SLIDE 1

Elastic RSS

Co-Scheduling Packets and Cores Using Programmable NICs

Alexander Rucker Tushar Swamy, Muhammad Shahbaz, and Kunle Olukotun Stanford University August 17, 2019

SLIDE 2

How do we meet

tail latency

constraints?

1

SLIDE 3

Existing systems have several limitations.

Random Hashing

Load imbalance
Over provisioned

NIC

Centralized Scheduling

Dedicated core
Limited throughput

2

SLIDE 4

Existing systems have several limitations.

Random Hashing

Load imbalance
Over provisioned

NIC

Centralized Scheduling

Dedicated core
Limited throughput

NIC

Sched

2

SLIDE 5

How do we

scalably & CPU-efgiciently

meet tail latency constraints?

3

SLIDE 6

eRSS uses all cores for useful work and runs at line rate.

eRSS

4

SLIDE 7

Design

SLIDE 8

eRSS’s packet processing maps to a PISA NIC with map-reduce extensions.

P a r s e r

Match-Action Pipeline Map-Reduce Block Match-Action Pipeline

D e p a r s e r

Programmable NIC

On-chip Core

(ARM or PowerPC)

PHV

H

s

t C P U s 5

SLIDE 9

1. Assign each packet to an application.

P a r s e r

Match-Action Pipeline Map-Reduce Block Match-Action Pipeline

D e p a r s e r

Programmable NIC

On-chip Core

(ARM or PowerPC)

PHV

H

s

t C P U s

For example, use IP address or port number.

6

SLIDE 10

2. Estimate the per-packet workload.

P a r s e r

Match-Action Pipeline Map-Reduce Block Match-Action Pipeline

D e p a r s e r

Programmable NIC

On-chip Core

(ARM or PowerPC)

PHV

H

s

t C P U s

Workload Estimation

per Application

Can use any set of packet header fields (currently, only packet size).
Model is periodically trained by the CPU.

7

SLIDE 11

3. Determine core count for the application.

P a r s e r

Match-Action Pipeline Map-Reduce Block Match-Action Pipeline

D e p a r s e r

Programmable NIC

On-chip Core

(ARM or PowerPC)

PHV

H

s

t C P U s

Workload Estimation

per Application

Core Allocation

per Application

Compare allocated cores to exponential moving average of workload.
Use heuristics and hysteresis to avoid ringing.

8

SLIDE 12

4. Select a virtual core.

P a r s e r

Match-Action Pipeline Map-Reduce Block Match-Action Pipeline

D e p a r s e r

Programmable NIC

On-chip Core

(ARM or PowerPC)

PHV

H

s

t C P U s

Workload Estimation

per Application

Core Allocation

per Application

Consistent Hashing with Weights

per Application’s Virtual Core

Virtual cores within each application are allocated densely, starting at 0.
Packets are hashed & the best allocated core is chosen.

9

SLIDE 13

5. Estimate queue depths.

P a r s e r

Match-Action Pipeline Map-Reduce Block Match-Action Pipeline

D e p a r s e r

Programmable NIC

On-chip Core

(ARM or PowerPC)

PHV

H

s

t C P U s

Workload Estimation

per Application

Core Allocation

per Application

Consistent Hashing with Weights

per Application’s Virtual Core

Queue-Depth Estimation

per Application’s Virtual Core Update weights (in 10µs)

Queues are estimated per-virtual core.
Estimates are used to adjust consistent hashing weights.

10

SLIDE 14

6. Map the virtual core to a physical core.

P a r s e r

Match-Action Pipeline Map-Reduce Block Match-Action Pipeline

D e p a r s e r

Programmable NIC

On-chip Core

(ARM or PowerPC)

PHV

H

s

t C P U s

Workload Estimation

per Application

Core Allocation

per Application

Consistent Hashing with Weights

per Application’s Virtual Core

Queue-Depth Estimation

per Application’s Virtual Core Update weights (in 10µs)

V2P Core Mapping

per Application

CPU assigns each physical core to an application as an active/slack core.
Look up ⟨Application, Virtual Core⟩ → Physical Core in match-action table.

11

SLIDE 15

1. An application needs additional headroom.

Run: Batch Run: Batch Sleep: Server Run: Server Linux Sched. Tick Poll NIC SW Alloc. Core NIC Interrupt NIC Dealloc.

App1

Host CPUs

eRSS

Manager

L

12

SLIDE 16

2. The core is initially running a batch job.

Run: Batch Run: Batch Sleep: Server Run: Server Linux Sched. Tick Poll NIC SW Alloc. Core NIC Interrupt NIC Dealloc.

App1

Host CPUs

eRSS

Manager

L

13

SLIDE 17

3. The sofuware manager starts and pins a sleeping thread to the core.

Run: Batch Run: Batch Sleep: Server Run: Server Linux Sched. Tick Poll NIC SW Alloc. Core NIC Interrupt NIC Dealloc.

App1

Host CPUs

eRSS

Manager

14

SLIDE 18

4. When the NIC allocates a core, it wakes up the resident thread.

Run: Batch Run: Batch Sleep: Server Run: Server Linux Sched. Tick Poll NIC SW Alloc. Core NIC Interrupt NIC Dealloc.

App1

Host CPUs

eRSS

Interrupt

Manager

15

SLIDE 19

5. Cores can run any server sofuware, incl. distributed work stealing or preemption.

Run: Batch Run: Batch Sleep: Server Run: Server Linux Sched. Tick Poll NIC SW Alloc. Core NIC Interrupt NIC Dealloc.

App1

Host CPUs

eRSS

Manager

16

SLIDE 20

6. Upon deallocation, the packet thread sleeps and the OS schedules a batch job.

Run: Batch Run: Batch Sleep: Server Run: Server Linux Sched. Tick Poll NIC SW Alloc. Core NIC Interrupt NIC Dealloc.

App1

Host CPUs

eRSS

Manager

17

SLIDE 21

Preliminary Evaluation

SLIDE 22

We simulate eRSS’s performance on a synthetic model.

Packets have Poisson-distributed inter-arrival times.
Packet sizes are representative of Internet trafgic.
Packet processing time correlates with size and added noise.

18

SLIDE 23

eRSS responds quickly to load variations.

10 20 30 40 16 32 48 64 1 2 3 4 5

Req. Trafgic (Gbps)

RSS Cores Allocated Time (ms)

19

SLIDE 24

eRSS responds quickly to load variations.

10 20 30 40 16 32 48 64 1 2 3 4 5

Req. Trafgic (Gbps)

RSS eRSS-a (90% load) Cores Allocated Time (ms)

19

SLIDE 25

eRSS responds quickly to load variations.

10 20 30 40 16 32 48 64 1 2 3 4 5

Req. Trafgic (Gbps)

RSS eRSS-a (90% load) eRSS-c (75% load) Cores Allocated Time (ms)

19

SLIDE 26

eRSS deallocates slowly to ensure queues are drained.

10 20 30 40 16 32 48 64 1 2 3 4 5

Req. Trafgic (Gbps)

RSS eRSS-a (90% load) eRSS-c (75% load) Cores Allocated Time (ms)

L

20

SLIDE 27

eRSS adds controllable tail latency.

1 0.2 0.4 0.6 0.8 0.1 1 10 100 CDF Latency (µs) RSS eRSS-a (90% load) eRSS-c (75% load)

L

SLO

21

SLIDE 28

Future Work & Summary

SLIDE 29

eRSS will be extended with ML.

Workload estimation
Efgicient core scheduling requires accurate workload estimates.
Use packet header fields and deep packet inspection to gather statistics.
Core scheduling with Reinforcement Learning (RL)
Replace heuristics for adding/removing cores to an application.
Replace consistent hashing for distributing packets between cores.

22

SLIDE 30

eRSS will be extended with ML.

Workload estimation
Efgicient core scheduling requires accurate workload estimates.
Use packet header fields and deep packet inspection to gather statistics.
Core scheduling with Reinforcement Learning (RL)
Replace heuristics for adding/removing cores to an application.
Replace consistent hashing for distributing packets between cores.

22

SLIDE 31

eRSS meets tail latency constraints while saving cores.

Parameters control trade-ofg between core use and tail latency.
eRSS runs at line rate using slight extensions to existing NICs.
eRSS is compatible with a variety of sofuware solutions.
eRSS can be extended with ML for automatic operation.

23

SLIDE 32

eRSS scalably & CPU-efgiciently

meets tail latency constraints.

Questions?

24

SLIDE 33

eRSS adds a controllable amount of additional queue depth.

10 20 30 40 10 20 30 1 2 3 4 5

Req. Trafgic (Gbps)

RSS eRSS-a (90% load) eRSS-c (75% load) Deepest Queue (kiB) Time (ms)

SLIDE 34

eRSS minimizes breaking flows.

0.7 0.8 0.9 1.0 2 4 6 8 10 CDF Break Counts eRSS-a (90% load) eRSS-c (75% load)
