SLIDE 1

TRU-46-7.28 Safety Study Public Involvement Meeting

Ohio Department of Transportation – District 4

PID 103908 September 5, 2018

SLIDE 2

Public Involvement Meeting

The purpose of this public involvement meeting is to present the findings of the TRU-46-7.28 Safety Study, and to solicit public feedback on the recommended countermeasures.

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 2

Meeting Purpose

SLIDE 3

TRU-46-7.28 Safety Study – Public Information Meeting

Background
Present Day Conditions
Proposed Condition

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 3

Presentation Agenda

SLIDE 4

Process

Coordination between stakeholders

Regular meetings with project stakeholders: ODOT, Trumbull County, Howland Township, Eastgate
Coordination with local Fire/EMS
Study accounts for school arrival/dismissal times and travel patterns
Builds off past studies and projects

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 4

How we got here

SLIDE 5

Background

SLIDE 6

Project Background

Six Study Locations

1. SR 46/SR 82 (EB Ramps) 2. SR 46/SR 82 (WB Ramps) 3. SR 82/Howland-Wilson Road 4. SR 46/Warren-Sharon Road 5. SR 46 from Warren-Sharon to SR 82 6. SR 46/Howland Springs Road

Expands upon previous studies/projects

2005 TRU-422 Corridor Study
2006 SR 82/Howland-Wilson Road Improvements
2012 SR 46/SR 82 Turn Lane Improvements
2012 SR 46 Corridor Signal Re-timing

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 6

SLIDE 7

Network Interconnectivity

The study area is a connected network

Congestion at one location spills back

through the network

Improvements at one location can have

both positive and negative impacts at the

thers
Careful balance of improvements

necessary

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 7

SLIDE 8

Network Interconnectivity

Howland-Wilson Road serves

as a “pressure relief valve” for the SR 46/SR 82 interchange

Issues heightened by existing

inefficiencies at SR 46/SR 82

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 8

SLIDE 9

Safety

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 9

TRU 2017 HSIP Safety Rankings

SLIDE 10

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 10

SLIDE 11

Present Day Conditions

SLIDE 12

Present Day Conditions

Congestion occurs throughout the day Multiple peak periods

AM (7:00a-9:00a)
Midday (11:00a-1:00p)
School Release (2:00p-3:00p)
PM (4:00p-6:00p)

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 12

Network Congestion

SLIDE 13

Present Day Conditions

Crash trend increasing
60-75 crashes per year (study area average)
Majority of crashes are rear end crashes
Injury Crashes
30% of all study area crashes
>40% of SR 82/Howland-Wilson Road Crashes
Increasing congestion
Commercial development

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 13

Safety and Driver Expectancy

SLIDE 14

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 14

SLIDE 15

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 15

SLIDE 16

Proposed Countermeasures

SLIDE 17

TRU-422 Corridor Study

The TRU-422 (2005) Corridor Study Evaluation

Previous alternatives were rejected because of:

Potential right of way impacts
High construction costs
Construction feasibility
Low safety benefit

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 17

Previously Considered Alternatives

SLIDE 18

Proposed Countermeasures

SR 46/SR 82 Interchange

Replace the existing interchange with a Diverging Diamond

Interchange (DDI)

Provide pedestrian access through the interchange

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 18

SLIDE 19

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 19

SLIDE 20

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 20

SLIDE 21

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 21

SLIDE 22

Proposed Condition

Safety

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 22

Why Choose a DDI?

SLIDE 23

Proposed Condition

Network Operations

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 23

Why Choose a DDI? 30% Less Driver Delay Overall 25% Less Driver Delay at Interchange 50% Fewer Vehicle Stops

SLIDE 24

Proposed Countermeasures

SR 82/Howland-Wilson Road

Restrict access to Right-In Only from SR 82 (Eastbound/Westbound)
Remove traffic signal
Cul-de-sac northbound and southbound Howland-Wilson Road
Fire/EMS access maintained

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 24

SLIDE 25

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 25

SLIDE 26

Proposed Countermeasures

SR 46/Warren-Sharon Road

Construct NB/SB Right Turn Lanes
Extend NB/SB/WB Left Turn lanes to meet expected design year queues
ADA/Pedestrian accommodations

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 26

SLIDE 27

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 27

SLIDE 28

Proposed Countermeasures

SR 46 from the Interchange to Warren-Sharon Road

Widen SR 46 from 2 lanes to 3 lanes including a center Two Way

Left Turn Lane (TWLTL)

Install sidewalk on both sides of roadway
Install closed drainage system along SR 46

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 28

SLIDE 29

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 29

SLIDE 30

Environmental Impacts

The proposed countermeasures at the SR 46/82 interchange have the potential to impact the E.N. Brown Residence (877 SR 46 [Niles Cortland Road]) determined to be eligible for inclusion on the National Register of Historic Places (NRHP). If anyone is interested in becoming a member of the Section 106 consulting party, please contact: Sean Carpenter, ODOT District 4 Environmental Specialist (sean.carpenter@dot.ohio.gov)

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 30

Historic Property

SLIDE 31

Proposed Condition

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 31

Project Timeline

2019-2023

Preliminary Engineering
Detailed Design
Right of Way

2023-2024

Construction of DDI

2025-2027

1. SR 46/Warren-Sharon
2. SR 82/Howland-Wilson
3. SR 46 TWLTL

*Project timeline contingent on securing funding

SLIDE 32

Thank you

SLIDE 33

Process

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 33

Support

SLIDE 34

Public Comments

SLIDE 35

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 35

SLIDE 36

Present Day Conditions

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 36

Crashes and Driver Expectancy

Traffic Crash Year Number % Type of Crash Number % 2012 83 20.8% Rear End 229 57.4% 2013 67 16.8% Left Turn 53 13.3% 2014 81 20.3% Angle 53 13.3% 2015 77 19.3% Sideswipe-Passing 45 11.3% 2016 91 22.8% Fixed Object 8 2.0% Grand Total 399 100.0% Other 11 2.8% Grand Total 399 100.0% Day of Week Number % Monday 65 16.3% Tuesday 64 16.0% Road Condition Number % Wednesday 63 15.8% Road - Dry 320 80.2% Thursday 62 15.5% Road - Wet 60 15.0% Friday 60 15.0% Road - Snow 11 2.8% Saturday 50 12.5% Road - Ice 7 1.8% Sunday 35 8.8% Other Road Condition 1 0.3% Grand Total 399 100.0% Grand Total 399 100.0%

SLIDE 37

Project Background

Expands upon previous studies/projects

TRU-422 (2005, PID 21310)
TRU-82-18.00 (2006, PID 22426)
TRU-46-7.32 (2012, PID 80657)
TRU-46-Signal Study (2012, PID 91307)

September 5, 2018 TRU-46-7.28 Safety Study | Public Involvement Meeting 37
