SLIDE 1
SCIENCE PASSION TECHNOLOGY
Cash Attacks on SGX
Daniel Gruss, Michael Schwarz September 9, 2017
Graz University of Technology
Outline
www.tugraz.at 2 Daniel Gruss, Michael Schwarz — Graz University of Technology
Cash Attacks on SGX Daniel Gruss, Michael Schwarz September 9, 2017 - - PowerPoint PPT Presentation
Cash Attacks on SGX Daniel Gruss, Michael Schwarz September 9, 2017 - - PowerPoint PPT Presentation
SCIENCE PASSION TECHNOLOGY Cash Attacks on SGX Daniel Gruss, Michael Schwarz September 9, 2017 Graz University of Technology Outline www.tugraz.at 2 Daniel Gruss, Michael Schwarz Graz University of Technology Outline www.tugraz.at 2
SLIDE 2
SLIDE 3
Outline
www.tugraz.at 2 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 4
Outline
www.tugraz.at
SGX
2 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 5
Outline
www.tugraz.at
SGX
2 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 6
Outline
www.tugraz.at
SGX
2 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 7
Outline
www.tugraz.at
SGX
2 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 8
SGX
www.tugraz.at
Application Untrusted part Operating System
3 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 9
SGX
www.tugraz.at
Application Untrusted part
Create Enclave
Operating System
3 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 10
SGX
www.tugraz.at
Application Trusted part Call Gate Untrusted part
Create Enclave Trusted Fnc.
Operating System
3 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 11
SGX
www.tugraz.at
Application Trusted part Call Gate Untrusted part
Create Enclave Call Trusted Fnc. Trusted Fnc.
Operating System
3 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 12
SGX
www.tugraz.at
Application Trusted part Call Gate Untrusted part
Create Enclave Call Trusted Fnc. Trusted Fnc.
Operating System
3 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 13
SGX
www.tugraz.at
Application Trusted part Call Gate Untrusted part
Create Enclave Call Trusted Fnc. Trusted Fnc.
Operating System
3 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 14
SGX
www.tugraz.at
Application Trusted part Call Gate Untrusted part
Create Enclave Call Trusted Fnc. Trusted Fnc. Return
Operating System
3 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 15
SGX
www.tugraz.at
Application Trusted part Call Gate Untrusted part
Create Enclave Call Trusted Fnc. Trusted Fnc. Return
Operating System
3 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 16
SGX
www.tugraz.at
Application Trusted part Call Gate Untrusted part
Create Enclave Call Trusted Fnc. . . . Trusted Fnc. Return
Operating System
3 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 17
SGX
www.tugraz.at
Application Trusted part Call Gate Untrusted part
Create Enclave Call Trusted Fnc. . . . Trusted Fnc. Return
Operating System
3 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 18
SGX Wallets
www.tugraz.at
- Ledger SGX Enclave for blockchain applications
- BitPay Copay Bitcoin wallet
- Teechain payment channel using SGX
4 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 19
SGX Wallets
www.tugraz.at
- Ledger SGX Enclave for blockchain applications
- BitPay Copay Bitcoin wallet
- Teechain payment channel using SGX
Teechain [...] We assume the TEE guarantees to hold and do not consider side-channel attacks [5, 35, 46] on the TEE. Such attacks and their mitigations [36, 43] are outside the scope of this work. [...]
4 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 20
Signatures (RSA)
www.tugraz.at
M = C
d mod n
5 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 21
Signatures (RSA)
www.tugraz.at
M = C
d mod n 1 1 1 1 0 . . . Result = C
5 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 22
Signatures (RSA)
www.tugraz.at
M = C
d mod n 1 1 1 1 0 . . . Result = Result × Result × C square multiply
5 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 23
Signatures (RSA)
www.tugraz.at
M = C
d mod n 1 1 1 1 0 . . . Result = Result × Result square
5 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 24
Signatures (RSA)
www.tugraz.at
M = C
d mod n 1 1 1 1 0 . . . Result = Result × Result square
5 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 25
Signatures (RSA)
www.tugraz.at
M = C
d mod n 1 1 1 1 0 . . . Result = Result × Result × C square multiply
5 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 26
Signatures (RSA)
www.tugraz.at
M = C
d mod n 1 1 1 1 0 . . . Result = Result × Result × C square multiply
5 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 27
Signatures (RSA)
www.tugraz.at
M = C
d mod n 1 1 1 1 0 . . . Result = Result × Result square
5 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 28
ECDSA
www.tugraz.at
- Used to sign transactions
6 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 29
ECDSA
www.tugraz.at
- Used to sign transactions
- Point multiplication is similar to RSA exponentiation
6 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 30
ECDSA
www.tugraz.at
- Used to sign transactions
- Point multiplication is similar to RSA exponentiation
- Simplest implemention double-and-add or constant-time
Montgomery ladder
6 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 31
ECDSA
www.tugraz.at
- Used to sign transactions
- Point multiplication is similar to RSA exponentiation
- Simplest implemention double-and-add or constant-time
Montgomery ladder
- Both algorithms have secret-dependent memory accesses
6 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 32
Prime+Probe Cache Attack
www.tugraz.at
Prime+Probe [OST06; Liu+15; Mau+17]...
7 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 33
Prime+Probe Cache Attack
www.tugraz.at
Prime+Probe [OST06; Liu+15; Mau+17]...
- exploits the timing difference when accessing...
7 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 34
Prime+Probe Cache Attack
www.tugraz.at
Prime+Probe [OST06; Liu+15; Mau+17]...
- exploits the timing difference when accessing...
- cached data (fast)
7 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 35
Prime+Probe Cache Attack
www.tugraz.at
Prime+Probe [OST06; Liu+15; Mau+17]...
- exploits the timing difference when accessing...
- cached data (fast)
- uncached data (slow)
7 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 36
Prime+Probe Cache Attack
www.tugraz.at
Prime+Probe [OST06; Liu+15; Mau+17]...
- exploits the timing difference when accessing...
- cached data (fast)
- uncached data (slow)
- is used to attack secret-dependent memory accesses
7 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 37
Prime+Probe Cache Attack
www.tugraz.at
Prime+Probe [OST06; Liu+15; Mau+17]...
- exploits the timing difference when accessing...
- cached data (fast)
- uncached data (slow)
- is used to attack secret-dependent memory accesses
- is applied to a part of the CPU cache, a cache set
7 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 38
Prime+Probe Cache Attack
www.tugraz.at
Prime+Probe [OST06; Liu+15; Mau+17]...
- exploits the timing difference when accessing...
- cached data (fast)
- uncached data (slow)
- is used to attack secret-dependent memory accesses
- is applied to a part of the CPU cache, a cache set
- works across CPU cores as the last-level cache is shared
7 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 39
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime)
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 40
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime)
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 41
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime)
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 42
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime)
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 43
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime)
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 44
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime)
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 45
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime)
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 46
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime)
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 47
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime)
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 48
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime)
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 49
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime) Step 1: Victim evicts cache lines by accessing own data loads data
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 50
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime) Step 1: Victim evicts cache lines by accessing own data loads data
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 51
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime) Step 1: Victim evicts cache lines by accessing own data l
- a
d s d a t a
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 52
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime) Step 1: Victim evicts cache lines by accessing own data l
- a
d s d a t a
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 53
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime) Step 1: Victim evicts cache lines by accessing own data
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 54
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime) Step 1: Victim evicts cache lines by accessing own data Step 2: Attacker probes data to determine if the set was accessed
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 55
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime) Step 1: Victim evicts cache lines by accessing own data Step 2: Attacker probes data to determine if the set was accessed fast access
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 56
Prime+Probe
www.tugraz.at
Attacker address space
Cache
Victim address space Step 0: Attacker fills the cache (prime) Step 1: Victim evicts cache lines by accessing own data Step 2: Attacker probes data to determine if the set was accessed slow access
8 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 57
Attack
SLIDE 58
Attack Settings
www.tugraz.at
Victim
9 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 59
Attack Settings
www.tugraz.at SGX
Victim
9 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 60
Attack Settings
www.tugraz.at SGX
Transaction Signature
+ private key
Wallet API
Victim
9 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 61
Attack Settings
www.tugraz.at
Attacker
SGX
Transaction Signature
+ private key
Wallet API
Victim
9 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 62
Attack Settings
www.tugraz.at SGX
Attacker
SGX
Transaction Signature
+ private key
Wallet API
Victim
9 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 63
Attack Settings
www.tugraz.at SGX
Key Extractor Loader
Attacker
SGX
Transaction Signature
+ private key
Wallet API
Victim
9 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 64
Attack Settings
www.tugraz.at SGX
Key Extractor Loader
Attacker
SGX
Transaction Signature
+ private key
Wallet API
Victim
9 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 65
Attack Settings
www.tugraz.at SGX
Key Extractor Loader
Attacker L1/L2 Cache
SGX
Transaction Signature
+ private key
Wallet API
Victim L1/L2 Cache
9 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 66
Attack Settings
www.tugraz.at SGX
Key Extractor
(Prime+Probe)
Loader
Attacker L1/L2 Cache
SGX
Transaction Signature
+ private key
Wallet API
Victim L1/L2 Cache
Shared LLC
9 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 67
SGX Limitations
www.tugraz.at
Classical Prime+Probe cannot be mounted within SGX:
10 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 68
SGX Limitations
www.tugraz.at
Classical Prime+Probe cannot be mounted within SGX:
- No access to high-precision timer (rdtsc)
10 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 69
SGX Limitations
www.tugraz.at
Classical Prime+Probe cannot be mounted within SGX:
- No access to high-precision timer (rdtsc)
- No syscalls
10 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 70
SGX Limitations
www.tugraz.at
Classical Prime+Probe cannot be mounted within SGX:
- No access to high-precision timer (rdtsc)
- No syscalls
- No shared memory
10 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 71
SGX Limitations
www.tugraz.at
Classical Prime+Probe cannot be mounted within SGX:
- No access to high-precision timer (rdtsc)
- No syscalls
- No shared memory
- No physical addresses
10 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 72
SGX Limitations
www.tugraz.at
Classical Prime+Probe cannot be mounted within SGX:
- No access to high-precision timer (rdtsc)
- No syscalls
- No shared memory
- No physical addresses
- No 2 MB large pages
10 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 73
Timer
www.tugraz.at
- We have to build our own timer
11 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 74
Timer
www.tugraz.at
- We have to build our own timer
- Timer resolution must be in the order of cycles
11 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 75
Timer
www.tugraz.at
- We have to build our own timer
- Timer resolution must be in the order of cycles
- Start a thread that continuously increments a global variable
11 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 76
Timer
www.tugraz.at
- We have to build our own timer
- Timer resolution must be in the order of cycles
- Start a thread that continuously increments a global variable
- The global variable is our timestamp
11 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 77
Timer
www.tugraz.at
- We have to build our own timer
- Timer resolution must be in the order of cycles
- Start a thread that continuously increments a global variable
- The global variable is our timestamp
- This is even 15 % faster than the native timestamp counter
1 mov ×tamp , %rcx 2 1:
i n c %rax
3 mov %rax ,
(%rcx )
4 jmp 1b
11 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 78
Physical Addresses
www.tugraz.at
- Cache set is determined by part of physical address [Mau+15]
12 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 79
Physical Addresses
www.tugraz.at
- Cache set is determined by part of physical address [Mau+15]
- We have no knowledge of physical addresses
12 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 80
Physical Addresses
www.tugraz.at
- Cache set is determined by part of physical address [Mau+15]
- We have no knowledge of physical addresses
- Use the reverse-engineered DRAM mapping [Pes+16]
12 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 81
Physical Addresses
www.tugraz.at
- Cache set is determined by part of physical address [Mau+15]
- We have no knowledge of physical addresses
- Use the reverse-engineered DRAM mapping [Pes+16]
- Exploit timing differences to find DRAM row borders
12 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 82
Physical Addresses
www.tugraz.at
- Cache set is determined by part of physical address [Mau+15]
- We have no knowledge of physical addresses
- Use the reverse-engineered DRAM mapping [Pes+16]
- Exploit timing differences to find DRAM row borders
- The 18 LSBs are ‘0’ at a row border
12 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 83
Physical Addresses
www.tugraz.at
127 4095
4 kB Page #1
Page #2 Page #3 Page #4 Page #5 Page #6 Page #7 Page #8 Page #1
8 kB row x in BG0 (1) and channel (1)
Page #3 Page #4 Page #5 Page #6 Page #7 Page #8 Page #1 Page #2
8 kB row x in BG0 (0) and channel (1)
Page #4 Page #5 Page #6 Page #7 Page #8 Page #1 Page #2 Page #3
8 kB row x in BG0 (1) and channel (0)
Page #5 Page #6 Page #7 Page #8 Page #1 Page #2 Page #3 Page #4
8 kB row x in BG0 (0) and channel (0)
13 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 84
Physical Addresses
www.tugraz.at
BG0 (0), Channel (0) BG0 (0), Channel (0) BG0 (0), Channel (0) BG0 (0), Channel (0) BG0 (0), Channel (0) BG0 (0), Channel (0) BG0 (0), Channel (0) BG0 (0), Channel (0) 127 4095
4 kB Page #1
Page #2 Page #3 Page #4 Page #5 Page #6 Page #7 Page #8 Page #1
8 kB row x in BG0 (1) and channel (1)
Page #3 Page #4 Page #5 Page #6 Page #7 Page #8 Page #1 Page #2
8 kB row x in BG0 (0) and channel (1)
Page #4 Page #5 Page #6 Page #7 Page #8 Page #1 Page #2 Page #3
8 kB row x in BG0 (1) and channel (0)
Page #5 Page #6 Page #7 Page #8 Page #1 Page #2 Page #3 Page #4
8 kB row x in BG0 (0) and channel (0)
13 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 85
Physical Addresses
www.tugraz.at
BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (0) BG0 (1), Channel (0) 127 4095
4 kB Page #1
Page #2 Page #3 Page #4 Page #5 Page #6 Page #7 Page #8 Page #1
8 kB row x in BG0 (1) and channel (1)
Page #3 Page #4 Page #5 Page #6 Page #7 Page #8 Page #1 Page #2
8 kB row x in BG0 (0) and channel (1)
Page #4 Page #5 Page #6 Page #7 Page #8 Page #1 Page #2 Page #3
8 kB row x in BG0 (1) and channel (0)
Page #5 Page #6 Page #7 Page #8 Page #1 Page #2 Page #3 Page #4
8 kB row x in BG0 (0) and channel (0)
13 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 86
Physical Addresses
www.tugraz.at
BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (1) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (1) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (1) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (1) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (1) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (1) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (1) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (1) 127 4095
4 kB Page #1
Page #2 Page #3 Page #4 Page #5 Page #6 Page #7 Page #8 Page #1
8 kB row x in BG0 (1) and channel (1)
Page #3 Page #4 Page #5 Page #6 Page #7 Page #8 Page #1 Page #2
8 kB row x in BG0 (0) and channel (1)
Page #4 Page #5 Page #6 Page #7 Page #8 Page #1 Page #2 Page #3
8 kB row x in BG0 (1) and channel (0)
Page #5 Page #6 Page #7 Page #8 Page #1 Page #2 Page #3 Page #4
8 kB row x in BG0 (0) and channel (0)
13 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 87
Physical Addresses
www.tugraz.at
BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (1) BG0 (1), Channel (1) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (1) BG0 (1), Channel (1) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (1) BG0 (1), Channel (1) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (1) BG0 (1), Channel (1) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (1) BG0 (1), Channel (1) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (1) BG0 (1), Channel (1) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (1) BG0 (1), Channel (1) BG0 (0), Channel (0) BG0 (1), Channel (0) BG0 (0), Channel (1) BG0 (1), Channel (1) 127 4095
4 kB Page #1
Page #2 Page #3 Page #4 Page #5 Page #6 Page #7 Page #8 Page #1
8 kB row x in BG0 (1) and channel (1)
Page #3 Page #4 Page #5 Page #6 Page #7 Page #8 Page #1 Page #2
8 kB row x in BG0 (0) and channel (1)
Page #4 Page #5 Page #6 Page #7 Page #8 Page #1 Page #2 Page #3
8 kB row x in BG0 (1) and channel (0)
Page #5 Page #6 Page #7 Page #8 Page #1 Page #2 Page #3 Page #4
8 kB row x in BG0 (0) and channel (0)
13 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 88
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 89
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 90
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 91
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 92
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 93
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 94
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 95
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 96
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 97
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 98
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 99
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 100
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 101
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 102
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 103
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 104
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 105
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 106
Physical Addresses
www.tugraz.at
row n row n + 1 row n + 2 row n + 3 row n + 4 row n + 5
14 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 107
Physical Addresses
www.tugraz.at
Result on an Intel i5-6200U 200 400 600 800 1,000 1,200 1,400 1,600 1,800 2,000 500 600 Array index [kB] Latency [cycles]
15 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 108
Combining Everything
www.tugraz.at
- 1. Use the counting primitive to measure DRAM accesses
16 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 109
Combining Everything
www.tugraz.at
- 1. Use the counting primitive to measure DRAM accesses
- 2. Through the DRAM side channel, determine the row borders
16 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 110
Combining Everything
www.tugraz.at
- 1. Use the counting primitive to measure DRAM accesses
- 2. Through the DRAM side channel, determine the row borders
- 3. Row borders have the 18 LSBs set to ‘0’ → maps to cache set ‘0’
16 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 111
Combining Everything
www.tugraz.at
- 1. Use the counting primitive to measure DRAM accesses
- 2. Through the DRAM side channel, determine the row borders
- 3. Row borders have the 18 LSBs set to ‘0’ → maps to cache set ‘0’
- 4. Build the eviction set for the Prime+Probe attack
16 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 112
Combining Everything
www.tugraz.at
- 1. Use the counting primitive to measure DRAM accesses
- 2. Through the DRAM side channel, determine the row borders
- 3. Row borders have the 18 LSBs set to ‘0’ → maps to cache set ‘0’
- 4. Build the eviction set for the Prime+Probe attack
- 5. Mount Prime+Probe on the buffer containing the
multiplier [Sch+17]
16 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 113
Results
SLIDE 114
Measured Trace
www.tugraz.at
Raw Prime+Probe trace...
17 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 115
Measured Trace
www.tugraz.at
...processed with a simple moving average...
18 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 116
Measured Trace
www.tugraz.at
...allows to clearly see the bits of the exponent
1 1 1 00 1 1 1 01 1 1 00000001 000 1 0 1 00 1 1 00 1 1 0 1 1 1 1 1 0 1 1 1 1 0 1 000 1 00 1 1 1 0 1 000 1 1 1 0000 1 1 1 19 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 117
Performance Counters
www.tugraz.at
L1 Hits L1 Misses L3 Hits L3 Misses 0.5 1 ·109 Performance counter value Native
20 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 118
Performance Counters
www.tugraz.at
L1 Hits L1 Misses L3 Hits L3 Misses 0.5 1 ·109 Performance counter value Native SGX
20 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 119
Countermeasures
SLIDE 120
Source Level
www.tugraz.at
- Cache attacks can be prevented on source level
21 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 121
Source Level
www.tugraz.at
- Cache attacks can be prevented on source level
- Use side-channel resistant crypto implementations
21 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 122
Source Level
www.tugraz.at
- Cache attacks can be prevented on source level
- Use side-channel resistant crypto implementations
- Exponent blinding for RSA prevents multi-trace attacks
21 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 123
Source Level
www.tugraz.at
- Cache attacks can be prevented on source level
- Use side-channel resistant crypto implementations
- Exponent blinding for RSA prevents multi-trace attacks
- Bit-sliced implementations are not vulnerable to cache attacks
21 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 124
Operating System Level
www.tugraz.at
- Trusting the operating system weakens SGX threat model
22 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 125
Operating System Level
www.tugraz.at
- Trusting the operating system weakens SGX threat model
- Method for the operating system to inspect enclave code
22 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 126
Operating System Level
www.tugraz.at
- Trusting the operating system weakens SGX threat model
- Method for the operating system to inspect enclave code
- Re-enable certain performance counters, such as L3 hits/misses
22 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 127
Operating System Level
www.tugraz.at
- Trusting the operating system weakens SGX threat model
- Method for the operating system to inspect enclave code
- Re-enable certain performance counters, such as L3 hits/misses
- Enclave coloring to prevent cross-enclave attacks
22 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 128
Operating System Level
www.tugraz.at
- Trusting the operating system weakens SGX threat model
- Method for the operating system to inspect enclave code
- Re-enable certain performance counters, such as L3 hits/misses
- Enclave coloring to prevent cross-enclave attacks
- Heap randomization to randomize cache sets
22 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 129
Hardware Level
www.tugraz.at
- Intel could prevent attacks by changing the hardware
23 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 130
Hardware Level
www.tugraz.at
- Intel could prevent attacks by changing the hardware
- Combine Cache Allocation Technology (CAT) with SGX
23 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 131
Hardware Level
www.tugraz.at
- Intel could prevent attacks by changing the hardware
- Combine Cache Allocation Technology (CAT) with SGX
- Instead of controlling CAT from the OS, combine it with eenter
23 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 132
Hardware Level
www.tugraz.at
- Intel could prevent attacks by changing the hardware
- Combine Cache Allocation Technology (CAT) with SGX
- Instead of controlling CAT from the OS, combine it with eenter
- Entering an enclave would automatically activate CAT for this core
23 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 133
Hardware Level
www.tugraz.at
- Intel could prevent attacks by changing the hardware
- Combine Cache Allocation Technology (CAT) with SGX
- Instead of controlling CAT from the OS, combine it with eenter
- Entering an enclave would automatically activate CAT for this core
- L3 is then isolated from all other enclaves and applications
23 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 134
Hardware Level
www.tugraz.at
- Intel could prevent attacks by changing the hardware
- Combine Cache Allocation Technology (CAT) with SGX
- Instead of controlling CAT from the OS, combine it with eenter
- Entering an enclave would automatically activate CAT for this core
- L3 is then isolated from all other enclaves and applications
- Provide a non-shared secure memory element which is not cached
23 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 135
Conclusion
SLIDE 136
Conclusion
www.tugraz.at
- Side channels can cost you money
24 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 137
Conclusion
www.tugraz.at
- Side channels can cost you money
- Do not consider side channels out-of-scope
24 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 138
Conclusion
www.tugraz.at
- Side channels can cost you money
- Do not consider side channels out-of-scope
- Exploitable code + SGX = exploitable SGX enclave
24 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 139
Thank you!
SLIDE 140
SCIENCE PASSION TECHNOLOGY
Cash Attacks on SGX
Daniel Gruss, Michael Schwarz September 9, 2017
Graz University of Technology
SLIDE 141
References
www.tugraz.at
- F. Liu, Y. Yarom, Q. Ge, G. Heiser, and R. B. Lee. Last-Level Cache Side-Channel Attacks
are Practical. In: S&P. 2015.
- C. Maurice, N. Le Scouarnec, C. Neumann, O. Heen, and A. Francillon. Reverse
Engineering Intel Complex Addressing Using Performance Counters. In: RAID. 2015.
- C. Maurice, M. Weber, M. Schwarz, L. Giner, D. Gruss, C. A. Boano, S. Mangard, and
- K. R¨
- mer. Hello from the Other Side: SSH over Robust Cache Covert Channels in the
- Cloud. In: NDSS. 2017.
- D. A. Osvik, A. Shamir, and E. Tromer. Cache Attacks and Countermeasures: the Case of
- AES. In: CT-RSA. 2006.
- P. Pessl, D. Gruss, C. Maurice, M. Schwarz, and S. Mangard. DRAMA: Exploiting DRAM
Addressing for Cross-CPU Attacks. In: USENIX Security Symposium. 2016.
- M. Schwarz, S. Weiser, D. Gruss, C. Maurice, and S. Mangard. Malware Guard Extension:
Using SGX to Conceal Cache Attacks. In: DIMVA. 2017.
26 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 142
Bonus: Error Probability
www.tugraz.at
Error probability depends on which cache set of the key we attack
1 2 3 4 5 6 7 8 9 10 20 30 40
33.68 29.87 29.83 6.96 4.19 3.75 6.1 5.36 4.29
Bit-error ratio [%]
4096-bit key 27 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 143
Bonus: Error Probability
www.tugraz.at
Error probability depends on which cache set of the key we attack
1 2 3 4 5 6 7 8 9 10 20 30 40
33.68 29.87 29.83 6.96 4.19 3.75 6.1 5.36 4.29
Bit-error ratio [%]
4096-bit key
3 5 7 9 11 20 40 60 80
69 15 4 1
Traces Bit-errors
27 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 144
Runtime
www.tugraz.at
Full recovery of a 4096-bit RSA key in approximately 5 minutes
Cache Set Detection (3 min) Prime+Probe (5 s) Pre-Processing (110 s) Key Recovery (20 s)
28 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 145
Bonus: Timer
www.tugraz.at
CPU cycles one increment takes
rdtsc 1 4.7 4.67 0.87 1
1 timestamp = r d t s c ( ) ;
29 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 146
Bonus: Timer
www.tugraz.at
CPU cycles one increment takes
C rdtsc 1 4.7 4.67 0.87 1 4.7
1 while (1)
{
2
timestamp++;
3 }
29 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 147
Bonus: Timer
www.tugraz.at
CPU cycles one increment takes
Assembly C rdtsc 1 4.7 4.67 0.87 1 4.7 4.67
1 mov ×tamp , %rcx 2 1 :
i n c l (%rcx )
3 jmp 1b
29 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 148
Bonus: Timer
www.tugraz.at
CPU cycles one increment takes
Optimized Assembly C rdtsc 1 4.7 4.67 0.87 1 4.7 4.67 0.87
1 mov ×tamp , %rcx 2 1 :
i n c %rax
3 mov %rax ,
(%rcx )
4 jmp 1b
29 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 149
Bonus: Docker
www.tugraz.at SGX
Malware
(Prime+Probe)
Loader SGX
RSA
(+ private key)
API 30 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 150
Bonus: Docker
www.tugraz.at SGX
Malware
(Prime+Probe)
Loader
Attacker container
SGX
RSA
(+ private key)
API
Victim container
Docker engine
30 Daniel Gruss, Michael Schwarz — Graz University of Technology
SLIDE 151
Bonus: Docker
www.tugraz.at SGX
Malware
(Prime+Probe)
Loader
Attacker container
SGX
RSA
(+ private key)
API
Victim container
SGX driver Docker engine
30 Daniel Gruss, Michael Schwarz — Graz University of Technology
