Early Improvements Update

15 May 2018

2

Project Process

3

Candidate Early Improvements

• 107 interventions
• Considered to the stage where sufficient willingness and

resource will enable delivery within three years

• Most still require definition, investigation and assessment
• Prioritised into 15 mostly geographic packages
• Identified potential candidates for showcase and trial
• Current estimate of cost is
• $M 40 – 60 capex (including 20 – 30 of cycling)
• $M 10 – 17 opex

4

Implementation Planning

107 interventions – if delivered under BAU

• WCC – 75
• NZTA – 31
• GWRC – 1

Legal advice confirms that WCC traffic resolution decisions cannot be delegated

• Any changes to parking or traffic restrictions on WCC roads

Therefore the delivery mechanism needs some thinking

5

Prioritisation

• Setting safer speeds first to prioritise safety
• Benefits realisation – seeking biggest benefit returns first
• Only a matter of months between different packages starting,

intention is to deliver as many as possible early in the programme

• Showcase and trial opportunities identified

6

Prioritisation

Package Description

Liveability Access Multimodal Safety Resilience

Prioritisation - weave these points into a story, it's only a matter of months between them and there's a bold desire to do it all Showcase Trial Setting Safer Speeds Reducing speed limits on selected roads in the CBD and sections of SH1 east of Mt Vic

2

• 1

1 3 5

Potential to significantly improve safety across the network Featherston St Corridor length improvements to walking and cycling priority, and provision of cycling facilities on Whitmore

2 1 2 1 6

Showcase project with good multi-modal benefits, and the potential to improve the last mile pedestrian trip from rail Golden Mile Bus priority enhancements, minor safety improvements, and trial restriction of general traffic on sections of northern Willis Street and Courtenay Place

2 1 2 1 6

Network wide PT benefits as a pre-cursor to lane drop on the Quays Basin Reserve Package of relatively low cost minor at-grade improvements to improve efficienct access

3 1 1 5

Improving a critical conflict point Hutt Road Public transport and cycling priority along the corridor with integrated pedestrian improvements

1 1 1 2 5

Improve PT and cycle trips from the north, begin to discourage private vehicle use as a pre-cursor to lane drop Isolated Minor Improvements Traffic signal and intersection enhancements, pedestrian crossing improvments and shelter and wayfinding enhancements, lengthening nine bus stops to meet minimum standard, further use of technology to improve management of on-street parking

1 1 1 1 1 5

Progress minor individual projects as possible Operational Improvements Improved signal operations, applying MaaS platform to Wellington context, improved incident management, enhancing existing TDM programmes

2 1 2 5

Progress minor individual projects as possible Willis/Victoria Corridor length improvements to walking and cycling priority

1 1 2 1 5

Large PT LoS gap, but not currently high numbers of buses

• r cyclists

Karo / Vivian Restrict parking on Vivian Street and minor efficiency improvements

2 1 1 4

Dixon Street Implementing cycling connections and pedestrian improvements

1 2 1 4

SH1 East of Mt Vic Pedestrian and cycle crossing signals on Cobham Drive, bus priority and minor intersection safety improvements (dependency with setting safer speeds)

1 1 2 4

Taranaki St Trial cycling and bus priority improvements in advance of final corridor form

1 1 1 1 4

Newtown Review bus lane priorities

1 2 3

The Terrace Pedestrian priority and crossing enhancements, Bowen Street bus lanes/clearways

1

• 1

2 1 3

Motorway Corridor Minor efficiency and safety improvements

1 1 2

Investment Objectives Sub-Total

7

Package Maps

DRAFT proposals for Setting Safer Speeds

Speed Limit Review

Liveability Access Multimodal Safety Resilience Capex 0.4-0.6 Opex 0.4-0.6

2

• 1

1 3

DRAFT proposals for Featherston Street

Optimise signals to favour pedestrians (consider LED strip lighting trial) Safety Improvements Add pedestrian crossing Provide Cycling Facility Widen footpath

Liveability Access Multimodal Safety Resilience Capex 2.5-4.1 Opex 0.3-0.6

2 1 2 1

DRAFT proposals for Golden Mile

Safety Improvements Remove Bus Stop PT Priority Upgrades Trial removal/ restriction of General Traffic Add pedestrian crossings/crosswalks Provide Cycling Facility Improved Laneway Second cycle minor phases Convert angle parking to parallel Pedestrian countdown timers

Liveability Access Multimodal Safety Resilience Capex 4.7-7.8 Opex 1.4-2.6

2 1 2 1

Potential shared space

DRAFT proposals for Basin Reserve

Close/restrict Ellice Street Remove/restrict parking Widen footpath At-grade access improvements Remove parking Southbound bus lane

Liveability Access Multimodal Safety Resilience Capex 5.8-9.3 Opex 0.5-0.9

3 1 1

DRAFT proposals for Hutt Road

Improved crossing

• pportunities

Improved Public Transport priority/HOV

Liveability Access Multimodal Safety Resilience Capex 2.2-3.5 Opex 0.2-0.4

1 1 1 2

Trial Cycling Facility Signalise pedestrian crossing

DRAFT proposals for Willis / Victoria

Provide Cycling Facility Improved Laneway Improved bus priority

Liveability Access Multimodal Safety Resilience Capex 1.5-2.4 Opex 0.3-0.5

1 1 2 1

Remove Parking

DRAFT proposals for Karo / Vivian

Restrict parking Restrict turns Optimise signals (queue conflict and PT delay) Second cycle right turn Remove Parking Second cycle Abel Smith (west) Second cycle right turn Second cycle Pirie Street

Liveability Access Multimodal Safety Resilience Capex 0.7-1.2 Opex 0.2-0.4

2 1 1

Change lane designations

DRAFT proposals for Dixon

Liveability Access Multimodal Safety Resilience Capex 1.5-2.5 Opex 0.1-0.2

1 2 1

Pedestrian Connection Provide Cycling Facility

DRAFT proposals for SH1 East of Mt Vic

Safety Improvements Add pedestrian and cycle crossing Pedestrian crossing

• pportunities

PT priority

Liveability Access Multimodal Safety Resilience Capex 4.8-7.7 Opex 0.4-0.8

1 1 2

DRAFT proposals for Taranaki Street

Trial cycling facility Add pedestrian crossings/ signalise zebra

Liveability Access Multimodal Safety Resilience Capex 3.4-5.5 Opex 0.3-0.5

1 1 1 1

PT priority improvements

DRAFT proposals for Newtown

Review bus lane times/ PT priority

Liveability Access Multimodal Safety Resilience Capex 0.1-0.5 Opex 0.0-0.0

1 2

DRAFT proposals for The Terrace

Improved right turn into Museum Street Improve pedestrian crossing

• pportunities

Improved pedestrian route Review clearway times/ PT priority

Liveability Access Multimodal Safety Resilience Capex 1.6-2.7 Opex 0.8-1.5

1

• 1

2 1

DRAFT proposals for Motorway Corridor

Increase off-ramp stacking capacity and optimise intersection Safety Improvements Test lane lights

Liveability Access Multimodal Safety Resilience Capex 1.8-3.0 Opex 0.3-0.6

1 1

Active queue warning sign

21

• Pedestrian wayfinding
• Additional countdown timers (traffic signals)
• Pedestrian sensors (traffic signals)
• Additional smart parking infrastructure
• Loading zone parking sensors
• Pedestrian shelter
• Widened footpaths (minor only)
• Airport travel choice VMS
• Additional CCTV for traffic operations monitoring
• Lengthen nine bus stops to minimum standard on 2018 core

routes

• Improved pedestrian lighting
• Cycle rumble strips on harbourside walkway
• Double right turn out of Hinemoa onto Waterloo Quay
• Remove two single car parks that affect intersection

capacity Tinakori Road

• Trial half cycle minor phases at traffic signals during peak
• peration
• Signalise zebra crossing on Tinakori Road
• Rationalise bus stops near Kilbirnie Aquatic Centre
• Improve pedestrian crossing on Molesworth near

Hawkestone

• Improve pedestrian crossing on Mulgrave at Thorndon Quay

Operational Improvements and Isolated Minor Improvements

• Improved Incident Response
• Applying MaaS platform to Wellington context
• Increased workplace and School travel planning
• Further encourage e-bike uptake
• Increase resource for operations
