Delaware Basin Stream Management Program

A partnership between NYCDEP and Delaware County Soil & Water Conservation District

2015 Update

2

Delaware Basin - Topics

 2015 Project Updates Restoration Projects SMIP Projects CSBI Projects  2016 Project Updates Restoration Projects CSBI Projects CREP Projects  Local Flood Analysis (LFA) Updates

Third Brook

Third Brook stream bed instability and hill slope failures

 Third Brook hill slope failures were identified in the Third Brook Watershed Management Plan  ACOE WRDA funded ($510 K) through the Department of Watershed Affairs matched with DEP funds ($170 K) to stabilize slopes contributing sediment and woody debris to Third Brook above the Village of Walton  Goal was to reduce stress on slope toe, halt head cuts and bed degradation upstream, and reduce sediment deposition downstream in the village  Originally projected costs to address all slopes (1-9) exceeded WRDA funding so project was segmented

Third Brook – Sites 8 & 9

Original work took place in 2014 Spring 2015 rains resulted in flanking of EWP structure and stream bank failure Some ACOE funds remained from 2014 construction and were available for emergency repair work on these slopes DCSWCD also requested additional funds from DEP to facilitate the emergency work

Third Brook - Sites 8 & 9 Design

 DCSWCD requested design assistance from Milone & MacBroom through DEP  The project was in part an emergency repair with additional funds provided to install boulder riffle structures and revetment (rip-rap) along the toe of slope Total length: 1,145.5 ft Total Cost: $807,638 (2014 & 2015)

Third Brook – Sites 8 & 9 Construction

Gulf Brook Streambank SMIP

 Located in the Town of Andes  Bank erosion along a town road due to channel incision caused by the 2007 flood  The project was awarded a SMIP grant in 2011, design postponed to 2014 due to Hurricane Irene in 2011 and EWP projects  Project designed by DCSWCD

7

Gulf Brook Streambank SMIP

 Installation of pinned, stacked rock wall on right bank  Installation of grade control structures downstream of wall  Project completed in September 2015 at a cost of $71,102

8

Holiday Brook Restoration SMIP

9

 Located in the Town of Andes  Stream bank instability exacerbated by unstable stream bed

Holiday Brook Restoration SMIP

 Installation of grade control structures (hardened riffles) upstream and downstream of culvert

Installation of rip-rap to stabilize right bank, up stream of culvert Installation of hardened riffles for grade control upstream and downstream of culvert  Project completed in September 2015 at a cost of $39,110

Delhi River Walk – Hoyt Park

 SMIP grant for River Walk Design - $39,750  SMIP grant for completion of River Walk - $60,537  Improve stream riparian buffer  Stabilize stream bank  Remove invasive Japanese Knotweed

11

Delhi Boat Launch – Hoyt Park

 SMIP grant for boat launch $61,200  Improve access for recreational activities: Boating Tubing Kayaking Fishing  Village of Delhi was also awarded funding by: CWC Stormwater Retrofit Program $94,000 DOS Local Waterfront Revitalization Program $107,666 OPRHP Recreational Trails Grant Program $163,862

12

Walton Green Space Project

• f

Walton Walton Greene Space $20,000 to complete final grading

 Located at the site of the former Walton Reporter building  Goal is to allow conveyance of flood waters from Delaware Street back to West Branch Delaware River  Senator Bonacic grant ($100 K) and local contributions from the Town of Walton ($20,678), Village of Walton($33,295), and Delaware County ($17,685) for purchase and removal of Walton Reporter building  Stream Management Program contributed $20,000 for floodplain grading and installation of stormwater infiltration trench

Walton Gravel Study SMIP

 Walton High School Environmental Science students completed cross- sectional surveys and pebble counts at eight stream sites in the Village of Walton from 2013 - 2015  Determine if stream channel is aggrading, degrading, or in equilibrium  Presented results to Walton Flood Commission on November 5, 2015

82 84 86 88 90 92 94 96 98 100 102

Elevation Feet on the Cam Line

BRANDOW'S & BREAKEY'S

11/21/2013 5/21/2013 6/3/2013 10/5/2015

2015 CSBI Projects

• f

Walton Walton Greene Space $20,000 to complete final grading

Project Bank Length (feet) Amount

Hamden: Terry Clove Native Planting 460 $5,690 Andes: Beech Hill Knotweed Control (year 3) 2600 $2,414 Delhi: Little Delaware Trib Post IS Control Native Planting 650 $4,762 New Kingston: Thomson Hollow IS Control 600 $730 New Kingston: Thomson Hollow Native Planting 680 $2,987 Walton: County Route 22 East Brook Native Planting 1420 $15,200 SUNY Delhi Outdoor Education Center Planting 375 $375 Roxbury Elementary School Planting 60 $43 Walton Third Brook Student Planting 720 $357 Walton Knotweed pull – Delaware Avenue 4H 90

• Delhi Hoyt Park Knotweed pull and clean-up

325

2015 CSBI Projects

Little Delaware Tributary Town of Delhi Terry Clove Town of Hamden

Total length: 460 feet Buffer width: 25 feet Acres: 0.32 Potted plants: 300 Herbaceous plugs: 428 Live stakes: 220 Total length: 650 feet Buffer width: 15 feet (both sides) Acres: 0.21 Potted plants: 175 Herbaceous plugs: 448 Live stakes: 300

2015 SMIP Grants Awarded

Recipient Type Project Stream Amount

Village of Delhi River Walk West Branch $60,534 Delaware County DPW Streambank stabilization East Brook $285,522 Village of Walton Streambank stabilization West Branch $398,545 Town of Bovina Culvert replacement Little Delaware trib $268,188 Town of Tompkins Culvert design Carrol Hollow $30,000 Town of Hamden Streambank stabilization East Brook $66,366 Town of Walton Stream bed stabilization Beers Brook $31,645 Town of Middletown Culvert design Platte Kill trib $30,000 Town of Stamford Streambank stabilization Town Brook $31,527 Village of Hobart Streambank stabilization Grant Brook $22,910 Total $1,225,239

Delaware County SWCD also leveraged matching funds from the DEC WQIP for: Miller Avenue Culvert Replacement in Bovina $182,856 South Street Streambank Stabilization in Walton $763,732 2015 SMIP Grant Awards - approved by PAC on September 10, 2015

Total SMIP Grants Awarded

Project Type Number of Projects Streambank Restoration 10 Stormwater 3 Recreation 8 Education 1 Infrastructure 9 Flood Hazard Mitigation 4 Total Number of Projects 35 Total SMIP Funding Awarded $2,809,384.96

More Restoration Project

 Located in the Town of Hamden  Site identified in WBDR Stream Management Plan as lacking adequate riparian buffer  Gradual bar formation and down valley meander migration has resulted in

• ver widened condition

 Project goals:

• establish stable stream

channel that maintains proper sediment transport

• establish riparian buffer

for long term stability of reach

19

Project site

More Restoration Project - Tasks

 Determined hydrology and verified using multiple sources  Identified bankfull indicators in April 2015 event and calibrated hydraulic model of bankfull to indicators  Calculated cross-sectional area  Calculated range for alignment geometry  Determined potential alignments  Obtained landowner agreements  Working on cropland CREP facilitation  Coordinating with the Farm Easement Program  Planned to be constructed in 2016

20

Other Projects

2016 SCMP Project

#

Projects Status

1

More Project in Hamden In Design

2

Little Delaware in Bovina 60% Design - SHPO archeology

3

Hamden Boat Launch Redesign for avoidance on archeology sensitive area

4

Walton Boat Launch Redesign for avoidance on archeology sensitive area

5

Walton Water St Floodplain Concept Design

6

Fleischmanns Site 4 Floodplain Designed (Buy-out on hold) 2016 Ag Projects # Projects Status 1 Steve Boyd in Walton 60% Design 2 Laura Phoenix in Hamden 30% Design 3 Willard Frisbee in Delhi Concept Design 2016 CSBI Projects # Projects Status 1 Oliver Farm in Meredith Designed 2 Depot Street in Fleischmanns Designed 3 Willow Drive in Middletown In Design

LFA Updates

Delaware Basin Local Flood Analysis (LFA) Updates

Walton LFA – Status of Implementation

 LFA completed for West Branch Delaware River in April 2015  Village of Walton has applied to CWC for funding to complete two feasibility studies that are associated with Water Street floodplain restoration:

• 1. CWC has approved funding for feasibility study for relocation of cell tower
• 2. CWC is reviewing funding application to complete feasibility study for

relocation of underground infrastructure  The Walton Flood Commission meets monthly to continue work on implementation of projects and review tributary analyses

Water Street Floodplain Restoration

Walton Tributary Analyses

East Brook Analysis

Status of Other LFAs

 Walton Flood Commission WBDR complete, tributaries underway (East Brook, West Brook, Third Brook)  East Branch Flood Commission Fleischmanns & Clovesville – nearing completion, awaiting draft report Arkville – consultant evaluating alternatives  Delhi Flood Commission Delhi & Fraser – consultant completing hydraulic analysis  Andes Flood Commission – contract executed with consultant  Hamden Flood Commission – entering contract with consultant

Contact Information

Nate Hendricks Project Manager NYCDEP Stream Management Program 71 Smith Avenue Kingston, NY 12401 (845) 340-7876 Graydon Dutcher Stream Program Coordinator DCSWCD 44 West Street, Suite 1 Walton, NY 13856 (607) 865-5223

www.catskillstreams.org/lfa
