Error Resilient Internet Video Transmission

Ciro A. Noronha, Ph.D.

Director of Technology, Compression Systems

Juliana W. Noronha

University of California, Davis

Motivation

• There are a number of protocols in use today to transport

Video over IP.

• Since the “I” in IP stands for “Internet”, the Internet can

(potentially) be used to transport Video over IP.

• Low-cost contribution links!!
• However, not all Video over IP protocols are suitable for

transporting Video on the Internet because:

• The Internet drops packets
• Video over IP is compressed and needs every bit
• Video over IP cannot take packet drops
• The Video over IP protocol has to handle this issue

“The nice thing about standards is that you have so many to choose from.”

Andrew Tanenbaum, Computer Networks, 2nd ed., p 254

• Where does packet loss happen?
• How much packet loss is acceptable?
• What can we do about packet loss?

— Protocol options — Theoretical analysis — Measurement Results

• Conclusions and recommendations

Outline

The Internet Protocol (IP)

The Internet Protocol defines an unreliable, connectionless, best-effort delivery mechanism for the Internet.

— Unreliable: packet delivery is not guaranteed — Connectionless: packets are treated independently; multiple packets between two nodes may take different paths and arrive out-of-order — Best Effort: packets are discarded when underlying networks fail or resources are exhausted

“I am going to try my best to deliver your packet, but if I cannot, no hard feelings.”

Where are packets lost?

Ethernet

√

No Loss

√

No Loss

Ethernet

So, where are packets really lost?

Router Congestion!

Congestion!

• Congestion happens when the traffic wanting to go out a

link exceeds the capacity of that link

• Routers have buffers that will accommodate small

fluctuations

• Once the buffer is full, packets are dropped

— A packet will traverse multiple routers and links – this can happen anywhere in the path — Normally, packets are dropped in bursts or blocks — This is the “best-effort” aspect of the Internet

Can’t this be fixed with traffic priorities?

• In theory, yes.

— Video traffic can be “marked” so it is recognizable at the router — Router can be configured to give priority to video packets

• If there is congestion, other traffic is dropped
• However:

— You can do this if you own and control all the routers in the path — You don’t own and control the routers in the Internet — Internet will ignore all packet markings

What is an “acceptable” packet loss?

• Video compression works by removing redundancy from

the content

— Every bit of compressed video is very important

• There is a simple way to look at the effect of packet

loss:

— Assume that every packet that is dropped by the network causes a noticeable glitch in the video

• A block of packets dropped together causes one glitch

— Decide how many glitches per (day/hour/minute) is acceptable to you

Some numbers

Dropping one packet in Produces a glitch every 1,000 2.6 seconds 10,000 26 seconds 100,000 4 minutes 23 seconds 1,000,000 44 minutes 10,000,000 7 hours 19 minutes

Assume a 4 Mb/s stream, with 1316-byte packets

In order to achieve reliable operation on the Internet, a network protocol is needed to “recover” in some way the packets that have been lost.

The Network Protocol Tradeoff

• Fundamentally, there is a tradeoff between LATENCY

and PACKET LOSS RESILIENCY:

— Decoders cannot “wait forever” – packets have expiration dates — You can give yourself time to deal with packet loss by pre- buffering before the decoder – the more time you give yourself, the better job you can do to recover from lost packets — However, many applications (e.g., contribution) have latency limits

The Network Protocol Tradeoff

Encoder

Internet

Buffer Decoder

Protocol Latency

Gives you time to recover from lost packets – the more time you have, the better job you can do!

Protocol Basics

End-to-end IP applications run on top of one of two protocols:

— User Datagram Protocol (UDP)

• “Raw” network service
• Packets are delivered as fast as possible, but may be dropped

— Transmission Control Protocol (TCP)

• “Reliable” network service
• Flow control (bad for encoders, unless rate changes on the fly)
• Unbounded latency

Protocol Roadmap

• We are limiting this discussion to protocols:

— That will work over the Internet — That have no limitations on media transport

• Roadmap:

— UDP based:

• RTP plus SMPTE-2022 FEC
• ARQ

— TCP based:

• HLS and similar variants

RTP plus SMPTE-2022 FEC

• Basic idea:

— Transmit the video using RTP

• That gets you timestamps and sequence numbers
• Sequence numbers let you know when packets were dropped

— Transmit “extra” FEC packets — If packets are lost in the network, it may be possible to rebuild them from the received packets and FEC packets:

• For each N packets send 1 FEC packets
• If there is one loss in this set of N+1 packets, it can be corrected

— Use a matrix arrangement to deal with burst losses

FEC Illustration

N Columns M Rows Column FEC: can recover a burst of up to N successive lost packets every NxM packets Row FEC (optional): can recover single packet losses in each row Overhead:

• N column packets
• M row packets

For each NxM video packets

Some FEC Numbers

Columns Rows Recovery Capability Overhead Latency @ 2 Mb/s Latency @ 10 Mb/s 5 5 5 pkts every 25 20% 263 ms 53 ms 10 5 10 pkts every 50 20% 526 ms 105 ms 20 5 20 pkts every 100 20% 1052 ms 211 ms 10 10 10 pkts every 100 10% 1052 ms 211 ms

ARQ

• ARQ stands for:

— Automatic Repeat reQuest — Automatic Repeat Query

• This is the generic name for a number of retransmission

strategies in the face of packet loss

— Standard TCP uses a couple of ARQ variants

• In video transmission, the most useful variant is

“Selective Retransmission” (NACK-based)

— If you don’t hear from me, everything is OK — If I miss anything, I let you know and you resend just that

• ARQ implementations in industry today do not

interoperate due to lack of standards

Cobalt RTP/ARQ

• Use RTP as the base video transmission layer

— Compatible with all professional IRDs (minus the packet loss correction) — Packet losses are detected using sequence numbers

• Use the RTCP NACK message from RFC-4585 to

request retransmission of lost packets

— One NACK message can request up to 17 packets

• It is possible to build a complete ARQ solution using
• nly published standards with no proprietary methods

ARQ Illustration

Encoder

Internet

Decoder Network Round-trip Delay This buffer adds no latency to the transmission

ARQ Notes

• The ARQ latency is at least one network round trip delay

— Allowing multiple round trip delays allows the receiver to retry a packet multiple times — Usual Latency x Reliability tradeoff

• The ARQ overhead is a function of the packet loss

— If there is no packet loss, there is zero overhead — Overhead increases with packet loss, as lost packets are retransmitted

• HLS is a protocol designed by Apple to provide streaming

using a standard (unmodified) web server

• Implemented primarily on mobile devices
• The video stream is divided into “chunks” of a few seconds

each

• The decoder downloads the chunks as files from the web

server with standard HTTP transactions, using a playlist

• Protocol supports adaptive streaming (multiple bit

rates/resolutions)

HTTP Live Streaming (HLS)

Encoder

File 565 File 566 File 567 Playlist File565 File566 File567

Web Server

Network

HTTP Get

Decoder

HLS Illustration – single stream/profile

• Characteristics:

— Very high latency: 3-4 times the chunk size (which varies from 2 to 30 seconds) — Extremely robust (uses TCP and HTTP) — Can potentially survive short network outages — Can easily scale to a large number of destinations

• Probably one of the most robust transports available if you

can afford the latency

• Supported as a transport mechanism in the Cobalt

encoder/decoder series

HLS Details

A little probability and statistics…

• Assume independent loss probability for each

transmitted packet (binomial distribution)

• Calculate the rate of packets still lost after correction

with statistical analysis

• This allows us to theoretically compare the performance
• f the various protocols and settings
• Our variables are:

R = number of requests (ARQ) N = number of packets per row (FEC) M = number of packets per column (FEC)

Overhead

• In both scenarios, additional packets are transmitted:

— FEC sends additional FEC packets — ARQ sends retransmissions

• We can also model the overhead of the various

protocols and settings 𝑝𝑤𝑓𝑠ℎ𝑓𝑏𝑒 = 𝑜𝑣𝑛𝑐𝑓𝑠 𝑝𝑔 𝑓𝑦𝑢𝑠𝑏 𝑞𝑏𝑑𝑙𝑓𝑢𝑡 𝑡𝑓𝑜𝑢 𝑢𝑝𝑢𝑏𝑚 𝑜𝑣𝑛𝑐𝑓𝑠 𝑝𝑔 𝑝𝑠𝑗𝑕𝑗𝑜𝑏𝑚 𝑞𝑏𝑑𝑙𝑓𝑢𝑡

Field Test Data

• Locations:
• Santa Clara, CA
• Champaign, IL
• ISP: Comcast
• Network Round Trip

Time: 75 ms

• Number of hops: 12
• Target bit rate:

3 Mb/s

• Equipment:
• 9223 Encoder
• 9990-DEC Decoder

Initial Link Characterization

Custom software was used to receive the video stream and measure statistics

Test Duration 25 hours 42 minutes Total Packets 26,381,219 Dropped Packets 8,187 Network Packet Loss 0.031% Packet Loss Instances 2,464 Average Packet Drop 3.3 packets Max Packet Drop 169 packets Network Glitch Interval 37.5 seconds

RTP/SMPTE-2022 Test Data

Test Duration 65 hours Test Start Date 05/19/17, 3:50PM Network Packet Loss 0.0158% Corrected Packet Loss 0.0027% Correction Ratio 83% Bandwidth Overhead 25% Network Glitch Interval 1 minute 13 seconds Corrected Glitch Interval 7 minutes 12 seconds Protocol Latency 702 ms

Parameters: 20x5 matrix, row and column

RTP/ARQ Test Data

Test Duration 169 hours Test Start Date 05/24/17, 12:30PM Network Packet Loss 0.0257% Corrected Packet Loss 0.000078% Correction Ratio 99.7% Bandwidth Overhead 0.027% Network Glitch Interval 46 seconds Corrected Glitch Interval 4 hours 7 minutes Protocol Latency 400 ms

Parameters: up to 4 retries allowed

FEC/ARQ Comparison

Scaling:

• Latency

— ARQ latency is constant — FEC latency decreases with increasing bit rate

• Overhead

— ARQ overhead will increase with packet loss — FEC overhead is constant

Parameter 2022 FEC ARQ Network Packet Loss 0.0158% 0.0257% Corrected Packet Loss 0.0027% 0.000078% Correction Ratio 83% 99.7% Bandwidth Overhead 25% 0.027% Network Glitch Interval 1 minute 13 seconds 46 seconds Corrected Glitch Interval 7 minutes 12 seconds 4 hours 7 minutes Protocol Latency 702 ms 400 ms

So, which one do I choose?

RTP plus SMPTE 2022 FEC RTP plus ARQ HTTP Live Streaming Latency Moderate (less than 1 sec) Moderate (less than 1 sec) Very High (multiple seconds) Overhead High Very Low Very Low (uses TCP) Correction Capability Poor Very Good Excellent Standard? Yes No (*) Yes Ease of setup Simple Moderate Trivial

Standardization Efforts

• The standard solutions today are limited:

— SMTPE-2022 does not work well on the Internet — HLS works well but has very high latency

• The Video Services Forum (VSF) has started a group

called RIST (Reliable Internet Stream Transport) to come up with a protocol

— Group launched during the Feb 2017 VSF meeting — Face-to-face organizational meeting during NAB 2017 — Target is to have a standard by NAB 2018 — Cobalt Digital is active in this group
