FILE SYSTEM IMPLEMENTATION

Sunu Wibirama

11.

Outline

 File-System Structure  File-System Implementation  Directory Implementation  Allocation Methods  Free-Space Management  Discussion

11.

Outline

 File-System Structure  File-System Implementation  Directory Implementation  Allocation Methods  Free-Space Management  Discussion

11.

File System Structure

 File system is provided by OS to allow the data to be

stored, located, and retrieved easily

 Two problems on file system design:

 How the file system should look to the user  Algorithms and data structures to map logical file

system onto the physical secondary-storage devices

 File system organized into layers, uses features from

lower levels to create new features for use by higher levels.

 I/O Control controls the physical device using

device driver

 Basic file system needs only to issue generic

commands to the device driver to read and write physical block on the disk (ex. drive 1, cylinder 73, track 2, sector 11)

11.

Outline

 File-System Structure  File-System Implementation  Directory Implementation  Allocation Methods  Free-Space Management  Discussion

11.

File System Implementation

 File organization module knows physical

and logical blocks, translating logical block address to physical block address. It also manages free-space on the disk

 Logical file system manages metadata

information (all file system structure except the actual data or contents of the file).

 Logical file system maintains file structure

via file-control blocks (FCB)

 File control block – storage structure

consisting of information about a file

 Basic file system and I/O control can be

used by multiple file systems.

 Recently, OS supports more than one FS

11.

A Typical File Control Block

11.

On-Disk File System Structures

 Boot control block contains info needed by system to boot

OS from that volume (UNIX: boot block, NTFS: partition boot sector)

 Volume control block contains volume details (UNIX:

superblock, NTFS: master file table)

 Directory structure organizes the files (UNIX: inode

numbers, NTFS: master file table)

 Per-file File Control Block (FCB) contains many details

about the file

11.

In-Memory File System Structures

 It is used for file-system management and performance

improvement (via caching).

 The data are loaded at mount time and discarded at

dismount.

 The structures including:

In-memory mount table: information of each mounted

volume

In-memory directory structure System-wide open-file table: a copy of FCB of each open

file

Per-process open-file table: a pointer to the appropriate

entry in the system-wide open-file table, as well as other information based on process that uses the file.

11.

New File Creation Process

 Application program calls the logical file

system

 Logical file system knows the directory

• structures. It allocates a new FCB.

 The system then reads the appropriate

directory into memory, updates it with the new file name and FCB, and writes it back to the disk.

 Now, the new created file can be used for

I/O operation, which will be explained in the next slide

11.

In-Memory File System Structures

File open File read

11.

Outline

 File-System Structure  File-System Implementation  Directory Implementation  Allocation Methods  Free-Space Management  Discussion

11.

Directory Implementation

 Directory-allocation and directory-management

algorithms significantly affects the efficiency, performance, and reliability of the file system. There are two impementations: linear list and hash table

 Linear list of file names with pointer to the data

blocks.

 simple to program  time-consuming to execute, because it requires a

linear search to create or delete file.

 Hash Table – linear list with hash data structure.

 decreases directory search time  problem:

collisions (two file names hash to the same

location)

fixed size of hash table (for 64 entries, the

hash function converts filename into integers from 0 to 63)

11.

Outline

 File-System Structure  File-System Implementation  Directory Implementation  Allocation Methods  Free-Space Management  Discussion

Dynamic Storage Allocation and Fragmentation

Review:

11.

Dynamic Storage Allocation

 At any given time, we have a set of free spaces (holes) of various sizes

scattered through the disk.

 Dynamic Storage Allocation problem: satisfying a request of size n

from a list of free spaces

 There are three solutions for dynamic storage allocation problem:

 First Fit: allocate the first hole that is big enough. Stop searching the

entire list as soon as we find a free hole that is large enough

 Best Fit: Allocate the smallest hole that is big enough. We must

search the entire list in the storage

 Worst Fit: allocate the largest hole. Again, we must search the entire

list in the storage

 In term of speed and disk utilization : first fit and best fit are better then

worst fit

11.

External Fragmentation

 First fit and best fit suffer from external fragmentation :

there is enough total storage space to satisfy the request, but the available spaces are not contiguous

OS File 2 File 3 File 8 50k 100k File 9 125k

?

11.

Internal Fragmentation

 Another approach : break the physical storage into fixed-sized

blocks and allocate storage in units based on block size.

 The storage space allocated to file may be slightly larger than the

requested space, but we get internal fragmentation.

OS A (part 3) A (part 2) A (part 1) Room for growth Allocated to A

11.

Fragmentation Solution?

 Minimize external fragmentation?

 Large disk blocks (but internal fragmentation occurs)  Choose the best allocation methods to allocate disk block  Compaction:

Shuffle memory contents to place all free memory together in one large block

(example: disk defragmenter)

Only for “execution time address binding” data (dynamic address relocation)

File 9 125k OS File 2 File 3 File 8 OS File 2 File 3 File 8 50k 100k OS File 2 File 3 File 8 90k 60k (a) (b)

Next, we want to allocate disk blocks

• effectively. But how?

11.

Allocation Methods

 An allocation method refers to how disk blocks are

allocated for files:

Contiguous allocation Linked allocation Indexed allocation

11.

Contiguous Allocation of Disk Space

11.

Contiguous Allocation

 OS : IBM VM/CMS  Each file occupies a set of contiguous blocks on the disk  Simple – only starting location (block #) and length (number of

blocks) are required

 Both sequential and direct access are supported  Disadvantages:

 Wasteful of space (dynamic storage-allocation problem)  External fragmentation: free space is broken into chunks  We must determine the size of needed space before we allocated  Preallocation may be inefficient if the file grow slowly over a long

period (months or years). The file therefore has a large amount of internal fragmentation

11.

Contiguous Allocation

 (a) Contiguous allocation of disk space for 7 files.  (b) The state of the disk after files D and F have been removed.

11.

Contiguous Allocation

One of several solutions: use a modified contiguous

allocation scheme (ex. : Veritas file system, replacing standard UNIX UFS)

Initially, a contiguous block of space is allocated If it is not to be large enough, another block is added,

which is called extent.

 An extent is a contiguous block of disks  A file consists of one or more extents

Another approach, we use Linked Allocation Method

11.

Linked Allocation

 Linked allocation solves all

problems of contiguous allocation

 Each file is a linked list of disk

blocks: blocks may be scattered anywhere on the disk.

 Ex: File “Jeep”

 Start at block 9  Then: block 16, 1, 10  Finally end at block 25

pointer (4 bytes) 1 block (512 bytes)

508 bytes

visible part to user

11.

Linked Allocation

 Advantages:

 Free-space management system – no waste of space  File can grow, depends on available free blocks

 Disadvantages:

 No random access (only sequential access)  Space required for pointers (0.78 percent of the disk is being used

for pointers, rather than for information). Solution, uses clusters (unit of blocks), so that pointers use much smaller percentage

 Clusters operation increase internal fragmentation  Reliability, pointer damage will cause unlinked blocks in a file.

 FAT (File Allocation Table): variation on linked allocation (ex.: MS-DOS

and OS/2 operating systems)

 Located at the beginning of each volume

11.

File-Allocation Table

 To do random access:

• 1. The disk head move to the start of volume

to read the FAT

• 2. Find the location of the desired block
• 3. Move to the location of the block itself

11.

Indexed Allocation

 Linked allocation: solves external fragmentation and size-declaration

problem

 FAT + Linked Allocation = efficient file retrieval using random access  Without FAT, linked allocation cannot support efficient direct access:

 because the pointers to the blocks are scattered with the block

themselves all over the disk

 the pointers must be retrieved in order (sequential access).

 How about collecting all pointers together into one location?

11.

Indexed Allocation

 Brings all pointers together into the

index block

 Each file has its own index block, which

is an array of disk-block addresses

 Directory contains the address of index

block

 Support direct access without external

fragmentation

 Each file has its allocation for all

pointers, so that it has wasted space greater than linked allocation (which contains one pointer per block).

 We want the index block as small as

possible, then we have several mechanisms:

• 1. Linked scheme
• 2. Multilevel index
• 3. Combined scheme

Index block

11.

Indexed Allocation

 Linked Scheme

 An index block is normally one disk block  Large files -> we can link together several index blocks  Example: an index block contains:

• a small header of file name
• a set of 100 disk-block addresses
• nil (for small file) or a pointer to another index block (for a large file)

 Multilevel index

 First-level index block points to second-level index blocks which in turn point

to the file blocks (see next slide)

 Combined scheme

 In unix, for example: 15 pointers in fileʼs inode  12 first pointer: direct blocks, for small file (no more than 12 blocks). If the

block size is 4KB, then up to 48KB (12 x 4KB) can be accessed directly

 The next pointers point to indirect blocks, which implement multilevel index

based on their sequence (see next two slide)

11.

Multilevel Index



1st-level index block

2nd-level index block

file

Back to Indexed Allocation

11.

Combined Scheme: UNIX UFS (4K bytes per block)

Back to Indexed Allocation

11.

Outline

 File-System Structure  File-System Implementation  Directory Implementation  Allocation Methods  Free-Space Management  Discussion

11.

Free-Space Management

 Disk space is limited, we need to reuse the space from deleted files for

new files, if possible

 To keep track of free disk space, the system maintains a free-space

list.

 Free-space list records all free disk blocks: those not allocated to

some file or directory

 Creating file:

 search the free-space list for the required amount of space  allocate that space to the new file  remove that space from the free-space list

 Deleting file: the disk space of the file is added to free-space list

11.

Free-Space Management

 Free-space list concept  Bit vector (n blocks)  Bit vector requires extra space.

Example:

block size = 212 bytes disk size = 230 bytes (1 gigabyte) n (amount of bits) = 230/212 = 218 bits (or 32K bytes)

…

1 2 n-1 bit[i] =



0 ⇒ block[i] free 1 ⇒ block[i] occupied Finding the free block number {(number of bits per word) *(number of 0-value words)} +offset of first 1 bit

1 1 1 1 1 1

1 2 3 4 5 6 7 8 9 10 11

1st word 2nd Word 3rd word

Assume 1word = 3bits, then finding block 11: (3 X 3)+2

11.

Free-Space Management

 The other free-space management methods include:

(1) Linked list

 Link together all the free disk blocks  Keeping a pointer to the first free block in a special location

• n the disk and caching it in memory.

 The first block contains a pointer to the next free disk block.  Must read each block to traverse list, increase I/O operation

time. (2) Grouping

 Storing the address of n free blocks in the first free block.  n-1 blocks are actually free blocks but the last block

contains the addresses of another n free blocks. (3) Counting (for contiguous free block)

 Several contiguous blocks may be freed simultaneously  Keep the address of the first free block and n of free

contiguous blocks that follow the first block.

 Each entry in free-space list consists of disk address and a

count (ex. address 4 + 15 --> we have 16 free blocks. 1st block starts at address 4, followed by 15 free blocks)

::Discussion

Comparing File System

Fragmentation in Windows (FAT 32) and Linux (ext)

Defragmentation

http://en.wikipedia.org/wiki/Defragmentation

Why Linux rarely needs defragmentation tools?

• Does fragmentation occur in Linux?

Yes, but in very small quantity

• Block Groups: group file-data together in

‘clumps’ to manage small and large file (remember combined scheme in indexed allocation)

• Only write files to unused portion of the disk

that are not predictably being fragmented in shorter time.

Combined Scheme

Possible to allocate bigger blocks for a file

Unix System

• Keep fragmentation level below 20%
• More than 20%? You certainly need to fix your hard

disk using shake-fs

• Run : e2fsck -nv /dev/sda1 as root, resulting:

Fragmented Part

Implementation

(*you should have known this before...)

http://geekblog.oneandoneis2.org/index.php/2006/08/17/ why_doesn_t_linux_need_defragmenting

Empty hard disk (*simplified assumption)

Start with FAT file system....

I have hello.txt OK, now add bye.txt I want to change hello.txt, dude...

?

Just copy, delete the original content, and wrap it up in the larger space..... Or, Put your extended file content to the next space.....

If the first approach requires huge read and write operation, then the most possible approach is the second one. That’s why FAT suffers from large fragmentation

1st approach 2nd approach

Initial condition

What About Linux?

What About Linux?

Add bye.txt

Change hello.txt

What About Linux?

Now you know...

why people (again) prefer Unix based OS for handling large data Defragmentation = decreasing productivity

Thank You
