Connectomics in Medicine: Pathways, Networks and Beyond Ragini Verma Center for Biomedical Image Computing and Analytics Radiology University of Pennsylvania Traffic in the Brain B0 (image without diffusion weighting) and atleast 6 gradient


slide-1
SLIDE 1

Connectomics in Medicine: Pathways, Networks and Beyond

Ragini Verma

Center for Biomedical Image Computing and Analytics Radiology University of Pennsylvania

slide-2
SLIDE 2

Traffic in the Brain

slide-3
SLIDE 3

( -1.0, 1.0, 0.0) (0.0, 0.0, 0.0 ) (1.0, 0.0, 1.0 ) (-1.0, 0.0, 1.0 ) (0.0, 1.0, 1.0 ) (0.0, 1.0, -1.0 ) (1.0, 1.0, 0.0 )

B0 (image without diffusion weighting) and atleast 6 gradient directions/slice

Reconstruct tensor using the Stejskal- Tanner equation           

zz yz xz yz yy xy xz xy xx

d d d d d d d d d D

Mean Diffusivity Fractional Anisotropy

slide-4
SLIDE 4

Joining the principal diffusion direction Starting criterion: Region of Interest Stopping criteria: ROI, curvature of fiber, diffusion measure of anisotropy

slide-5
SLIDE 5

Probabilistic tractography

Start point

At every step, draw a step direction from the pdf of the underlying fiber orientation.

Fractional anisotropy

A probability density function of the fiber

  • rientation in each point.

Courtesy C-F Westin

slide-6
SLIDE 6

Putting Things in Perspective

Courtesy Susumu Mori

slide-7
SLIDE 7

1: Parcellation of T1 structural scan into 95 cortical and sub-cortical regions 2: Transfer of region labels to diffusion space and computing the GM-WM boundary. 3: Probabilistic fiber tracking from each seed ROI i to target ROI j . 4: Connectivity quantification between each ROI pair (i,j) computed from Pij * active surface area of the seed. Edge-wise t-test Topological measures/ Lobe/node-specific measures Clustering / pattern classification 5: Construction of weighted structural connectivity network W 6: Statistics on networks (binarized/ weighted)

RIGHT RIGHT LEFT LEFT

The Structural Connectome

slide-8
SLIDE 8

The Functional connectome

1) Localize frequency specific activity and use spatial sparsity pattern to compute inverse

  • perator.

2) Use SVD to extract principal time course for each atlas defined region. 3) Connectivity quantification between each ROI pair (i,j) using Synchronization Likelihood.

Time Course ROIi Time Course ROIj

slide-9
SLIDE 9

Connectome Based Morphometry

p < 0.01 Females > Males Males > Females Age < 13 years; p < 0.001 Age : 13 -18 years; p < 0.0001 Age > 18 years; p < 0.001 Data: Raquel & Ruben Gur, Neuropsychiatry

slide-10
SLIDE 10

Gender Sub-networks

  • Y. Ghanbari

MEG-based connectivity in population with ASD DTI-based connectivity in a healthy population 8-23 years of age

slide-11
SLIDE 11

Sub-Networks in Autism

  • Y. Ghanbari

37 ASD 40 TDC male children aged 6-14 years (age difference p>0.6)

slide-12
SLIDE 12

Temporal Dynamics

slide-13
SLIDE 13

What parcellation to use?

  • Resolution of parcellation
  • Functional / structural

connectivity should be the basis

  • Validation?
slide-14
SLIDE 14

Finding the “one”

slide-15
SLIDE 15

How do we know this is the “one”?

  • Validating in humans – not animal models
  • What should be the measure of connection strength
  • How to validate the connectivity matrix
slide-16
SLIDE 16

Putting things back in perspective

slide-17
SLIDE 17

What is best method for analysis?

  • High dimensionality - multiple

comparison correction

  • Small sample size
  • Posthoc interpretation of graph

theory numbers

  • Subject-wise variability is not

quantified

  • Results not always interpretable
slide-18
SLIDE 18

So what do we do?

Hypothesis : Ask the question Validation : Question the answer

Get the neuroscientist and clinician involved!
