Cell-based Architecture An Emerging Architecture Pattern for Agile - - PowerPoint PPT Presentation

Asanka Abeysinghe

Cell-based Architecture

An Emerging Architecture Pattern for Agile Integration

Deputy CTO & VP, Architecture - CTO Office WSO2 Inc.

2019 1997 2003

Architect

2012

VP Solutions Architecture

2001 2008

Director Solutions Architecture Deputy CTO Open Source Distributed Computing Programmer COBOL

OLE, OLE2 COM, COM+ DCOM CORBA

Java Developer

J2EE MMS 286-DX4 Eventing FIX HL7

Co Co

CONNECT-health Global architecture team 500+ customers Champions program

Chief Architect

2005

QSP AR Trusted advocate

Game hacker C++ programmer

Age-16

Hedge fund tools

• Ref. Architecture
• Ref. Methodology

Evangelize

2018

Middleware Developer/Architect

Entrepreneur

Objectives #1 why: created a new pattern #2 introduce: Cell-based architecture

picture credit: https://www.flickr.com/

Motivation

Centralized & Layered

picture credit: https://www.flickr.com/photos/kaktuslampa/

Centralized & Layered

picture credit: https://www.flickr.com/photos/kaktuslampa/

picture credit: https://www.flickr.com/photos/69929929@N06/

Powerpoint Architects

picture credit: https://www.flickr.com/photos/johnerlandsen/

Reality of the Enterprise

Brownfield > Greenfield

picture credit: https://www.apstra.com/home/landscape-of-meadow-field-with-the-changing-environment-2/

Legacy, monolithic Microservices, sprawl

Reference Implementations

picture credit: https://www.marinersmuseum.org/

picture credit: http://unlocked.footlocker.com/

Underutilization of the Technology

Gap: architecture | development | deployment

picture credit: https://www.flickr.com/photos/28994379@N02/

picture credit: https://www.solarpowerworldonline.com/2017/07/georgia-contractor-sells-farmers-solar-tough-market/

Dependency management

picture credit: https://www.solarpowerworldonline.com/2017/07/georgia-contractor-sells-farmers-solar-tough-market/

Dependency management

picture credit: https://www.flickr.com/photos/tiocfaidh_ar_la_1916/

Architecture Patterns

Timeline

Background: Layered Architecture

picture credit: https://www.flickr.com/photos/23119666@N03/

A platform with an agile team

100 APIs, 60 message flows, 80 services, n DBs Multi-tenanted, 3 active tenants First release after 3 years

picture credit: https://www.flickr.com/photos/imcountingufoz/

Rise of Microservices

Pragmatic Microservices

Netflix: APIs Uber: Edge Gateway eBay: API Facade Gartner: Mini Services

Background: Layered Architecture with MSA

Background: Segmented Architecture

BS-1 BS-2 BS-n G-1 G-2 US-1 US-n

Platform of Platforms

Platform (shared capabilities) Project 1 Project 2 Project 3 Project n Platform (shared capabilities) Project 1 Project 2 Project 3 Project n Platform (shared capabilities) Project 1 Project 2 Project 3 Project n Platform (shared capabilities) Project 1 Project 2 Project 3 Project n

CI/CD User Store

picture credit: https://www.flickr.com/photos/ableman/

Making of……

picture credit: https://commons.wikimedia.org/wiki/User:Frank_Schulenburg CC BY 3.0

picture credit: https://clutchpoints.com/phil-jackson-talks-about-the-kobe-bryant-michael-jordan-comparison/

Paul Fremantle - CTO, Co-Founder - WSO2

Building the Concept

Business vs technical services

picture credit: https://www.flickr.com/photos/arpadlukacs/

Service: Technical definition

A code exposes through an interface that describes a collection of operations that are network accessible using a standardized messaging protocol.

Service: Business definition

Software components that can be spontaneously discovered, combined, and recombined to provide a solution to a business problem.

Microservice: Technical definition

A microservice must have a single purpose and be loosely coupled in design and deployed independently of

• ther microservices.

"Micro" is a concept of scope rather than size.

Microservice: Business definition

Microservices is an approach to application development in which a large application is built as a suite of modular components or services. These services are built around business capabilities.

Group of (Micro)services

The cell is the basic structural, functional, and biological unit of all known living organisms

Cell-based Reference Architecture

Component: Atomic Units

A component represents a process or business logic running in a container, serverless environment, or an existing runtime. A component is designed based on a specific scope, which can be independently run and reused at the runtime.

Cell: Units of Enterprise Architecture

A cell is a collection of components, grouped from design and implementation into deployment. A cell is independently deployable, manageable, and observable.

Cell:Component 1:M 1:1

Connected Cells

picture credit: https://www.medicalnewstoday.com/

Control Plane:

• Signaling of the network
• Makes decisions about the traffic flow

Data Plane:

• Forwards traffic between hops
• Takes data packets

picture credit: https://www.flickr.com/photos/teflon/

Management Plane:

• Configure
• Observeabiltty, Monitor

Inter and Intra Cell communication

DP- data plane CP- control plane MP- management plane

Inter and Intra Cell communication

Local-mesh Global-mesh

DP- data plane CP- control plane MP- management plane

Connected Cells

Cell gateway (ingress) Sidecar (egress) Adaptor (egress) Ambassador (egress)

API-centric Architecture

picture credit: https://www.flickr.com/photos/hugh_nelson/

API-centric Architecture

API-centric Architecture

Pull APIs

• RESTful HTTP, gRPC

Push APIs

• Events JMS, AMQP, SMTP
• Streams Kafka, MQTT

Gateway Pattern

picture credit: https://www.flickr.com/photos/ell-r-brown/

Automated Governance (Re)-enables Flow

Policy Store (Registry) Observability (Monitoring/
 Analytics) Policy
 Enforcement (GW)

Automated governance is made

• f three things:

A source of truth:

Policy store/registry

Enforcement of the policy

Gateway or plugin attempting to keep the desired state

Observability

How close to the desired state are we?

Security of Cells

picture credit: https://www.flickr.com/photos/laurelfan/ https://www.flickr.com/photos/sahdblunders/

Security of Cells

Developer Experience (DX)

• f a Cell

Creating Cells

Brand new Cell Existing (micro)services Update an existing Cell Create a new version

Lifecycle of a Cell

picture credit: https://www.flickr.com/photos/rincon_de_lula/

Structured Agility

Versioned Components Versioned Cells Dependency managed Autowired Reusable Enhanced MSA & CNA

Cell-based Enterprise Architecture

Cell Types

Cell Type Components

Logic Microservices, Functions, MicroGateways, lightweight storages Integration MicroESB or other integration microservices, lightweight storage and/or cache Legacy Existing systems, legacy services External SaaS and partner systems Data RDBMS, NoSQL, File, Message Broker* Identity IDP, user stores Channel Web Apps, IoT, mobile apps

Reference Implementation L0

Reference Implementation L1

Human-centric Architecture

picture credit: https://www.vertoanalytics.com/human-vs-data-centric-marketing/

Cells and Podular Organizations

picture credit: https://www.flickr.com/photos/woordenaar/

Cell Boundaries

Defining Cell boundaries

The design of systems has always required an approach to the clustering of functionality, and it remains an open Computer Science problem - so don't expect a definitive answer! The number of component-component connections within a cell should be higher than the number that crosses the cell boundary. Other approaches such as Domain-driven Design (DDD) may help, but fundamentally the cell model is there to provide team boundaries.

Hence the size of a cell should be based on the size, responsibility, and output of a team

• and the size and output of a team based on team concepts.

Cell-based architecture aims to create business focussed architectural constructs that can reuse at a higher level, so naturally organizing the teams and cells around business functions is essential.

Measure the success

picture credit: https://www.marketingdonut.co.uk/direct-marketing/running-a-direct-mail-campaign/getting-the-measure-of-your-marketing

https://www.tasktop.com/blog/5-best-metrics-youve-never-met/ https://dzone.com/articles/reducing-mttr

Mean Time to Repair

Self-contained Deployable as a unit Independently elastic Data, control & management plane

Summary: Cell-based Architecture

My Contribution: walk the talk

picture credit: https://www.omgubuntu.co.uk/2018/06/microsoft-buying-github

picture credit: https://www.flickr.com/photos/josephmorris/

Just a (steady) start

https://github.com/wso2/reference-architecture

picture credit: https://www.flickr.com/photos/vasile23/

https://github.com/wso2/reference-methodology

Reference Methodology

https://cellery.io/

Build, run, and manage code-first composites

• n

Kubernetes

Cellery - simple composition and graphical view

A cloud-native programming language for microservices and APIs

• A compiled, transactional, statically and

strongly typed programming language with textual and graphical syntaxes.

• Incorporates fundamental concepts of

distributed system integration

• Offers a type safe, concurrent environment

to implement microservices with distributed transactions, reliable messaging, stream processing, and workflows

• Compiles into container images for

deployment on Kubernetes and Docker

https://ballerina.io/

Ballerina - code and visual syntax in sync

picture credit: https://www.flickr.com/photos/infomatique/

Invitation to consume and contribute

https://ballerina.io https://cellery.io https://github.com/wso2/reference-architecture https://github.com/wso2/reference-methodology

@asankama

THANK YOU

https://www.linkedin.com/in/asankaabeysinghe/
