Company presentation in short Sub sea applications Sub sea technology Allan Jansson 30 years experience in electro optics and lasers Net work organisation with about 10-15 experienced partners with unique knowledge in special technical

SLIDE 1

Company presentation in short Sub sea applications Sub sea technology

SLIDE 2

Allan Jansson 30 years experience in electro optics and lasers Net work organisation with about 10-15 experienced partners with unique knowledge in special technical areas Located in Täby just north Stockholm Sweden 90 % of turnover is export

SLIDE 3

Sub sea cameras and laser radar systems
Airborne laser radars and sensors
Military sensors and technology
Laser radar and 3D measurement applications
Automatic home land security systems

Experience in following areas

SLIDE 4

Range gated active laser cameras
Sub sea cameras
See through cameras for turbide water
Sub sea laser radar systems
Paravan camera systems
LED illumination systems
Diving equipment and lighting

Experience in sub sea applications

SLIDE 5

Sub sea cameras

Standard sub sea and special made cameras CCD and C-Mos cameras with illumination Extremely sensitive Dynaview camera for operating down to 200-400 meter with no need for lamps (10 microlux FV)

SLIDE 6

Range gated laser camera systems

Active laser camera with time of flight control laser

strobing and image intensification

Range increase in turbide water 2-3times normal sub

sea cameras AquaLynx system

SLIDE 7

Image processing for better video Lyynification filter for improving video quality by advanced image processing DSP soft ware processing of video at full speed

SLIDE 8

See through camera systems

Cameras with LED and laser illumination capable of penetrating dirty and turbide water

SLIDE 9

Sub sea Laser radar systems

Laser radar systems operating sub sea 3D output in real coordinates

SLIDE 10

Paravan camera system for high speed area imaging

f sea bottom at up to 6 knots

Operating depth down to 300 meters Intelligent control functions Paravan camera LaserDolphin

SLIDE 11

Compact Paravan camera Compact sub sea camera cowering large areas at up to 3 knots in speed. Weight 25 kg Cameras Enviromental sensors High intensity LED illumination

SLIDE 12

Atometry sensing system Non contact detection of all kinds of materials by nuclear gamma spectral analyze Detects explosives through thick steel by chemical formula and weight Over 99% reliability in detection Advanced analyze replacing lab works of all kinds

SLIDE 13

Spectral illumination for better range Spectrally designed LED illumination increasing visible range up to 100% more compared to Halogen or Xenon lamps. Penetrates water better than ordinary lamps Better function of camera shutter and color ballance in most murky waters

SLIDE 14

LED and laser illumination

LED and solid state lamp solutions 100 000 hours life time Vibration resistant High water transmission 70% energy savings makes battery

peration realistic

SLIDE 15

Cooperation partner Bill Stone State of the art sub sea technology Phase array ultrasonic systems AUV systems
