CPU Side-Channel Attacks

the Meltdown Attack Heechul Yun

1

This Week: Hardware Security

• Introduction

– Meltdown

• Papers

– Spectre Attacks: Exploiting Speculative Execution, IEEE Security and Privacy (S&P), 2019 (Dustin) – SpectreGuard: An Efficient Data-centric Defense Mechanism against Spectre Attacks, DAC, 2019 (Jacob)

2

Meltdown

• What is it?

– An attack that exploits Intel CPU’s flaw that allows any user-level process to read the content of the kernel-

• nly accessible memory---usually the entire dram
• What’s the impact?

– An attacker can dump the entire memory, including password and other confidential information

• Which CPUs are affected?

– Almost all Intel CPUs that do Out-of-Order Execution to improve performance

3

Meltdown

• Is there any solution to address the issue?

– Yes. Major OS vendors already provide a solution. – But it comes at a performance cost of a varying

• degree. (we will see why later)
• What’s the technical details?

– Meltdown paper

• Meltdown, Moritz Lipp, Michael Schwarz, Daniel Gruss, Thomas Prescher, Werner Haas, Stefan Mangard, Paul

Kocher, Daniel Genkin, Yuval Yarom, Mike Hamburg, arXiv preprint (Submitted on 3 Jan 2018) 4

Outline

• Background

– Virtual Memory – Out-of-Order Execution – Cache Side-Channel

• Meltdown Attack
• Meltdown Defense
• Other Side-Channel Attacks

5

Virtual Memory

• Abstraction

– A large (e.g., 4GB) linear address space for each process

• Reality

– A limited (e.g., 1GB) amount

• f actual physical memory

shared with many other processes

• How?

6

MMU

7

Process A Process B Process C Physical Memory

MMU

Virtual address physical address

Page Table

• OS managed table that describe virtual to

physical address mapping.

8

Properties of Virtual Memory

• Memory isolation among different processes

– E.g., Process A cannot see process B’s memory (vice versa.)

• What about memory isolation between kernel

and user?

– Q1. how does kernel map its own private memory? – Q2. how to prevent user processes from accessing the kernel mapped memory?

9

Kernel/User Virtual Memory

• Kernel memory

– Kernel code, data – Identical to all address spaces – Fixed 1-1 mapping of physical memory

• User memory

– Process code, data, heap, stack,... – Unique to each address space – On-demand mapping (page fault)

10

Kernel User 0xFFFFFFFF 0xC0000000 0x00000000

Kernel/User Virtual Memory

• Every user-process has mappings to

kernel memory

• But the kernel memory is only

accessible at the kernel mode

– when you execute system calls or interrupt handlers.

• Benefits of this design: Performance

– Kernel can move data between user memory and kernel memory easily w/o changing the address space.

11

Kernel User 0xFFFFFFFF 0xC0000000 0x00000000

ARM Page Table

12

Kernel/User Virtual Memory

• Meltdown tricks the CPU so that

the user can access its kernel memory

• How?

– By exploiting weaknesses in Intel’s out-

• f-order execution engine

13

Kernel User 0xFFFFFFFF 0xC0000000 0x00000000

Out-of-Order Execution

• Background
• A cache-miss can take ~100 cycles
• Idling CPU while waiting data from memory is bad
• Out-of-order execution

– A technique to minimize data waiting time by executing future instructions – Introduced in 1967 (Tomasulo algorithm)

• Most (all) high-performance CPUs use OoOE

– Intel, AMD, ARM, ….

14

Out-of-Order Execution

• Instructions are

fetched into a queue

• Any instructions

whose data (operands) are ready are executed

• ut-of-order (subject

to data dependency)

• Results are “retired”

in-order.

15

Speculative Execution

• Guess which branch to

take.

• Speculatively execute

instructions in the likely branch.

• If guessed wrong,

squash the results

• But the side-effect

(cache state change) remain

16

If (condition) { Do something A1 Do something A2 Do something A3 } else { Do something B1 Do something B2 Do something B3 }

Cache Side-Channel Attack

• Side-effect of memory access is changes in

micro-architectural state (cache state change)

• By measuring access timing differences of a

memory location, an attacker can determine whether the memory is cached or not.

• This can be used to leak secret information
• Methods: Flush + Reload, Prime + Probe, etc.

17

Flush+Reload Attack

• Flush the shared cache-lines
• Let the victim execute
• Measure access timing of each cache-line

– Fast: accessed by the victim, Slow: not-accessed

18 Image credit: “Cache Side Channels: State of the Art and Research Opportunities” by Prof. Yinqian Zhang at OSU

Prime+Probe Attack

• The attacker prime the cache sets
• The victim runs and evicts attacker’s cache-lines
• The attacker measure access timing of each set

– Slow: victim accessed, fast: victim not accessed

19 Image credit: “Cache Side Channels: State of the Art and Research Opportunities” by Prof. Yinqian Zhang at OSU

Outline

• Background
• Meltdown Attack
• Meltdown Defense
• Other Side-Channel Attacks

20

Meltdown

• An exploit of Out-of-Order Execution, which

change the microarchitectural state in a way that leaks information

21

Toy Example

• Line 1 diverts execution flow to the exception

handler.

• So, line 3 should not be reached.

22

Toy Example

• But due to OoOE, Line 3 may have already been

executed, before raising the exception.

• The OoOE results will be squashed, but the side-

effect (cache state change) remains.

23

Toy Example

• By measuring access timings, you can uncover

the value of ‘data’

24

Meltdown

• This is it.

25

Meltdown

• Step 1: load an attacker chosen kernel address

into a register. This would raise an exception but it may take some time.

26

Meltdown

• Step 2: access memory based on the secret

content of the rax register. This access will be in the cache.

27

Meltdown

• Step 3: measure the access timing of the

probe array (one per page) to determine which is in the cache. Which in turn tell what was the content of the kernel address [rcx]

28

Meltdown

• Entire physical memory is 1-to-1 mapped into

part of kernel memory. So, you can dump it.

29

Kernel User Physical Memory Process address space

Outline

• Background
• Meltdown Attack
• Meltdown Defense

– KAISER/KPTI

• Other Side-Channel Attacks

30

KAISER/KPTI

• OS solution to mitigate the meltdown attack.
• Idea: Do not map kernel in each process’s address
• space. Instead kernel has its own address space.
• If kernel is not mapped in user process’s address space,

there’s no way to access kernel memory, thus preventing meltdown.

• But, to enter the kernel (system call or interrupt), you

have to first make a context switch it.

• There’s direct/indirect overhead of a context-switch.
• I/O intensive workloads are especially affected by this.

31

KAISER/KPTI

• Hide kernel from user’s address space.
• Switch to kernel’s address space to enter kernel (i.e.,

system calls, interrupt handling)

32

KAISER/KPTI

• Just the top-level table (PML4) needs to have two

distinct copies. Memory overhead is low.

• Benefits: kernel address is not mapped in the user’s
• space. So, no speculative reads can happen.

33

KAISER/KPTI: Overhead

• Flush TLB on context-switch between user/kernel

– PCID (or ASID) supporting CPUs don’t need to flush TLB.

• Page table swapping (CR3 update): ~hundreds cycles
• The overhead is incurred for every single system-

call/interrupt.  noticeable performance hit (5-30%)

34

Summary

• OoOE introduces side-effect, which can be

exploited in a way to leak information.

• Meltdown is such an attack, exploiting weakness

in Intel CPU’s OoOE implementation. It can dump entire kernel memory.

• KAISER/KPTI mitigates the issue by completely

separating kernel from user process’s address space.

• But the cost can be quite high for OS intensive

workloads.

35

References

• M. Lipp et al., Meltdown, arXiv preprint, 2018
• D. Gruss et al., KASLR is Dead: Long Live KASLR, 2017
• https://lwn.net/Articles/738975/

36

Reliability Side-Channel

• Disturbance errors in DRAM (*)
• a.k.a. Row Hammer Bug
• Repeated opening/closing a DRAM row can cause bit flips

in adjacent rows.

• In more than 80% DRAM modules between 2010 -2013
• Google demonstrated successful hacking method utilizing

the bug (**)

– manipulate page tables at the user-level

37 (*) Yoongu Kim et al, “Flipping Bits in Memory Without Accessing Them: An Experimental Study of DRAM Disturbance Errors,” ISCA’14 (**) Google Project Zero. Exploiting the DRAM rowhammer bug to gain kernel privileges, 2015

DRAM Chip

Row of Cells Row Row Row Row Wordline

VLOW VHIGH

Victim Row Victim Row Aggressor Row

Repeatedly opening and closing a row induces disturbance errors in adjacent rows

Opened Closed

38 This slide is from the Dr. Yoongu Kim’s ISCA 2014 presentation

RowHammer

39

References

• Flipping Bits in Memory Without Accessing

Them: An Experimental Study of DRAM Disturbance Errors. ISCA, 2014

• Drammer: Deterministic Rowhammer Attacks
• n Mobile Platforms, CCS'16 [blog] (optional)

40

DeepPicar Build

• Parts

– Playstation Eye camera x1 – Pololu DRV8835 motor hat x1 – New Bright 1:24 RC Car x1 – INIU USB power bank battery (2.4A) x1 – Form board 11x14x3/16in x1 – Machine Screw: #2-56, 1/4″ x4 (or more) – JST-USB cable x1 – Jumper wires male->female x6

• Instruction

– https://docs.google.com/document/d/1Tzx2_GrA6KHZhD3 Up83Q3eieVpPXd5ZUJ4jvwPXNy6o/edit?usp=sharing

41

Appendix

42

Address Layout

• 32 bit systems

– User: 3GB (0x00000000 to 0xbfffffff) – Kernel: 1GB (0xc0000000 to 0xffffffff)

• 64 bit systems (x86-64)

– User: 2^47 (zero to 0x7fffffffffff) – Kernel: 0xffff880000000000 – 0xffffffffffffffff

43

Foreshadow

• https://software.intel.com/security-software-

guidance/insights/deep-dive-intel-analysis-l1- terminal-fault

44
