Cold-gas Propulsion for Small Satellite Attitude Control, Station Keeping, and Deorbit. John Furumo*, Nathan Walsh, Evan Greer, Daniel Wukelic, Dr. A. Zachary Trimble, Dr. Trevor Sorensen. 1 Agenda Small Satellite Background Information


slide-1
SLIDE 1

Cold-gas Propulsion for Small Satellite Attitude Control, Station Keeping, and Deorbit. John Furumo*, Nathan Walsh, Evan Greer, Daniel Wukelic, Dr.

  • A. Zachary Trimble, Dr. Trevor Sorensen.

1

slide-2
SLIDE 2

▶ Small Satellite Background Information ▶ Project Objectives ▶ Cold-Gas System Analysis ▶ Satellite Dynamics ▶ Prototype ▶ Test Results ▶ Conclusion ▶ Future Work and Improvements

2

Agenda

slide-3
SLIDE 3

▶ Small Satellite maneuvers

  • Attitude Control, De-orbit, Orbit Maintenance

▶ 1 year operational lifetime ▶ < 25% total payload mass/volume ▶ Space-rated system ▶ HSFL’s HiakaSat

3

Functional Requirements

slide-4
SLIDE 4

4

Delta-V Budget

Supplemental Slide 48

slide-5
SLIDE 5

5

Propulsion System Trade Study

Category Cold Gas Electric Mono Biprop Size 1.250 2.321 2.488 1.850 Performance 0.003 1.000 0.240 1.300 Feasibility 5.000 2.525 2.150 0.615 Total 6.253 5.846 4.878 3.765

slide-6
SLIDE 6

6

Why We Chose Cold Gas

▶ Simplest satellite propulsion system ▶ Cheap to build (~$5k budget) ▶ Components and propellant gases readily available ▶ UH facilities are sufficient for fabrication and testing ▶ Propellants are safe to handle and test

slide-7
SLIDE 7

▶ Propellant Type

  • Specific Heat Capacity Ratio
  • Molar mass
  • Limited by availability, price

▶ Propellant Storage

  • Volume

⚫ Limited by satellite volume

  • Pressure

⚫ Limited by pressure vessel

  • Temperature

⚫ Limited by spacecraft thermal control

7

Cold-Gas System Performance

slide-8
SLIDE 8

8

Cold-Gas Propellant Options

Cold Gas Propellant N2 CO2 NH3 N2O H2 He Xe Specific Impulse, theoretical, metric (s) 76.8 67.3 108.3 66.2 285.5 174.7 30.0 Propellant Mass (kg) 3.83 6.01 2.32 6.01 0.27 0.55 17.95 Delta-V (m/s) 57.66 79.42 49.37 78.10 15.32 18.74 105.56

Assumptions: Storage Volume = 10 Liters Storage Pressure = 4500 psi (~31MPa) Storage Temp = 0°C

Supplemental Slide 47

slide-9
SLIDE 9

9

System Layout

slide-10
SLIDE 10

▶ Trade-off between

thrust and time

▶ Set amount of ΔV

required for orbit maintenance, deorbit

▶ Variable amount of ΔV

for attitude control

10

From Delta-V to Thrust

slide-11
SLIDE 11

11

System Physics

De Laval Nozzle Diagram [1]

slide-12
SLIDE 12

12

Thruster Design Variables

slide-13
SLIDE 13

13

Thruster Force/Pressure Relation

slide-14
SLIDE 14

14

Preliminary Thrust Analysis

Thrust (N) 0.1 1 10 100 Propellant Mass Flow Rate (kg/s) 0.00015 0.00152 0.01515 0.15152 Thruster Pressure (psi) 3.77 37.67 376.73 3767.25 Total Burn Time (s) 11 hours 66.2 min 6.62 min 40 s

Assumptions: Nozzle Throat Diameter = 1/16” Nozzle Exit Velocity = 660 m/s Propellant = CO2 Propellant mass = 6.01 kg

Supplemental Slide 47

slide-15
SLIDE 15

15

Single Axis Maneuver [1]

tm θm Iv n F L 7.05 s 180° 2.08 kg*m2 2 1 N 0.2627 m (Enough ΔV for 563 maneuvers)

slide-16
SLIDE 16

▶ Non-ACS thrust vs. time

  • Orbit Maintenance
  • Deorbit
  • Different thruster pressures

▶ More accurate way to characterize ΔV requirement for

attitude control

▶ Consult faculty for supersonic flow considerations,

nozzle geometry

▶ Control scheme design ▶ Estimation of end-of-life performance

16

Future Analysis Required

slide-17
SLIDE 17

17

Computational Fluid Dynamics Simulations

slide-18
SLIDE 18

18

Nozzle Simulation

  • Simple turbulent flow

model through a converging-diverging geometry

  • Input boundary

condition of 10 m/s

  • Throat velocity

increases to approximately 100 m/s

slide-19
SLIDE 19

19

slide-20
SLIDE 20

▶ Using tabulated data

  • T1=293.15K, P1=1 atm=101.3 kPa, V1 = 10 m/s
  • A1=0.001257 m2, A2 = 0.0001398 m2
  • a1= 269.37 m/s (calculated speed of sound, ϒ=1.31)
  • M1= V1/a1=0.0307
  • From tables relating M to A/A*:

⚫ A1/A* ≈15, A1/A2 =0.1112, and A2/A*=1.668 ⚫ Using A2/A*, M2≈0.375 ⚫ V2 ≈ 0.375(269.37) = 101 m/s

20

Validation:

slide-21
SLIDE 21

▶ Change in

geometry

▶ Decrease in

throat area

▶ Input condition of

2 m/s

21

Second Simulation

slide-22
SLIDE 22

22

slide-23
SLIDE 23

▶ We wish to simulate the flow under an operating

pressure of 37.7 psi

▶ The turbulent flow physical model within Comsol only

supports flow, Ma < 0.3

▶ We will use the high mach number flow model

23

Future Simulation Work

slide-24
SLIDE 24

▶ Errors have been encountered that suggest the

problem is not fully defined

▶ Attempts to look at the set up of other example

models have failed to solve the problem

▶ We will consult Comsol support to resolve issues of

this model

24

slide-25
SLIDE 25

25

Satellite Dynamics

slide-26
SLIDE 26

26

Moments

slide-27
SLIDE 27

27

Couple Moment

slide-28
SLIDE 28

28

Pairs of Thrusters

Rotation Type Thrusters Used X-Negative 1,5 X-Positive 3,7 Y-Negative 1,3 2,4 1,2,3,4 Y-Positive 5,7 6,8 5,6,7,8 Z-Negative 4,6 Z-Positive 2,8

Maneuvers:

  • Attitude Control (ACS)
  • De-Orbit
  • Orbit Maintenance
slide-29
SLIDE 29

29

Deliverables

slide-30
SLIDE 30

30

Prototype Will Be Built For Testing Flight Model Concept Only

Deliverables

slide-31
SLIDE 31

▶ For 1-axis control testing ▶ 4 Thrusters to control spin in both directions ▶ Nozzle designed for ambient atmospheric application ▶ All parts are COTS other than nozzles ▶ Manually controlled components

31

Prototype

slide-32
SLIDE 32

▶ Full Features ▶ Space worthy components ▶ Differences from prototype

  • 8 nozzles (3-axis control)
  • More custom parts
  • Electronically controlled components
  • Nozzle designed for use in vacuum

32

Flight Model

slide-33
SLIDE 33

33

Manufacturing Approach

slide-34
SLIDE 34

34

Pressure Transducer

Model: PX300 Series [2] Range: 0 to 1000 Psi Accuracy: 0.25% Full Scale Excitation: 10 Vdc (5 to 15 Vdc Limits) Output: 3mV/V ratiometric 30mV ±1mV @ 10V Model: G17M0142F21000# [3] Range: 0 to 1000 Psi Accuracy: +/-0.5% Full Scale Output: 4 to 20 mA at 12 to 30VDC Power Required: 9 to 36VDC

  • Max. Pressure: 2000 psi
slide-35
SLIDE 35

35

Tank

Ninja Carbon Fiber Tank [4] Size: 90 cubic inch Max Tank Pressure: 4500 psi Output Pressure: 800~850 psi Cylinder Weight: 3.3 pounds

http://www.paintballrevolution.com/pureenergy70ci4500psiultrapaintballtank-1-1-1-1-1-1-1-1.aspx http://www.ultimatepaintball.com/p-9515-ninja-carbon-fiber-n2-paintball-tank-90ci4500psi-grey.aspx?CAWELAID=1513094504&catargetid=1391382590&ca gpspn=pla&gclid=CNaozPKA_7MCFSFyQgodNEsA1Q (pic used in CDR)

Luxfer D Air Tank [5] Service Pressure 2015 psi Oxygen Capacity 14.7 cu ft Outside Diameter 4.4” Empty Weight 5.0 lbs Internal Volume 172 cu in Thread Size 0.750-16 UNF-2B

slide-36
SLIDE 36

36

Pressure Regulator

Mega Regulator Dual Stage [6] · Dual Stage Regulator · Adjustable from 0-950 PSI · Tank Thread 5/8(.625)inch -18 UNF PR-57 Series Pressure Regulator [7] · 316L stainless steel construction · 20µ filter · Inlet pressure maximum 10,000 psi · Outlet pressure ranges are 0–10,00 psi · Operating temperatures: −40° F to +150° F

slide-37
SLIDE 37

37

Carbon Dioxide Phase Diagram [8]

slide-38
SLIDE 38

38

Cold Gas Thruster Valve

Solenoid Actuated Thruster Valve (Single Seat) [9] Operating Pressure: 500 psig Response time: 15 ms maximum Power Consumption: 27 Watts Engine Thrust Rating: 40 N Weight: 0.23 kg Type: Stainless Steel Model No. SVS03 [10] Operating Pressure: 1750 psi Response Time: < 10 ms Operating Voltage: 28 ± 4 VDC Engine Thrust: 5 N Weight: 0.110 Kg Type: Stainless Steel

slide-39
SLIDE 39

▶ Completely custom ▶ Throat diameter: 1/16” ▶ Exit diameter: 1” ▶ Area expansion ratio: ~257 ▶ Converging-diverging profile TBD

39

Thruster Nozzles

slide-40
SLIDE 40

40

Project Management

slide-41
SLIDE 41

41

Projected Cost and Budget

slide-42
SLIDE 42

42

Project Schedule

UPDATE

slide-43
SLIDE 43

43

Mahalo!

slide-44
SLIDE 44

[1] Brown, Charles D. “Fig. 2.1 Rocket Nozzle”, Spacecraft Propulsion, 1st Edition. AIAA Press, 1996. [2]http://www.omega.com/pptst/px300.html [3]http://www.drillspot.com/products/1330697/Pressure_Transducer_G17M0142F21000_Pressure_Transducer ?s=1&catargetid=1623454804&gclid=CJv5ydui_bMCFQhyQgod73oA1A [4] http://www.ultimatepaintball.com/p-9515-ninja-carbon-fiber-n2-paintball-tank-90ci4500psi-grey.aspx?CA WELAID=1513094504&catargetid=1391382590&cagpspn=pla&gclid=CNaozPKA_7MCFSFyQgodNEsA1Q [5]http://lakecourt.com/pc_product_detail.asp?key=4A2113A89C1541758F7D665427ACFE6E [6] http://www.sakworldpaintball.com/meredustadta.html [7] http://www.circle-seal.com/products/pressure_regulators/pr57/index.html [8] University of Toronto, “Physics: The Properties of Permafrost” Mentorship Program. Available online. Link: http://www.physics.utoronto.ca/~exploration/UofT-mentorship/Physics_CO2.html [9] http://www.moog.com/products/propulsion-controls/spacecraft/components/thruster-valves/solenoid-act uated-thruster-valve-single-seat-/ [10] http://www.ampacispcheltenham.eu/pages/prsolenoid8.htm

44

References

slide-45
SLIDE 45

45

Supplemental Slide - Old Delta-V Budget

slide-46
SLIDE 46

46

Supplemental Slide - Propulsion System Size Estimates

slide-47
SLIDE 47

Cold Gas Electronic Mono Biprop Solid Performance low med high high very high Thrust .001-3.5N 8-2000mN .19-3780N .009-110kN 25-81kN Specific Impulse 45-73s 500-3000s 200-235s 274-466s 290-304s

47

Supplemental Slide - Propulsion System Performance

slide-48
SLIDE 48

48

Supplemental Slide - Cold Gas Propellants

slide-49
SLIDE 49

49

Supplemental Slide - New Delta-V Budget

slide-50
SLIDE 50

50

Supplemental Slide – System Delta-V

Itotal (N·s): Total propellant mass consumed times the average specific impulse Isp (s): Specific impulse is the thrust generated per unit mass flow rate of propellant

slide-51
SLIDE 51

51

Supplemental Slide – Propellant Choice

Vexit: Exit velocity of exhaust (m/s) k: Specific heat capacity ratio of gas R: Universal gas constant (8.314 J/kmol·K) Mprop: Molar mass of gas (kg/kmol)
