Characterization of Potential Carbon Sequestration Targets in New York State Brian Slater 1 , Alexa Stolorow 1 , Langhorne Smith 1 Kathryn Tamulonis 2 , John Conrad 3 1 NY State Museum 2 Cornell University 3 Conrad Geoscience Corp. CAP ROCK CAP

SLIDE 1

Characterization of Potential Carbon Sequestration Targets in New York State

Brian Slater1, Alexa Stolorow1, Langhorne Smith1 Kathryn Tamulonis2, John Conrad3

1NY State Museum 2Cornell University 3Conrad Geoscience Corp.

SLIDE 2

SLIDE 3

SLIDE 4

SLIDE 5

CAP ROCK CAP ROCK CAP ROCK CAP ROCK

TARGET

CAP ROCK

TARGET TARGET TARGET

SLIDE 6

SLIDE 7

AES Delaney Well ~20 Miles 1634.5’ 1640’

Delaney Well (31-011-13645-00-00)

SLIDE 8

Porosity In the Delaney Well

SLIDE 9

SLIDE 10

Barron Well

High Resolution Isopach Map

shows that the AES Power Plant lies in what appears to have been a channel during deposition of the Queenston and therefore has a thicker section of the formation.

Capacity Calculations indicate

that the 25 square mile area surround the plant could hold up to 38.5 million tons of CO2 (16 years of output from the AES power plant).

SLIDE 11

Hydrothermal Dolomite Reservoirs

Whiteman #1 well

From County Line Field
Well has produced about 0.5 BCF to date
Vuggy porosity lines with saddle dolomite
Permeability up to >10 darcies in some whole core

measurements

SLIDE 12

SLIDE 13

Trenton Black River Production

SLIDE 14

Enhanced Oil/Gas Recovery

SLIDE 15

The Galway Formation is made up of 3 sandy sections (Rose Run, B-Sand, C-Sand), 2 dolomitic sections (A- Dolomite and B-Dolomite), and 2 interbedded transition zones (Rose Run Interbedded and B-Interbedded) Although these sections may be labeled or depicted as sandstones and dolomites, the range of lithology more accurately varies from dolomitic sand to sandy dolomite.

SLIDE 16

2854’ 2841’ 1 mm

1 2 3 4 5 6 7 8 9 2 4 6 8 10 12 Porosity (%) Permeability (md)

2866’

SLIDE 17

Basal Little Falls Rose Run

SLIDE 18

6370.5’ 0.5 mm 7100’ 0.5 mm 7070’ 1mm

SLIDE 19

Lab Results

y = 0.0005e0.8862x 0.0001 0.001 0.01 0.1 1 2 4 6 8 Porosity at NCS, percent Permeability to Air, millidarcys

Vacuum Dried @ 180F Net Confining Stress: 1200 psi

Sidewall Cores

y = 0.0006e1.1946x y = 0.0018e0.4087x 0.0001 0.001 0.01 0.1 1 10 100 2 4 6 8 10 12 Porosity at NCS, percent Permeability to Air, millidarcys Pilot Samples Conventionals

Conventional Core Plugs

SLIDE 20

Comparison to Nearby Wells

SLIDE 21

Deepest Well in the state (13,500’)
1,750 feet of Cambrian Sands
Cored intervals will be studied in the future

SLIDE 22

Newark Rift Basin

NB-1

(From Schlische et al, 2005) From USGS, 2003 http://3dparks.wr.usgs.gov/nyc/mesozoic/newarkbasin.htm

I-80

From Schlische et al, 2005

SLIDE 23

Offshore Sequestration

Georges Bank Baltimore Canyon Trough

SLIDE 24

Baltimore Canyon Trough

SLIDE 25
