Deep Water Marine Surveys Deep Sea International Consortium Workshop Rio de Janeiro, February 01st & 2nd Fred Marins Marketing Director fred.marins@gardline.com.br www.gardline.com Key Aspects Gardline: Since 1969 + 1500 employees

SLIDE 1

www.gardline.com

Deep Water Marine Surveys

Deep Sea International Consortium Workshop

Rio de Janeiro, February 01st & 2nd Fred Marins Marketing Director fred.marins@gardline.com.br

SLIDE 2

www.gardline.com www.gardline.com

Key Aspects

 Gardline: Since 1969  + 1500 employees  14 Multi Purpose vessels  Leading contractor for Oil & Gas, Ports & Harbours, Telecomunication, Ocean Mining, Renewables and Governement Projects  Gardline Brasil  Founded 2013  +65 employees in Brazil  1 x Deep Water Survey Vessel  1 x Shallow Water Survey Vessel  +20 surveys per year

SLIDE 3

www.gardline.com www.gardline.com

Gardline Group

SLIDE 4

www.gardline.com www.gardline.com

Specialists in Marine Sciences

 Marine Geology & Geophysics  Environmental Surveys – Seabed sampling, Water Column sampling; Habitat Assessments; Plankton Surveys  MetOcean Surveys  Geochemical Surveys – Piston Corer / Heat Flow  High & Ultra High Resolution Seismic Surveys  Geotechnical Investigations (CPT, Piston Corer, Vibrocorer, boreholes)  Emergency Response Surveys  Surface & SubSea Positioning Services (Rig Move, Metrology, Construction Support)  Marine Wildlife Surveys – MMOs & PAMS

SLIDE 5

www.gardline.com

Where we are?

SLIDE 6

www.gardline.com

Deep Water Fleet

SLIDE 7

www.gardline.com

National Fleet – MV Ocean Stalwart

SLIDE 8

www.gardline.com

National Fleet– MV Carmen

Ocean EYE CTD Rosette Env.Lab

ADCP

POS-MV Survey.Lab Sub Bottom Profiler MBES

SLIDE 9

www.gardline.com

South America Largest Equipment Pool

SLIDE 10

www.gardline.com

Selection of Still & Video Cameras

50m 400m

SLIDE 11

www.gardline.com

ROV Services

SAAB Seaeye Cougar XT Dimensions  Depth Rating: 2000m  Lenght: 1515mm  Height: 790mm  Width: 1000mm  Payload: 80kg Survey Tools:  Octans 3000 Fibre Optic Gyro  Teledyne TSS440 Pipetracker  Blue View Forward Scanning Sonar Dual câmera booms for pipeline inspection  Multibeam Echo Sounder with DVL  High Resolution Camera Systems

SLIDE 12

www.gardline.com

ROV Services

Triton MRV Dimensions  Depth Rating: 1000m  Lenght: 3500mm  Height: 1700mm  Width: 2100mm  Payload: 200kg  HPU Size: 100 HP Survey Tools:  Octans 3000 Fibre Optic Gyro  Teledyne TSS440 Pipetracker  Blue View Forward Scanning Sonar Dual câmera booms for pipeline inspection  Multibeam Echo Sounder with DVL  High Resolution Camera Systems

SLIDE 13

www.gardline.com

ROV Services

Triton MRV4 Dimensions  Depth Rating: 3000m  Lenght: 3200mm  Height: 1900mm  Width: 2000mm  Payload: 250kg  HPU Size: 150 HP Survey Tools:  Octans 3000 Fibre Optic Gyro  Teledyne TSS440 Pipetracker  Blue View Forward Scanning Sonar Dual câmera booms for pipeline inspection  Multibeam Echo Sounder with DVL  High Resolution Camera Systems

SLIDE 14

www.gardline.com

Integrated Marine Surveys

SLIDE 15

www.gardline.com

Gardline experience

 Geophysical, Geotechnical and Environmental data represents major areas of interest for Oil & Gas companies  Seabed Morfology, Soil Resistance and Habitat Assessments are key elements for subsea engineering and biodiversity studies and can be easily combined onto a single survey cruise  Multidisciplinary personnel + Multi Purpose vessels = cost effective soltuion

SLIDE 16

www.gardline.com

Key Projects in Brazil 2013-2016

SLIDE 17

www.gardline.com

Key Projects in Brazil – LEPLAC

LEPLAC Project – UNCLOS SURVEY  Period: March /2009 – June /2010  Water depths: 20-4500m  Client: Brazilian Navy  50.000 km – MBES, SBP  8.000 km – Multichannel Seismic

SLIDE 18

www.gardline.com

Key Projects in Brazil – Pipeline Route Surveys

Vessel: MV Carmen Scope: MBES, SSS, SBP, Piston Coring Duration: 24 months Water depths: 15m-200m

SLIDE 19

www.gardline.com

Location: NE Brazil Depth: 10 to 100 meters Corridor width: 1000 meters Equipment: Reason Seabat 7125 MBES, Van Veen Grab Sampler

Key Projects in Brazil – Pipeline Route Surveys

SLIDE 20

www.gardline.com

Side Scan Sonar Image Grided Surface (MBES)

Pipe Pipe Pipe Pipe Free spam

Location: SE Brazil Depth: 10 to 90 meters Corridor width: 300 meters Equipment: Reason Seabat 7125 (MBES), Edghtech 4200 (SSS) and Kongsberg Geopulse (SBP)

Key Projects in Brazil – Pipeline Route Surveys

SLIDE 21

www.gardline.com

Location: NE Brazil Depth: 10 to 100 meters Corridor width: 1000 meters Equipment: Reason Seabat T-20 (MBES), Edghtech 4200 (SSS) and Kongsberg Geopulse Plus (SBP)

Carbonatic Formation Paleochannel

Side Scan Sonar Data Grided Bathynetry data

Key Projects in Brazil – Pipeline Route Surveys

SLIDE 22

www.gardline.com

Key Projects in Brazil – Santos Basin Environmental Baseline Survey

Santos Basin EBS – 2014 Vessel: Kommandor ADCP casts, +350 seabed samples/ +150 water samples Duration: 45 days Water depths: 100-3000m

SLIDE 23

www.gardline.com

Key Projects in Brazil – Barreirinhas Environmental Baseline Survey

Location: Barreirinhas Vessel: Ocean Stalwart +60 seabed samples/ +50 water samples / Habitats Assessment Duration: 45 days Water Depths: 25m-2500m

SLIDE 24

www.gardline.com

Key Projects in Brazil – Barreirinhas Environmental Baseline Survey

SLIDE 25

www.gardline.com

Key Projects in Brazil – Environmental Baseline Survey

Vessel: MV Ocean Stalwart Scope: +2500 seabed samples ; +3500 water samples ; +300 coring samples ; Habitats Assessment ; Piston Coring, Vibrocoring

SLIDE 26

www.gardline.com

Key Projects in Brazil – Marine Wildlife PAMS

Passive Acoustic Monitoring Survey– 2014 Vessel: MV Oceanic Champion Scope: 3 x PAMS Operators (24 coverage) Duration: 240 days

SLIDE 27

www.gardline.com

Key Projects in Brazil – Marine Geotechnics

Geotechnical Investigations

Location: Rota-2 & Rota-3
Duration: 60 days
Approx 150 CPTs
Approx 80 VC (3m)
WD- 15m-2500m

SLIDE 28

www.gardline.com

Key Projects in Brazil – Barreirinhas MetOcean

Vessel: MV Clarisse Scope: 3 x Mooring Lines + 1 x Met Buoy + 1x Wave Buoy Water depths: 25m-1900m

SLIDE 29

www.gardline.com

Key Projects in Brazil – ES MetOcean Surveys

Vessel: MV Carmen Scope: 2 x Sub-Surface Mooring Lines Water depths: 1900m – 2600m

SLIDE 30

www.gardline.com

Watchdog Buoy

Key Projects in Brazil – Frade MetOcean System

Location: Bacia de Campos Mooring Design: 1500m real time system: ADCPs , CTDs, SCM, Met & Wave

SLIDE 31

www.gardline.com

Key Projects in Brazil – LIBRA MetOcean

Vessel: MV Carmen Scope: 1 x Deep water buoy real time data trasmition 1 x deep water mooring line Water depths: 2200m

SLIDE 32

www.gardline.com

Key Projects in Brazil – Cable Route Surveys

Scope: Geophysical Cabel Route Survey Routes: SEABRAS-1, BRUSA, SACS Water depths: 0m – 4500m

SLIDE 33

www.gardline.com

Decomissioning Surveys

Experience with most important guidelines:  DECC – Departament for Energy & Climate Change (2013)  OSPAR – Convention for the Protection of the Marine Environment of the North-East Atlantic
