CHOICIRCIATI CULTURAL CENTER EXPANSION MANHATTAN COMMUNITY BOARD 3 - - PowerPoint PPT Presentation

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016

CHOICIRCIATI CULTURAL CENTER EXPANSION

MANHATTAN COMMUNITY BOARD 3 LANDMARKS PRESERVATION COMMISSION PRESENTATION

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 EXISTING BUILDING PHOTO EXISTING CHOICIRCIATI CULTURAL CENTER BUILDING AS SEEN FROM E 4TH STREET

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 PROPOSED CHOICIRCIATI CULTURAL CENTER BUILDING AS SEEN FROM E 4TH STREET PROPOSED BUILDING RENDER

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 LOCATION PLAN AT BOROUGH SCALE CHOICIRCIATI CULTURAL CENTER BUILDING IS LOCATED IN MANHATTAN N

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016

CHOICIRCIATI CULTURAL CENTER E 4TH ST 2ND AVE BOWERY E 3RD ST

LOCATION PLAN AT BLOCK SCALE BUILDING IS LOCATED IN EAST VILLAGE. N

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 SITE PHOTO AERIAL VIEW OF SITE AND BUILDING

CHOICIRCIATI CULTURAL CENTER

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 4TH STREET SOUTH ELEVATION BUILDING IS LOCATED ON THE SOUTH SIDE OF 4TH STREET

2 Av 1 Av E 4 St Av A E 7 St E 6 St E 3 St E 2 St E 5 St

• St. Mark's Pl

Bowery 3 Av

East Village / Lower East Side Historic District

Queens Brooklyn Manhattan

Boundary of Historic District

Landmarks Preservation Commission Calendared: June 28, 2011 Public Hearing: June 26, 2012 Designated: October 9, 2012

Existing Historic Districts East Village/Lower East Side Historic District

¯

250 Feet Tax Map Lots in Historic District

East Village / Lower East Side Historic District Borough of Manhattan, NY [LP-2491] NoHo Historic District Extension NoHo East Historic District

Boundaries of Existing Districts

CHOICIRCIATI CULTURAL CENTER 1 2 3 4 5 6 7 8 9 10 11 12 13 14

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 4TH STREET SOUTH ELEVATION EXAMPLE ELEVATIONS ALONG 4TH STREET

1 8 2 9 3 10 11 12 4 5 13 6 14 7

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 4TH STREET SOUTH ELEVATION

10 12 3

ENLARGED EXAMPLE ELEVATIONS ALONG 4TH STREET: ARTICULATION OF THE COMMERCIAL BASE

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 STREET ELEVATION DIAGRAM NOT TO SCALE CLEAR DISTINCTION BETWEEN ORIGINAL RESIDENTIAL STRUCTURES AND NEWER COMMERCIAL BASE MODIFICATIONS

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016

57 54 86 91

B

• w

e r y

LA MAMA Rod Rodgers & DUO Downtown Art & Alpha Omega Theatrical Dance Company New York Theater Workshop LA MAMA

EAST 4TH STREET CULTURAL DISTRICT THEATER COMPANIES AT STREETFRONT

New York Theater Workshop Fourth Street Theatre Kraine Theater

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 HISTORICAL DEVELOPMENT Photograph from 1875; view of the middle four (and part of a fjfth) of the original twelve houses of Albion Place, built in 1832. The building on the right is 64 E 4th Street. Originally built as a three story building, very similar to the building with the ‘Lager Bier’ sign to the left, this photograph shows it already with its one story addition.

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 HISTORICAL DEVELOPMENT

1870’s 1930’s

Photograph from 1875; isolated view

• f No. 64 addressed

for “Metropolitan Assembly Rooms”,

• perating as a

boarding house. Note the asymmetrical facade. Tax photo (1939) provides the fjrst visual evidence of the 1906 storefront additions at the basement and parlor

• fmoors. The stoop,

handrail, and doors remains, but modifjed. An ornamental fjre escape has been

• added. Also note brick

wing wall supporting new storefront. The accompanying cornice and staircase protrude beyond the property line.

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 HISTORICAL DEVELOPMENT

1980’s 1970’s

Note deteriorating storefront and the missing counterweight fjre escape stair. Facade partially boarded up. Storefront is entirely non-operational and the remaining elevation exhibits full deterioration. While stoop remains, handrails have disappeared.

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 HISTORICAL DEVELOPMENT

2015 2000’s

Storefront is removed

• completely. Replaced

masonry facade is aligned with the plane

• f the original facade.

Fire escape is also

• missing. Note the

new large centered

• pening.

Damaged windows and masonry is

• restored. Note the

remaining masonry wing wall and the

• riginal cornice.

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 BUILDING CONCEPT DIAGRAM NOT TO SCALE

• riginal:

1832-1906 proposed condition first storefront addition: 1906-1980s existing condition: 1990s-present

REGISTRATION OF LAYERED HISTORY OUTLINING A SERIES OF FACADE EXTENSIONS

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 HISTORICAL DEVELOPMENT REMAINING MASONRY WINGWALL, LACK OF ENGAGEMENT WITH THE STREET

1930’s STOREFRONT VOLUME ADDITION 2016: RECAPTURING STOREFRONT VOLUME

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 BUILDING ELEVATION DIAGRAM NOT TO SCALE ELEVATION DIAGRAM 1930’S FRONT ELEVATION CURRENT FRONT ELEVATION 1870’S FRONT ELEVATION PROPOSED FRONT ELEVATION

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 EXISTING AND PROPOSED FACADES E 4TH STREET ELEVATION (SOUTH) EXISTING FRONT ELEVATION PROPOSED FRONT ELEVATION

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 EXISTING AND PROPOSED FACADES E 4TH STREET ELEVATION (SOUTH) PROPOSED FRONT ELEVATION ANGLED MULLIONS & THREE WINDOW BAY ALIGNMENT UPPER PLAN OF FACADE LOWER PLAN OF FACADE

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016

EXISTING & PROPOSED CELLAR FLOOR PLAN 1/8”=1’-0”

UTILITY ROOM CONTROL BOOTH WOMEN’S RESTROOM WOMEN’S RESTROOM ACCESSORY CLASSROOM STAIR 2 REST ROOM DRESSING ROOM DRESSING ROOM DRESSING ROOM DRESSING ROOM REST ROOM LOBBY MEN’S RESTROOM MEN’S RESTROOM MECHANICAL LOBBY STAIR 3 STAIR 1 LIFT

UTILITY ROOM CONTROL BOOTH WOMEN’S RESTROOM WOMEN’S RESTROOM ACCESSORY CLASSROOM STAIR 2 REST ROOM DRESSING ROOM DRESSING ROOM DRESSING ROOM DRESSING ROOM REST ROOM LOBBY MEN’S RESTROOM MEN’S RESTROOM JANITORS MECHANICAL LOBBY STAIR 3 STAIR 1 LIFT

EXISTING PROPOSED

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016

EXISTING AND 1ST FLOOR PLAN 1/8”=1’-0”

STAIR 1 LOBBY LIFT CONTROL BOOTH MULTI-PURPOSE ROOM STAIR 2 STAIR 1 LOBBY LIFT STAIR 3 CONTROL BOOTH STORAGE MULTI-PURPOSE ROOM STAIR 2

EXISTING PROPOSED

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 EXISTING SECTION NOT TO SCALE

LOBBY LOBBY ACCESSORY OFFICE ACCESSORY OFFICE ACCESSORY OFFICE ACCESSORY CLASSROOM ACCESSORY CLASSROOM ACCESSORY CLASSROOM ACCESSORY CLASSROOM DRESS- ING ROOM DRESS- ING ROOM DRESS- ING ROOM PASSAGE MULTI-PURPOSE ROOM MECHANICAL ROOM STAIRWELL STAIRWELL STAIRWELL

EXISTING

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 PROPOSED SECTION NOT TO SCALE

LOBBY

PROPOSED

LOBBY ACCESSORY OFFICE ACCESSORY OFFICE ACCESSORY OFFICE ACCESSORY CLASSROOM ACCESSORY CLASSROOM ACCESSORY CLASSROOM ACCESSORY CLASSROOM DRESS- ING ROOM DRESS- ING ROOM DRESS- ING ROOM PASSAGE MULTI-PURPOSE ROOM MECHANICAL ROOM STAIRWELL STAIRWELL STAIRWELL

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 DAY RENDERING NOT TO SCALE SIDE PERSPECTIVE OF EXISTING AND PROPOSED CONDITION

EXISTING PROPOSED

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016

PROPOSED EXISTING

DAY RENDERING NOT TO SCALE FRONT PERSPECTIVE OF EXISTING AND PROPOSED CONDITION

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016

PROPOSED EXISTING

DAY RENDERING NOT TO SCALE FRONT PERSPECTIVE OF EXISTING AND PROPOSED CONDITION DAY RENDERING NOT TO SCALE FRONT PERSPECTIVE OF EXISTING AND PROPOSED CONDITION (FULL FACADE VIEW)

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016

PROPOSED EXISTING

DAY RENDERING NOT TO SCALE DAY RENDERING NOT TO SCALE SIDE PERSPECTIVE OF EXISTING AND PROPOSED CONDITION

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 VARIOUS PERSPECTIVE CONDITIONS OF THE PROPOSED FACADE SYSTEM

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 ENLARGED PROPOSED ELEVATION NOT TO SCALE WING WALL: HISTORIC BRICK METAL SIGNAGE: FRONT FACE POWDER-COATED STEEL TO MATCH MULLIONS ADDRESS SIGNAGE: POWDER-COATED STEEL NUMBERS “64” FIXED TO SIDE OF MULLION MONITOR: BEHIND GLAZING FOR PROGRAMMING INFO DISPLAY SIDEWALK SIAMESE: CAST BRASS STOREFRONT: STEEL MULLIONS W/ RECESSED GLAZING ORGANIZATION STRATEGY & MATERIAL PALETTE RECESSED MAILBOX: STAINLESS STEEL

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 FACADE MATERIAL WING WALLS: HISTORIC BRICK STOREFRONT INFILL: STEEL MULLIONS WING WALLS: HISTORIC BRICK NEW STOREFRONT: STEEL MULLIONS WITH RECESSED GLAZING

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 FACADE MATERIAL METAL SIGNAGE: POWDER COATED STEEL/ REFLECTIVE CHROME METAL SIGNAGE: POWDER COATED STEEL FRONT/REFLECTIVE CHROME BACK SIGN FONT: FRANKLIN GOTHIC DEMI-REGULAR FIN MOUNTED RUST-PROOF. 20 GAUGE THICKNESS FOR DURABILITY. MEDIUM-GLOSS FINISH. REFLECTIVE CHROME POWDER COATED STEEL

FRONT ELEVATION AXONOMETRIC

(NOT VISIBLE) 2’-6 1/2” 1’-6” 3” 10’-0” 2’-6 1/2” 2’-3” (LEGIBLE)

SIDE ELEVATION

METAL SIGNAGE

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 FACADE MATERIAL ADDRESS SIGNAGE: POWDER-COATED STEEL MONITOR: PROGRAMMING INFO DISPLAY ADDRESS SIGNAGE: POWDER-COATED STEEL FIXED TO SIDE OF MULLION MONITOR: INSTALLED BEHIND GLAZING FOR PROGRAMMING INFO DISPLAY Sony KLV-32R306 32” BRAVIA HD

FRONT ELEVATION

(NOT VISIBLE) (LEGIBLE)

SIDE ELEVATION

ADDRESS SIGNAGE

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016 RECESSED MAILBOX: STAINLESS STEEL SIDEWALK SIAMESE: CAST BRASS SIDEWALK SIAMESE: MOON AMERICAN #231. CAST BRASS, 18” SLEEVE, ESCUTCHEON PLATE AND PLUGS. MAILBOX: CUSTOM DESIGN. STAINLESS STEEL. BRUSHED STEEL

DEPARTMENT OF DESIGN AND CONSTRUCTION CHOICIRCIATI CULTURAL CENTER 05.03.2016

CHOICIRCIATI CULTURAL CENTER EXPANSION

MANHATTAN COMMUNITY BOARD 3 LANDMARKS PRESERVATION COMMISSION PRESENTATION
