDEWALK POINTS OF REFERENCE.

EAST VIEW FROM FREDERICK DOUGLAS BLVD. LOOKING TOWARDS ADAM CLAYTON POWELL BLVD. PRIVATE ALLEY ENTRANCE 3

F R E D E R I C K DOUGLAS BLVD. W E S T 1 3 8 T H S T R E E T WEST 139TH STREET

AREA OF PROPOSED WORK: 234 W 139TH STREET

ADAM C. POWELL BLVD.

PRIVATE ALLEY PRIVATE ALLEY

LEGEND: 3

KEY PLOT PLAN 234 W. 139TH ST.

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 6 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC

F R E D E R I C K DOUGLAS BLVD. W E S T 1 3 8 T H S T R E E T WEST 139TH STREET

AREA OF PROPOSED WORK: 234 W 139TH STREET

ADAM C. POWELL BLVD.

PRIVATE ALLEY PRIVATE ALLEY

LEGEND: 4

NOTE: REAR PORTION OF THE PROPERTY IS NOT VISIBLE VIA PUBLIC SIDEWALK POINTS OF REFERENCE.

WEST VIEW FROM ADAM CLAYTON POWELL BLVD. LOOKING TOWARDS FREDERICK DOUGLAS BLVD. PRIVATE ALLEY ENTRANCE 4

KEY PLOT PLAN 234 W. 139TH ST.

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 7 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC

NOTE: REAR PORTION OF THE PROPERTY IS NOT VISIBLE VIA PUBLIC SIDEWALK POINTS OF REFERENCE.

EAST VIEW FROM INSIDE PRIVATE ALLEY LOOKING TOWARDS ADAM C. POWELL BLVD. 5

F R E D E R I C K DOUGLAS BLVD. W E S T 1 3 8 T H S T R E E T WEST 139TH STREET

AREA OF PROPOSED WORK: 234 W 139TH STREET

ADAM C. POWELL BLVD.

PRIVATE ALLEY PRIVATE ALLEY

LEGEND: 5

KEY PLOT PLAN 234 W. 139TH ST.

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 8 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC

F R E D E R I C K DOUGLAS BLVD. W E S T 1 3 8 T H S T R E E T WEST 139TH STREET

AREA OF PROPOSED WORK: 234 W 139TH STREET

ADAM C. POWELL BLVD.

PRIVATE ALLEY PRIVATE ALLEY

LEGEND: 6

NOTE: REAR PORTION OF THE PROPERTY IS NOT VISIBLE VIA PUBLIC SIDEWALK POINTS OF REFERENCE.

WEST VIEW FROM INSIDE PRIVATE ALLEY LOOKING TOWARDS FREDERICK DOUGLAS BLVD. 6

KEY PLOT PLAN 234 W. 139TH ST.

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 9 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC 234 WEST 139TH STREET 234 WEST 139TH STREET

234 w. 139TH ST. 234 w. 139TH ST.

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 10 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC SOUTH VIEW TOWARDS ALLEY 234 WEST 139TH STREET REAR DECK - PARLOR LEVEL SOUTH VIEW TOWARDS PRIVATE ALLEY 234 WEST 139TH STREET REAR DECK - PARLOR LEVEL

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 11 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC NORTH VIEW TOWARDS HOUSE 234 WEST 139TH STREET REAR DECK - PARLOR LEVEL NORTH VIEW TOWARDS HOUSE 234 WEST 139TH STREET REAR DECK - PARLOR LEVEL EXHAUST LOUVER TO BE FLUSHED W/ MASONRY NORTH VIEW TOWARDS HOUSE 234 WEST 139TH STREET REAR DECK - PARLOR LEVEL

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 12 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC EXISTING INTERNET/CABLE SERVICE CONDUITS INTO NEIGHBORHOOD EXISTING INTERNET/CABLE SERVICE CONDUITS INTO NEIGHBORHOOD EXISTING INTERNET/CABLE SERVICE CONDUITS INTO NEIGHBORHOOD

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 13 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC VIEW OF ORIGINAL HISTORICAL BUILDING EXTENSIONS VIEW OF ORIGINAL HISTORICAL BUILDING EXTENSIONS

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 14 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC PROPOSED EXTERIOR LIGHT FIXTURE TO BE LEGALIZED REAR PATIO PROPOSED EXTERIOR LIGHT FIXTURE TO BE LEGALIZED REAR PATIO PROPOSED EXTERIOR LIGHT FIXTURE REAR GARAGE

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 15 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC

14'-4" 2'-6" 28" 3'-0" (E) 2HR. MASONRY WALLS (E) GARAGE (E) RAILING EXISTING GARAGE FROM PERMIT "ALT 2523-22" LOCATION & SIZE APPROXIMATED DUE TO UNFOUND RECORDS. 236 W. 139TH STREET 232 W. 139TH STREET

LLC

16'-63 4" DN UP EXISTING BATHROOM NEW GARAGE 17'-6" 8" 14'-4" EXISTING RADIATOR UNCONDITIONED SPACE (N) FIRE-RATED 1.5HRS. EXTERIOR DOOR PER NYCFD. UNCONDITIONED SPACE (E) TUB, SINK AND TOILET EXISTING RADIATOR (N) GARAGE DOOR EXISTING VESTIBULE (N) CONC. STAIRCASE (N) CMU WALLS (N) EXPOSED CMU WALLS A (E) 2HR. MASONRY WALLS (E) MASONRY WALLS (E) DRAIN. TYP. CH: 7'-6" B.O. F.C. 9'-03 4" PROPERTY LINE PROPERTY LINE CH: 7'-11" F.F. TO B.O. F.C. 2'-5" 12'-0" 2'-13 4" 28" (E) BATHROOM. FULLY VENTED TYP. A A SHADED AREA PART OF THE (N) REAR GARAGE EXTENSION & ADDITIONS. 3'-0" 2'-5" 1" STRUCTURAL SEPARATION GAP 1" STRUCTURAL SEPARATION GAP GARAGE F.F. ON GRADE WITH COMMON PRIVATE CAR ROAD. D D 236 W. 139TH STREET 232 W. 139TH STREET

LLC

PREVIOUS BASEMENT FLOOR PLAN PROPOSED BASEMENT FLOOR PLAN

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 16 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC

6'-63 4" 1'-53 4" 113 4" (E) GARAGE BELOW EXISTING GARAGE FROM PERMIT "ALT 2523-22" LOCATION & SIZE APPROXIMATED DUE TO UNFOUND RECORDS. (E) WINDOW TO BE REPLACED WITH (N) DOORS. SEE REAR ELEVATIONS FOR REFERENCE. 236 W. 139TH STREET 232 W. 139TH STREET

LLC

6'-714" 16'-714" UP (N) NON-COMBUSTIBLE STONE PAVERS O/

• CONC. DECK.

EXISTING POWER ROOM 7'-11" 16'-714" 14'-8" 31'-3" 42" REF. 2'-0" 5'-0" (N) SKYLIGHT (N) SKYLIGHT 1'-53 4" SLOPE TO DRAIN TYP. SLOPE SLOPE SLOPE SLOPE (E) CABINETS CTOP (N) MASONRY PARAPET 43" AFF TYP. (E) MASONRY

• WALLS. TYP.

(N) MASONRY PARAPET 43" AFF TYP. 16'-0" CH: 10'-4" F.F. TO F.C. (E) BATHROOM. FULLY VENTED TYP. (N) 1" STRUCTURAL SEPARATION GAP. (N) 1" STRUCTURAL SEPARATION GAP. (N) NON-COMBUSTIBLE STONE PAVERS O/

• CONC. DECK.

(N) DOOR (N) VENTS. SEE ELEVATIONS. SHADED AREA PART OF THE (N) REAR GARAGE EXTENSION. 236 W. 139TH STREET 232 W. 139TH STREET

LLC

PREVIOUS PARLOR FLOOR PLAN PROPOSED PARLOR FLOOR PLAN

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 17 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC

P L P L P L P L

6'-10" 12'-13 4" 10'-1014" 11'-9" 41'-7" EXISTING GRADE TO T.O. ROOF T.O.2ND LEVEL F.F. T.O. 3RD LEVEL F.F. T.O. ROOF T.O. GARAGE F.F. T.O. 1ST LEVEL F.F. DASHED FLOOR ASSEMBLY BYND. TYP. (E) WINDOW TO BE REPLACED WITH (N) DOORS. DASHED FLOOR ASSEMBLY BYND. TYP. DASHED (E) FLOOR FRAMING BYND. (E) GUTTER TO REMAIN. DASHED CELLAR FL. BYND. (E) RED BRICK FACADE TO REMAIN. (E) DOWNSPOUTS TO REMAIN TYP. ALL (E) WINDOWS TO REMAIN TYP. UON. (E) GARAGE TO BE REPLACED WITH (N). ALL (E) WINDOWS TO REMAIN TYP. UON. ALL (E) WINDOWS TO REMAIN TYP. UON. ALL (E) WINDOWS TO REMAIN TYP. UON. ALL (E) CONCRETE LINTELS TO REMAIN TYP. (E) CONC. SILLS TO REMAIN GARAGE F.F. ON GRADE WITH COMMON PRIVATE CAR ROAD.

9'-2"

(E) RED BRICK FACADE TO REMAIN. (E) GUTTER TO REMAIN. (E) PARAPET WALL TO REMAIN

P L P L P L P L

LLC

ASSUMED PREVIOUS REAR FACADE ELEVATION

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 18 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC

P L P L P L P L

6'-10" 12'-13 4" 10'-1014" 11'-9" 41'-7" EXISTING GRADE TO T.O. ROOF T.O.2ND LEVEL F.F. T.O. 3RD LEVEL F.F. T.O. ROOF T.O. GARAGE F.F. T.O. 1ST LEVEL F.F. DASHED FLOOR ASSEMBLY BYND. TYP. (E) WINDOW TO BE REPLACED WITH (N) DOORS. DASHED FLOOR ASSEMBLY BYND. TYP. DASHED (E) FLOOR FRAMING BYND. (E) GUTTER TO REMAIN. DASHED CELLAR FL. BYND. (E) RED BRICK FACADE TO REMAIN. (E) DOWNSPOUTS TO REMAIN TYP. ALL (E) WINDOWS TO REMAIN TYP. UON. (E) GARAGE TO BE REPLACED WITH (N). ALL (E) WINDOWS TO REMAIN TYP. UON. ALL (E) WINDOWS TO REMAIN TYP. UON. ALL (E) WINDOWS TO REMAIN TYP. UON. ALL (E) CONCRETE LINTELS TO REMAIN TYP. (E) CONC. SILLS TO REMAIN GARAGE F.F. ON GRADE WITH COMMON PRIVATE CAR ROAD.

9'-2"

(E) RED BRICK FACADE TO REMAIN. (E) GUTTER TO REMAIN. (E) PARAPET WALL TO REMAIN PREVIOUS VENTS & CONDUITS TO BE FLUSHED WITH FACE OF BRICK WALL & PAINTED WITH BENJAMIN MOORE BRICK RED 2084-10 AURA EXTERIOR PAINT FLAT PREVIOUS CABLE PROVIDER SERVICE BOX TO BE LOWERED OUT OF SIGHT LINE (E) SERVICE LINES TO REMAIN.

P L P L P L P L

LLC

P L P L P L P L P L P L P L P L

6'-10" 12'-13 4" 10'-1014" 11'-9" 41'-7" EXISTING GRADE TO T.O. ROOF T.O.2ND LEVEL F.F. T.O. 3RD LEVEL F.F. T.O. ROOF T.O. GARAGE F.F. T.O. 1ST LEVEL F.F. (E) RED BRICK PARAPET TO REMAIN. DASHED FLOOR ASSEMBLY BYND. TYP. (N) RED BRICK PARAPET/ GUARDRAIL TO REMAIN. (N) CONC. COPING. PROPOSED LEGALIZATION DOOR TO REPLACE PREVIOUS

• WINDOW. PREVIOUS

WINDOW SILL TO BE DROPPED. DASHED FLOOR ASSEMBLY BYND. TYP. DASHED (E) FLOOR FRAMING BYND. (E) GUTTER TO REMAIN. DASHED CELLAR FL. BYND. PROPOSED LEGALIZATION VENTS & CONDUITS TO BE FLUSHED WITH FACE OF BRICK WALL & PAINTED WITH BENJAMIN MOORE BRICK RED 2084-10 AURA EXTERIOR PAINT FLAT PROPOSED LEGALIZATION STEEL ROLL-UP GARAGE DOOR FINISHED IN WHITE. (E) DOWNSPOUTS TO REMAIN TYP. ALL (E) WINDOWS TO REMAIN TYP. UON. (N) EXTERIOR LIGHT. ALL (E) WINDOWS TO REMAIN TYP. UON. ALL (E) WINDOWS TO REMAIN TYP. UON. ALL (E) WINDOWS TO REMAIN TYP. UON. ALL (E) CONCRETE LINTELS TO REMAIN TYP. (E) CONC. SILLS TO REMAIN.

8'-3" BASEMENT F.F. TO DECK F.F. 3'-113 4" STONE CAP RAILING

(N) 1" STRUCTURAL SEPARATION GAP. (N) 1" STRUCTURAL SEPARATION GAP. GARAGE F.F. ON GRADE WITH COMMON PRIVATE CAR ROAD.

11'-113 4"

(N) RED BRICK FACADE TO MATCH (E)

• THROUGHOUT. TYP.

(N) FLOOD LIGHT (E) GUTTER TO REMAIN.

1'-10" 5" 6'-6" 4'-812" 1'-1" 3'-512" TO NEAREST WINDOW 4" 8" 5'-4" 7'-7" 9"

PROPOSED LEGALIZATION CABLE PROVIDER SERVICE BOX TO BE LOWERED OUT OF SIGHT LINE (N) FLOOD LIGHT ALL (E) MECHANICAL UNITS REFER TO MITSUBISHI OUTDOOR UNIT MODEL# MUZ-GL18NA-U1. (E) SERVICE LINES TO REMAIN. PREVIOUS LINTEL TO REMAIN. PREVIOUS PARAPET WALL TO SCREEN

• MECH. UNITS. MECH.

UNITS SETBACK. TYP.

LLC

EXISTING REAR FACADE ELEVATION PROPOSED REAR FACADE ELEVATION

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 19 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC

P L P L P L P L P L P L P L P L

T.O.2ND LEVEL F.F. T.O. GARAGE F.F. T.O. 1ST LEVEL F.F. (E) RED BRICK PARAPET TO REMAIN. DASHED FLOOR ASSEMBLY BYND. TYP. (N) RED BRICK PARAPET/ GUARDRAIL TO REMAIN. (N) CONC. COPING. PROPOSED LEGALIZATION DOOR TO REPLACE PREVIOUS

• WINDOW. PREVIOUS

WINDOW SILL TO BE DROPPED. PROPOSED LEGALIZATION VENTS & CONDUITS TO BE FLUSHED WITH FACE OF BRICK WALL & PAINTED WITH BENJAMIN MOORE BRICK RED 2084-10 AURA EXTERIOR PAINT FLAT PROPOSED LEGALIZATION STEEL ROLL-UP GARAGE DOOR FINISHED IN (N) EXTERIOR LIGHT. ALL (E) WINDOWS TO REMAIN TYP. UON.

8'-3" BASEMENT F.F. TO DECK F.F. 3'-113 4" STONE CAP RAILING

(N) 1" STRUCTURAL SEPARATION GAP. (N) 1" STRUCTURAL SEPARATION GAP.

11'-113 4"

(N) RED BRICK FACADE TO MATCH (E)

• THROUGHOUT. TYP.

(E) GUTTER TO REMAIN.

1'-10" 5" 6'-6" 4'-812" 1'-1" 3'-512" TO NEAREST WINDOW 4" 8" 5'-4" 7'-7" 9"

PROPOSED LEGALIZATION CABLE PROVIDER SERVICE BOX TO BE LOWERED OUT OF SIGHT LINE (N) FLOOD LIGHT ALL (E) MECHANICAL UNITS REFER TO MITSUBISHI OUTDOOR UNIT MODEL# MUZ-GL18NA-U1. (E) SERVICE LINES TO REMAIN. PREVIOUS LINTEL TO REMAIN. PREVIOUS PARAPET WALL TO SCREEN

• MECH. UNITS. MECH.

UNITS SETBACK. TYP.

LLC

ENLARGED PROPOSED REAR FACADE ELEVATION MATERIAL SPECIFICATION: PROPOSED MECHANICAL LOUVERS TO BE FLUSHED WITH EXISTING MASONRY. PROPOSED LOUVERS & CONDUITS TO BE PAINTED TO MATCH EXISTING BRICK MATERIAL.................................................................................................................................................... BENJAMIN MOORE BRICK RED 2084-10 AURA

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 20 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC REAR FACADE LOOKING FROM PRIVATE ALLEYWAY REAR FACADE LOOKING INTO THE BUILDING FROM PRIVATE ALLEYWAY

234 w. 139TH ST. 234 w. 139TH ST.

REAR FACADE LOOKING FROM PRIVATE ALLEYWAY

234 w. 139TH ST.

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 21 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC PROPOSED LONGITUDINAL BUILDING SECTION - REAR PORTION OF THE BUILDING SIGHT LINE DIAGRAM IN RELATION TO PROPOSED MECHANICAL UNITS

6'-0"

HOUSE OPPOSITE SUBJECT PROPERTY SIGHT LINE @ OPPOSITE END OF THE PRIVATE REAR ALLEYWAY. (N) REAR GARAGE EXTENSION. (N) EXHAUST VENT FLUSHED WITH (E) MASONRY. PROPERTY LINE

7'-11"

(N) MECHANICAL UNITS.

VIEW OF MECHANICAL UNITS FROM PRIVATE ALLEY

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 22 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC

ALL (E) WINDOWS TO REMAIN TYP. UON. (N) GARAGE

7'-11"

BATHROOM (E) GARAGE (UNCONDITIONED) DASHED (E) STAIRS BYND. TYP. DASHED (E) STAIRS BEYOND. TYP. HALLWAY 7'-8" BASEMENT F.F. TO F.C. BATHRM. ALL (E) WINDOWS TO REMAIN TYP. UON. (E) WALL TO

• REMAIN. TYP.

(E) CURB & ROOF SLOPING SCUPPERS TO (E) GUTTER. GARAGE F.F. ON GRADE WITH COMMON PRIVATE CAR ROAD. 3'-6" (N) 42" PARAPET W/ BRICK VENEER ±7'-7" BASEMENT F.F. TO B.O. J. ALL (E) WINDOWS TO REMAIN TYP. UON. (N) GARAGE

7'-11"

BATHROOM (N) GARAGE (UNCONDITIONED) DASHED (E) STAIRS BYND. TYP. DASHED (E) STAIRS BEYOND. TYP. HALLWAY 7'-8" BASEMENT F.F. TO F.C. BATHRM. EXTERIOR CONC. DECK ALL (E) WINDOWS TO REMAIN TYP. UON. (E) WALL TO

• REMAIN. TYP.

NOTE: ALL MECHANICAL UNITS REFER TO MITSUBISHI OUTDOOR UNIT MODEL# MUZ-GL18NA-U1. (E) CURB & ROOF SLOPING SCUPPERS TO (E) GUTTER. 2

G-002.00

GARAGE F.F. ON GRADE WITH COMMON PRIVATE CAR ROAD. (N) EXHAUST VENT TO BE FLUSHED WITH (E) MASONRY & PAINTED WITH BENJAMIN MOORE BRICK RED 2084-10 AURA EXTERIOR PAINT FLAT 6'-10" 12'-13 4" 10'-1014" 11'-9" 41'-7" EXISTING GRADE TO T.O. ROOF T.O.2ND LEVEL F.F. T.O. 3RD LEVEL F.F. T.O. ROOF T.O. GARAGE F.F. T.O. 1ST LEVEL F.F.

PREVIOUS LONGITUDINAL BUILDING SECTION PROPOSED LONGITUDINAL BUILDING SECTION PREVIOUS LONGITUDINAL BUILDING SECTION PROPOSED LONGITUDINAL BUILDING SECTION

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 23 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC

ALL (E) WINDOWS TO REMAIN TYP. UON. (E) GARAGE (UNCONDITIONED) ALL (E) WINDOWS TO REMAIN TYP. UON. (E) CURB & ROOF SLOPING SCUPPERS TO (E) GUTTER. (E) WINDOWS AND OPENINGS 6'-10" 12'-13 4" 10'-1014" 11'-9" 41'-7" EXISTING GRADE TO T.O. ROOF T.O.2ND LEVEL F.F. T.O. 3RD LEVEL F.F. T.O. ROOF T.O. GARAGE F.F. T.O. 1ST LEVEL F.F. 3'-6" (N) 42" PARAPET W/ BRICK VENEER ±7'-7" BASEMENT F.F. TO B.O. J. ALL (E) WINDOWS TO REMAIN TYP. UON. (N) GARAGE

8'-0"

(N) GARAGE (UNCONDITIONED) (E) STEPS TYP. STORAGE EXTERIOR CONC. DECK ALL (E) WINDOWS TO REMAIN TYP. UON. (E) WINDOW TO

• REMAIN. TYP.

NOTE: ALL MECHANICAL UNITS REFER TO MITSUBISHI OUTDOOR UNIT MODEL# MUZ-GL18NA-U1. (E) CURB & ROOF SLOPING SCUPPERS TO (E) GUTTER. 2

G-002.00

GARAGE F.F. ON GRADE WITH COMMON PRIVATE CAR ROAD. (N) EXHAUST VENT TO BE FLUSHED WITH (E) MASONRY & PAINTED WITH BENJAMIN MOORE BRICK RED 2084-10 AURA EXTERIOR PAINT FLAT (N) DOORS TO BE LEGALIZED. DROPPED SILL DASHED STAIR BEHIND. DASHED GUARD RAIL (N) COVERED PASSAGE/ STORAGE TO BE LEGALIZED

PREVIOUS LONGITUDINAL BUILDING SECTION PROPOSED LONGITUDINAL BUILDING SECTION

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 24 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC 234 WEST 139TH STREET 236 WEST 139TH STREET 232 WEST 139TH STREET 238 WEST 139TH STREET 230 WEST 138TH STREET 228 WEST 139TH STREET GARAGE(S) CONTEXT AROUND 139TH ST.

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 25 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC 229 WEST 138TH STREET 231 WEST 138TH STREET 227 WEST 138TH STREET 233 WEST 138TH STREET 225 WEST 138TH STREET 223 WEST 138TH STREET GARAGE(S) CONTEXT AROUND 138TH ST.

SUBJECT PROPERTY: 234 WEST 139TH STREET, NEW YORK, NEW YORK, 10030

PAGE 26 DATE: 05.22.2018 ARCHETYPE 224 W. 79TH ST. • NEW YORK, NEW YORK, 10024 • ALAN BERMAN, R.A. PLLC SUBJECT PROPERTY: 234 W. 139TH ST. NORTH VIEW TOWARDS HOUSE PRIVATE ALLEY

234 W. 139TH ST.
