De Novo Adaption of Streptococcus thermophilius CRISPR in Escherichia coli Mitesh Agrawal, Calvin Goveia, Kettner Griswold Hannah Keith, Priya Kurani, Paul Sebexen GEORGIA INSTITUTE OF TECHNOLOGY INTRODUCTION Abstract GEORGIA INSTITUTE OF

slide-1
SLIDE 1

De Novo Adaption of Streptococcus thermophilius CRISPR in Escherichia coli

GEORGIA INSTITUTE OF TECHNOLOGY

Mitesh Agrawal, Calvin Goveia, Kettner Griswold Hannah Keith, Priya Kurani, Paul Sebexen

slide-2
SLIDE 2

INTRODUCTION

slide-3
SLIDE 3

Abstract

The ultimate goal of our project was to utilize the CRISPR system as a mobile gene targeting system capable of eliminating antibiotic resistance. The protoype construct, pSTINGER, was designed for quantitative modeling, proof of concept, and vaccination

  • n a single plasmid. As a result of experimental error,

intellectual property agreements, and material availability, our biobrick constructs remain experimentally theoretical, though we have rigorously modeled our system in various scenarios.

GEORGIA INSTITUTE OF TECHNOLOGY
slide-4
SLIDE 4

Objectives

  • Utilize the CRISPR system as a mobile

gene targeting system capable of eliminating antibiotic resistance

  • Rigorously model our system to prove its

functionality as a vaccination on a single plasmid

  • Further human health by providing a tool

in the fight against resistant strains

GEORGIA INSTITUTE OF TECHNOLOGY
slide-5
SLIDE 5

CRISPR

GEORGIA INSTITUTE OF TECHNOLOGY
slide-6
SLIDE 6

Components of the Locus

GEORGIA INSTITUTE OF TECHNOLOGY
  • Cas genes
  • Leader sequence
  • Repeats
  • Spacers
  • Terminator sequence
slide-7
SLIDE 7

Repeat

GEORGIA INSTITUTE OF TECHNOLOGY
slide-8
SLIDE 8

CRISPR

GEORGIA INSTITUTE OF TECHNOLOGY
slide-9
SLIDE 9

Streptococcus thermophilus

  • Possesses a well-documented CRISPR system
  • Lactic acid bacteria used in industrial fermentation to

produce yogurt

GEORGIA INSTITUTE OF TECHNOLOGY
slide-10
SLIDE 10

Superbugs

  • Antibiotic susceptible

bacteria can gain immunity to antibiotics through horizontal gene transfer

  • Immunity is granted

through expression of an enzyme present on a plasmid

  • CRISPR can target this

plasmid and eliminate the resistance

  • Examples: MRSA, NDM-1

http://en.wikipedia.org/wiki/Super_bug_(bacteria)

GEORGIA INSTITUTE OF TECHNOLOGY
slide-11
SLIDE 11

EXPERIMENTS

slide-12
SLIDE 12

Mobile CRISPR system from S. thermophilus DGCC 7710 Strain

Mobilize CRISPR system

  • n a plasmid

Biobrick Constructs Chromosomal Integration

  • f CRISPR1 locus from S.

thermophilus to B. subtilis Experiments and Future Applications

GEORGIA INSTITUTE OF TECHNOLOGY
slide-13
SLIDE 13

Mobile CRISPR system from S. thermophilus DGCC 7710 Strain

  • S. thermophilus

DGCC 7710 strain

  • E. coli

CRISPR locus amplified from DGCC strain with kan spacer Shuttle vector with kanamycin resistance pNT1 vector with CRISPR locus No growth on kanamycin plates Expected outcome

GEORGIA INSTITUTE OF TECHNOLOGY
slide-14
SLIDE 14

CRISPR from S. thermophilus LMD9 Strain and Biobricks

  • CRISPR sequence is analogous to the DGCC strain
  • Amplify only Spacer/Repeat Region and ligate it into the

pSB1C3 vector

GEORGIA INSTITUTE OF TECHNOLOGY

Bba_K582000

slide-15
SLIDE 15

CRISPR from S. thermophilus DGCC LMD9 Strain and Biobricks

  • cas9 itself is sufficient for the expression of

CRISPR

GEORGIA INSTITUTE OF TECHNOLOGY

Bba_K582003

slide-16
SLIDE 16

Chromosomal Integration of CRISPR in Bacillus Subtilis

  • B. subtilis is a model organism
  • Similar promoters present as in S. thermophilus
  • Integration vector ece113/pDG1662 used
  • S. thermophilus

DGCC 7710 strain CRISPR locus amplified from DGCC strain with kan spacer ece113 vector with CRISPR locus Bacillus Subtilis with CRISPR locus integrated in its chromosome Expected Outcome

GEORGIA INSTITUTE OF TECHNOLOGY
slide-17
SLIDE 17

Results/Explanation

GEORGIA INSTITUTE OF TECHNOLOGY
slide-18
SLIDE 18

FUTURE

slide-19
SLIDE 19 GEORGIA INSTITUTE OF TECHNOLOGY

The Ideal Vaccine

  • Mechanism for rendering antibiotic

susceptibility

  • Method for introduction into population.
  • Mechanism for transfer across a population
slide-20
SLIDE 20

A Conjugating Vaccine

GEORGIA INSTITUTE OF TECHNOLOGY

Introduction to Population

Transformation Conjugation

slide-21
SLIDE 21

Rendering Antibiotic Susceptibility

GEORGIA INSTITUTE OF TECHNOLOGY
slide-22
SLIDE 22

Mechanisms for delivery of pSTINGER

GEORGIA INSTITUTE OF TECHNOLOGY

Nonlysogenic Phage Delivery of Cosmid DNA

  • In vitro packaged lambda

phage

  • Common phage therapy

leads to resistant plasmids in solution.

  • Added cos sites for

packaging

  • Immune response to

phages has been experimentally low

  • Extremely host specific
  • Transforms E. Coli

Obligative Predatory Cells Bearing Cosmid DNA

  • Bdellovibrio

Bacteriovorus

  • Probiotic delivery in

chickens successful

  • Broad spectrum gram-

negative prey

slide-23
SLIDE 23

Mechansms for delivery of pSTINGER

GEORGIA INSTITUTE OF TECHNOLOGY

Lambda Phage Mechanisms

  • B. bacteriovorus

Mechanisms

slide-24
SLIDE 24

Methods for Transfer Across a Population

GEORGIA INSTITUTE OF TECHNOLOGY

Origins of Replication

  • pIP501 derived

transgenic Ori

  • pMB1 (puc18

derivative) Origins of Transfer

  • F-plasmid origin
  • IncP type
  • IncQ type
  • Pheremone

type

  • Conjugative

transposon Tn4555

slide-25
SLIDE 25

Rendering Antibiotic Susceptibility

GEORGIA INSTITUTE OF TECHNOLOGY
slide-26
SLIDE 26

MODELING

slide-27
SLIDE 27

Population Model of E.coli

Consider 3 Sub-Populations

GEORGIA INSTITUTE OF TECHNOLOGY
slide-28
SLIDE 28

Logistic Growth

  • Consider 3 Sub-Populations

Basic form: Specific Growth:

Image Credit: Public Domain

GEORGIA INSTITUTE OF TECHNOLOGY
slide-29
SLIDE 29

Interaction Model

  • Fundamental System of form Y’=AY
  • Parameters expand into operators of form
GEORGIA INSTITUTE OF TECHNOLOGY
slide-30
SLIDE 30

Model in Matrix Notation

GEORGIA INSTITUTE OF TECHNOLOGY
slide-31
SLIDE 31

Rewrite as a System of Equations

GEORGIA INSTITUTE OF TECHNOLOGY
slide-32
SLIDE 32

Numerical Solutions

MATLAB ode15s Solver

GEORGIA INSTITUTE OF TECHNOLOGY
slide-33
SLIDE 33

Software Tool

GEORGIA INSTITUTE OF TECHNOLOGY
  • Standalone

Application

  • Source and

binaries maintained on Google Code SVN Repository

slide-34
SLIDE 34

Rendering Antibiotic Susceptibility

GEORGIA INSTITUTE OF TECHNOLOGY
slide-35
SLIDE 35

References

  • Uri Alon. An Introduction to Systems Biology: Design Principles of Biological Circuits. Chapman & Hall /

CRC, 2007.

  • Z. Baharoglu, D. Bikard, and D. Mazel. Conjugative dna transfer induces the bacterial sos response and

promotes antibiotic resistance development through integron activation. PLoS Genetics, 2010.

  • Don B. Clewell. Nature of Col E1 plasmid replication in Escherichia coli in the presence of
  • chloramphenicol. Journal of Bacteriology, 1972.
  • H. Fujikawa, A. Kai, and S. Morozumi. A new logistic model for escherichia coli growth at constant and

dynamic temperatures. Food Microbiology, 2004.

  • Dianne Godwin and J. Howard Slater. The influence of the growth environment on the stability of a drug

resistance plasmid in Escherichia coli K12. Journal of General Microbiology, 1979.

  • Richard E. Lenski, Michael R. Rose, Suzanne C. Simpson, and Scott C. Tadler. Long-term experimental

evolution in eschericia coli. i. adaptation and divergence during 2,000 generations. American Naturalist, 1991.

  • Kirsten Skarstad, Harold B. Steen, and Erik Boye. Cell cycle parameters of slowly growing Escherichia coli

B/r studied by flow cytometry. Journal of Bacteriology, 1983.

  • P. Horvath, R. Barrangou. CRISPR/Cas, the immune system of bacteria and archaea. Science, 2010.
  • Blake Wiedenheft, G. C. L., Kaihong Zhou, Matthijs M. Jore, Stan J. J. Brouns, John van der Oost, Jennifer A.

Doudna & Eva Nogales (September 22, 2011). "Structures of the RNA-guided surveillance complex from a bacterial immune system." Nature 477: 4.

  • Banfield, A. F. A. a. J. F. (May 23, 2008). "Virus Population Dynamics and Acquired Virus Resistance in

Natural Microbial Communities." Science 320(5879): 4.
