Compound Semiconductors: Process Flow, Process Integration, Devices - - PowerPoint PPT Presentation

1 4/28/2010

Ravi Ramanathan Skyworks Solutions, Inc.

Compound Semiconductors: Process Flow, Process Integration, Devices and Testing

May 2010

2 4/28/2010

Prelude

• Compound Semiconductor Market Value
• An Example: Process Technologies in a Radio
• Industry Trend in Power Amplifier/Front-end Modules
• Multi-Mode, Multi-Band Radio
• Process Technology Evolution
• Widely Used Compound Semiconductor Devices
• Heterostructures

3 4/28/2010

Compound Semiconductor Market Value

GaN LED: http://www.lbl.gov/Science-Articles/Archive/assets/images/2002/Dec-17-2002/indium_LED.jpg Laser Diode: http://www.aeropause.com/archives/Blu-ray-cover_plat.jpg

Mobile Internet Laser Diodes Smart Grid HB-LED/SSL 3G, 4G Data Cards

http://www.bccresearch.com/report/SMC032C.html

CAGR of 10%-18%

Embedded Wireless Platforms

4 4/28/2010

CMOS

RF-CMOS, BiCMOS GaAs HBT, BiCMOS, LDMOS E/D pHEMT D-pHEMT, SOI, SOS

Mainstream Tech. Optimum choice of technologies and MCM packaging approach dominate the cellular hardware architecture!

Process Technologies in Radio Module

5 4/28/2010

Industry Trend in PA/Front End Modules

Discrete PA to multiple band “converged” PA architectures to multimode FEM – drives complex integration, on-chip as well as MCM

2007-08 >2009

• 05’

2006

1710 -1770 WCDMA X 1749.9 -1784.9 WCDMA IX 880(890)

• 915

E-GSM / WCDMA VIII 2500 -2570 WCDMA VII 830 -840 WCDMA VI 824 -849 GSM 850 / WCDMA V 1710 -1755 WCDMA IV 1710 -1785 DCS / WCDMA III 1850 -1910 PCS / WCDMA II 1920 -1980 WCDMA I TX / MHz

Standard

1710 -1770 WCDMA X 1749.9 -1784.9 WCDMA IX 880(890)

• 915

E-GSM / WCDMA VIII 2500 -2570 WCDMA VII 830 -840 WCDMA VI 824 -849 GSM 850 / WCDMA V 1710 -1755 WCDMA IV 1710 -1785 DCS / WCDMA III 1850 -1910 PCS / WCDMA II 1920 -1980 WCDMA I

TX / MHz

& Wi-Fi + RFID + DTV + GPS +FM

Single Band PAs FEMs Cellular, WiFi FEMs with Pass-thru Ports Converged PA/FEM Architectures U-FEM

Seamless Mobility Rich Applications

6 4/28/2010

• Radios are becoming complex with the introduction of multiple

modes and multiple bands in a single package (SiP).

• Compound Semiconductors dominate the power amplifier, front-end

modules and switch applications.

– Power amplifiers and front-end modules are fabricated using heterojunction bipolar transistors

• N. Sokal, RF Power Amplifiers - Classes A Through F (Overview), IEEE, 1996.
• S.C. Cripps, RF Power Amplifiers for Wireless Communications, Artech House, Book

publication.

– Antenna switch modules (ASMs) and diversity switches are fabricated using depletion mode pHEMT and J-pHEMT devices, low noise amplifiers using E/D pHEMT devices.

• H. Tosaka et al., An Antenna Switch MMIC Using E/D Mode p-HEMT for

GSM/DCS/PCS/WCDMA Bands Application, 2003 IEEE Radio Frequency Integrated Circuits Symposium, page 519.

• S. Tamari et al., Recessed JPHEMT Technology for Low Distortion and Low Insertion Loss

Switch, CS MANTECH Conference, May 2009, Tampa, Florida, USA

Multi Mode and Multi Band Radio

7 4/28/2010

• MOSFET, HEMT and MESFETs are lateral conduction devices while BJT,

HBT devices are vertical conduction devices

fT ~ 10 × fop (LNA) fT ~ 3-5 × fop (PA) fmax ~ fT BV ~ 2-4 x Vsupply (PA)

Rule of Thumb

Source: INTEL

MOSFET: Racing down the μm nm curve

Figures of Merit

• CMOS

: Gate Length, Threshold, Gate Leakage

• BiCMOS

: Unit Current gain frequency (Ft) Unit Power gain frequency (Fmax) DC/RF Gain (Beta, Hfe)

• HBT

: DC Gain, BVceo, Ft, Fmax

• pHEMT

: Gate Length, Ron, gm, Idss, Coff

• SoI/SoS

: Gate Length, Csub, Ron, Threshold

Evolution in RF Transistors

&

Lower cost

Process Technology Evolution

End of traditional Vcc, GoX, Lg scaling era!

J.J. Liou, F. Schwierz, Journal of Telecommunications & Information Technology, page 99, 2004

8 4/28/2010

Compound Semiconductor Devices

• Heterojunction Bipolar Transistors

– HBT used for power amplification

• pHEMT (Pseudomorphic High Electron Mobility Transistors)

– Used as diversity switches, antenna switch module, low noise amplifier, mmWave amplifiers

• BiFET (Integration of Heterojunction Bipolar and Metal-

Semiconductor Field Effect Transistors)

– HBT used for power amplification – FET used in the bias circuit and as a “switch”

• BiHEMT (Integration of Heterojunction Bipolar and High Electron

Mobility Transistors)

– HBT used for power amplification – HEMT used in the bias circuit as well as a “switch” to turn some HBT arrays “ON” and “OFF”

9 4/28/2010

Heterostructures

• Heterostructure junction based devices dominate the

mainstream compound semiconductor applications.

• In heterostructure devices, the band offset between

conduction bands and/or the valence bands of the adjoining materials is exploited to get the desired device performance.

• InGaP HBT as well as pHEMT are heterostructure

based devices.

• Some of the commonly used heterostructures are:

1.8 Al0.3Ga0.7As 1.422 GaAs

ΔEv = 0.22 eV ΔEc = 0.15 eV

• D. Arnold et al., APL, 45, 1237 (1984)

1.451 In0.52Al0.48As 0.737

ΔEv = 0.194 eV ΔEc = 0.52 eV

In0.53Ga0.47As 1.9 In0.48Ga0.52P 1.422 GaAs

ΔEv = 0.33 eV ΔEc = 0.14 eV**

4.04 3.44

ΔEv = 0.18 eV ΔEc = 0.42 eV

GaN Al0.3Ga0.7N

** Depends on Orderliness

• f the InGaP

10 4/28/2010

Organization of Process Flows

• Front-end of Line Device Processing

– HBT – pHEMT – BiFET vs. BiHEMT – Diodes (Schottky, Junction Diodes)

• Back-end of Line Interconnect Processing

– General Process Flow – Passives

• Resistors
• Capacitors
• Inductors
• Bondpads
• Backside Process Flow (through Wafer Via)

11 4/28/2010

HBT

• Thinner the base, higher the beta
• High-base doping is needed to reduce base resistance → high Fmax.
• High-base doping reduces emitter injection efficiency (hole storage in emitter)
• In HBT, barrier for hole is higher than that for electrons → high-base doping can be used

Zhores Alferov & Herbert Kroemer (Nobel Prize 2000)

s r p r n B c

I I I I I I I + + − = = β

DC Gain

In Ic Ir Ib

*

Ip Is

Emitter Current: Ie = In + Ip + Is Collector Current: Ic = In – Ir Base Current: Ib = Ip + Ir + Is

⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ Δ = β kT E V V N N

g pE nB B E

exp

max

RF

) 2 1 2 1

c b bc eb ec t

f τ + τ + τ + π(τ = πτ =

BC B t MAX

C R f f π = 8

For Speed: Low Rb Low Cbc Low Ce

n CBO CEO

BV BV β =

Breakdown

Influenced by collector doping & thickness

12 4/28/2010

InGaP/GaAs HBT

Key Features:

(i) Very low output conductance (high base doping), (ii) Fairly constant gain as function of Ib, (iii) Low turn on voltage, (iv) High breakdown voltage Emitter contact: Ti/Pt (n-type ohmic contact) Base contact: Pt/Ti (p-type ohmic contact) Collector contact: AuGeNi (n-type alloyed contact)

Careful design of epitaxial layer structures as well as optimized device layout geometry are critical to achieve consistent device and circuit performance.

InGaP (Emitter) GaAs (Base)

• HBT devices must be protected with

proper ballasting scheme to ensure thermal stability Base Ballasting Emitter Ballasting

Rbb Reb Rbb = β Reb

13 4/28/2010

Layout

Establishing “Statistical Process Control” at device fabrication steps is vital to achieve high yield and consistent performance.

Typical Process Flow Device

TEM I nGaP Emitter Mesa I nGaAs Cap Contact Metal

TEM

• f

Emitter

• f

HBT structure

MOCVD HBT Wafers MOCVD HBT Wafers Emitter Contact Photo & Metal Emitter Contact Photo & Metal E/ B/ C Nitride Photo & Etch E/ B/ C Nitride Photo & Etch Emitter Mesa Photo & Etch Emitter Mesa Photo & Etch Collector Photo Etch & Metal Collector Photo Etch & Metal Base Pedestal Photo & Etch Base Pedestal Photo & Etch I solation Photo & I mplant I solation Photo & I mplant Base Photo Etch & Metal Base Photo Etch & Metal RTP Alloy RTP Alloy Nitride Deposition Nitride Deposition MOCVD HBT Wafers MOCVD HBT Wafers Emitter Contact Photo & Metal Ti/ Pt Emitter Contact E/ B/ C Nitride Photo & Etch Contact Vias E/ B/ C Emitter Mesa Photo & Etch Emitter Mesa Dry or Dry/ Wet etch Collector Photo Etch & Metal Collector Definition (Wet Etch) Base Pedestal Photo & Etch Base Pedestal Dry or Wet etch I solation Photo & I mplant I mplant I solation (He+ + ) Base Photo Etch & Metal Base Contact Definition RTP Alloy Au-Ge-Ni Alloy Process Nitride Deposition Nitride Passivation

HBT Fabrication – Carving the device

Epitaxial Material

14 4/28/2010

• pHEMT is an acronym for pseudomorphic high electron

mobility transistor. First AlGaAs-GaAs HEMT device was reported by Fujitsu Corporation, Japan in 1982 and the AlGaAs/InGaAs pHEMT in 1986.

• pHEMT is an heterojunction field effect transistor.
• Pseudomorphic refers to the fact that there is strain in

and between layers due to the lack of crystal lattice matching (AlGaAs – InGaAs: below tcritical).

• Primarily one tries to minimize the channel sheet

resistance, Rch by increasing electron density and mobility.

• Higher bandgap discontinuity (ΔEc) between AlGaAs &

InGaAs → higher carrier sheet density and higher current; helps noise and linearity due to better carrier confinement.

• Mobility can be thought of as the relative ease at which

carriers can move through a material; higher mobility translates into higher speed transistors.

pHEMT

15 4/28/2010

Doped AlGaAs layer on top of an undoped InGaAs layer supplies electrons to the InGaAs channel layer Flow of electrons in the InGaAs layer with no scattering (undoped channel). This also provides better noise figure.

Von Helmut Brech, 1998 Doctoral Dissertation, Optimization of GaAs based HEMT by Numerical Simulations, Vienna Univ of Technology, Vienna, Austria

pHEMT: Epitaxial Layer Construction

Spacing between AlGaAs and InGaAs channel is adjusted to achieve desired breakdown characteristics and separates the 2DEG from any ionized donors from n+ active. 10-20 periods of AlGaAs/GaAs super lattices grown on GaAs to inhibit substrate conduction Bottom layer heterojunction (double heterojunction pHEMT) InGaP or AlAs etch stops

More than 50+ layers are grown by MBE.

Real Bandgap Engineering…

16 4/28/2010

pHEMT Device Process Flow

RF FETs use n-channel. A more positive gate voltage w.r.t source increases the number of carriers (electrons) in the channel

MOCVD HBT MOCVD HBT Wafers MOCVD HBT

MBE Epitaxial Wafers Emitter Contact Photo & Metal Emitter Contact Photo & Metal Emitter Contact Photo & Metal Mesa Isolation Wet-Etch or Implant Emitter Mesa Photo & Etch Emitter Mesa Photo & Etch Emitter Mesa Photo & Etch Ohmic Metals Source, Drain Cnt. Base Pedestal Photo & Etch Base Pedestal Photo & Etch Base Pedestal Photo & Etch Channel Definition Wet Etch Isolation Photo & Implant Isolation Photo & Implant Isolation Photo & Implant Gate Definition Gate Recess Etch Base Photo Etch & Metal Base Photo Etch & Metal Base Photo Etch & Metal Gate Metallization Ti/Pt/Au/Ti Nitride Deposition Nitride Deposition Nitride Deposition Nitride Passivation Nitride Deposition Nitride Deposition Nitride Deposition In-Line Electrical Test “Integrity Check”

More than 50+ layers are grown in MBE Heavy-ion Implant provides not only good isolation but also yields a “planar” process Au-Ge-Ni alloy ohmic

contact to n++ GaAs

Need an “etch stop” layer such as AlAs, InGaP and etch pit free surface

• Photo Defined or Etch Defined Gate Layer Process
• Surface Passivation Steps Prior to Gate Metallization
• Single or Multi-gate Devices

Need an “etch stop” layer such as AlAs, InGaP and etch pit free surface Ti/Pt/Au or Ti/Pd/Au Gate Schottky

contact to n-AlGaAs

Check threshold, leakage to ensure wet etch process uniformity and device layers

17 4/28/2010

“Photo” Defined Gate

Advantages:

• Independent gate definition step

controlled by photo/develop step only.

• SiNx passivation on gate metal
• Gate metal free of “cracks/seams”

Disadvantages:

• Pt or Au diffusion into the channel, leads

to low Schottky turn-on.

• Prone to “gate walking”/poor gate-to-

recess gap control

tAu >> tTi tTi > tPt

“Etch” Defined Gate

Advantages:

• Can increase Au thickness to reduce Rg
• No “gate-sinking” or “Au diffusion” into

channel since Au foot terminates on SiNx.

• No “gate walking”
• Good control in gate-to-recess gap (gate δ).

Disadvantages:

• Etch profile and metal “seam” control.
• Damage to Schottky interface due to higher

bias dry etch process.

• Multi-gate FET will lead to larger device

area.

pHEMT Gate Definition

18 4/28/2010

Typical Device Characteristics of D-mode and E-mode pHEMT

Depletion/Enhancement Mode pHEMT

• In a typical depletion mode pHEMT, the gate must be

made negative to turn off the “normally on” device.

• In contrast, an enhancement mode device is “normally
• ff” at Vg = 0 and requires that the gate be made more

positive than the source for normal operation.

• Therefore a negative power supply voltage is not

required for an enhancement mode device.

• Biasing an enhancement mode pHEMT is much like

biasing the typical bipolar junction transistor

19 4/28/2010

pHEMT DC Characteristics

DC Parameters from several different sizes of devices have to be measured to verify the integrity of the process as well as used to generate statistical models

• Process control monitors are measured on every wafers to identify the

“known-good-wafer”.

20 4/28/2010

pHEMT RF Characteristics

• For multi-gate, multi-pole/multi-throw switches, it is vital to monitor

the RF characteristics of the switch to identify “known-good-die”.

21 4/28/2010

HBT Vs pHEMT

InGaP HBT pHEMT

Gain has exponential dependence with voltage Gain is linear with voltage Good power density Stacks FETs in series for Ruggedness Uses depleted ledge (Reliability) Good noise performance RF Power & Linear Amplifiers > 2.4V, 0.8-5.4 GHz Switches, Attenuators – high RF isolation High Speed Logic - SONET Can be used for higher band freqs. and low Vbatt Can modify process for HV infrastructure PAs Can modify process for LNA, Direction Detector, Passives Mature 6" Wafer Process Process variability (Yield, Cost) need to be well understood. Larger device critical dimensions (> 1μm) Demanding critical dimensions (>0.25 μm) High volume MOCVD Growth and ability to perform electrical test on large area devices before processing the wafers. MBE growth control required. Since device is sensitive to gate surface condition, often "Quick Lot" characterization is not meaningful to check the device quality. Typically poor noise – limited use for LNA and Mixers. Amplifiers are typically based on E-mode device and consumes larger area compared to HBT based amplifier. Ledge limits high Freq. performance. Other material systems such as InP bridges the gap. Performance is influenced by surface states Vbe limits low voltage performance (BiFET helps). No push pull, Complementary logic requires E & D mode No push pull or complementary logic.

Characteristics Applications Process Control Limitations

22 4/28/2010

• PIN-FET: Integration of P-I-N diode and MESFET

1983

• BiFET: HBT Integration with Ion-implanted J-FET (National)

1983

• Monolithic Integration of Laser Diodes and HBT

1984

• BiFET: FET Integrated into Collector of HBT (Single Growth)

1989

• BiHEMT: HEMT Integration with HBT (Re-growth, Selective MBE)

1991, 1995

• BiFET: FET Integrated into Emitter of HBT (Single Growth)

1992

• BiFET-based Products – Skyworks, Anadigics

2005

In many cases, FET and/or HBT performance is compromised due to limitations in epitaxial profile and/or process complexities.

Incorporation of Simple MESFET Layer Scheme, in the Emitter Stack of HBT Incorporation of HFET or pHEMT Layer Schemes, underneath the Collector

Monolithic Integration in GaAs - History

23 4/28/2010

BiFET & BiHEMT Race…

Increased level of process complexity and higher cost.... Skyworks, 2005 BiFET Anadigics, 2005 InGaP-PlusTM TriQuint, 2006 TQBiHEMTTM

• M. Shokrani et al, CS Mantech, 2006
• M. Sun et al, CS Mantech, 2006
• T. Henderson et al, CS Mantech, 2007
• MESFET is added to the

emitter of HBT

• C-V profile from large area

device established to verify the integrity of FET

• Impacts Cbe, Re of HBT
• pHEMT/HFET is added below

the collector of HBT

• Had to rely on layer

calibration growth runs to establish the integrity of FET

• Impacts breakdown, thermal
• E/D pHEMT is added below

the collector of HBT

• Had to rely on layer

calibration growth runs to establish the integrity of FET

• Impacts breakdown, thermal

InGaP –Plus is a trademark of Anadigics, Inc. TQBiHEMT is a trademark of TriQuint, Inc.

24 4/28/2010

• Low Turn-on, Unlike HBT, Makes it Ideal for On-chip

Bias/Analog Control Circuits

• HBT bias (Vref) are limited by 2Vbe and over 80%

varies with temperature and process

• BiFET enables operation to 1.6V with improved

variation over PVT conditions

• Low Voltage Analog Control
• Bias ON/OFF digital switch
• External analog control pin, 0-1V range for PA bias
• Internal reference voltage generated exclusively

from battery voltage, using BiFET circuitry

• Enable Advanced Functionality, Enhanced Performance
• Novel biasing networks ( “AutoSmartTM,” variable

ballast zero-current Iapc, over-voltage protection, low voltage op amp, etc.)

• Pre-distortion/linearization circuits, power detectors

BiFET/BiHEMT Applications

“AutoSmart is a trademark of Skyworks Solutions, Inc.

25 4/28/2010

Process Flow for BiFET/BiHEMT

MOCVD HBT Wafers MOCVD HBT Wafers MOCVD HBT Wafers MOCVD BiFET/ BiHEMT Wafer Emitter Contact Photo & Metal Emitter Contact Photo & Metal Emitter Contact Photo & Metal Emitter Contact Emitter Mesa Photo & Etch Emitter Mesa Photo & Etch Emitter Mesa Photo & Etch Emitter Mesa Dry or Dry/ Wet Etch Collector Photo Etch & Metal Collector Photo Etch & Metal Collector Photo Etch & Metal Collector Definition Base Pedestal Photo & Etch Base Pedestal Photo & Etch Base Pedestal Photo & Etch Base Pedestal Dry or Wet Etch I solation Photo & I mplant I solation Photo & I mplant I solation Photo & I mplant I mplant I solation (He+ + ) Base Photo Etch & Metal Base Photo Etch & Metal Base Photo Etch & Metal Base Contact Definition RTP Alloy RTP Alloy RTP Alloy Au-Ge-Ni Alloy Process Nitride Deposition Nitride Deposition Nitride Deposition Nitride Passivation & Vias Emitter Contact Photo & Metal Emitter Contact Photo & Metal Emitter Contact Photo & Metal Channel Mask and Wet Etch Process Emitter Contact Photo & Metal Emitter Contact Photo & Metal Emitter Contact Photo & Metal Gate Mask and Metallization I solation Photo & I mplant I solation Photo & I mplant I solation Photo & I mplant FET I SOLATI ON

(Shared Process)

Emitter Contact Photo & Metal Emitter Contact Photo & Metal Emitter Contact Photo & Metal Channel Mask and Wet Etch Process Emitter Contact Photo & Metal Emitter Contact Photo & Metal Emitter Contact Photo & Metal Gate Mask and Metallization

BiFET BiHEMT Emitter Base Collector

TOPOLOGY

Challenging to define 0.5μm or sub 0.5μm gates. Requires large spacing between pHEMT and HBT to avoid topology depending processing issues.

26 4/28/2010

BiFET/BiHEMT – Integration Challenges

5 mA/mm and 50 mV for every 10A shift in etch-stop thickness 3 mA/mm and 30 mV for every 10A shift in GaAs thickness 80% change in Idss and 30% change in Vp for every 10% shift in channel doping.

• Influence of Epitaxial Layers (Design of Experiments to Correlate Epi

Material Characterization Parameters and End-of-Line Device Parameters)

• Influence of Process Conditions

― Layout and wet-process optimizationGalvanic corrosion in gate periphery ― Nitride vs. photo-defined gate Gate-length control ― Surface-passivation step Improved Schottky interface ― Gate-placement in HBT flow Thermal stability and Idss/Vt drift

Multitude of “Variables” Can Impact FET Performance and BiFET Yield

100 80 60 40 20 100 80 60 40 20 100 80 60 40 20 100 80 60 40 20

Lg Channel

27 4/28/2010

Surface Preparation Prior to Gate Metal – Critical to Prevent Sinking Ti

Optimized Surface Prep. Unstable Schottky

Optimized Surface Treatment

• “Gate sinking” is a well-known phenomena in MESFET/pHEMTs.
• Choice of gate metal and surface preparation prior to gate

metallization are critical to get consistent FET performance.

• Placement of the “Gate” in the BiFET/BiHEMT process flows and

subsequent thermal annealing steps determine the stability of FET.

Forward Turn-on Voltage

Channel Channel Ti Ti Au Au

Gate-surface Preparation

• M. Sun et al., CS Mantech, 2006

100 80 60 40 20 100 80 60 40 20

28 4/28/2010

0.2 0.4 0.6 0.8 1 1.2

Design Flexibility/TTM Inter-channel Isolation, Noise Extendibility to Complex Tx/Radio Supply Chain Complexity Yield & Integration Risk Capability to Multi-sourcing IP Re-use Option Reliability Size (Form- Factor) Fabrication Cost (Yield)

On-chip Integration vs. MCM

Trade-offs have to be considered in choosing a process technology and integration scheme.

MCM: Multi-Chip Module

29 4/28/2010

• Backend of line can be common to both pHEMT and HBT devices.
• Processing steps that define resistors, capacitors, inductors and interconnects.
• Devices are finally protected by thick silicon nitride and thick polymer layers.
• Plated Au interconnects are used when thick metals (>2μm) are desired.

Nitride Via Opening Via Definition Thin Film Resistor Metal 1 (Ti/Au/Ti) MIM Nitride Deposition Inter Level Dielectric (ILD) Metal-2 (Ti/Au/Ti) Polymer Scratch Protection (Optional) Nitride Overcoat Nitride Etch (Bondpad Opening) DC/RF Parametric

Layout

Scratch protection improves die integrity against scratches as well as moisture protection.

Passives and Backend of Line

Lift-Off or Dry Etch Evaporation/ Plating PE-CVD O2 or O2+CF4 Dry Etch Polyimide or Nitride or BCB Evaporation or Electro-Plating PE-CVD BCB/PBO/Poly CF4 Plasma Etch Additional metal layers require additional ILD layers and metallization steps.

30 4/28/2010

• In III-V compound semiconductor technologies, MIM consists of Au metal layers with SiNx

dielectric layer and the cap densities range from 0.25 – 1.5 fF/μm2 (single or stacked).

• Plasma enhance CVD technique is used to deposit pin-hole free SiNx dielectric layer.
• Capacitors are constructed typically between Metal-1 and Metal-2.
• Low leakage, low voltage coefficient (VC) and temperature coefficient (TC) of capacitance,

high-breakdown voltage and higher MTTF are desirable.

Passives: Capacitor

d A C

dielectric

ε =

LC fR π 2 1 =

C L R RC f R X Q

R c

1 2 1 = = = π

Higher Q

Au/Ti Bottom Plate

Ti/Au/Ti

SiNx

MIM ( SiNx < 500A)

Top plate

ILD

Au/Ti Bottom Plate Ti/Au/Ti

MIM (SiNx > 500 A)

SiNx

ILD

31 4/28/2010

• Q-factor of an inductor describes how good an inductor can work as

an energy-storage element. In the ideal case, inductance is pure energy-storage element (Q approaches infinity), while in reality, parasitic resistance and capacitance reduce Q. Self-resonant frequency fSR marks the point where the inductor turns to capacitive.

• Solenoid and spiral inductors are popular in GaAs technology.
• In Si technologies, techniques to minimize eddy current loss due to

substrate coupling are critical to achieve reasonable Q-values.

Patterned Ground Shield Inductor on Deep Trench Oxide Filled Trenches underneath Inductors Variable Line Width

Shielding Inductor

Passives: Inductor

Design of Components and Circuits Underneath Integrated Inductors Frank Zhang, IEEE JOURNAL OF SOLID-STATE CIRCUITS, VOL. 41, NO. 10, October 2006

LC fR π 2 1 =

C L R R L f R X Q

R L

1 2 = = = π

Coupling Effect of On-Chip Inductor with Variable Metal Width, Heng-Ming Hsu, IEEE MICROWAVE AND WIRELESS COMPONENTS LETTERS, VOL. 17, NO. 7, JULY 2007

32 4/28/2010

Passives: Resistor

NiCr or TaN I LD 20-50 ohms/ sq

• Resistors are defined either by dry etch of thin-films (Cl2/N2 plasma for

TaN) or by lift-off technique; process is typically done before Metal-1.

• Linearity, current carrying capability, substrate leakage and the tolerance
• f the resistors (VCR = voltage coefficient of resistor, TCR = Temperature

coefficient of resistor) are critical parameters that define the quality of the resistor.

• Influence of current crowding (ΔR/R) and contact resistance are also

important considerations.

( ) W

L e 1 δ ρ R : Frequency High t W L ρ R : condition DC

t/δ ⋅

− = ⋅ =

−

ty conductivi : & ty permeabili : μ frequency;

• peration

: ω depth; skin the : 1 δ σ σ μ π f =

c b b 2 2 sq sq c sq c sh c b b sh

W W W k where k 1 k ln 1 k 1 k ln k 1 π 1 Δ crowding

• r

spreading current : Δ , resistance contact : R Δ W W R R 2 W L R R − = ⎥ ⎦ ⎤ ⎢ ⎣ ⎡ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ − + ⎟ ⎠ ⎞ ⎜ ⎝ ⎛ − + = ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ ⎟ ⎟ ⎠ ⎞ ⎜ ⎜ ⎝ ⎛ + ⋅ + + =

b c

W W >>

Current Spreading

Real-life Resistor Layout

33 4/28/2010

• Wafer thinning, through wafer via (TWV) formation, tape mount, scribe and break
• r laser dicing constitute the wafer backside processing steps.

Removal of Metal in Scribe Mounting on Sapphire Backside Polishing Through Wafer Via and Metal Demount/Probe Tape Mount, Laser Dicing Inspection Circled regions are through-wafer vias to wafer-backside in

• rder to obtain a low-

inductance ground for the power amplifier.

Backside Process and through Wafer Via

Au

Vertical Via Bread Loafing of Metal and Poor-step Coverage Sloped Via Good Metal-step Coverage

L vα h/d Rvα 1/A = f(A, tAu, profile, σ)

34 4/28/2010

TWV Characterization

• Characterizing the TWV is useful to generate “model” and helpful in circuit

simulations to properly account for ground inductance and resistance.

• Via resistance (DC) also serves as a useful measurement for fab process control.
• Via inductance can be characterized in three different ways: (i) simple geometric

influence, (ii) one-port or two-port S-parameter measurement, (iii) using a L-C resonant structure.

• 3D electromagnetic simulations (HFSS from Ansoft, Inc.) can also be used.

One-Port

LC f R π 2 1 =

Resonant Structure

C f L

R 2

4 1

2

π =

Metal-1

h

d = 2r

• M. E. Goldfarb and R. A. Pucel, ``Modeling Via Hole Grounds in Microstrip,'' IEEE Microwave and Guided Wave

Letters, vol. 1, no. 6, pp. 135-137, June 1991. M.J. Brophy et al., Resistance and Inductance of TWV: Measurement, Modeling, and Scaling, CS Mantech, 2005.

35 4/28/2010

Why Modeling and Simulation

• Consider “device application” when modeling! Most

accurate model is not always the most useful model

• Must represent ALL devices used in design
• Provide flexibility to design teams (device selections)
• Educate designers on correct use of models.
• Document the model vs. hardware fits
• Understand the behavior of the

circuit as a function of changes to the circuit elements.

• “Simulate” before you “fabricate”!
• Validate the “simulations” with the

circuit level measurements – emphasize the correct prediction of the behavior than the accuracy.

• Perform “corner” simulations.
• Feedback observed “anomalys” to processing
• Physics is usually right
• Translate circuit level needs to processing

groups

• Modelers should understand what changes the

device

• Pay attention to

modeling the variations, for e.g., variation of gm & Ic with Vbe, τf and Ccb with Ic & Vce, in HBTs, sub-threshold characteristics of the FETs, etc.

• Include thermal effects

and recommendation of “safe-operating area”.

Zampardi, Industrial Practices of Characterization and Modeling of III-V Technology , Oct.. 3, 2007, Boston, Mass.

(Zampardi, CMRF, 2007)

• Apply computational and device physics

methods, combined with the measurements to generate “models”.

36 4/28/2010

Interactive Models – Designer Experience!

Simulation Setup Variable Effects and Pareto Charts DC and RF Characteristics, Ranges and Correlations Circuit Schematics

All in ADS work interactively through built-in and customized functions

(Yang 2008 PA Workshop)

37 4/28/2010

Physics Based Geometric Models

Features

• Parameters calculated or directly

measured – forced to be physically okay.

• Single characterization database

and test structure set.

• Scalable device models.
• Re-use parameters for various

device blocks.

• PCM-driven statistics and DOE

simulation.

• Modularized-model code.

Benefits

• No “golden” wafer required; model re-centering to electrical specs.
• Allows sans GaAs explorations of circuit performance.
• Less mask space, quicker model turn-around, behavioral consistency

across device suite (geometries and type).

• Identify potential process issues or opportunities, multiple

geometries supported.

• Allows mix-and-match models. Optimize materials for class of circuit

performance leveraging GaAs process.

• Design FMEA, debug, and process sensitivity analysis. Constant

stream of PCM data “for-free” from in-line electrical test. Continuous feedback loop.

• Minimize number of files to maintain – less chance of error. Also

provides flexibility to add new devices.

Physics Based Models REALLY Allow Us to Work Smarter, Not Harder

(Zampardi CMRF 2007)

38 4/28/2010

• GaN (Group III-Nitrides) devices cater to a broad range of applications, including

microelectronic and optoelectronic products, optical sensors and high-voltage rectifiers. – Large Bandgap (3.4 eV, Compared to 1.4 of GaAs or 2.9 of SiC) Blue Lasers (λ = 364 nm) and Solid State Lighting (SSL). – High Power Density and High Ft and High-breakdown Voltage RF Power Transistors for Base Station, Power Conditioning and Convertors. (Pmax α Eg

4vs 2/F2)

GaN – A Late Bloomer

λ in nm

400 500 600 700 300 800 900

GaN InGaN GaAs

39 4/28/2010

Processing of III-Nitrides

Power Devices Opto-Electronic Devices

• Apart from the complexity in the design and growth
• f epitaxial layers, steps to carve the device are

very similar to the pHEMT process previously discussed.

• Mesa isolation and gate recess etches were done

by Cl2/BCl3 or CH4/H2 based chemistries

• Ohmic contacts in S/D are Ti/Al/Ni/Au or

Ti/Mo/Ni/Au and Schottky Ni/Au contacts in Gate layers.

GaN Essentials: Substrates for GaN RF Devices, Nitronex Corporation, AN011

G S D

Field Plate High Resistivity Silicon AlGaN/GaN HEMT

• Low I * R drop ohmic metallization to n-type and p-

type GaN

• Mesa isolation with Cl2 based dry-etch (CAIBE:

ECR, ICP Plasmas) and defect-free side walls to produce “etched facets/reflective mirrors” for stimulated emission.

40 4/28/2010

Processing Challenges of III-Nitrides

• The reproducibility in the growth of epitaxial layers due to the

extremely high growth temperatures

• Gate recess etches – control of bias is crucial to achieve damage free

surface and sidewalls.

• Difficult to achieve good ohmic contacts due to the high bandgap

contact layer

• Appropriate wet clean or surface passivation is essential to get oxide-

free surface prior to gate metallization.

• RTP at elevated temperatures (>750C) is needed to stabilize the
• hmic contacts as well as remove the dry-etch induced damage in the

gate region.

• Progress in Etched Facet Technology for GaN and Blue Lasers, A.A. Behfar et al., CSMAX 2005
• A. Weimar, A. Lell, G. Bruederl, S. Bader and V. Haerle. “Investigations of Low-Resistance Metal Contacts on p-

Type GaN using the Linear and Circular Transmission Line Method”, phys. stat. sol. (a) vol. 183, no. 169, 2001

• From High Electron Mobility GaN/AlGaN Heterostructures to Blue-Violet InGaN Laser Diodes. Perspectives of MBE

for Nitride Optoelectronics, C. Skierbiszewski, ACTA PHYSICA POLONICA A , No. 4, Vol 108, page 635 (2005)

41 4/28/2010

Summary

• While III-V compound semiconductor device designs depend on proper engineering of

the materials with different bandgaps, processing of those heterojunction materials predominantly depends on the control of surface states, passivation, ohmic and Schottky contacts.

• Backend of line processing lacks “planarity” when used SiNx and polyimide as inter-

level dielectrics, while BCB gives excellent planarity.

• 2 to 3 levels of gold metallization are commonly used as interconnect layers, but the

steady increase in gold price and year-over-year erosion in “selling price” of products will lead way to alternate interconnect materials that are used in the Si industry.

• Though through wafer via process is matured for low inductance ground, Cu flipchip is

making an inroad into the power amplifiers and front-end modules. Cu flipchip should be a desirable alternative in GaN based devices for efficient heat transfer due to lack of cost-effective TWV etch process in SiC substrates.

• GaN and InP technologies are slowly entering into high power and/or high speed

commercial markets. However, the price vs. performance seems to impede their rapid progress.

42 4/28/2010

Acknowledgement

Thanks to:

My colleagues in Skyworks’ Technology Development, Design, Operations and Quality for their contributions and help to further my knowledge in compound-semiconductor technology and to my management for their continued support.

43 4/28/2010

Backup

44 4/28/2010

• GaAs: Gallium Arsenide (III-V Compound Semiconductor)
• BJT: Bipolar Junction Transistor
• HBT: Heterojunction Bipolar Transistor
• FET: Field Effect Transistor
• CMOS: Complementary Metal Oxide Semiconductor (MOS) FET
• pHEMT: Pseudomorphic High Electron Mobility Transistor
• E/D pHEMT: Enhancement/Depletion Mode pHEMT Devices
• BiCMOS: Combination of Bipolar and CMOS in the Same Wafer Processing
• BiFET: HBT and FET Integrated on the Same Wafer
• BiHEMT: HBT and pHEMT Integrated on the Same Wafer
• MCM: Multi Chip Module (Multiple ICs in a Single Plastic Encapsulated Package)
• PA and FEM: Power Amplifier and Front-end Modules
• BCB: BenzoCycloButene (a Low Dielectric Constant Polymer Resin)
• PBO: Poly Benzoxazole (a Low Dielectric Constant Polymer Film

Acronyms

45 4/28/2010

Useful References

• David Pehlke and Dimitris Pavlids, “Evaluation of the Factors Determining HBT High-Frequency Performance by Direct Analysis of

S-Parameter Data,” IEEE Trans. On Microwave Theory and Techniques, Vol.40, No.12, Dec. 1992.

• Modulation doping was discovered by R. Dingle, “New high-speed III-V devices for integrated circuits,” IEEE Trans. on Electron

Devices , 31, pp. 1662-1667, 1984.

• H. Kroemer, Theory of wide-gap emitter for transistor, Proc. IRE, 45, 1535 (1957).
• A Review of Semiconductor Heterojunctions, D. T. Calow et al., JOURNAL OF MATERIALS SCIENCE 2 (1967) 88-96
• Methods for Monitoring Passivation Ledges in a Manufacturing Environment, P. Zampardi, L. Rushing, P. Ma, M.F. Chang, GaAs

Mantech 2002 Digest, paper #11B, pp. 225-228.

• I. S. Vasil’evskiĭ et al., Electrical and structural properties of PHEMT Heterostructures based on AlGaAs/InGaAs/AlGaAs and δ-

doped on two sides, Semiconductors, 42, Number 9, page 1084-1091, 2008.

• A Novel Optical Effect in InGaP Compound Collector Hetero-junction Bipolar Transistors, P. Zampardi and R.L. Pierson, 2002

Bipolar Circuits and Technology Meeting, pp. 232-235.

• Development of High Breakdown Voltage InGaP/GaAs DHBTs, Jiang Li, Cristian Cismaru, Pete Zampardi, Eugene Babcock, Mike

Sun, and Ravi Ramanathan, and Kevin Stevens, 2007 GaAs Mantech Conference, Session 9, Paper 4.

• A DOE Approach to Product Qualification For Linear Handset Power Amplifiers, P.J. Zampardi, D. Nelson, P. Zhu, C. Luo, S.

Rohlfing, and A. Jayapalan, 2004 Compound Semiconductor Mantech Conference, Miami, FL, pp. 91-94.

• InGaP-GaAs HBT Statistical Modeling for RF Power Amplifier Designs, J. Hu, P. J. Zampardi, H. Shao, K. H. Kwok, C. Cismaru,

Digest of the Compound Semiconductor Integrated Circuit Symposium 2006, San Antonio, 2006, pp. 219-222.

• An Innovative and Integrated Approach to III-V Circuit Design, Y. Yang, P. Zampardi, M. Fredriksson, J. Zu, S. Chen, G. Zheng, J.

Sifri, Microwave Journal, September 2008, pp. 136-156.

• Practical Statistical Simulation for Efficient Circuit Design, Pete Zampardi, Yingying Yang, Juntao Hu, Bin Li, Mats Fredricksson, Kai

Kwok, Hongxiao Shao, IMS Workshop WMB, IMS Boston, June 2009.

• Analysis and modeling on linearity for multi-throw TX/RX switches, C.J. Wei et al, 3rd MAPE intern’l conference, Beijing, Oct 27-29,

2009.

• Enhanced High-Current VBIC model, C.J. Wei, J. Gering and Y. A. Tkachenko, SBMICRO 2004, Sept.9 2004 in Brazil, also

published in Trans MTT-53, No.4,2005 pp. 1235-1243.

• DC/RF and statistic model of four terminal InGaP/GaAs BIFET for wireless communications, C. J. Wei, A. Metzger, Y. Zhu, C.

Cismaru, P. Zampardi, R. Ramanathan, and Y. A. Tkachenko, 2005 European Microwave Conference, Manchester, Sept. 2006.
