SLIDE 1

DISTRICT-WIDE FACILITIES ASSESSMENT + ELCO HIGH SCHOOL UPDATE MEETING

JANUARY 09, 2016

SLIDE 2

KCBA - Architecture | Interior | Structural Design Moore Engineering Company - MEP Engineering Corsi Associates - Foodservice Consulting

Feasibility Study Team ELCO School District

SLIDE 3

Jackson ES (Grades K-2) Fort Zeller ES (Grades K-2) ELCO IS (Grades 3-5) ELCO MS (Grades 6-8) ELCO HS (Grades 9-12)

SLIDE 4

Facilities Assessment

SLIDE 5

Fort Zeller ES (Grades K-2)

SLIDE 6

Fort Zeller ES (Grades K-2)

• Fort Zeller Elementary School (ZES)

was originally built in 1972, with a renovation completed in 2005

• Building 53,500 sq. ft. (1 story

building)

• Fort Zeller Elementary School is 44

years old, due to recent renovations and excellent maintenance the building is in good condition

Building Analysis - History ELCO School District

SLIDE 7

Fort Zeller ES (Grades K-2)

• The building is located on a 25 acre

site in Millcreek Township

• The curb at the front entrance is

deteriorating at the handicap

• entrance. Some heave and drop was

noted in several areas at the front of the building and approach

• The soft play areas are not handicap

accessible

Building Analysis - Site ELCO School District

SLIDE 8

Fort Zeller ES (Grades K-2)

• The building entrance is secure.
• The approach to classrooms are

undersized and do not allow for ADA pull side access.

• The egress width of the corridors

appeared to be obstructed by instructional furniture within the hallways.

Building Analysis – Security + Building Code ELCO School District

SLIDE 9

Fort Zeller ES (Grades K-2)

• Hot water boilers leak water at every

shutdown and startup of the system which is causing premature corrosion.

• Recommend lowering the

thermostats to a more desirable height.

• The exterior chilled water piping

insulation is deteriorating and in need of replacement

Building Analysis - MEP ELCO School District

SLIDE 10

Fort Zeller ES (Grades K-2)

• The building does not contain a

dedicated classroom for Science

• Small Group Instruction (SGI) or

Large Group Instruction (LGI) does not exist within the school. Corridors were used to facilitate the function, possibly diminishing required egress width

Existing Schools - Educational ELCO School District

SLIDE 11

Jackson ES (Grades K-2)

SLIDE 12

Jackson ES (Grades K-2)

• Jackson Elementary School (JES)

was originally built in 1958, with alterations and additions completed in 1997 + 2005

• 38,400 sq. ft. (1 story building)
• Jackson Elementary School is 58

years old, due to recent renovations and excellent maintenance the building is in good condition.

Building Analysis - History ELCO School District

SLIDE 13

Jackson ES (Grades K-2)

• The building is located on an 11 acre

site near downtown Myerstown

• The bus lane is shared with visitor

parking, causing a potential crossing

• f paths for vehicles and pedestrians.

Curb does not allow for handicap access

• It was noted that flooding occurs at

the vehicular entrance to the school

• The soft play areas are not handicap

accessible.

Building Analysis - Site ELCO School District

SLIDE 14

Jackson ES (Grades K-2)

• The building entrance is secure,

although the vestibule is not directly attached to the front office

• Mechanical room was not in

compliance, used as storage

• Items in hallway blocked clear width
• f egress at doors exiting from main

hallway

• Classroom sinks were noted to not

be handicap accessible because of the base cabinets

Building Analysis – Security + Building Code ELCO School District

SLIDE 15

Jackson ES (Grades K-2)

• Hot water boilers leak water at every

shutdown and startup of the system which is causing premature corrosion

• The water heater is showing its age

and has regular maintenance issues. It is nearing the end of its life expectancy

Building Analysis - MEP ELCO School District

SLIDE 16

Jackson ES (Grades K-2)

• The building does not contain a

dedicated classroom for Science

• Small Group Instruction (SGI) or

Large Group Instruction (LGI) does not exist within the school.

Existing Schools - Educational ELCO School District

SLIDE 17

ELCO IS (Grades 3-5)

SLIDE 18

ELCO IS (Grades 3-5)

• ELCO Intermediate School (EIS) was
• riginally built in 2010
• Building 94,800 sq. ft. (2 story

building)

• ELCO Intermediate School is 6 years
• ld and the building is in excellent

condition.

Building Analysis - History ELCO School District

SLIDE 19

ELCO IS (Grades 3-5)

• The sidewalk along the front of the

school appears to be in good

• condition. It was noted that the curb

transition heaves significantly in the winter

Building Analysis - Site ELCO School District

SLIDE 20

ELCO IS (Grades 3-5)

• It was noted that the food serving line

is dimensionally tight and causes crowding during lunch.

• It was also noted that the cafeteria

room is acoustically live (too noisy), creating a chaotic environment during lunches.

• Classroom sinks did not appear to be

handicap accessible

Building Analysis – Security + Building Code ELCO School District

SLIDE 21

ELCO IS (Grades 3-5)

• The systems are in very good

condition including the piping, pumps, and boiler.

• A backdraft damper was not installed

at the stage exhaust system, whenever the unit is not operating

• utside air blows into the space
• Water is pumped to the Middle

School where it is treated and pumped back to the Intermediate School, causing low pressure problems

Building Analysis - MEP ELCO School District

SLIDE 22

ELCO IS (Grades 3-5)

• It was noted that the main stage is

used primarily for band as the current music room is too small to function properly for that activity.

• Spaces for Small Group Instruction

are centrally located to the classrooms and do not have walls. It was noted that the spaces might function better with walls and the possibility of creating two smaller spaces from one large SGI was also discussed.

Existing Schools - Educational ELCO School District

SLIDE 23

ELCO MS (Grades 6-8)

SLIDE 24

ELCO MS (Grades 6-8)

• ELCO Middle School (EMS) was
• riginally built in 1972, with

alterations and additions completed in 2005.

• Building 137,400 sq. ft. (2 story

building)

• ELCO Middle School is 44 years old

and in good condition. Educational issues are structural, relating to absence of natural light and classroom capacity

Building Analysis - History ELCO School District

SLIDE 25

ELCO MS (Grades 6-8)

• The building is located on an 40 site

adjacent to the ELCO Intermediate School on Evergreen Drive.

• The visitor parking is outboard of the

bus lane, causing a potential crossing of paths for vehicles and pedestrians

Building Analysis - Site ELCO School District

SLIDE 26

ELCO MS (Grades 6-8)

• The Entry vestibule is secure but

there is a lack of direct vision to the vestibule + main entry hall from the front desk.

• No area for handicap seating at the

Forum

• ADA accessibility issues at the

elevator

Building Analysis – Security + Building Code ELCO School District

SLIDE 27

ELCO MS (Grades 6-8)

• We recommend that the domestic

water systems undergo a complete upgrade as part of any renovation project

• Water coolers are not ADA compliant
• Majority of the drainage system is

likely to be original from 1972 + at the end of its typical life cycle. If any drainage piping will remain as part of any major renovation it should be water jetted and scoped with a camera to identify problem areas.

Building Analysis - MEP ELCO School District

SLIDE 28

ELCO MS (Grades 6-8)

• Limited Small Group Instruction
• Forum could function as a Large

Group Instruction, but amphitheater seating is not ideal

• About 1/3rd of the classroom spaces

are interior and lack natural light

Existing Schools - Educational ELCO School District

SLIDE 29

ELCO HS (Grades 9-12)

SLIDE 30

ELCO HS (Grades 9-12)

• ELCO High School (EHS) was
• riginally built in 1964, with

alterations and additions completed in 1991.

• Building 169,000 sq. ft. (2 story

building – 25,000 SF 2nd floor)

• ELCO High School is over 52 years
• ld, with the last major renovation
• ccurring 25 years ago. Much of the

infrastructure, both MEP and building envelope, is in need of a full renovation / restoration.

Building Analysis - History ELCO School District

SLIDE 31

ELCO HS (Grades 9-12)

• The visitor parking is located closer

to the DAO entrance than the EHS entrance, causing confusion

• The bus loop is tight and difficult to

navigate, it also does not provide enough room for loading/unloading

• Visitors park in the bus loop,

sometimes remaining until 2PM when the buses arrive.

Building Analysis - Site ELCO School District

SLIDE 32

ELCO HS (Grades 9-12)

• The building does not have a secure
• entrance. The entry foyer is located

across the hall from the front office, allowing visitors immediate access to the school

• There is minimal visibility from the
• ffice due to heavy mullion system

that obstructs the views

• Difficult to monitor exterior of the

building due to lack of transparency

Building Analysis – Security + Building Code ELCO School District

SLIDE 33

ELCO HS (Grades 9-12)

• Chorus room has only one exit for

capacity exceeding 50 occupants

• Most interior doors and hardware are

not ADA accessible

• Classrooms have impediments to

ADA use, of particular note are the science labs

Building Analysis – Security + Building Code ELCO School District

SLIDE 34

ELCO HS (Grades 9-12)

• The exterior of the building is

primarily brick with areas of EIFS

• The brick is in poor to fair condition,

showing signs of surface deterioration and needs restoration

• The EIFS is in poor condition with

several areas of damage noted as well as an overall need to be restored

Building Analysis – Security + Building Code ELCO School District

SLIDE 35

ELCO HS (Grades 9-12)

• The exterior glazing system was

replaced on 1990 and is now over 25 years old.

• The glazing system is in fair to poor

condition and needs to be replaced. Several areas of failed glazing seals were noted

Building Analysis – Security + Building Code ELCO School District

SLIDE 36

ELCO HS (Grades 9-12)

• Interior walls were generally in fair

condition for their age, several areas

• f damage were noted, on in

particular was cracking and heaving near the mechanical room.

• The ceilings throughout are primarily

ACT and they are in fair to poor

• condition. There is noticeable wear

and cupping to the tiles in the hallways and classrooms.

Building Analysis – Security + Building Code ELCO School District

SLIDE 37

ELCO HS (Grades 9-12)

• HVAC, Plumbing + Electrical systems

should be upgraded throughout due to the age + condition of the existing infrastructure

• Ventilating classrooms through unit

ventilators does not typically provide adequate ventilation

Building Analysis - MEP ELCO School District

SLIDE 38

ELCO HS (Grades 9-12)

• Classrooms are right sized + current

capacities of 25 or 18 students per room (depending on SF) are adequate to high

• Current Large Group Instruction (LGI)

space is used as two classrooms due to a lack of available classrooms

• Lacking Small Group Instruction

(SGI) spaces throughout the school

Existing Schools - Educational ELCO School District

SLIDE 39

ELCO HS (Grades 9-12)

• There is a lack of science classrooms

with adequate lab space.

• Chemical storage and disposal

systems are not sufficient

• STEM is not available for all 9th grade

students because of capacity

• Expanding offerings of Science +

Agricultural Science requires additional space

Existing Schools - Educational ELCO School District

SLIDE 40

ELCO HS (Grades 9-12)

• Square footage in the Tech Ed spaces

needs to be increased to enhance student safety

• AG Science space with proper

ventilation and feed storage is needed for livestock

• Greenhouse is small and leaks

significantly

Existing Schools - Educational ELCO School District

SLIDE 41

ELCO HS (Grades 9-12)

• The gymnasium has a large bi-folding

door that is past its useful life and does not operate properly or safely

• Gymnasium capacity of about 800

spectators meets the desired

• capacity. The issue is that proper

clearances from the competition zones are not sufficient, putting both athletes and spectators into potentially dangerous situations

• Current gymnasium is not air

conditioned

Existing Schools – Educational ELCO School District

SLIDE 42

ELCO HS (Grades 9-12)

• The Athletics Director and Assistant

Athletics Director/Trainer should be collocated and adjacent to the weight room.

• Storage is a significant issue within

the athletics area as is limited locker space (lockers cannot be locked to safely store student valuables)

• Security concern – use of space

allows public access to full building do to a lack of coordinated building entries

Existing Schools - Educational ELCO School District

SLIDE 43

ELCO HS (Grades 9-12)

• Seating in the auditorium is

negatively affected by the changing slope of the finished floor, which dips to a low spot and then comes back up for several rows before the stage, creating a large area of obstructed view seating

• There is not ADA access to the stage

directly from the auditorium

• Back of house lacks large/high door

access to the stage

Existing Schools - Educational ELCO School District

SLIDE 44

ELCO HS (Grades 9-12)

• The Band + Chorus rooms are

undersized and may impede proper egress from the existing spaces

• Lack of storage impacts performance
• f the performing arts program

spaces

• Art classrooms are undersized + do

not provide adequate activity clearances or storage.

Existing Schools - Educational ELCO School District

SLIDE 45

ELCO HS (Grades 9-12)

• Kitchen equipment is in need of

replacement

• Kitchen lacks adequate storage
• Serving layout is inefficient
• Capacity of cafeteria is adequate but

does not provide variety in seating to appeal to all students

• Loading dock is in poor shape + does

not function well

Existing Schools - Educational ELCO School District

SLIDE 46

ELCO High School Assessment Summary

• Safety concerns with Entries + lack of visibility/control for Front Office
• Safety concerns with Gymnasium / Ag + Tech. Education / Choral Rooms
• ADA + Building code issues throughout the building
• Mechanical / Electrical / Plumbing infrastructure needs replacement
• Building envelope in need of restoration + repair

ELCO HS Building Assessment - Summary ELCO School District

SLIDE 47

Enrollment Trends

SLIDE 48

Building Analysis – Capacity ELCO School District

Recommended HS Capacity is 85% or 22 Students / Classroom

SLIDE 49

Lebanon County Planning Commission – Population Projections ELCO School District

School District Statistics + Trends

• The ELCO, Northern Lebanon and

Palmyra Area, School Districts are expected to grow dramatically, each growing between 21% and 29% over the two projected decades.

• The fastest growth over a single decade

is expected to occur in Jackson Township between 2000 and 2010, where undeveloped land zoned for residential uses is available. More than 1,550 new residents are projected by 2010 followed by another 1,000 new residents by 2020.

SLIDE 50

Lebanon County Planning Commission – Population Projections ELCO School District

1990 US Census Pop. 2000 US Census Pop. Absolute Change from 1990 Percent Change 2010 Projected Pop. Absolute Change from 2000 Percent Change 2020 Projected Pop. Absolute Change from 2010 Percent Change Lebanon County 113,811 120,327 6,516 5.73% 130,682 10,355 8.61% 140,075 9,393 7.19% Annville-Cleona SD 12,065 11,891

• 174
• 1.44%

12,063 172 1.45% 12,825 762 6.32% Annville Cleona

• N. Annville
• S. Annville

4,294 2,322 2,441 3,008 4,518 2,148 2,279 2,946 224

• 174
• 162
• 62

5.22%

• 7.49%
• 6.64%
• 2.06%

4,638 2,093 2,311 3,021 120

• 55

32 75 2.66%

• 2.56%

1.40% 2.55% 4,723 2,098 2,358 3,646 85 5 47 625 1.83% 0.24% 2.03% 20.69% Cornwall-Lebanon SD 27,648 31,052 3,404 12.31% 34,515 3,463 11.15% 37,165 2,650 7.68% Cornwall Mount Gretna

• N. Cornwall
• N. Lebanon
• S. Lebanon
• W. Cornwall

3,231 303 4,886 9,741 7,491 1,996 3,486 242 6,403 10,629 8,383 1,909 255

• 61

1,517 888 892

• 87

7.89%

• 20.13%

31.05% 9.12% 11.91%

• 4.36%

4,122 234 7,328 11,537 9,355 1,939 636

• 8

925 908 972 30 18.24%

• 3.31%

14.45% 8.54% 11.59% 1.57% 4,619 234 8,023 12,098 10,230 1,961 497 695 561 875 22 12.06% 0.00% 9.48% 4.86% 9.35% 1.13% ELCO SD 16,909 17,770 861 5.09% 20,002 2,232 12.56% 21,813 1,811 9.05% Heidelberg Jackson Millcreek Myerstown Richland 3,797 5,732 2,687 3,236 1,457 3,832 6,338 2,921 3,171 1,508 35 606 234

• 65

51 0.92% 10.57% 8.71%

• 2.01%

3.50% 3,911 7,888 3,553 3,116 1,534 79 1,550 632

• 55

26 2.06% 24.46% 21.64%

• 1.73%

1.72% 4,066 8,974 4,074 3,120 1,579 155 1,086 521 4 45 3.96% 13.77% 14.66% 0.13% 2.93% Lebanon SD 25,672 25,297

• 375
• 1.46%

25,202

• 95
• 0.38%

25,257 55 0.22% Lebanon City

• W. Lebanon

24,800 872 24,461 836

• 339
• 36
• 1.37%
• 4.13%

24,333 869

• 128

33

• 0.52%

3.95% 24,308 949

• 25

80

• 0.10%

9.21% Northern Lebanon SD 14,475 14,992 517 3.57% 16,728 1,736 11.58% 18,152 1,424 8.51% Bethel Cold Spring

• E. Hanover

Jonestown Swatara Union 4,343 80 3,058 931 3,318 2,745 4,526 49 2,858 1,028 3,941 2,590 183

• 31
• 200

97 623

• 155

4.21%

• 38.75%
• 6.54%

10.42% 18.78%

• 5.65%

4,971 47 2,946 1,363 4,556 2,845 445

• 2

88 335 615 255 9.83%

• 4.08%

3.08% 32.59% 15.61% 9.85% 5,399 49 3,057 1,405 5,110 3,132 428 2 111 42 554 287 8.61% 4.26% 3.77% 3.08% 12.16% 10.09% Palmyra Area SD 17,042 19,325 2,283 13.40% 22,172 2,847 14.73% 24,863 2,691 12.14%

• N. Londonderry

Palmyra

• S. Londonderry

5,630 6,910 4,502 6,771 7,096 5,458 1,141 186 956 20.27% 2.69% 21.24% 8,063 7,141 6,968 1,292 45 1,510 19.08% 0.63% 27.67% 9,588 7,186 8,089 1,525 45 1,121 18.91% 0.63% 16.09%

2020 Population Projections ELCO SD + 9.0% to 21,813

SLIDE 51

Building Analysis – Enrollment Data ELCO SD ELCO School District

2017 1995 2300 2350 2400 2450 2500 2000 2010

2414 2423 2419 2428 2439 2457 2452 2458 2510 2474 2485 2410 2436 2425 2392 2396 2305 2340 2323 2298 2304 2292 2299 2280

SLIDE 52

Building Analysis – Enrollment Data ELCO SD ELCO School District

2430 2300 2350 2400 2450 2500 2017 1995 2000 2010 17 Year District Average for Enrollment

SLIDE 53

Building Analysis – Enrollment Data ELCO SD ELCO School District

2430 17 Year District Average 2011-2012 | 738 2016-2017 | 725 2021-2022 | 824 PDE Projections ELCO High School 704 current enrollment

SLIDE 54

Building Analysis – Enrollment Data ELCO SD ELCO School District

918 Current HS PDE capacity 2011-2012 | 738 2016-2017 | 725 2021-2022 | 824 PDE Projections ELCO High School 704 current enrollment

SLIDE 55

Hi High gh Sc School hool Progra rogramming mming

SLIDE 56

Building Analysis – Existing Program Ground Floor ELCO School District

SLIDE 57

Building Analysis – Existing Program Ground Floor ELCO School District

SLIDE 58

Building Analysis – Existing Program Second Floor ELCO School District

SLIDE 59

Building Analysis – Program Development ELCO School District

SLIDE 60

ELCO High School Programming Summary

• Successful programs lack critical space + availability to meet student demand
• Art / Performing Arts / Technical + Agricultural Education / Science / Athletics

need additional space to function properly + safely

• Lack of collaborative spaces (SGI’s + LGI’s – Maker Spaces) | Library should

transition to Creativity Center and become HUB of collaboration

• Front Office / Guidance / Nurse compromised by space + location
• Consolidate DAO staff to one space for operational efficiency + provide secure

storage for critical files

Programming Summary ELCO School District

SLIDE 61

Building Analysis – Opportunities ELCO School District

SLIDE 62

Building Analysis – Programmatic Deficiencies ELCO School District

SLIDE 63

Building Analysis – Spatial Corrections ELCO School District

SLIDE 64

Building Analysis – 21st Century Learning ELCO School District

SLIDE 65

Building Analysis – Arrival + Security ELCO School District

SLIDE 66

Building Analysis – Efficiency + Opportunity ELCO School District

SLIDE 67

Opt Options ions Ne New w or

• r Im

Impr proved

• ved

SLIDE 68

Building Analysis – Probable Cost Build New School ELCO School District

New School Desired Size = 220,000 SF

SLIDE 69

$280/SF

Building Analysis – Probable Cost Build New School ELCO School District

New School Desired Size = 220,000 SF

SLIDE 70

$280/SF

Building Analysis – Probable Cost Build New School ELCO School District

= $61.6M New School Desired Size = 220,000 SF

SLIDE 71

$280/SF

Building Analysis – Probable Cost Build New School ELCO School District

= $61.6M New School Desired Size = 230,000 SF contingencies + soft costs (33%) increase the total project cost to over $81.9M

SLIDE 72

Building Analysis – Opportunity ELCO School District

Cafeteria Sciences + Technology Creativity Center + Front Office

SLIDE 73

Building Analysis – Main Entrance ELCO School District

Creativity Center + Front Office Cafeteria Sciences + Technology

SLIDE 74

Building Analysis – Opportunity ELCO School District

Athletics Performing Arts Gymnasium

SLIDE 75

Building Analysis – Arts + Athletics Entrance ELCO School District

Performing Arts Gymnasium Athletics

SLIDE 76

Building Analysis – Two Additions ELCO School District

Performing Arts Gymnasium Athletics Creativity Center + Front Office Cafeteria Sciences + Technology

SLIDE 77

Building Analysis – Existing Program Ground Floor ELCO School District

Performing Arts Athletics Gymnasium

Diagram 1

SLIDE 78

Building Analysis – Existing Program Ground Floor ELCO School District

Performing Arts Athletics Gymnasium Creativity Center + Front Office Cafeteria

Diagram 2

SLIDE 79

Building Analysis – Existing Program Ground Floor ELCO School District

Performing Arts Athletics Gymnasium Cafeteria Creativity Center + Front Office

Diagram 3

SLIDE 80

Building Analysis – Existing Program Ground Floor ELCO School District

Performing Arts Athletics Gymnasium Cafeteria Creativity Center + Front Office

Diagram 4

SLIDE 81

Building Analysis – Existing Program Ground Floor ELCO School District

Performing Arts Athletics Gymnasium Cafeteria Creativity Center + Front Office

Diagram 4

SLIDE 82

Building + Programming Summary

• Address major safety concerns – Building Entries + Spatial Clearances
• Increase student access to Arts / Performing Arts / STEM / Agriculture
• Creativity Center as the HUB of schoolwide collaboration
• Provide spaces that support the needs of students, administration + teachers
• Integrate 21st Century learning (Robotics, Maker Space, Agriculture Science)
• Create an infrastructure that supports the next 50 years of learning

Pres- Summary ELCO School District

SLIDE 83

Q+A Q+A
