Indiana Bridge Inspection QA/QC Procedures

2 1 7

I N D O T B R I D G E I N S P E C T I O N C O N F E R E N C E

February 15, 2017

Indiana Bridge Inspection QA/QC Procedures

Discussion Topics

 INDOT Quality Assurance Procedures/Scope  Focus Moving Forward/Reference Materials  Review of Changes to the Bridge Inspection Requirements

Indiana Bridge Inspection QA/QC Procedures

Need for QA/QC Procedures?

 Federal requirement for QA/QC

♦ 23 CFR 650.313(g) Quality Control and Quality Assurance

requires each state to assure that systematic Quality Control (QC) and Quality Assurance (QA) procedures are being used to maintain a high degree of accuracy and consistency in the inspection program

 Without QA/QC procedures in place, FHWA would find INDOT non-compliant, NBIS Metric #20  INDOT designated Beam, Longest & Neff (BLN) as Quality Assurance Officer (2011 – Present)

Indiana Bridge Inspection QA/QC Procedures

Goal of QA/QC Procedures?

 To Help Ensure:

♦ Accuracy ♦ Consistency ♦ A Quality Product ♦ Public Safety ♦ Maintenance and Repairs ♦ Prioritize Recommended Work ♦ Identify Training Needs

Indiana Bridge Inspection QA/QC Procedures

QA/QC Procedures

 review is the Internal Review conducted from within an inspecting agency  Focuses on at-risk bridges  Office and field reviews  Reviewed by Inspection agency – INDOT or Inspection Consultant

Indiana Bridge Inspection QA/QC Procedures

QA/QC Procedures

 review is the External Review conducted from outside an inspecting agency  Independent oversight reviews to focus on at-risk bridges  Reviews by INDOT and BLN

Indiana Bridge Inspection QA/QC Procedures

Quality Assurance Procedures

 Quality Assurance Reviews

♦ QA/QC Procedures – Part 2 Indiana Bridge Inspection Manual (IBIM) ♦ INDOT

• Control Bridge – 2 year cycle

♦ BLN and BFS

• Independent Oversight Review
• Bridge File Review
• County Load Rating Verification Reviews

Indiana Bridge Inspection QA/QC Procedures

 Quality Assurance Review Scope

♦ All reviews and forms in accordance with QA procedures per IBIM Part 2 ♦ Bridge reviews as selected by INDOT ♦ 24 Bridges chosen for team leaders who did not attend control bridge, per IBIM Part 2, Section 3.2

 Changes in Scope

♦ QA form changes, IBIM Part 2, Appendix ♦ Office reviews revised to bridge file reviews ♦ Reviews based on Metric comparison and not a score

Quality Assurance Review Scope and Changes

Indiana Bridge Inspection QA/QC Procedures

Quality Assurance Review Scope and Changes

 Quality Assurance Form

♦ Metric Comparison vs. Scoring

Indiana Bridge Inspection QA/QC Procedures

Independent Oversight Review

 Independent review of inspection data and findings for accuracy  Selected bridges based on posting, condition ratings, need for improvements, and Team Leader  Compared QA Officer results to

• riginal inspection results and

notes  Reviews Conducted on District and Consultant Team Leaders throughout the state

Indiana Bridge Inspection QA/QC Procedures

Bridge File Review

 Review of bridge files for accuracy and completeness  Selected bridges by INDOT search of files for known and suspected inaccuracies  Bridge file checked for required items as

• utlined in the AASHTO Manual for Bridge

Evaluation, Section 2  Reviews of County and District bridges

Indiana Bridge Inspection QA/QC Procedures

Load Rating Verification Review

 Independent Review of load rating computations for county bridges  Selected bridges based on INDOT query, consultant, team leader, condition ratings, and load posting  QA Officer performed field inspection and load rating  Compared QA Officer load rating to consultant load rating  Results reviewed based on QA form and NBIS Metric 13

Indiana Bridge Inspection QA/QC Procedures

 Determined from findings from all QA reviews  Based on reoccurrence of similar comments and procedures

♦ Bridge File ♦ Critical Findings ♦ Load Rating ♦ Fracture Critical Reports

Focus Moving Forward:

Indiana Bridge Inspection QA/QC Procedures

Bridge File Documentation

 IBIM Part 1, Section 2.5 and 4.1  Official bridge file is the central database information in BIAS, used to report NBI data and supplemental state information to FHWA  Historic data and updated bridge inspection data  Other attachments, past reports, load rating summary, correspondence, Scour Plan of Action reports, and special reports such as Underwater, Fracture Critical, Special Detail

Indiana Bridge Inspection Application System (BIAS): https://indot-it.bentley.com/login.aspx

Indiana Bridge Inspection QA/QC Procedures

Bridge File Documentation / Reports

 Note enough deficiencies to provide justification for condition rating.  Verify deficiencies noted are consistent between sketches, comments, and executive summary  Bridge deck rating for adjacent box beam bridge without deck to be based on beam condition not wearing surface condition  Approve bridge data within 60 days of inspection  Use text and abbreviations that are easy to follow

Indiana Bridge Inspection QA/QC Procedures

Critical Findings

 Structural or safety related deficiency that requires immediate follow-up inspection or action  IBIM Part 1, Section 5.2

♦ All bridges - Notification to State Program Manager of critical finding and document finding in BIAS, IBIM 5.2.2 ♦ Documented in BIAS under Maintenance Tab

Indiana Bridge Inspection QA/QC Procedures

Critical Findings

 IBIM Part 1, Section 5.2

♦ Locally owned bridges – Report to ERC and State Bridge Inspection Program Manager ♦ Inspection agency to document action taken in BIAS ♦ Take action in reasonable time ♦ Provide closeout documentation in BIAS to closeout critical finding report

Indiana Bridge Inspection QA/QC Procedures

Load Ratings

 IBIM Part 3  When in the Field……

♦ Take extra time in field to verify structure member sizes,

bridge dimensions, and section loss

♦ Document section loss and remaining section ♦ Verify condition at each phase of inspection, including

annual inspections

Indiana Bridge Inspection QA/QC Procedures

Load Ratings

Indiana Bridge Inspection QA/QC Procedures

Load Ratings

 When in the Office…..

♦ If significant deficiencies or change in condition visible, calculate rating quickly and recommend load posting changes ♦ Verify remaining section or section loss noted matches load rating calculation ♦ Include shear and moment in load rating calculations ♦ Verify load rating calculations or summary are signed and include Load Rating Engineer(LRE) information

Indiana Bridge Inspection QA/QC Procedures

Load Ratings

 When in the Bridge File…

♦ Inspection agency to make sure load rating information

added to bridge file in BIAS, does not have to include all pages of the calculation

♦ Make sure load rating matches BIAS data, must

unapproved initial reports after load rating report approved

♦ Make recommendations for posting

changes if needed. Remember to recommend advance posting signs.

Indiana Bridge Inspection QA/QC Procedures

Fracture Critical Reports

 IBIM Part 4

♦ Develop Fracture Critical or Special Detail reports

♦ Providing fatigue categories and ratings for all

fracture critical members at connections

♦ Members within 12”

• f connection

Fracture Critical Member (Tension) Limits of Fracture Critical Connection (12”)

Although this member is not Fracture Critical, this portion is within the limits of a fracture critical connection

Fracture Critical Member (Tension)

Indiana Bridge Inspection QA/QC Procedures

Fracture Critical Reports

 IBIM Part 4

♦ Fracture Critical Reports to provide condition ratings and fatigue categories for floor beams at connections

♦ Need to report section loss ♦ Need to report cracks or holes

Indiana Bridge Inspection QA/QC Procedures

Fracture Critical Reports

 Fatigue Details – IBIM Part 4, Appendix B  Sample Report – IBIM Part 4, Appendix A

Indiana Bridge Inspection QA/QC Procedures

Additional Documents for Reference

 Indiana Coding Guide – BRAGI  FHWA Bridge Inspector’s Reference Manual  AASHTO Manual for Bridge Evaluation, 2010

http://www.fhwa.dot.gov/bridge/nbis/pubs/nhi12049.pdf

Indiana Bridge Inspection QA/QC Procedures

Additional Documents for Reference

 Manual for Repair and Retrofit of Fatigue Cracks in Steel Bridges, FHWA-IF-13-020  AASHTO Manual for Bridge Element Inspection, 1st Ed.

http://www.fhwa.dot.gov/bridge/steel/pubs/hif13020/hif13020.pdf

Indiana Bridge Inspection QA/QC Procedures

Additional Documents for Reference

 Quality Control Documentation

♦ IBIM Part 2

 NBIS Metrics for the Oversight of the National Bridge Inspection Program

https://www.fhwa.dot.gov/bridge/nbip/metrics.pdf

Indiana Bridge Inspection QA/QC Procedures

Past Year in Review

 Bridge Inspection Compliance Month (Memo 15-09)

♦ Counties > 150 bridges, inspection over 2 months (Memo 16-05)

 Scour Assessment (Memo 16-01 & 16-13)

♦ To be implemented per INDOT scour compliance schedule ♦ Now available in BIAS

 Load Rating Policy (Memo 16-02)

♦ Load Rating updates with AASHTOWare BrR per INDOT

compliance schedule

Changes to Bridge Inspection Requirements

Indiana Bridge Inspection QA/QC Procedures

Changes to Bridge Inspection Requirements Past Year in Review

 ERMS Bridge Inspection Reports (Memo 16-03)

♦ Bridge Inspection Reports and files to be uploaded to

ERMS bridge inspection documents database

 Load Rating of New Bridges (Memo 16-06)  Culvert Type Structure Data in BIAS (Memo 16-07)  Reporting Critical Findings (Memo 16-08)  Team Member/Team Leader Profiles in BIAS (Memo 16-11)

Indiana Bridge Inspection QA/QC Procedures

Moving Forward…

 QA/QC procedures updates

♦ Always evolving process, QA procedures and forms

 Review Compliance months for Load Rating and Scour Evaluations  Continue to reference bridge Inspection memos

• nline

♦ Ongoing Discussion in INDOT/ACEC Bridge Inspection Committee ♦ INDOT Bridge inspection home page ♦ Common errors during FHWA Reviews (Memo 15-08)

Changes to Bridge Inspection Requirements

Indiana Bridge Inspection QA/QC Procedures

Contact: John Lukac Jlukac@b-l-n.com BIAS - INbridgeshelp@indot.IN.gov
