Network Solutions made Easy and Affordable DATUM SYSTEMS M7 Modular Series Introduction May 2016 Company Highlights Manufacturer of Low Cost Bandwidth Efficient Satellite Modems Highly Respected Company in San Jose, California USA

slide-1
SLIDE 1

DATUM SYSTEMS

Network Solutions made Easy and Affordable…

M7 Modular Series Introduction

May 2016

slide-2
SLIDE 2
  • Manufacturer of Low Cost Bandwidth Efficient Satellite Modems
  • Highly Respected Company in San Jose, California USA
  • Solely Focused on Quality Satellite Modems for Over 20 Years
  • Innovative and Modular Modem Platforms for SCPC/MCPC
  • Specializing in SCPC Point-to-Point, Point-to-Multipoint, Mesh & SCADA
  • Released 4th Next Generation Modem “M7 Modular Series”
  • New Card Based Modular Modem Design that’s Future Proof
  • DVBS2(X) Card-Set, Data Rates Up to 350 Mbps (72 MHz)
  • Leaders of Smart Features and Affordability
  • 30,000+ Modems Sold Worldwide

May 2016 Rev 0.8 - Datum Systems Proprietary 2

Company Highlights

slide-3
SLIDE 3

May 2016 Rev 0.8 - Datum Systems Proprietary 3

  • Compact 1/2 Rack Wide
  • Space Saver (50% Savings)
  • IF or L-Band
  • Modem or Dual-Demod

M7 / M7L / M7D / M7LD

  • Full Featured
  • 1:1 Redundancy in 1RU
  • 2 Units in a Single Rack
  • Modem or Dual-Demods
  • 4 Independent Demods in 1 RU

M7 Side x Side M7LT Remote Sat-Terminal

  • L-Band
  • High Stability
  • BUC & LNB Power

M7 Modem Card Sets

  • Stand-alone
  • IF or L-Band
  • DC Power
  • Advanced Web Interface
  • Modem, Mod or Demod
  • Dual-Demod Configurable

New M7 Modular Base Modem Series

with “Smart” Technology

The most modular, flexible and future proof modem imaginable…

slide-4
SLIDE 4

May 2016 Rev 0.8 - Datum Systems Proprietary 4

  • Earth Station Benefits
  • Saves Rack Space
  • Power Efficient Design
  • Smaller Shipping Containers
  • Lower Shipping Costs
  • Mounting Options
  • M7/M7L/M7D/M7LD

M7 / M7L / M7D / M7LD Desktop

Compact and Efficient Design

slide-5
SLIDE 5

May 2016 Rev 0.8 - Datum Systems Proprietary 5

M7 Series Rear Panel Options

  • M7, M7L

M7D, M7LD

  • M7, M7D

IF Version (BNC)

  • M7L/M7LD

LB Version (SMA)

slide-6
SLIDE 6

May 2016 Rev 0.8 - Datum Systems Proprietary 6

  • Future Proof
  • Flexible Slots
  • Fast Card Level Repairs
  • Low Cost Spares
  • Easy Hardware Replacement
  • Easy Key SW Upgrades
  • Data Rate Increases
  • Modulation Types
  • FEC Types

M7 Superior Modularity

slide-7
SLIDE 7

May 2016 Rev 0.8 - Datum Systems Proprietary 7

  • Professional SCPC Remote Terminal
  • Most Flexible Featured Modem
  • Low Cost
  • Highly Reliable and Rugged
  • Supports Independent Outbound/Inbound Data Rates

M7LT Remote Terminal

slide-8
SLIDE 8

May 2016 Rev 0.8 - Datum Systems Proprietary 8

  • Rear Panel RF Connections
  • TX Out N(50Ω) or F(75Ω) Type
  • RX In N(50Ω) or F(75Ω) Type
  • BUC and LNB Indicators
  • Common M7 Assemblies

 Interfaces, Controller, Front Panel, Backplane

  • Features
  • Integrated BUC/LNB Power
  • High Stability 10 MHz Reference
  • Common M7 Interfaces
  • Light Weight – only 11” Deep

Same M7 Rear Configuration

M7LT Features and Flexibility

slide-9
SLIDE 9

May 2016 Rev 0.8 - Datum Systems Proprietary 9 BUC Power Supply Input Voltage BUC Power Supply Output Voltage BUC power Supply Power Rating BUC power Supply Max Current 90-264 VAC 24 VDC 100 Watt 4.2 Amps 90-264 VAC 24 VDC 120 Watt 5.0 Amps 90-264 VAC 48 VDC 100 Watt 2.1 Amps 90-264 VAC 48 VDC 150 Watt 3.2 Amps 90-264 VAC 48 VDC 240 Watt 5.0 Amps 20-60 VDC 24 VDC 100 Watt 4.2 Amps 20-60 VDC 24 VDC 120 Watt 5.0 Amps 20-60 VDC 48 VDC 100 Watt 2.1 Amps 20-60 VDC 48 VDC 150 Watt 3.2 Amps 20-60 VDC 48 VDC 200 Watt 4.2 Amps

  • Features
  • AC and DC Input Optional
  • 5 BUC Power Supply Options
  • LNB Power 13 and 18 VDC

BUC P.S. Location

Available Input & BUC Power Options

M7LT Input and BUC PS Options

slide-10
SLIDE 10

May 2016 Rev 0.8 - Datum Systems Proprietary 10

  • IF 50 – 180 MHz or L-Band 950 to 2150 MHz (M7LT L-Band Only)
  • TX/ RX Carrier Filter Roll-Off Values: 5, 8,10,15,20,25,30,35,40%
  • AUPC Point-to-Point , Point-to-Multipoint or Mesh Modes
  • Compact Space Saver, Light Weight and Lowest Power
  • Highly Configurable Modem Platform with many Software Upgrade Features
  • Full Modem, Mod-Only or Dual Demod Configurations
  • Viterbi, Reed Solomon (Optional FlexLDPC SW Upgradeable, TPC HW Option)
  • Best Spectral Efficiency of ANY SCPC Modem
  • Lowest Latency in Industry, <15 ms at 64 kbps ¾ QPSK
  • 1.2 kbps to 1 Mbps (Optional SW Data Rate Upgrades up to 59 Mbps)
  • Unmatched EB/No vs. BER Performance
  • Fastest Carrier Acquisition Time
  • Modulation BPSK, QPSK & OQPSK (8PSK/8QAM & 16QAM Optional)
  • SNMP v1 & v2, plus an Advanced Web Browser Interface
  • MCC for very Efficient Remote Monitor and Control Channels
  • Easy Local and Remote (Over-the-Air) Software Upgrades via Web Browser
  • Up to 99 Store, Recall and Restore Locations (Auto Configuration Recall- ACR)
  • Built-in 1:1 Redundancy Control
  • Meaningful Event Log with over 2000 Time Stamped Events Available

Standard Features and Highlights

slide-11
SLIDE 11

May 2016 Rev 0.8 - Datum Systems Proprietary 11

  • FlexLDPC (Flexible LDPC FEC)
  • Sharp Carrier TX/RX Filter Roll-Off
  • Datum’s 8QAM Advantage
  • Smart Carrier Cancelling
  • IP Optimization
  • DVBS2/DVBS2X Card-Sets

Smart Features and DVBS2X Options

slide-12
SLIDE 12

May 2016 Rev 0.8 - Datum Systems Proprietary 12 M7 Series Spectral Efficiency: Typical Performance

Most Spectral Efficient LDPC Modem

slide-13
SLIDE 13

May 2016 Rev 0.8 - Datum Systems Proprietary 13

New Link Margin Monitor/Function

slide-14
SLIDE 14

May 2016 Rev 0.8 - Datum Systems Proprietary 14

Datum Performance Comparison

Datum Competitive Technology

slide-15
SLIDE 15

May 2016 Rev 0.8 - Datum Systems Proprietary 15

FlexLDPC vs. TPC Comparisons

M7 Series: FlexLDPC vs. TPC Typical Performance

FlexLDPC vs. TPC Comparisons

slide-16
SLIDE 16

May 2016 Rev 0.8 - Datum Systems Proprietary 16

Carrier Alpha 0.4 0.35 0.3 0.25 0.2 0.15 0.1 0.08 0.05 # of 1Msps carriers 25 26 27 28 30 31 32 33 34 % improvement from 0.4 Alpha 0% 4% 8% 12% 20% 24% 28% 32% 36%

Sharp Carrier TX/RX Roll-Off Filters

TX/RX Roll-off Selections of 5, 8, 10, 15, 20, 25, 30, 35 and 40%

Example: Going from 35% to 8%, bandwidth savings of 20%!

to

slide-17
SLIDE 17

May 2016 Rev 0.8 - Datum Systems Proprietary 17

10 dB Higher Adjacent Channels Sharp Carrier Plot

Adjacent Channel Sharp Carrier Plots

Equal Power Adjacent Channels Sharp Carrier Plot

slide-18
SLIDE 18

May 2016 Rev 0.8 - Datum Systems Proprietary 18

slide-19
SLIDE 19

May 2016 Rev 0.8 - Datum Systems Proprietary 19

Datum's 8QAM Performance Advantage

Datum Competitive Technology

slide-20
SLIDE 20

May 2016 Rev 0.8 - Datum Systems Proprietary 20

The Smarter and More Affordable Carrier Cancelling!!

From

  • Up to 50 % Bandwidth Savings
  • Channel Capacity Increase of 2 dB
  • Robust Operation
  • Nonlinear Compensation
  • Modulation Independent

To

Smart Carrier Cancelling

slide-21
SLIDE 21

May 2016 Rev 0.8 - Datum Systems Proprietary 21

Up to 60% Bandwidth Savings!

35% to 8% Roll-Off

to Smart Carrier

Be Smart! FlexLDPC + Sharp & Smart Carrier

slide-22
SLIDE 22

May 2016 Rev 0.8 - Datum Systems Proprietary 22

No Canceller vs. Canceller Plot

2 − 1 − 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 1 2 3 4 5 6 7 8 9 10

Shannon Capacity no Cancelling Datum QPSK Datum 8QAM Datum 16QAM Shannon Capacity, Symmetrical Carrier Cancelling Datum QPSK 2 Carriers Shared Datum 8QAM 2 Carriers Shared Datum 16QAM 2 Carriers Shared

Datum16 K ModCods Shannon Plot with Cancelling

C/N (dB) Bits/Hz

slide-23
SLIDE 23

May 2016 Rev 0.8 - Datum Systems Proprietary 23

Datum M7 Comparison Calculator Tool

slide-24
SLIDE 24

May 2016 Rev 0.8 - Datum Systems Proprietary 24

  • Meets New DVBS2X Open Standard
  • Capacity up to 72 MHz
  • TX/RX Filter Roll-off’s (35% down to 5%)
  • Higher order modulations: 32APSK/64APSK
  • Data Rates to 350 Mbps (SR = 72 Msps)
  • Supports Smart Carrier Cancelling
  • ACM

M70 DVBS2/DVBS2X Mod and Demod

DVBS2/DVBS2X Card-Sets

M70 DVBS2/DVBS2X Demodulator for M7 M70 DVBS2/DVBS2X Modulator for M7

  • Independent Mod and Demod Cards
  • Easily Installs in existing M7 Platform

DVBS2X Outbound DVBS2X Inbound

  • r

Perfect for Point-to-Multipoint Configurations

slide-25
SLIDE 25

25

M70 Card-Set Highlights for DVBS2X

DVB-S2X Preferred ModCods

0.50 1.00 1.50 2.00 2.50 3.00 3.50 4.00 4.50 5.00 5.50

  • 3.00 -2.00 -1.00 0.00 1.00 2.00 3.00 4.00 5.00 6.00 7.00 8.00 9.00 10.0011.0012.0013.0014.0015.0016.0017.0018.00

Bits/Hz Es/No

Mode QEF Es/No Bits/Hz Pilot QPSK 13/45

  • 2.03

0.567805 No QPSK 9/20 0.22 0.889135 No QPSK 1/2 1.00 0.988858 No QPSK 11/20 1.45 1.088581 No QPSK 3/5 2.23 1.188304 No QPSK 2/3 3.10 1.322253 No QPSK 3/4 4.03 1.487473 No QPSK 4/5 4.68 1.587196 No QPSK 5/6 5.18 1.654663 No QPSK 8/9 6.20 1.766451 No QPSK 9/10 6.42 1.788612 No 8APSK 5/9-L 4.73 1.647211 No 8APSK 26/45-L 5.13 1.713601 No 8PSK 3/5 5.50 1.739569 Yes 8PSK 23/36 6.12 1.853113 Yes 8PSK 2/3 6.62 1.935658 Yes 8PSK 25/36 7.02 2.062148 No 8PSK 13/18 7.49 2.145136 No 8PSK 3/4 7.91 2.228124 No 8PSK 5/6 9.35 2.478562 No 8PSK 8/9 10.69 2.646012 No 8PSK 9/10 10.98 2.679207 No 16APSK 1/2-L 6.07 1.972253 No 16APSK 8/15-L 6.65 2.104850 No 16APSK 5/9-L 6.94 2.193247 No 16APSK 26/45 7.61 2.281645 No 16APSK 3/5 7.90 2.370043 No 16APSK 28/45 8.20 2.458441 No 16APSK 23/36 8.48 2.524739 No 16APSK 2/3-L 8.53 2.635236 No 16APSK 2/3 9.07 2.637201 No 16APSK 25/36 9.37 2.745734 No 16APSK 13/18 9.81 2.856231 No 16APSK 3/4 10.31 2.896320 Yes 16APSK 7/9 10.75 3.077225 No 16APSK 4/5 11.13 3.165623 No 16APSK 5/6 11.71 3.300184 No 16APSK 77/90 12.09 3.386618 No 16APSK 8/9 12.99 3.523143 No 16APSK 9/10 13.23 3.567342 No 32APSK 2/3-L 11.35 3.289502 No 32APSK 32/45 12.00 3.510192 No 32APSK 11/15 12.42 3.620536 No 32APSK 3/4 12.98 3.703295 No 32APSK 7/9 13.30 3.841226 No 32APSK 4/5 13.89 3.866247 Yes 32APSK 5/6 14.53 4.119540 No 32APSK 8/9 15.94 4.397854 No 32APSK 9/10 16.30 4.453027 No 64APSK 32/45-L 14.38 4.206428 No 64APSK 11/15 15.21 4.338659 No 64APSK 7/9 15.87 4.603122 No 64APSK 4/5 16.27 4.735354 No 64APSK 5/6 16.95 4.936639 No Normal Frame DVB-S2X

Available Modcods (54 Combinations) Preferred Modcods for ACM

May 2016 Rev 0.8 - Datum Systems Proprietary

slide-26
SLIDE 26

May 2016 Rev 0.8 - Datum Systems Proprietary 26

  • Embedded Xiplink Optimizer

 TCP/IP Acceleration

 X1/X2 Payload Compression  ROHC Header Compression  Web and Byte Caching  Advanced QoS  Modern Web Browser with IP Monitoring

  • Embedded Sevis Backhaul Optimizer

 2G-IP, 3G-Iuh, 3G-Iub, 4G/LTE

  • Compression
  • Packet Coalescing
  • Acceleration

IP Optimization

slide-27
SLIDE 27

May 2016 Rev 0.8 - Datum Systems Proprietary 27

  • Simple Point to Multi-Point

 All Remotes in Same Sub Network

 Separate Remote Networks via VLAN  Provision Provider and Subscriber Ports  802.1Q Tunneling / Q-in-Q  Easy QoS

  • RWED or String Priority Queuing
  • VLAN Priority by PCP (Pri) Bits
  • No VLAN - IPV4 Diffserv / IPV6 TC Bits

Express Satellite Bridge

slide-28
SLIDE 28

Ultra Efficient Overhead Channel

May 2016 Rev 0.8 - Datum Systems Proprietary 28

  • Ultra Efficient Overhead “Modem Control Channel” (MCC)
  • Supports the following Overhead Capabilities
  • Automatic Uplink Power Control for
  • Point-to-Point (P2P)
  • Point-to-Multipoint (P2MP)
  • Mesh
  • Local to Remote SNMP for Monitor & Control
  • Local Control of SNMP enabled equipment out the Remote IP Control Port
  • Local to Remote Web Browser Connectivity
  • Using local IP Control to Efficiently Access the Remote Modem Web Browser
slide-29
SLIDE 29

May 2016 Rev 0.8 - Datum Systems Proprietary 29

slide-30
SLIDE 30

May 2016 Rev 0.8 - Datum Systems Proprietary 30

Local and Remote SNMP

slide-31
SLIDE 31

May 2016 Rev 0.8 - Datum Systems Proprietary 31

Remote Web Browser Interface

slide-32
SLIDE 32

May 2016 Rev 0.8 - Datum Systems Proprietary 32

Local & Remote Web Browser Identification

Local M7 under control Remote M7 under control

slide-33
SLIDE 33

May 2016 Rev 0.8 - Datum Systems Proprietary 33

Express Ethernet Serial Dual G.703/E1 Drop & Insert Advanced IP HSSI

Easy Plug-in Interface Cards

slide-34
SLIDE 34

May 2016 Rev 0.8 - Datum Systems Proprietary 34

* M7 Supports 2 Full Independent Interface Slots

  • Express Ethernet 5 Port Bridge Interface
  • 4 Std RJ-45, 1 SFP Port (Layer 2 Switched Bridge)
  • QoS and VLAN (Line Speed 10/100/GbE, Jumbo)
  • Synchronous Serial
  • (RS422/RS232/V.35/EIA-530)
  • HSSI Interface
  • Supports full Data Rate of Modem
  • Adv IP Interface (10/100/Gigabit Ethernet)
  • Vyatta/Linux Bridge & Router Modes
  • 70,000 Packets Per Second, Jumbo Packets
  • Dual G.703/E1 Full or Fractional E1 (D&I)
  • Supports 2 Independent G.703/E1 Ports, D&I
  • Fully Independent Time Slot Selections
  • Ultra Low Overhead

M7 Series Interface Highlights

slide-35
SLIDE 35

May 2016 Rev 0.8 - Datum Systems Proprietary 35

Serial (S7) - Advanced IP (I7) - Advanced IP (I7) - Express Ethernet (E7) - Dual G.703 (G7) - More Combinations Available! Dual G.703 (G7) -

M7 Dual Interface Examples

slide-36
SLIDE 36

May 2016 Rev 0.8 - Datum Systems Proprietary 36

M7/M7L/M7LT Web Browser

Summary Page Example Unit Page Example

slide-37
SLIDE 37

May 2016 Rev 0.8 - Datum Systems Proprietary 37

Mod IF Page Example Demod Data Page Example

WB Configuration Examples Cont’

slide-38
SLIDE 38

May 2016 Rev 0.8 - Datum Systems Proprietary 38

Live Web Browser Monitors

Spectrum Analyzer Page Example I/Q Constellation Page Example

slide-39
SLIDE 39

May 2016 Rev 0.8 - Datum Systems Proprietary 39

Idle packets sent in place

  • f unused bandwidth for live PER

IP (E7 & I7) Web Browser Statistics

I7/E7 IP Statistics Page Example

slide-40
SLIDE 40

May 2016 Rev 0.8 - Datum Systems Proprietary 40

M7 Series Event Log

slide-41
SLIDE 41

May 2016 Rev 0.8 - Datum Systems Proprietary 41

Software Downloads via Web Browser

slide-42
SLIDE 42

May 2016 Rev 0.8 - Datum Systems Proprietary 42

  • Backward compatibility with the PSM-500 Series
  • Same low price as PSM-500
  • Smaller, lighter and more power efficient
  • IF is now 50 to 180 MHz in same chassis
  • Extended TX/RX L-Band Frequency range of 950 to 2150 MHz
  • Sharper TX/RX Roll-offs all the way down to 5% (standard with all modems)
  • Real time clock with event monitoring and event logs
  • Advanced Web Browser interface
  • Easy Software Downloads
  • Spectrum Analyzer and I&Q Constellation Monitoring
  • Efficient MCC In-Band Channel for Remote Web Browser access
  • Efficient MCC In-Band Channel for Remote SNMP access
  • Super Efficient Multiplexer for ESC Channel (supports 300 bits to 3 Mbps)
  • Dedicated Remote IP interface (Web Browser & SNMP)
  • M7 Advanced IP Interface (I7), supports 70,000 + PPS
  • Low cost 4 Port Layer 2-Bridge Express Ethernet interface (E7) -supports SFP Port for Optic Fiber Plug-in
  • QoS and VLAN standard with Express Ethernet Interface (E7)
  • Preprogrammed E7 interface for both Hub and Remote PtP, PtMP and Mesh applications
  • Efficient and time independent Dual G.703/E1 interfaces with fully flexible Drop and Insert timeslots
  • Modular Design, Same basic hardware for Point-to-Point, Point-to-Multipoint and Mesh
  • P2MP AUPC for all return channels
  • Data Rates up to 59 Mbps
  • Same Modular platform supports Modem, Mod-only, Demod-only or Dual Demod in half-rack wide chassis
  • M7LT Model (full-rack wide) supports both AC and DC input versions (5 types of BUC power options each)
  • Future SW upgradeable to ACM

M7 Advantages over Legacy PSM-500

slide-43
SLIDE 43

May 2016 Rev 0.8 - Datum Systems Proprietary 43

On-the Move Point-to-Point Point-to-Multipoint Mesh

M7 Multi-Purpose Platform

slide-44
SLIDE 44

May 2016 Rev 0.8 - Datum Systems Proprietary 44

Five Interface Types

Serial(S7) Advanced IP (I7) Dual G.703 (G7) Express Ethernet (E7) HSSI (H7)

Point-to-Point Link

slide-45
SLIDE 45

May 2016 Rev 0.8 - Datum Systems Proprietary 45

P2MP Diagram Point-to-Multipoint Network Diagram

slide-46
SLIDE 46

May 2016 Rev 0.8 - Datum Systems Proprietary 46

  • Remote Sites Benefit from Shared MCPC Outbound
  • Stat-Mux BW Saving Benefits on Outbound Traffic
  • Supports Full Asymmetrical Traffic Patterns
  • Reduced Cost of Hub Equipment using Multi-Demods

Why MCPC Point-to-Multipoint?

slide-47
SLIDE 47

May 2016 Rev 0.8 - Datum Systems Proprietary 47

1 2 3 4 5 6 7 8 9 10 11 12 13 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8 1.9 2 2.1 2.2 2.3 2.4 2.5

BPSK-2D16S QPSK-2D16S-170B QPSK-2D16S-438B 8PSK-2D16S Shannon Channel Capacity Datum QPSK 16K Block Alpha 5% Datum 8QAM 16K Block Alpha 5%

Spectral Efficiency vs. Required C/N

C/N (dB) Spectral Efficiency (bps/Hz)

Datum Spectral Efficiency vs. leading TDMA Solution

slide-48
SLIDE 48

May 2016 Rev 0.8 - Datum Systems Proprietary 48

Very Simple to Configure!!

M7 Smart Point-to-Multipoint Network

slide-49
SLIDE 49

May 2016 Rev 0.8 - Datum Systems Proprietary 49

Easy Hub and Remote Site Connections!

Point-to-Multipoint Hub and Remote

slide-50
SLIDE 50

May 2016 Rev 0.8 - Datum Systems Proprietary 50

MCPC/SCPC Mesh

slide-51
SLIDE 51

May 2016 Rev 0.8 - Datum Systems Proprietary 51

M7 Mesh Network Example

slide-52
SLIDE 52

May 2016 Rev 0.8 - Datum Systems Proprietary 52

M7 Mesh Network

slide-53
SLIDE 53

May 2016 Rev 0.8 - Datum Systems Proprietary 53

On-the-Move Diagram On-the-Move Diagram

slide-54
SLIDE 54

May 2016 Rev 0.8 - Datum Systems Proprietary 54

  • High Coding Gain LDPC
  • Exceptionally Robust Demod
  • locks to very low SNR’s
  • Light Weight
  • Low Power
  • Low Cost
  • Easy to operate

On-the-Move Performance

slide-55
SLIDE 55

M7 Modular Card Sets

May 2016 Rev 0.8 - Datum Systems Proprietary 55

  • Key Benefits

 Free Standing Small & Compact 3.5” x 7” x 1.5”  DC Input 8 – 36 VDC  Data Rates as low as 1.2 kbps  High Coding Gain FlexLDPC  Exceptional EB/No vs. BER Performance

  • Applications:

 Small Fly-Away VSAT Terminals  On-the-Move Systems  Integrated Outdoor Products

Compact, Lightweight & Low Power!! 1:1 Redundancy in 1 RU

On-the-Move Options

slide-56
SLIDE 56

May 2016 Rev 0.8 - Datum Systems Proprietary 56

  • Quick Quotes (Direct or Distributor)
  • Easy Order Process
  • Short Lead-times
  • Guaranteed Quality and Reliability
  • 2 Year Standard Warranty
  • Meets CE Standards for:
  • EN50022 Emissions
  • EN50024 Immunity
  • ETSI EN301 489-1 V1.9.2 Emissions and Immunity
  • EN60950 Safety
  • Fully RoHS Compliant
  • Friendly Customer Service and Support
  • No Annual Maintenance Contracts Required

Datum Systems Intangibles
