Faster MySQL replication using dependencies

Abhinav Sharma Facebook Inc.

2

Motivation

Replication lag is bad news

• Stale reads on slaves
• Potential data-loss

3

Motivation

Can we eliminate replication lag? No!

• There will always be a finite replication lag
• Network delay (bounded by speed of light)
• Transaction processing on the slave
• Minimum lag = Network lag + Transaction time

4

Motivation

Can we have bounds on replication lag? Yes!

• Increasing lag is a function of difference in throughput between

master and slave

• Given master and the slave run on similar hardware and the slave is

able to utilize it at least as much as the master we should never see unbounded lag

5

Problem

Log shipping

• Parallel transactions on the master are serialized in a log
• Slave sees a linear stream of transactions that it can apply one-by-
• ne to obtain a serializable schedule
• Master is multithreaded, slave is single threaded
• Throughput differential causes unbounded lag

6

Problem

Log shipping

Master Slave

Tx1 Tx2 Tx3 Tx1 Tx2 Tx3 Tx1 Tx2 Tx3

7

Solution

Log shipping with batching information

• Record information about batching at the master in the log
• Trivially, all transactions that commit together at the master can be

executed in parallel on the slave (group commit)

8

Solution

Log shipping with batching information

Master Slave

Tx1 Tx2 Tx3 Tx1 Tx2 Tx3 Tx4 Tx5 Tx1 Tx2 Tx3

9

Problem

Log shipping with batching information

• This still misses some independent transactions because we’re

checking transactions that “committed” together not “executing” together

• Batch size gets smaller with each hop in chain replication

10

Solution

Tracking dependencies between transactions

• By definition we just need to satisfy RW and WW conflicts
• Logs are awesome for shipping but they’re one dimensional
• Row based format of MySQL already has all the data required to find

RW and WW conflicts!

• Convert the log into a DAG of conflicts

11

Solution

Tracking dependencies between transactions

Master Slave

Tx1 Tx2 Tx3 Tx1 Tx2 Tx3 Tx4 Tx5 Tx1 Tx2 Tx4 Tx4 Tx3 Tx5 Tx5

12

Problem

Tracking dependencies between transactions

• Are we done? Not yet…
• We’re serializing transactions even if a single row is common

between them

• On the master two conflicting transactions can run partially in

parallel, on the slave we’re serializing them completely

• Extreme example: A workload where all transactions conflict will be

serialized on a single thread on the slave

13

Solution

Tracking fine grained dependencies

• Track conflicts between individual row events
• Dispatch events to workers immediately and pause execution on the

workers for conflicting events

• It can be proved that this is a necessary and sufficient condition to

achieve bounded lag

14

Solution

Tracking fine grained dependencies

Tx1 Tx2 Tx1 Tx2

Transaction granularity Row granularity

vs.

15

Solution

Tracking fine grained dependencies

Master

Tx1 Tx2 Tx3 Tx1 Tx2 Tx3 Tx4 Tx5 Tx4 Tx5

Slave

Tx1 Tx2 Tx3 Tx4 Tx5

16

Solution

Tracking fine grained dependencies

• What about ordering of commits?
• Commit ordering is sometimes important for reads on the slave
• Two ways to solve this:
• Never commit a transaction before it’s preceding transaction is
• committed. Trivial, easy to implement but can increase commit

latency

• Commit out of order and take periodic checkpoints at a prefix of the
• log. All clients read from the checkpoint. Caveat: This will still

produce slave logs that are out of order

• If we treat commit order as a kind of conflict, the 1st solution is

analogous to conflict serializable and the 2nd to view serializable

17

Solution

Tracking fine grained dependencies: Commit ordering

Tx1 Tx2

Checkpointing Force Order

Execution done Commit done

Wait for commit

Prev Checkpoint Next Checkpoint

Commit out of order Execute out of order but commit after checkpoint

RO transactions always see prefix of the log

18

Solution

sysbench write-only

5000 10000 15000 20000 25000 30000 50 100 150 200 250 300

TPS Threads

sysbench write-only

Master Slave Old Slave

~4-5x ~1.3x

19

Solution

Fully conflicting workload

1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 50 100 150 200 250 300

TPS Threads

Fully conflicting workload

Master Slave Old Slave

MySQL 8.x WRITE_SET will also behave like this

20

Solution

Tracking fine grained dependencies Can we do any better? Yes!

• Eliminate 2PL
• If replication workers are the only ones writing we can disable row

locking altogether because we take care of conflicts explicitly

• Replication threads will need to run in READ UNCOMMITTED

isolation level

• Rely on MVCC for consistent client reads
• Transaction rewriting
• Tx1: update tb1 set a = 2 where a = 1
• Tx2: update tb1 set a = 3 where a = 2
• Rewrite as Tx1 + Tx2: update tb1 set a = 3 where a = 1

21

Problems

Tracking fine grained dependencies Some implementation problems

• Coordinator/scheduler is the bottleneck. Anything more we do to

make transaction processing faster is useless right now

• Unpacking row events to find keys is expensive
• Interaction between IO and SQL thread make things worse

22

MySQL 8.x WRITE_SET

• MySQL 8.x supports WRITE_SET replication which uses transaction level

dependencies extracted at the master

• Workers are simple in WRITE_SET, both conflict detection and resolution

happens in the coordinator

• We use finer granularity than WRITE_SET and don’t sacrifice anything on

the master

• We also separate conflict detection (in the coordinator) and conflict

resolution (in the workers) which allows better parallelization

23

Future Plans

• Getting the best of both worlds
• Use WRITE_SET to give hints about dependencies
• All independent transactions go straight to the workers
• Parse out finer row dependencies only for conflicting transactions

24

Resources

Code: https://github.com/facebook/mysql-5.6 Relevant variables:

• mts_dependency_replication = {NONE|TBL|STMT}
• mts_dependency_order_commits = {0|1}
• slave_tx_isolation = {keep it at READ-COMMITTED or

lower}

25
