Dillwyn Elementary Repurposing Project

Library and Community Center

Buckingham County, VA

Crabtree, Rohrbaugh & Associates – Architects Monday December 11, 2017

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 2

Agenda

existing conditions concept library floorplans, interior and exterior proposed library construction cost concept community center floorplan proposed community center costs design and construction schedule

1 2 3 4 5 6

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 3

existing conditions

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 4

1

existing conditions Parking Lot 2 RT 15 – JAMES MADISON HWY Parking Lot 1

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 5

1

existing conditions Classrooms Classrooms Cafeteria Administration Parking Lot 2 To RT 15

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 6

library renovation

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 7

2

library renovation – concept floorplan PARKING LOT 2

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 8

2

library renovation – interior walkthrough 1

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 9

2

library renovation – interior walkthrough 1

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 10

2

library renovation – exterior entrance rendering

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 11

2

library renovation – exterior entrance rendering View from Parking Lot 1

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 12

2

library renovation – exterior entrance rendering View from Parking Lot 2

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 13

2

library renovation – exterior entrance rendering View from Parking Lot 2

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 14

3

library renovation – probable construction costs

1 Standing Seam Metal Roof SF 8.80 $ 7,851 69,088.80 $ 2 4" Rigid Roof Insulation SF 4.00 $ 7,851 31,404.00 $ 3 Gabled Roof Trusses and Plywood Sheathing SF 9.90 $ 7,851 77,724.90 $ 4 Dormers and skylights EA 4,508.00 $ 8 36,064.00 $ 5 Demolish a portion of the existing roof and structure SF 7.00 $ 2,000 14,000.00 $ 6 Add columns and beams to support roof structure LF 90.60 $ 290 26,274.00 $ 7 Foundations and shoring EA 2,600.00 $ 10 26,000.00 $ 8 Library Entrance - metal roof canopy SF 150.00 $ 144 21,600.00 $ 9 Selective demolition and asbestos abatement SF Lump 12,000 12,000.00 $ 10 Exterior envelope - replace storefront with EIFS/Storefront SF 26.60 $ 2,304 61,286.40 $ 11 Interior renovation of Library Suite SF 125.00 $ 7,851 981,375.00 $ 12 Outdoor patio / canopy / sidewalk SF 65.05 $ 761 49,503.05 $ 1,406,320.15 $ Construction Contingency 49,221.21 $ 281,264.03 $ 135,181.00 $ 1,871,986.39 $ Architect/Engineer Design Fees, Inspections Total Probable Project Costs Subtotal Library Renovation Contractor General Conditions, Overhead and Profit *costs are shown in the current bidding climate

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 15

community center renovation

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 16

4

community center renovation – concept floorplan

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 17

4

community center renovation – concept floorplan Multi-use flexible rooms

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 18

4

community center renovation – concept floorplan Multi-use space with catering kitchen

Entrance

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 19

5

community center renovation – Route 15 elevation concept rendering

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 20

5

community center renovation – probable construction costs

Standing Seam Metal Roof SF 8.80 $ 29,900 263,120.00 $ 4" Rigid Roof Insulation SF 4.00 $ 29,900 119,600.00 $ Gabled Roof Trusses and Plywood Sheathing SF 9.90 $ 29,900 296,010.00 $ Demolish a portion of the existing roof and structure SF 4.90 $ 2,000 9,802.00 $ Add columns and beams to support roof structure LF 90.60 $ 290 26,274.00 $ Foundations and shoring EA 2,600.00 $ 10 26,000.00 $ Metal Roof Canopy SF 150.00 $ 144 21,600.00 $ Dormers and skylights EA 4,508.00 $ 8 36,064.00 $ 798,470.00 $ Repoint exterior brick SF 7.20 $ 4,500 32,400.00 $ Elevation 1|2 - replace storefront with EIFS/Storefront SF 26.60 $ 7,200 191,520.00 $ Selective demolition and asbestos abatement SF Lump 12,000 12,000.00 $ Interior Renovation / Fit Out - General Community Center Toilet Rooms and Corridors (9,608 sf) $60 - $90/SF 9,608 576,480.00 $ Interior Renovation / Fit Out - Multipurpose room / Kitchen (3,803 sf) $60 - $90/SF 3,803 228,180.00 $ Food Service Equipment 70,000.00 $ 1,909,050.00 $ 381,810.00 $ 152,724.00 $ 2,443,584.00 $ Contractor General Conditions, Overhead and Profit Architect/Engineer Design Fees, Inspections Subtotal Probable Construction Costs Subtotal Probable Construction Costs Subtotal Gabeled Metal Roof

*costs are shown in the current bidding climate

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 21

design and construction schedule

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 22

6

schedule review Design and Construction Schedule after approval from Board of Supervisors Design Schedule | Duration = 7 – 9 months

• Schematic Design –

2-3 months

• Design Development -

2-3 months

• Construction Documents -

3 months

• Public Bidding -

1 month

Construction Schedule | Duration = 9 – 13 months

• Contracts – Schedule development 1 month
• Construction -

8-12 months

Crabtree, Rohrbaugh & Associates – Architects | December 11, 2017 | 23

questions?
