Bacterial Source Tracking April 1, 2016 San Antonio River Basin Basin 19 1905 13 Classified Segments, including 1902 1910 1911 Basin # Segment # 1903 1901 2 San Antonio River Basin Segments divided into Assessment Units

slide-1
SLIDE 1

Bacterial Source Tracking

April 1, 2016

slide-2
SLIDE 2

San Antonio River Basin

  • Basin 19
  • 13 Classified Segments,

including…

2

1901 1902 1903 1905 1910 1911

Basin # Segment #

slide-3
SLIDE 3

San Antonio River Basin

  • Segments divided into Assessment Units

(AU’s)

  • Cibolo Creek:

3

– 1902_01 – Lower 5 miles of segment – 1902_02 – From 5 mi. upstream of confluence with the SAR to FM 541 – 1902_03 – FM 541 to confluence w/Clifton Branch – 1902_04 – Confluence w/Clifton Branch to confluence w/ Elm Creek – 1902_05 – Upper end of segment

slide-4
SLIDE 4

Bacterial Impairments

  • Primary Contact Recreation standard on

the 13 classified segments:

– 126 colony forming units (cfu)/100 mL

4

50 colonies in a 10 mL dilution = 500 cfu/100 mL

slide-5
SLIDE 5

Bacterial Impairments

  • Segments

w/Impairments: 1901 – Lower SAR* 1902 – Lower Cibolo* 1903 – Lower Medina 1906 – Lower Leon 1908 – Upper Cibolo 1910 – Salado Creek 1911 – Upper SAR*

5

  • Segments w/o Impairments:

1904 – Medina Lake 1905 – Upper Medina 1907 – Upper Leon 1909 – Medina Diversion Lake 1912 – Medio Creek 1913 – Mid-Cibolo*

*Denotes segments w/BST sample sites

slide-6
SLIDE 6

Bacterial Impairments

  • 83 Assessment Units (Including

Unclassified Segments)

  • 29 (34.9%) w/bacterial impairments
  • Kendall, Bexar, Wilson, Karnes & Goliad

Counties

6

slide-7
SLIDE 7

Why Bacterial Source Tracking (BST)?

  • Working Hypothesis…

– Agricultural impact in urban waterways – Human Impact in rural waterways

  • Shift in thought

7

Lower Cibolo Creek

slide-8
SLIDE 8

Why BST?

8

Lower Cibolo Creek

To try and better understand the sources of bacterial loading contributing to the impairments throughout the San Antonio River basin.

Lower Cibolo Creek

slide-9
SLIDE 9

What is BST?

  • Fundamental idea is that some intestinal

bacteria differs from one animal group to another, due to:

– Basic Habitat

  • Body temp., food supply, digestive system, etc.

– Natural Selection

  • Direct competition, prior exposure to agents like

antibiotics

9

slide-10
SLIDE 10

What is BST?

  • Library “Independent” vs. “Dependent”:

– Both depend on ‘sourcing’ bacteria from known organisms – Both use ‘signatures’ to identify sources of bacterial contamination – Dependent methods require a ‘library’ to be constantly updated

10

slide-11
SLIDE 11

Methods

  • Field Observations

– Weather, recreation, flow level, water color, signs of wildlife

  • Field Parameters:

– Flow, DO, pH, specific conductance, temperature, days since last precipitation event

  • Composite Sample

– Grabs 5-minutes apart

11

slide-12
SLIDE 12

BST Methods

  • Library-dependent analysis,

sources identified by AgriLife using ERIC-PCR and RiboPrinting

  • 10 Isolates/sample
  • Results in 3-Way & 7-Way Splits

– High confidence – Less confidence in species classifications

12

slide-13
SLIDE 13

13

  • Phase 1
  • Phase 2
  • Phase 3
slide-14
SLIDE 14

Phase 1

9 Sept 2013 – 9 March 2016

14

Phase 1 (Rural) - Lower San Antonio River & Tributaries Station ID Site Description Seg/AU County Lat Long

S0036 UNNAMED TRIBUTARY IMMEDIATELY UPSTREAM OF THE CONFLUENCE WITH THE SAN ANTONIO RIVER 750 METERS DOWNSTREAM OF GOLIAD WWTP DISCHARGE 1901_01 Goliad 28.660482

  • 97.392913

S0037 ESCONDIDO CREEK IMMEDIATELY UPSTREAM OF THE CONFLUENCE WITH THE SAN ANTONIO RIVER 1901A_01 Karnes 28.847796

  • 97.749661

17858 SAN ANTONIO RIVER @ US 59 4.6 KM SOUTHWEST OF GOLIAD, TEXAS 1901_01 Goliad 28.651148

  • 97.43291

12797 CIBOLO CREEK @ FM 81 EAST OF PANNA MARIA 1902_01 Karnes 28.972057

  • 97.874924

12879 SAN ANTONIO RIVER @ FM 791 SW OF FALLS CITY, TEXAS 1911_01 Karnes 28.951504

  • 98.064363
slide-15
SLIDE 15

Phase 1 Results

15

Station Ambient Samples

  • E. coli

Geomean (cfu/100 mL)

  • Avg. Flow

(cfs) High-Flow Samples

  • E. coli

Geomean (cfu/100 mL)

  • Avg. Flow

(cfs) Goliad Trib. 4 320.6 0.2 2* 5099.0 0.2 SAR @ US 59 4 94.4 280.0 2 2683.3 930.5 Escondido Creek 4 452.6 1.3 2 7071.1 18.2 Cibolo @ FM 81 4 137.7 29.2 2 1805.5 548.0 SAR @ FM 791 4 102.6 195.5 2 1578.0 1256.0 *Sample collected March 9, 2016; results yet to be received

slide-16
SLIDE 16

Phase 1: 3-Way Split

16

53.1% 29.7% 7.1% 10.1%

Overall 3-Way Split

Wildlife (n=157) Livestock & Domesticated Animals (n=88) Human (n=21) Unidentified (n=30)

Source classification of E. coli isolates (combined n=296) from 29 combined samples

slide-17
SLIDE 17

Phase 1: 7-Way Split

17

36.8% 16.2% 9.5% 6.1% 9.8% 7.1% 5.1% 9.5%

Overall 7-Way Split

Non-Avian Wildlife (n=109) Avian Wildlife (n=48) Cattle (n=28) Other Livestock, Avian (n=18) Other Livestock, Non-Avian (n=29) Human (n=21) Pets (n=15) Unidentified (n=28)

Source classification of E. coli isolates (combined n=296) from 29 combined samples

slide-18
SLIDE 18

Phase 1: Species Summary

18

42 27 25 23 20 17 17 16 15 15 15

5 10 15 20 25 30 35 40 45

10 Most Common Isolate Origins

Source classification of E. coli isolates (combined n=296) from 29 combined samples

slide-19
SLIDE 19

19

Phase 2

15 Dec 2014 – 26 Oct 2015

Phase 2 (Rural) - Lower Cibolo Creek & Tributaries Station ID Site Description

Seg/AU County Lat Long 14211 CIBOLO CREEK @ CR 389 NEAR CESTOHOWA, TEXAS 1902_02 Karnes 29.01700 -97.91900 S0060 CLIFTON BRANCH IMMEDIATELY UPSTREAM OF ITS CONFLUENCE WITH CIBOLO CREEK 1902C_01 Wilson 29.20291 -97.99999 S0061 UNNAMED TRIBUTARY OF CIBOLO CREEK 30 METERS UPSTREAM OF CR 401 1902 Wilson 29.21996 -98.00966 12805 CIBOLO CREEK @ FM 539 1902_03 Wilson 29.27977 -98.05329 12741 MARTINEZ CREEK ON NORTH GABLE ROAD SOUTH OF ZUEHL 1902A_01 Bexar 29.44415 -98.16889 12919 CIBOLO CREEK 40 METERS DOWNSTREAM FROM IH 10/US 90 ON EAST BANK 1913_01 Bexar 29.50055 -98.18639

slide-20
SLIDE 20

20

Station Ambient Samples

  • E. coli

Geomean (cfu/100 mL) Avg. Flow (cfs) High-Flow Samples

  • E. coli

Geomean (cfu/100 mL) Avg. Flow (cfs) Cibolo @ CR 389 3 126.0 54.3 2 9695.4 1020.0 Clifton Branch Confluence 3 470.9 0.17 2 1553.1 0.9 Unnamed Cibolo Tributary 3 551.8 0.2 2 3435.1 0.2 Cibolo @ FM 539 3 249.2 36.3 2 3566.5 423.0 Martinez Creek @ N Gable 3 308.7 12.3 2 3203.1 101.0 Cibolo Down IH-10 3 73.1 21.3 2 358.9 37.0

Phase 2

slide-21
SLIDE 21

Cibolo Creek @ CR 389

21

July 30, 2015 - 60 cfsApril 13, 2015 – 1020 cfs

slide-22
SLIDE 22

Phase 2: 3-Way Split

22

52.7% 26.4% 3.9% 17.0%

Overall 3-Way Split

Wildlife (n=164) Livestock & Domesticated Animals (n=82) Human (n=12) Unidentified (n=53)

Source classification of E. coli isolates (combined n=311) from 30 samples

slide-23
SLIDE 23

Phase 2: 7-Way Split

23

39.9% 12.9% 6.1% 5.8% 7.4% 3.9% 7.1% 17.0%

Overall 7-Way Split

Non-Avian Wildlife (n=124) Avian Wildlife (n=40) Cattle (n=19) Other Livestock, Avian (n=18) Other Livestock, Non-Avian (n=23) Human (n=12) Pets (n=22)

Source classification of E. coli isolates (combined n=311) from 30 samples

slide-24
SLIDE 24

Phase 2: Species Summary

24

31 30 30 24 20 19 17 16 13 13

5 10 15 20 25 30 35

Feral Hog Cattle Opossum Human Coyote Chicken Goat Duck Fox Dog

10 Most Common Isolate Origins

Source classification of E. coli isolates (combined n=311) from 30 samples

slide-25
SLIDE 25

25

Basin Wide: 3-Way Summary

53% 28% 5% 14%

Overall 3-Way Split

Wildlife (n=321) Livestock & Domesticated Animals (n=170) Human (n=33) Unidentified (n=83)

Source classification of E. coli isolates (combined n=607) from 59 samples

slide-26
SLIDE 26

Basin Wide: 7-Way Summary

26

38.4% 14.5% 7.7% 5.9% 8.7% 5.4% 6.1% 13.3%

Overall 7-Way Split

Non-Avian Wildlife (n=233) Avian Wildlife (n=88) Cattle (n=47) Other Livestock, Avian (n=36) Other Livestock, Non-Avian (n=52) Human (n=33) Pets (n=37) Unidentified (n=81)

Source classification of E. coli isolates (combined n=607) from 59 samples

slide-27
SLIDE 27

Basin Wide: Species Summary

27

72 57 56 42 39 37 32 31 29 28

10 20 30 40 50 60 70 80

10 Most Common Isolate Origins

Source classification of E. coli isolates (combined n=607) from 59 samples

slide-28
SLIDE 28

28

Phase 3

29 Feb 2016 – 9 March 2016

Phase 3 (Urban) - Upper San Antonio River & Tributaries Station ID Site Description

Seg/AU County Lat Long 12909 SAN ANTONIO RIVER AT MULBERRY STREET 1911_09 Bexar 29.45618

  • 98.47589

12906 SAN ANTONIO RIVER AT PECAN STREET 1911_09 Bexar 29.42864

  • 98.49173

12904 SAN ANTONIO RIVER AT ALAMO STREET 1911_09 Bexar 29.41034

  • 98.49525

12707 SAN PEDRO CREEK AT FURNISH STREET 1911D_01 Bexar 29.40626

  • 98.51049

12897 SAN ANTONIO RIVER AT IH 410 LOW WATER CROSSING CAMINO COAHUILATECHAN 0.25 KM BELOW THE BRIDGE IN SAN ANTONIO 1911_07 Bexar 29.31953

  • 98.44889
slide-29
SLIDE 29

29

Station Ambient Samples

  • E. coli

(cfu/100 mL) Flow (cfs) High-Flow Samples

  • E. coli

(cfu/100 mL) Flow (cfs) SAR @ Mulberry 1 650 8.7 1 >20000 231 SAR @ Pecan 1 180 8.8 1 12000 <0.01 SAR @ Alamo 1 280 27 1 14000 25 San Pedro Creek @ Furnish 1 140 2.3 1 >20000 135 SAR @ Loop 410 1 240 21 1 >20000 704

Phase 3

slide-30
SLIDE 30

Future of Effort

  • Three additional

Phase 3 samples

  • Pending results will

determine high-flow

  • r ambient collection

30

SAR @ Mulberry

slide-31
SLIDE 31

31

Questions???
