Excellence in Engineering Since 1946

PUBLIC INVOLVEMENT MEETING

PLEASANT VIEW ROAD (Mineral Point Road to US 14) June 28, 2018

• Project Introduction
• Project team
• Project location and limits
• Project purpose and need
• Design Alternatives
• Roadway typical sections
• Intersection alternatives
• Bike and pedestrian

accommodations

• Project Schedule
• Questions

Overview

Project Team

• City of Madison
• Christy Bachmann, P.E. Principal Engineer
• Andrew Zwieg, P.E. Project Manager
• City of Middleton
• Shawn Stauske, P.E. City Engineer
• Gary Huth, P.E. Asst. City Engineer
• Strand Associates, Inc.
• Brian Andreas, P.E.
• Elisa Becker, P.E.
• Elizabeth Garfoot, P.E.

Project Location and Limits

UW Agriculture UW Agriculture Blackhawk Neighborhood Pleasant View Golf Course Junction Ridge Neighborhood Old Cemetery

NORTH

Quarry CTH S (Mineral Point Rd) Old Sauk Rd Blackhawk Rd US 14 Elderberry Rd University Avenue

Pleasant View Road Mineral Point Rd. to US 14

• Provide important transportation link
• Transport people and products safely

and efficiently

• Support future traffic demand
• Minimize impacts to environment

Project Purpose

Middleton Madison Verona

• Provide a safe and functional corridor for all users,

including

• Motor vehicles
• Bicycles
• Pedestrians
• Address existing roadway deficiencies including
• Substandard sight distances
• Poor pavement condition

Project Needs

• Accommodate travel demand from planned future

growth and urban development

• Provide well designed intersections that minimize

impacts

• Integrate the facility into its surroundings with

aesthetic design

Project Needs

Environmental Review

• Design Constraints
• Cemetery
• Original German Lutheran Cemetery
• Public Recreational Land (Section 4(f) property)
• Pleasant View Golf Course
• Historical resources
• German Lutheran Church
• Existing land use
• Agricultural Research Station
• Residences
• Commercial
• Utilities

8’ 14’ 21’ 8’ 19’ 11’ 11’ 11’ 11’

Roadway Typical Section – Mineral Point Rd to Blackhawk Rd

21’ 8’ 8’ 12’ 5’ 7’ 7’ 11’ 11’

With Multi-Use Path and Sidewalk Without Multi-Use Path and Sidewalk

11’ 11’

8’ 14’ 21’ 8’ 19’ 11’ 11’ 11’ 11’ 8’ 5’ 9’ 21’ 8’ 10’ 9’ 11’ 11’ 11’ 11’

Roadway Typical Section – Blackhawk Rd to US 14

With Multi-Use Path and Sidewalk Without Multi-Use Path and Sidewalk

Pedestrian and Bike Accommodations

Wisconsin Act 59 has created challenges for local governments by prohibiting the use of eminent domain for pedestrian and bicycle facilities.

Mineral Point Rd Blackhawk Rd Blackhawk Rd US 14 Old Sauk Rd

Multi-Use Path Sidewalk

NORTH NORTH

Elderberry Rd Pleasant View Rd Quarry Rd University Ave

Intersection Control Evaluation (ICE)

• Examination of different intersection types/control
• Accommodation of future traffic volumes and needs
• Traffic Signal
• Provides signal control for pedestrian crossings
• Less right of way is needed
• Offers flexibility with timing adjustments
• Roundabout
• Slower speeds - Safety
• Better traffic operations
• Less severe crashes

Evaluation Factors

• Safety
• Level of Service (LOS)
• Indicates intersection ability to handle travel demand
• LOS A = excellent operation conditions
• LOS F = extremely congested conditions
• Pedestrians & Bicycles
• Right of way
• Access
• Construction Cost
• Environmental Impacts
• Operation & Maintenance Cost

Elderberry Road – Revised Two-Way Stop Control Alternative

*LOS A when signalized (and meets traffic signal warrants)

LOS Impacts F* 0.8 Acres

Elderberry Rd

NORTH

Pleasant View Rd Existing R/W (Typ.)

Elderberry Road – Roundabout Alternative

LOS Impacts B 0.8 Acres

NORTH

Elderberry Rd Pleasant View Rd Existing R/W (Typ.)

Blackhawk Road – Revised Traffic Signal Alternative

LOS Impacts B 0.1 Acres

NORTH

Pleasant View Rd Blackhawk Rd Existing R/W (Typ.)

Blackhawk Road – Roundabout Alternative

LOS Impacts B 0.2 Acres

NORTH

Pleasant View Rd Blackhawk Rd Existing R/W (Typ.)

Greenway Boulevard – Traffic Signal Alternative

LOS Impacts B 0.4 Acres

NORTH

Pleasant View Rd Existing R/W (Typ.)

Greenway Boulevard – Roundabout Alternative

LOS Impacts A 0.5 Acres

NORTH

Pleasant View Rd Existing R/W (Typ.)

Quarry Road – Revised Two-Way Stop Control Alternative

*LOS A when signalized (and meets traffic signal warrants)

NORTH

Quarry Rd Existing R/W (Typ.)

LOS Impacts F* 0.5 Acres

Quarry Road – Roundabout Alternative

NORTH

LOS Impacts A 0.7 Acres

Quarry Rd Existing R/W (Typ.)

US 14 – Revised Traffic Signal Alternative

LOS Impacts C 0.0 Acres

NORTH

Pleasant View Rd US 14 University Ave Existing R/W (Typ.)

Full and restricted access to Pleasant View Road is based on safety, traffic volumes, and proximity to intersections

• Full access with turn lanes are provided for all public roads

intersecting Pleasant View Road.

• Most driveways accessing Pleasant View Road will be

limited to right-in/right-out access and will not have a median

• pening.
• Please review the roll plots to see specifics regarding

access.

Access to Pleasant View Road

Pedestrian and Bike Accommodations

• Alternatives for Existing Multi-Use Path Crossing
• Pedestrian bridge crossing over Pleasant View Road
• Maintain existing at-grade crossing

NORTH

Pedestrian Bridge Crossing Over Pleasant View Road Alternative

NORTH

At Grade Crossing Of Pleasant View Road Alternative

Street Lighting

• New continuous LED street lighting will be

installed as part of the proposed improvements.

• Pleasant View Road will remain open to traffic

during construction:

• One travel lane in each direction
• Short-term closure may be required with detour

posted

Staging of Traffic During Construction

Tentative Project Schedule

• 30 Percent Design – Summer 2017 to Fall 2018
• Public Meeting No.1 – June 28, 2018
• Continue preliminary design incorporating comments –

Summer/Fall 2018

• Public Meeting No.2 – Winter 2018/19
• Complete Preliminary Design – Spring 2019
• Final Design – Spring 2019 to Summer 2020
• Public Meeting No.3 - Summer 2019
• Public Meeting Prior to Construction - Early 2021

UW Agriculture UW Agriculture Blackhawk Neighborhood Pleasant View Golf Course Junction Ridge Neighborhood Old Cemetery

NORTH

Quarry CTH S (Mineral Point Rd) Old Sauk Rd Blackhawk Rd US 14 Elderberry Rd University Avenue

Tentative Construction Schedule

Phase 3 Mineral Point Rd – Old Sauk Rd 2023 Construction Phase 2 Old Sauk Rd – Greenway Blvd 2022 Construction Phase 1 Greenway Blvd – US 14 2021 Construction

Anticipated Construction Costs

• Preliminary Roadway Construction Cost of about $28.1 Million
• Roadway partially funded with Federal funds
• Property owners will be assessed for the local share per City
• f Madison or City of Middleton policy

Feedback

• Sign in
• Review Exhibits
• Ask questions
• Provide feedback &

comments

Additional Information/Stay Up-to-Date

• Project Website
• Project Contact Info.
• PDF of this Presentation
• PDF of Meeting Exhibits
• Sign-Up for Project Updates

http://www.cityofmadison.com/engineering/projects/pleasant-view-road

Questions
