Equipment Presentation The Complete Turn-key DEF Solution Product Information - Technology When injected into the exhaust, DEF hydrolyses and forms ammonia. This triggers the chemical reaction that converts the NOx gases in the exhaust into

SLIDE 1

Equipment Presentation The Complete Turn-key DEF Solution

SLIDE 2

Product Information - Technology

= Exhaust

Exhaust leaves the engine with the pollutants NOx and PM

SCR Catalyst

NOx PM

NOx

Particulate Matter (PM) is trapped in the Diesel Particulate Filter (DPE)

PM DEF injected into the exhaust stream

DEF

NH3

DEF solution ‘hydrolyzes’ into ammonia (NH3) which mixes with the exhaust

Ammonia (NH3) and Nitrogen Oxides (NOx) react in the catalyst to form Nitrogen and Water

N2 H2O

When injected into the exhaust, DEF hydrolyses and forms ammonia. This triggers the chemical reaction that converts the NOx gases in the exhaust into harmless nitrogen and water (the Selective Catalytic Reduction process).

= Diesel Exhaust Fluid (DEF)

SLIDE 3

Product Information

SLIDE 4

Mandated Legislative Timeline

2009 - Light duty tier 2 cars 2010 - Heavy duty trucks / buses 2014 - Non road equipment, Largest C2 Marine Engines 2015 - Locomotives (fully phased in 2017) 2016 - C3 Ocean Going Vessels 2017 - C1 Marine

Source: United States - EPA’s National Clean Diesel Campaign

SLIDE 5

The Total Supply Chain Picture

Lubrication Solutions Inc. worked closely with equipment partners to design a DEF storage and handling methodology to maintain both DEF quality and integrity. The result is cost effective solutions for our distributors and end users. We considered a number of factors when designing our packaging and equipment system, including:

Common Industry Practice
Cost
Functionality
Durability
Product quality
DEF replenishment mechanism

SLIDE 6

Wrong Solutions / Do not try to re-invent

Diesel Exhaust Fluid is extremely corrosive fluid. You can only use HDPE or Stainless Steel. All of the responsibility to educate your customers falls on

you. Do not try to connect things with glues or adhesives.

Horror pictures of what people have done in the field. Hand pump, that a customer decided would seal better by adding plumber’s putty to it.

SLIDE 7

Wrong Solutions / Do not try to reinvent

Customer decided to pull from the bottom

f the tote with brass

cam lock fittings.

SLIDE 8

Closed System - Details

Tote pumping out Tote re-filling

RSV Stainless Steel Container Valve Tamper Evident Stainless Steel Wire Seal

SLIDE 9

PISTON-SYSTEM DRUM PUMP

SLIDE 10

TOTE (IBC) DISPENSING SYSTEM

Dispensing System

SLIDE 11

Air Operated Tote Pump Pro Package

SLIDE 12

OPTIONS TO CUSTOMIZE CLIENT NEEDS!

SLIDE 13

DEF Fleet Fuel Island Dispenser

Unit Includes Pump, Mounting

Pedestal, Pulse Meter, SS Auto Nozzle, LCD Screen & Keypad

Works With Most Fleet Card Readers
Available in Stand-Alone Inventory

Control System with Software

SLIDE 14

End-User Bulk Solutions (ALL IN ONE PACKAGE)

SLIDE 15

Bulk Tank Solutions

6,500 – 10,000 Gallon Tanks Single Wall or Double Wall Tank Cross linked or HDPE Poly Tank Three year warranty from date of purchase on all premium weight tanks and a five year warranty on all heavy weight tanks. 12 manufacturers across the country.

SLIDE 16

Turn-key Bulk Dispensing & Transfer Systems

SLIDE 17

Distributor On-Site Packaging Solution

With the DEF PRO 6000 system you can transfer from tank to tote, tote to tote or tote to drum. The flow rates depend on the type of equipment used to build the system. From 23- 120 GPM.

SLIDE 18

Self Powered engine DEF Cart W&M LCRII Ticket Printing Bulk Transfer Skid with LCRII W&M Ticket Printer Ultra Mobile DEF Dolly with Mechanical W&M Ticket Printer.

Bulk Transfer Systems Weights & Measures Solutions

SLIDE 19
