CMPSCI 645 Database Design & Implementation

Instructor: Gerome Miklau

Welcome to

Overview of Databases

Gerome Miklau

CMPSCI 645 – Database Design & Implementation UMass Amherst

Jan 29, 2008

Some slide content courtesy of Zack Ives, Ramakrishnan & Gehrke, Dan Suciu, Ullman & Widom

Today

• Student information form
• Overview of databases
• Course topics
• Course requirements

Databases & DBMS’s

• A database is a large, integrated collection of

data.

• A database management system (DBMS) is a

collection of software designed to store and manage databases, allowing:

– Define the kind of data stored – Querying/updating interface – Reliable storage & recovery of 100s of GB – Control access to data from many concurrent users

Can filesystems do it?

• Schema for files is limited
• No query language for data in files
• Files can store large amounts of data, but

– no efficient access to items within file – no recovery from failure

• Concurrent access not safe

No

Evolution

• Early DBMS’s (1960’s), evolved from

file systems.

• Data with many small items & many

queries or modifications:

– Airline reservations – Banking

Early DB systems

• Tree-based hierarchical data model
• Graph-based network data model
• Encouraged users to think about data

the way it was stored.

• No high level query language

Data model

The data model includes basic assumptions about what’s an “item” of data, how to represent it and interpret it.

The Relational Model

• The relational data model (Codd, 1970):

– Data independence: details of physical storage are hidden from users – High-level declarative query language

• say what you want, not how to compute it.
• mathematical foundation

– A theory of normalization guides the design of relations Side-note: Turing Awards in Databases 1973: Bachman, networked data model 1981: Codd, relational model 1998: Jim Gray, transaction processing

DBMS Benefit #1: Generality and Declarativity

• The programmer or user does not need to

know details like indices, sort orders, machine speeds, disk speeds, concurrent users, etc.

• Instead, the programmer/user programs with

a logical model in mind

• The DBMS “makes it happen” based on an

understanding of relative costs of different methods

Benefit #2: Efficiency and Scale

• Efficient storage of hundreds of GBs of data
• Efficient access to data
• Rapid processing of transactions

Benefit #3: Management of Concurrency and Reliability

• Simultaneous transactions handled safely.
• Recovery of system data after system failure.
• More formally: the ACID properties

– Atomicity - all or nothing – Consistency - sensible state not violated – Isolation - separated from effects – Durability - once completed, never lost

How Does One Build a Database?

• Start with a conceptual model
• Design & implement schema
• Write applications using DBMS and other

tools

– Many ways of doing this (DBMS, API writers, library authors, web server, etc.) – Common applications include PHP/JSP/servlet- driven web sites

• The DBMS takes care of query optimization

and execution

Conceptual Design

STUDENT COURSE Takes name sid cid name PROFESSOR Teaches semester fid name

Designing a Schema (Set of Relations)

• Convert to tables +

constraints

• Then need to do

“physical” design: the layout on disk, indices, etc.

sid name 1 Jill 2 Bo 3 Maya fid name 1 Diao 2 Saul 8 Weems sid cid 1 645 1 683 3 635 cid name sem 645 DB F05 683 AI S05 635 Arch F05 fid cid 1 645 2 683 8 635

STUDENT Takes COURSE PROFESSOR Teaches

Queries

• Find all courses that “Mary” takes
• What happens behind the scene ?

– Query processor figures out how to answer the query efficiently. SELECT C.name FROM Students S, Takes T, Courses C WHERE S.name=“Mary” and S.sid = T.sid and T.cid = C.cid

Queries, behind the scene

Query execution plan: SELECT C.name FROM Students S, Takes T, Courses C WHERE S.name=“Mary” and S.sid = T.sid and T.cid = C.cid Declarative SQL query

Students Takes

sid=sid sname name=“Mary” cid=cid

Courses

The optimizer chooses the best execution plan for a query

An Issue: 80% of the World’s Data is Not in a DB!

Examples:

– Scientific data (large images, complex programs that analyze the data) – Personal data – WWW and email (some of it is stored in something resembling a DBMS)

Data management is expanding to tackle these problems

DBMSs in the Real World

A huge industry for 20% of the world’s data!

• Big, mature relational databases

– IBM DB2, Oracle, Microsoft SQL Server – Adding advanced features, including “native XML” support

• “Middleware” above these systems

– SAP, Siebel, PeopleSoft, dozens of special-purpose apps

• Integration and warehousing systems

– BEA AquaLogic, DB2 Information Integrator

• Current trends:

– Web services; XML everywhere – Smarter, self-tuning systems – Distributed databases, column-stores

Database Research

• One of the broadest, most exciting areas in CS!
• A microcosm of CS in general
• languages, operating systems, concurrent

programming, data structures, algorithms, theory, distributed systems, statistical techniques.

• Theory and systems well-integrated.

Recent Trends in Databases

• XML

– Relational databases with XML support – Middleware between XML and relational databases – Large-scale XML message systems

• Main memory database systems
• Peer data management
• Stream data management
• Model management, provenance
• Security and privacy
• Modeling uncertainty, probabilistic databases

What is the Field of Databases ?

• To an applied researcher (SIGMOD/VLDB/ICDE)

– Query optimization – Query processing (yet-another join algorithm) – Transaction processing, recovery (but most stuff is already done) – Novel applications: data mining, high-dimensional search

• To a theoretical researcher (PODS/ICDT/LICS)

– Focus on the query languages – Query language = logic = complexity classes

Course topics

• Fundamentals: relational design, query

languages.

• Theory: expressiveness of query languages,

static analysis, complexity.

• Database internals: storage, indexing, query

processing, query optimization, transaction management.

• XML and semi-structured data models.
• Security: access control, privacy.
• Advanced topics: incomplete/probabilistic

DBs, parallel and distributed DBs.

Prerequisites

• Official: undergrad course in DB or OS
• Also:

– Elementary complexity theory

Grading

• Homework: 30%
• Paper reviews & participation: 15%
• Midterm: 30%
• Project: 25%

Homework: 30%

• ~ 4 assignments throughout the course

– written problem sets – practical experience with SQL, XQuery

Paper Reviews & Participation: 15%

• Approximately 5 classic papers will be

assigned

• Short written reviews are due before

the day of class. Email to:

– cs645-reviews@cs.umass.edu

First paper review: Read thru 1.4 of Codd’s paper Due Wed Feb 5th

Project: 25%

• General theme: apply database principles to a new

problem

• Suggested topics will be discussed next Tuesday
• Groups of 2 preferred. 3 possible.
• Project work will include:

– Reading some of the research literature – Implementation – Written report – In-class presentation

• Periodic consultation with the instructor

Midterm Exam (30%)

• Midterm scheduled for Apr 17th at 7pm
• (No Final!)

Textbook

Database Management Systems

Ramakrishnan and Gehrke

Other useful resources

• Database systems: the complete book (Ullman,

Widom and Garcia-Molina)

• Readings in Database Systems (Stonebraker and

Hellerstein)

• Foundations of Databases (Abiteboul, Hull, Vianu)
• Data on the Web (Abiteboul, Buneman, Suciu)
• Parallel and Distributed DBMS (Ozsu and Valduriez)
• Transaction Processing (Gray and Reuter)
• Data and Knowledge based Systems (volumes I, II)

(Ullman)

• Proceedings of SIGMOD, VLDB, PODS conferences.

Communication

• Instructor

– Office hours: by appointment – Email: miklau at cs dot umass dot edu

• Check the course webpage often
• You should have been added to the

mailing list.

31

Questions about the course?

32
