technology from seed Bundles Fragmentation in Vehicular Delay-Tolerant Networks Narcio Magaia, Paulo Rogrio Pereira , Augusto Casaca, (Inesc-ID, Portugal), Joel J. P. C. Rodrigues, Joo A. Dias, Joo N. Isento, (IT, Portugal) Cristina

slide-1
SLIDE 1

technology

from seed

Bundles Fragmentation in Vehicular Delay-Tolerant Networks

Naércio Magaia, Paulo Rogério Pereira, Augusto Casaca, (Inesc-ID, Portugal), Joel J. P. C. Rodrigues, João A. Dias, João N. Isento, (IT, Portugal) Cristina Cervelló-Pastor, Javier Gallego (UPC, Spain).

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 111

technology

from seed

Summary

  • DTN/VDTN Architecture
  • VDTN Fragmentation
  • Experimental evaluation
  • Conclusion

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 222

slide-2
SLIDE 2

technology

from seed

Summary

  • DTN/VDTN Architecture
  • VDTN Fragmentation
  • Experimental evaluation
  • Conclusion

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 27-06-2011 3333

technology

from seed

Introduction

  • Delay/Disruption Tolerant Networks (DTNs) are networks

that may experience frequent and long duration partitions.

  • Examples: military communications in the battlefield, deep

space communications, some forms of ad-hoc sensor/actuator networks, rescue actions in catastrophe

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 4

sensor/actuator networks, rescue actions in catastrophe hit areas, wild life monitoring, offering Internet connectivity in developing regions, vehicular networks.

4

slide-3
SLIDE 3

technology

from seed

Bundle Layer

  • Link disruptions are not properly handled by the Internet

protocols, due to high delays and high packet loss.

  • The DTN Research Group, which was chartered as part of the

Internet Research Task Force (IRTF), has proposed an architecture (RFC 4838) and a communication protocol for DTNs (RFC 5050).

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 555

  • “Bundle Layer” added on top of the

transport layer for the end-to-end exchange of messages (called bundles) taking advantage of scheduled, predicted, opportunistic

  • r permanent connectivity.

Application Application Bundle end point Bundle end point Bundle end point Bundle end point Transport Transport Transport Transport Network Network Network Network

DTNs (RFC 5050).

technology

from seed

DTN characteristics

  • Random and predictable node mobility
  • Intermittent/Scheduled/Opportunistic Links
  • Large or variable delays
  • High Error Rates / Low Usable Capacity
  • Limited node uptime (e.g. to save power)

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 666

  • Limited node uptime (e.g. to save power)
  • Link bandwidth/loss/delay asymmetry
  • Heterogeneous Network Architectures
  • End-to-end path may not exist
slide-4
SLIDE 4

technology

from seed

Delay-Tolerant Networking Architecture

  • Goals

– Support interoperability across ‘radically heterogeneous’ networks – Tolerate delay and disruption

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 7

  • Acceptable performance in high

loss/delay/error/disconnected environments

  • Decent performance for low loss/delay/errors

technology

from seed

Message Abstraction

  • Network protocol data unit: bundles

– “postal-like” message delivery – origination and useful life time -assumes synchronized clocks – source, destination, and respond-to EIDs (Endpoint Identifiers) – Options: return receipt, “traceroute”-like function, alternative reply-to field, custody transfer – fragmentation capability

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 8

– fragmentation capability – overlay atop TCP/IP or other (link) layers: layer ‘agnostic’

  • Applications send/receive messages

– “Application data units” (ADUs) of possibly-large size – Applications should “bundle” together all data concerning a transaction that is sent asynchronously, to minimize interactions with large RTT – Adaptation to underlying protocols via ‘convergence layer’

slide-5
SLIDE 5

technology

from seed

Vehicular Contact Times

  • Contact times between vehicles crossing each other are rather short
  • Results for UDP with packet size 1460 bytes over IEEE 802.11a/g

[6]: Car speed Transferred data Contact Time Goodput 20 Km/h 13.0 MB 38.48 s 2.75 Mbps

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

  • For TCP, the performance is very low: average of 80 KB transferred

in a crossing at 60 Km/h (relative speed 120 Km/h), in 4 out of 10 experiments no data is transferred at all.

  • Motivates the study of fragmentation, necessary for large bundles.

40 Km/h 3.6 MB 14.90 s 1.90 Mbps 60 Km/h 1.6 MB 10.83 s 1.15 Mbps

27-06-2011 9 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks

technology

from seed

VDTN

  • Vehicular networks may benefit from DTN concepts

– especially in regions with no communications infrastructure or with few vehicles, such as: rural and mountainous regions. – non real-time applications, such as: traffic information, meteorological information – the use of fixed relay nodes in cross-roads may improve the

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

– the use of fixed relay nodes in cross-roads may improve the delivery ratio

27-06-2011 10 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks

slide-6
SLIDE 6

technology

from seed

VDTN Architecture

  • Bundle layer below the network layer

– objective is to route large size messages instead of small size IP packets – results in fewer packets processing and routing decisions, which can be translated to less complexity, lower cost and energy savings

BAD layer: Bundle Aggregation and De-aggregation

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

  • BAD layer: Bundle Aggregation and De-aggregation

Application Layer Transport Layer Network Layer BAD Layer BSC Layer MAC Layer MAC Layer PHY Layer PHY Layer Data Plane Control Plane Persistent Storage

  • BSC layer: Bundle Signaling Control
  • Persistent storage to avoid data loss
  • Relay nodes only have the lower

layers

27-06-2011 11 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks

technology

from seed

Summary

  • DTN/VDTN Architecture
  • VDTN Fragmentation
  • Experimental evaluation
  • Conclusion

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 27-06-2011 12 12 12 12

slide-7
SLIDE 7

technology

from seed

IP fragmentation

  • Fragmentation in IP networks has been considered

harmful

– poor performance or complete communication failure – additional headers, additional bandwidth, additional processing – complex reassembly mechanisms at the receiver

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

– loss of fragments requires retransmission of the entire original datagram

  • IPv6 disallows fragmentation inside the network, requiring

that fragmentation is done in the source node

  • HTTP protocol allows byte ranges of objects to be

individually retrieved: useful to resume partial file transfers

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 13

technology

from seed

DTN Fragmentation Types

  • Two types of fragmentation
  • Proactive: a node divides a bundle in fragments before

transmission

– used primarily when the contact duration is known (or predicted) in advance, e.g. satellite networks

  • Reactive: nodes in communication fragment a bundle when

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

  • Reactive: nodes in communication fragment a bundle when

a contact is broken

– the received part is a fragment – the undelivered part is another fragment – “toilet paper” variant allows fragmentation only at predefined boundaries

  • Fragments reassembled at the destination only.
  • Any fragment loss results in the entire bundle loss.

27-06-2011 14 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks

slide-8
SLIDE 8

technology

from seed

Fragmentation Operation

  • Different types of fragmentation:

i) no fragm entation ii) proac tive fragm entation

ac k header

Da ta (4 KB )

ac k header

Da ta (4 KB )

ack header

Da ta

header

D a ta (4 KB ) Da ta (4 KB )

ack

Da ta (2KB )

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

  • ACK used to prevent data loss when the contact is broken

– particularly important when routing uses only a single copy of bundles – not necessary for Epidemic routing

iii) reactive fragmentation

ac k header

Da ta (4 KB )

ac k header

Da ta (4 KB )

ack header (2 KB ) ac k header

Da ta (4 KB )

ac k

Da ta (4 KB )

ac k

Da ta (2KB )

27-06-2011 15 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks

technology

from seed

Summary

  • DTN/VDTN Architecture
  • VDTN Fragmentation
  • Experimental evaluation
  • Conclusion

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 27-06-2011 16 16 16 16

slide-9
SLIDE 9

technology

from seed

VDTN laboratory prototype

  • Car made with Lego Mindstorm NXT robot with a PDA
  • Bluetooth 2.0 (3 Mbit/s) used for out-of-band signaling
  • IEEE 802.11b (11 Mbit/s) used for data transmission

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

27-06-2011 17 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks

technology

from seed

Test parameters

  • A single mobile node going back and forth
  • Contact times vary from 9-21 seconds (average 15

seconds, standard deviation 3.5 seconds)

– corresponds to vehicles crossing at a relative speed of approximately 80 Km/h

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

  • Interval between successive contacts varies from 1-27

seconds (average 9 seconds, standard deviation 7 seconds)

  • Each situation tested 20 times. Repeated if necessary.
  • UDP maximum datagram size (in the PDA): 32 KB

– Tested with 4KB, 8KB and 32KB datagrams

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 18

slide-10
SLIDE 10

technology

from seed

Average number of contacts to transfer a message

  • Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa
  • Using 32 KB data chunks
  • With fragmentation: average 1.4 contacts to transfer a

900KB message

  • Without fragmentation: almost impossible to transfer a

900KB message

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 19

  • technology

from seed

Message Delivery Latency 4KB data chunk

  • Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa
  • Almost impossible to transfer a 600KB message without fragmentation
  • Fragmentation is worth being used even for 100 KB messages
  • Proactive fragmentation has a significant overhead

– signaling and headers.

  • Reactive fragmentation performs better, without degradation

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 20

slide-11
SLIDE 11

technology

from seed

Data overhead

Message Size Data Chunk

100 KB 300 KB 600 KB 900 KB 4 KB 117 KB 347 KB 693 KB 1010 KB 8 KB 108 KB 322 KB 642 KB 962 KB 32 KB 103 KB 306 KB 611 KB 915 KB

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 21

  • Fragmentation results in additional headers, as shown in

the table

  • Each fragment has to be individually announced through

signaling and processed

technology

from seed

Message Delivery Latency 8KB data chunk

  • Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa
  • Fragmentation overhead is reduced
  • Proactive fragmentation still performs 25-85% worse than

reactive fragmentation

  • Fragmentation greatly outperforms no fragmentation

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 22

slide-12
SLIDE 12

technology

from seed

Message Delivery Latency 32KB data chunk

  • Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa
  • Proactive fragmentation overhead now has little significance
  • The difference is smaller than the confidence interval
  • Proactive fragmentation has less processing during contacts
  • Difficult to adjust fragment sizes proactively

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 23

  • technology

from seed

Summary

  • DTN/VDTN Architecture
  • VDTN Fragmentation
  • Experimental evaluation
  • Conclusion

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 27-06-2011 24 24 24 24

slide-13
SLIDE 13

technology

from seed

Conclusions

  • DTN is a new networking paradigm that can overcome

challenging situations.

  • Fragmentation allows the transfer of messages larger than

the typically short contacts between vehicles, resulting in an increased delivery ratio and decreased delivery

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 25 25

an increased delivery ratio and decreased delivery latency.

  • Reactive fragmentation adapts the fragments size

dynamically to the duration of the contact, resulting in an efficient use of the contact opportunities.

  • Proactive fragmentation requires an a priori definition of

the fragment size, which is difficult to adjust to contacts.

25

technology

from seed

Future Work

  • Test more complex VDTN scenarios
  • Use contact duration prediction mechanisms to combine

scheduling and fragmentation of bundles to optimize the data transfer phase.

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 26 26 26

slide-14
SLIDE 14

technology

from seed

technology

Thank you! Questions?

Instituto de Engenharia de Sistemas e Computadores Investigação e Desenvolvimento em Lisboa

27-06-2011 NGI'2011: Bundles Fragmentation in Vehicular Delay-Tolerant Networks 27 20-06-2011 Título da apresentação 27

technology

from seed
