Notes for presentation to Carbon Sequestration Working Group February 9, 2009

Brian Jeffries Executive Director Wyoming Pipeline Authority

Lake DeSmet DKRW Madden

16” 12” 16” 20” 16”

A (very) rough outline

• f a CO2 grid to serve

Wyoming – roughly 400 miles of new line Existing Exxon/Anadarko System Exxon

Slide from WPA presentation at Big Sky Sequestration Partnership Annual Energy Forum August 23, 2007 Bozeman, MT (Reflects “back of an envelope” level of analysis)

Design Issues for an integrated system

• Locations of sources and sinks
• Different quality requirements
• Different pressure requirements/availabilities
• Compression responsibility
• Incremental treating
• Single system possible?

Output goals for WPA – EORI effort

• What would a system that benefited

from clairvoyance look like

• A first level cost estimate of such a system
• Provide a common framework for discussion
• WPA and EORI to provide update of study
• n May 19th after WPA public meeting in

Casper

Developing CO2 Sources in Wyoming

Scoped Field Reservoir Combinations and Sources (and Sequestration sites)
