DATUM SYSTEMS M7 Modular Series Introduction June 2015 Company - - PowerPoint PPT Presentation

DATUM SYSTEMS

Saving Bandwidth made Easy and Affordable…

M7 Modular Series Introduction

June 2015

• Manufacturer of Low Cost Bandwidth Efficient Satellite Modems
• Highly Respected Company in San Jose, California USA
• Solely Focused on Quality Satellite Modems for Over 20 Years
• Innovative and Modular Modem Platforms for SCPC/MCPC
• Specializing in SCPC Point-to-Point, Point-to-Multipoint, Mesh & SCADA
• Released 4th Next Generation Modem “M7 Modular Series”
• New Card Based Modular Modem Design that’s Future Proof
• Leaders of Smart Features and Affordability
• 25,000+ Modems Sold Worldwide

June 2015 Rev 0.3 - Datum Systems Proprietary 2

Company Highlights

June 2015 Rev 0.3 - Datum Systems Proprietary 3

• Compact 1/2 Rack Wide
• Space Saver (50% Savings)
• IF or L-Band
• Modem or Dual-Demod

M7 / M7L / M7D / M7LD

• Full Featured
• 1:1 Redundancy in 1RU
• 2 Units in a Single Rack
• Modem or Dual-Demods
• 4 Independent Demods in 1 RU

M7 Side x Side M7LT Remote Sat-Terminal

• L-Band
• High Stability
• BUC & LNB Power

M7 Modem Card Sets

• Stand-alone
• IF or L-Band
• DC Power
• Advanced Web Interface
• Modem, Mod or Demod
• Dual-Demod Configurable

New M7 Modular Base Modem Series

with “Smart” Technology

The most modular, flexible and future proof modem imaginable…

June 2015 Rev 0.3 - Datum Systems Proprietary 4

• Earth Station Benefits
• Saves Rack Space
• Power Efficient Design
• Smaller Shipping Containers
• Lower Shipping Costs
• Mounting Options
• M7/M7L/M7D/M7LD

M7 / M7L / M7D / M7LD Desktop

Compact and Efficient Design

June 2015 Rev 0.3 - Datum Systems Proprietary 5

M7 Series Rear Panel Options

• M7, M7L

M7D, M7LD

• M7, M7D

IF Version (BNC)

• M7L/M7LD

LB Version (SMA)

June 2015 Rev 0.3 - Datum Systems Proprietary 6

• Future Proof
• Flexible Slots
• Fast Card Level Repairs
• Low Cost Spares
• Easy Hardware Replacement
• Easy Key SW Upgrades
• Data Rate Increases
• Modulation Types
• FEC Types

M7 Superior Modularity

June 2015 Rev 0.3 - Datum Systems Proprietary 7

• Professional SCPC Remote Terminal
• Most Flexible Featured Modem
• Low Cost
• Highly Reliable and Rugged
• Supports Independent Outbound/Inbound Data Rates

M7LT Remote Terminal

June 2015 Rev 0.3 - Datum Systems Proprietary 8

• Rear Panel RF Connections
• TX Out N(50Ω) or F(75Ω) Type
• RX In N(50Ω) or F(75Ω) Type
• BUC and LNB Indicators
• Common M7 Assemblies

 Interfaces, Controller, Front Panel, Backplane

• Features
• Integrated BUC/LNB Power
• High Stability 10 MHz Reference
• Common M7 Interfaces
• Light Weight – only 11” Deep

Same M7 Rear Configuration

M7LT Features and Flexibility

June 2015 Rev 0.3 - Datum Systems Proprietary 9 BUC Power Supply Input Voltage BUC Power Supply Output Voltage BUC power Supply Power Rating BUC power Supply Max Current 90-264 VAC 24 VDC 100 Watt 4.2 Amps 90-264 VAC 24 VDC 120 Watt 5.0 Amps 90-264 VAC 48 VDC 100 Watt 2.1 Amps 90-264 VAC 48 VDC 150 Watt 3.2 Amps 90-264 VAC 48 VDC 240 Watt 5.0 Amps 20-60 VDC 24 VDC 100 Watt 4.2 Amps 20-60 VDC 24 VDC 120 Watt 5.0 Amps 20-60 VDC 48 VDC 100 Watt 2.1 Amps 20-60 VDC 48 VDC 150 Watt 3.2 Amps 20-60 VDC 48 VDC 200 Watt 4.2 Amps

• Features
• AC and DC Input Optional
• 5 BUC Power Supply Options
• LNB Power 13 and 18 VDC

BUC P.S. Location

Available Input & BUC Power Options

M7LT Input and BUC PS Options

June 2015 Rev 0.3 - Datum Systems Proprietary 10

• IF 50 – 180 MHz or L-Band 950 to 2150 MHz (M7LT L-Band Only)
• TX/ RX Carrier Filter Roll-Off Values: 5, 8,10,15,20,25,30,35,40%
• AUPC Point-to-Point , Point-to-Multipoint or Mesh Modes
• Compact Space Saver, Light Weight and Lowest Power
• Highly Configurable Modem Platform with many Software Upgrade Features
• Full Modem, Mod-Only or Dual Demod Configurations
• Viterbi, Reed Solomon (Optional FlexLDPC SW Upgradeable, TPC HW Option)
• Best Spectral Efficiency of ANY SCPC Modem
• Lowest Latency in Industry, <15 ms at 64 kbps ¾ QPSK
• 1.2 kbps to 1 Mbps (Optional SW Data Rate Upgrades up to 59 Mbps)
• Unmatched EB/No vs. BER Performance
• Fastest Carrier Acquisition Time
• Modulation BPSK, QPSK & OQPSK (8PSK/8QAM & 16QAM Optional)
• SNMP v1 & v2, plus an Advanced Web Browser Interface
• MCC for very Efficient Remote Monitor and Control Channels
• Easy Local and Remote (Over-the-Air) Software Upgrades via Web Browser
• Up to 99 Store, Recall and Restore Locations (Auto Configuration Recall- ACR)
• Built-in 1:1 Redundancy Control
• Meaningful Event Log with over 2000 Time Stamped Events Available

Standard Features and Highlights

June 2015 Rev 0.3 - Datum Systems Proprietary 11

• FlexLDPC (Flexible LDPC FEC)
• Sharp Carrier TX/RX Filter Roll-Off
• Datum’s 8QAM Advantage
• Smart Carrier Cancelling
• New DVBS2/DVBS2X Card-Sets

Datum Advanced Smart Features

June 2015 Rev 0.3 - Datum Systems Proprietary 12 M7 Series Spectral Efficiency: Typical Performance

Most Spectral Efficient LDPC Modem

June 2015 Rev 0.3 - Datum Systems Proprietary 13

Datum Performance Comparison

Datum Competitive Technology

June 2015 Rev 0.3 - Datum Systems Proprietary 14

FlexLDPC vs. TPC Comparisons

M7 Series: FlexLDPC vs. TPC Typical Performance

FlexLDPC vs. TPC Comparisons

June 2015 Rev 0.3 - Datum Systems Proprietary 15

Carrier Alpha 0.4 0.35 0.3 0.25 0.2 0.15 0.1 0.08 0.05 # of 1Msps carriers 25 26 27 28 30 31 32 33 34 % improvement from 0.4 Alpha 0% 4% 8% 12% 20% 24% 28% 32% 36%

Sharp Carrier TX/RX Roll-Off Filters

TX/RX Roll-off Selections of 5, 8, 10, 15, 20, 25, 30, 35 and 40%

Example: Going from 35% to 8%, bandwidth savings of 20%!

to

June 2015 Rev 0.3 - Datum Systems Proprietary 16

10 dB Higher Adjacent Channels Sharp Carrier Plot

Adjacent Channel Sharp Carrier Plots

Equal Power Adjacent Channels Sharp Carrier Plot

June 2015 Rev 0.3 - Datum Systems Proprietary 17

Performance Comparisons Relative Peak-to-Average Power Ratios of Modulation Constellation Points

• Datum – Only 1 db Back-off from 8PSK
• 1.4 db less back-off required than Comtech
• 0.7 db Overall better performance

Datum 8QAM Reduced Power Advantage

June 2015 Rev 0.3 - Datum Systems Proprietary 18

Datum's 8QAM Performance Advantage

Datum Competitive Technology

June 2015 Rev 0.3 - Datum Systems Proprietary 19

The Smarter and More Affordable Carrier Cancelling!!

From

• Up to 50 % Bandwidth Savings
• Channel Capacity Increase of 2 dB
• Robust Operation
• Nonlinear Compensation
• Modulation Independent

To

Smart Carrier Cancelling

June 2015 Rev 0.3 - Datum Systems Proprietary 20

Up to 60% Bandwidth Savings!

35% to 8% Roll-Off

to Smart Carrier

Be Smart! FlexLDPC + Sharp & Smart Carrier

June 2015 Rev 0.3 - Datum Systems Proprietary 21

No Canceller vs. Canceller Plot

2  1  1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 1 2 3 4 5 6 7 8 9 10

Shannon Capacity no Cancelling Datum QPSK Datum 8QAM Datum 16QAM Shannon Capacity, Symmetrical Carrier Cancelling Datum QPSK 2 Carriers Shared Datum 8QAM 2 Carriers Shared Datum 16QAM 2 Carriers Shared

Datum16 K ModCods Shannon Plot with Cancelling

C/N (dB) Bits/Hz

June 2015 Rev 0.3 - Datum Systems Proprietary 22

Datum M7 Comparison Calculator Tool

June 2015 Rev 0.3 - Datum Systems Proprietary 23

• Sharper Roll-off Filters
• Increased MODCOD Granularity
• Higher order modulations: 32APSK/64APSK
• Data Rates to 350 Mbps (SR = 72 Msps)
• Easy Hardware Replacement
• Supports Smart Carrier Cancelling

M70 DVBS2/DVBS2X Mod and Demod

NEW DVBS2/DVBS2X Card-Sets

M70 DVBS2/DVBS2X Demodulator for M7 M70 DVBS2/DVBS2X Modulator for M7

• Independent Mod and Demod Cards
• Easily Installs in existing M7 Platform

DVBS2X Outbound DVBS2X Inbound Perfect for Point-to-Multipoint Configurations

24

M70 Card-Set Highlights for DVBS2X

DVB-S2X Preferred ModCods

0.50 1.00 1.50 2.00 2.50 3.00 3.50 4.00 4.50 5.00 5.50

• 3.00 -2.00 -1.00 0.00 1.00 2.00 3.00 4.00 5.00 6.00 7.00 8.00 9.00 10.0011.0012.0013.0014.0015.0016.0017.0018.00

Bits/Hz Es/No

Mode QEF Es/No Bits/Hz Pilot QPSK 13/45

• 2.03

0.567805 No QPSK 9/20 0.22 0.889135 No QPSK 1/2 1.00 0.988858 No QPSK 11/20 1.45 1.088581 No QPSK 3/5 2.23 1.188304 No QPSK 2/3 3.10 1.322253 No QPSK 3/4 4.03 1.487473 No QPSK 4/5 4.68 1.587196 No QPSK 5/6 5.18 1.654663 No QPSK 8/9 6.20 1.766451 No QPSK 9/10 6.42 1.788612 No 8APSK 5/9-L 4.73 1.647211 No 8APSK 26/45-L 5.13 1.713601 No 8PSK 3/5 5.50 1.739569 Yes 8PSK 23/36 6.12 1.853113 Yes 8PSK 2/3 6.62 1.935658 Yes 8PSK 25/36 7.02 2.062148 No 8PSK 13/18 7.49 2.145136 No 8PSK 3/4 7.91 2.228124 No 8PSK 5/6 9.35 2.478562 No 8PSK 8/9 10.69 2.646012 No 8PSK 9/10 10.98 2.679207 No 16APSK 1/2-L 6.07 1.972253 No 16APSK 8/15-L 6.65 2.104850 No 16APSK 5/9-L 6.94 2.193247 No 16APSK 26/45 7.61 2.281645 No 16APSK 3/5 7.90 2.370043 No 16APSK 28/45 8.20 2.458441 No 16APSK 23/36 8.48 2.524739 No 16APSK 2/3-L 8.53 2.635236 No 16APSK 2/3 9.07 2.637201 No 16APSK 25/36 9.37 2.745734 No 16APSK 13/18 9.81 2.856231 No 16APSK 3/4 10.31 2.896320 Yes 16APSK 7/9 10.75 3.077225 No 16APSK 4/5 11.13 3.165623 No 16APSK 5/6 11.71 3.300184 No 16APSK 77/90 12.09 3.386618 No 16APSK 8/9 12.99 3.523143 No 16APSK 9/10 13.23 3.567342 No 32APSK 2/3-L 11.35 3.289502 No 32APSK 32/45 12.00 3.510192 No 32APSK 11/15 12.42 3.620536 No 32APSK 3/4 12.98 3.703295 No 32APSK 7/9 13.30 3.841226 No 32APSK 4/5 13.89 3.866247 Yes 32APSK 5/6 14.53 4.119540 No 32APSK 8/9 15.94 4.397854 No 32APSK 9/10 16.30 4.453027 No 64APSK 32/45-L 14.38 4.206428 No 64APSK 11/15 15.21 4.338659 No 64APSK 7/9 15.87 4.603122 No 64APSK 4/5 16.27 4.735354 No 64APSK 5/6 16.95 4.936639 No Normal Frame DVB-S2X

Available Modcods (54 Combinations) Preferred Modcods for ACM

June 2015 Rev 0.3 - Datum Systems Proprietary

Ultra Efficient Overhead Channel

June 2015 Rev 0.3 - Datum Systems Proprietary 25

• Ultra Efficient Overhead “Modem Control Channel” (MCC)
• Supports the following Overhead Capabilities
• Automatic Uplink Power Control for
• Point-to-Point (P2P)
• Point-to-Multipoint (P2MP)
• Mesh
• Local to Remote SNMP for Monitor & Control
• Local Control of SNMP enabled equipment out the Remote IP Control Port
• Local to Remote Web Browser Connectivity
• Using local IP Control to Efficiently Access the Remote Modem Web Browser

June 2015 Rev 0.3 - Datum Systems Proprietary 26

Mod IF AUPC Mode = Enabled Unit IP Control Address = 192.168.1.100 Dmd IF AUPC Remote Path = Disabled AUPC Packet Path Mod IF AUPC Mode = Enabled Intf MCC Send Address = 1 MCC Rcv Address = 1 Unit Remote Modem 1 Dmd (option for AUPC) IF AUPC Remote Path = Local Intf MCC Send Address = 0 MCC Rcv Address = 0 Hub Modulator Dmd 1 IF AUPC Remote Path = Out IP Port IF Remote MCC Address = 1 Dmd 2 IF AUPC Remote Path = Out IP Port IF Remote MCC Address = 2 Intf MCC Rcv 1 Address = 0 MCC Rcv 2 Address = 0 Unit

Hub Dual Demod A AUPC Packet Path Dmd 1 IF AUPC Remote Path = Out IP Port IF Remote MCC Address = 3 Dmd 2 IF AUPC Remote Path = Out IP Port IF Remote MCC Address = 4 Intf MCC Rcv 1 Address = 0 MCC Rcv 2 Address = 0 Unit

Hub Dual Demod B Dmd IF AUPC Remote Path = Disabled Mod IF AUPC Mode = Enabled Intf MCC Send Address = 2 MCC Rcv Address = 2 Unit Remote Modem 2 Dmd IF AUPC Remote Path = Disabled Mod IF AUPC Mode = Enabled Intf MCC Send Address = 3 MCC Rcv Address = 3 Unit Remote Modem 3 Dmd IF AUPC Remote Path = Disabled Mod IF AUPC Mode = Enabled Intf MCC Send Address = 4 MCC Rcv Address = 4 Unit Remote Modem 4 E7 Eth I/O E7 Eth I/O E7 Eth I/O

AUPC Path for Remote Outbound Control

M7 PTMP or MESH AUPC

June 2015 Rev 0.3 - Datum Systems Proprietary 27

Express Ethernet Serial Dual G.703/E1 Drop & Insert Advanced IP HSSI

Easy Plug-in Interface Cards

June 2015 Rev 0.3 - Datum Systems Proprietary 28

* M7 Supports 2 Full Independent Interface Slots

• Express Ethernet 5 Port Bridge Interface
• 4 Std RJ-45, 1 SFP Port (Layer 2 Switched Bridge)
• QoS and VLAN (Line Speed 10/100/GbE, Jumbo)
• Synchronous Serial
• (RS422/RS232/V.35/EIA-530)
• HSSI Interface
• Supports full Data Rate of Modem
• Adv IP Interface (10/100/Gigabit Ethernet)
• Vyatta/Linux Bridge & Router Modes
• 70,000 Packets Per Second, Jumbo Packets
• Dual G.703/E1 Full or Fractional E1 (D&I)
• Supports 2 Independent G.703/E1 Ports, D&I
• Fully Independent Time Slot Selections
• Ultra Low Overhead

M7 Series Interface Highlights

June 2015 Rev 0.3 - Datum Systems Proprietary 29

Serial (S7) - Advanced IP (I7) - Advanced IP (I7) - Express Ethernet (E7) - Dual G.703 (G7) - More Combinations Available! Dual G.703 (G7) -

M7 Dual Interface Examples

June 2015 Rev 0.3 - Datum Systems Proprietary 30

M7/M7L/M7LT Web Browser

Summary Page Example Unit Page Example

June 2015 Rev 0.3 - Datum Systems Proprietary 31

Mod IF Page Example Demod Data Page Example

WB Configuration Examples Cont’

June 2015 Rev 0.3 - Datum Systems Proprietary 32

Live Web Browser Monitors

Spectrum Analyzer Page Example I/Q Constellation Page Example

June 2015 Rev 0.3 - Datum Systems Proprietary 33

Idle packets sent in place

• f unused bandwidth for live PER

IP (E7 & I7) Web Browser Statistics

I7/E7 IP Statistics Page Example

June 2015 Rev 0.3 - Datum Systems Proprietary 34

M7 Series Event Log

June 2015 Rev 0.3 - Datum Systems Proprietary 35

Software Downloads via Web Browser

June 2015 Rev 0.3 - Datum Systems Proprietary 36

• Backward compatibility with the PSM-500 Series
• Same low price as PSM-500
• Smaller, lighter and more power efficient
• IF is now 50 to 180 MHz in same chassis
• Extended TX/RX L-Band Frequency range of 950 to 2150 MHz
• Sharper TX/RX Roll-offs all the way down to 5% (standard with all modems)
• Real time clock with event monitoring and event logs
• Advanced Web Browser interface
• Easy Software Downloads
• Spectrum Analyzer and I&Q Constellation monitoring
• Efficient MCC In-Band Channel for Remote Web Browser access
• Efficient MCC In-Band Channel for Remote SNMP access
• Super Efficient Multiplexer for ESC Channel (supports 300 bits to 3 Mbps)
• Dedicated Remote IP interface (Web Browser & SNMP)
• M7 Advanced IP Interface (I7), supports 70,000 + PPS
• Low cost 4 Port Layer 2-Bridge Express Ethernet interface (E7) -supports SFP Port for Optic Fiber Plug-in
• QoS and VLAN standard with Express Ethernet Interface (E7)
• Preprogrammed E7 interface for both Hub and Remote PtP, PtMP and Mesh applications
• Efficient and time independent Dual G.703/E1 interfaces with fully flexible Drop and Insert timeslots
• Modular Design, Same basic hardware for Point-to-Point, Point-to-Multipoint and Mesh
• P2MP AUPC for all return channels
• Data Rates up to 59 Mbps
• Same Modular platform supports Modem, Mod-only, Demod-only or Dual Demod in half-rack wide chassis
• M7LT Model (full-rack wide) supports both AC and DC input versions (5 types of BUC power options each)
• Future SW upgradeable to ACM

M7 Advantages over PSM-500

June 2015 Rev 0.3 - Datum Systems Proprietary 37

On-the Move Point-to-Point Point-to-Multipoint Mesh

M7 Multi-Purpose Platform

June 2015 Rev 0.3 - Datum Systems Proprietary 38

Five Interface Types

Serial(S7) Advanced IP (I7) Dual G.703 (G7) Express Ethernet (E7) HSSI (H7)

Point-to-Point Link

June 2015 Rev 0.3 - Datum Systems Proprietary 39

P2MP Diagram Point-to-Multipoint Network Diagram

June 2015 Rev 0.3 - Datum Systems Proprietary 40

• Remote Sites Benefit from Shared MCPC Outbound
• Stat-Mux BW Saving Benefits on Outbound Traffic
• Supports Full Asymmetrical Traffic Patterns
• Reduced Cost of Hub Equipment using Multi-Demods

Why MCPC Point-to-Multipoint?

June 2015 Rev 0.3 - Datum Systems Proprietary 41

1 2 3 4 5 6 7 8 9 10 11 12 13 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2 2.1 2.2 2.3 2.4 2.5

BPSK-2D16S QPSK-2D16S-170B QPSK-2D16S-438B 8PSK-2D16S Shannon Channel Capacity Datum QPSK 16K Block Alpha 5% Datum 8QAM 16K Block Alpha 5%

Spectral Efficiency vs. Required C/N

C/N (dB) Spectral Efficiency (bps/Hz)

Datum Spectral Efficiency vs. leading TDMA Solution

June 2015 Rev 0.3 - Datum Systems Proprietary 42

Very Simple to Configure!!

M7 Smart Point-to-Multipoint Network

June 2015 Rev 0.3 - Datum Systems Proprietary 43

Easy Hub and Remote Site Connections!

Point-to-Multipoint Hub and Remote

June 2015 Rev 0.3 - Datum Systems Proprietary 44

MCPC/SCPC Mesh

June 2015 Rev 0.3 - Datum Systems Proprietary 45

M7 Mesh Network Example

June 2015 Rev 0.3 - Datum Systems Proprietary 46

M7 Mesh Network

June 2015 Rev 0.3 - Datum Systems Proprietary 47

On-the-Move Diagram On-the-Move Diagram

June 2015 Rev 0.3 - Datum Systems Proprietary 48

• High Coding Gain LDPC
• Exceptionally Robust Demod
• locks to very low SNR’s
• Light Weight
• Low Power
• Low Cost
• Easy to operate

On-the-Move Performance

M7 Modular Card Sets

June 2015 Rev 0.3 - Datum Systems Proprietary 49

• Key Benefits

 Free Standing Small & Compact 3.5” x 7” x 1.5”  DC Input 8 – 36 VDC  Data Rates as low as 1.2 kbps  High Coding Gain FlexLDPC  Exceptional EB/No vs. BER Performance

• Applications:

 Small Fly-Away VSAT Terminals  On-the-Move Systems  Integrated Outdoor Products

Compact, Lightweight & Low Power!! 1:1 Redundancy in 1 RU

On-the-Move Options

June 2015 Rev 0.3 - Datum Systems Proprietary 50

• Quick Quotes (Direct or Distributor)
• Easy Order Process
• Short Lead-times
• Guaranteed Quality and Reliability
• 2 Year Standard Warranty
• Meets CE Standards for:
• EN50022 Emissions
• EN50024 Immunity
• ETSI EN301 489-1 V1.9.2 Emissions and Immunity
• EN60950 Safety
• Fully RoHS Compliant
• Friendly Customer Service and Support
• No Annual Maintenance Contracts Required

Datum Systems Intangibles
