Common Structure Control Panel - Features Graphics LCD display Touch keypad Proxy reader RFID PSTN, GSM and Ethernet communication with CMS ISM Transceiver for 2-Way communication CAN Bus interface for External

SLIDE 1

SLIDE 2

SLIDE 3

SLIDE 4

SLIDE 5

Common Structure

SLIDE 6

Graphics LCD display
Touch keypad
Proxy reader RFID
PSTN, GSM and Ethernet communication with CMS
ISM Transceiver for 2-Way communication
CAN Bus interface for External Peripherals
Two way voice support with echo cancellation
Digital Voice prompts recorder
Alarm Picture Verification
Multilanguage User friendly menu (15 languages)

Features

Control Panel

SLIDE 7

Up to 32 Wireless detectors (2-Way)
Up to 2 Wired zones
Up to 8 Wireless Sirens (2 Way)
Up to 4 Wireless Keypads with full control and configuration
Up to 7 Wired Keypads (CAN bus)
Up to 16 Outputs
External CAN Bus boards support
Receiving pictures from PIR Camera detectors
Wireless 2-Way voice support
Multilanguage Vocal Guide

Control Panel – Peripheral communication features

SLIDE 8

2-Way Wireless Communication Advantages

Efficient communication
Communication indication (at device)
Extended range
Events saved at device until acknowledged
Short message burst (Battery Saving)
Remote device control (walk test)
Low current technology
Dedicated 24 bit ID
Acknowledgment
Missing device ping (supervision)
Encryption option

(AES128 standard)

SLIDE 9

INTRUSION

PIR DETECTION WITH PICTURE SNAPSHOT

TRANSMISSION

Video Verification

Wireless PIR Detector with CMOS Camera and IR Led for night shots
Special DSP Software:
Human Recognition
Reliable and light pictures: Fast transmission
Sending of 1 to 5 pictures. Remote Configuration
All pictures stored in remote server
Battery life 4 years

SLIDE 10

GSM / GPRS Features

Optional Module plugged directly on the board
GSM report channels options:
Contact ID
GSM IP: Ethernet trough GSM
SMS Notifications
Voice Messages

SLIDE 11

REMOTE ACCESS

Control & Configure the Serenity™

Full Remote Status indication
Full Remote Control
Ethernet/GPRS/PSTN connection
User friendly interface
Receiver Server configuration

EasySerenity Remote Control application

SLIDE 12

SLIDE 13

SLIDE 14

SLIDE 15

GSM Module TCP/IP USB WIRELESS INTERNAL SOUNDER

MICROPHONE AUDIO SPEAKER CONNECTIONS FOR:

2 WIRED ZONES
PSTN
2 OUTPUTS
CAN-BUS KEYPADS
POWER SUPPLY
