Delaware River Basin Water Resource Management

Mark Klotz, P.E. Director, Division of Water

NYS Department of Environmental Conservation

Water, Water, Everywhere, But Not Enough for Me

Ecological/habitat Water supply Flood mitigation Water quality

NYS Department of Environmental Conservation

Constraints

• Goals, Objectives and Constraints (Feb. 21, 2006)

– No stream flow alterations that result in additional negative impacts to lower basin uses – No stream flow alterations resulting in need to revise NPDES permits – No increase in NYC or NJ diversion rates without flow augmentation storage – No significant increase in drought frequency or storage drawdown – No significant reduction in out of basin diversions

NYS Department of Environmental Conservation

Habitat Protection

NYS Department of Environmental Conservation

Discharge Mitigation

Ashokan Reservoir, Runoff vs. Spill Discharge Storm Event April 1-4, 2005

10 20 30 40 50 60

9:15 11:45 14:30 17:00 19:30 22:00 0:30 3:00 5:30 8:00 10:30 13:00 15:30 18:00 20:30 23:00 1:30 4:00 6:30 9:00 11:30 14:00 16:30 19:00 21:30 0:00 2:30 5:00 7:30 10:00 12:30 15:00

Discharge, cfs X 1000

Inflow into Ashokan Reservoir (cfs) Spill from Ashokan Reservoir (cfs) 4/4/05 4/3/05 4/2/05 Maximum inflow into Ashokan Reservoir 48,438 cfs, 4/3, 3:15 am Maximum discharge from Ashokan Reservoir 29,672 cfs, 4/3, 7:30 am 4/1/05

NYS Department of Environmental Conservation

NYS Goals for Future Releases Program

• Zero Sum Pursuits
• Water Conservation
• Modify the Montague and Trenton flow objectives to better

manage the available water

• Thermal mitigation and dampening of rapid flow changes
• Coordination with DRBC on water availability and use
• Enhancements
• Additional Storage

NYS Department of Environmental Conservation

Questions?
