CONNECTING AT THE SPEED OF LIGHT TM Clear CCT Connection Tool Fast, Effective Fiber Connector End-Face Cleaning CONNECTING AT THE SPEED OF LIGHT TM INTRODUCING: Clear Connection Tool CCT Easy to use for quick and reliable

slide-1
SLIDE 1

CONNECTING AT THE SPEED OF LIGHTTM

CCT

™ Clear

Connection Tool

Fast, Effective Fiber Connector End-Face Cleaning

slide-2
SLIDE 2

CONNECTING AT THE SPEED OF LIGHTTM

INTRODUCING:

  • Easy to use for quick and

reliable cleaning

  • Uses Combination

Cleaning™ process for first time cleaning, every time

  • Effective for the widest

range of contaminants

  • Rugged and durable, great

for all work sites

  • Up to 800 cleanings per kit

– 33% more than other tools

CCT Clear Connection Tool 2

CCT

™ Clear Connection Tool

slide-3
SLIDE 3

CONNECTING AT THE SPEED OF LIGHTTM

Versatile Fiber Optics Connector Cleaning

CCT Clear Connection Tool 3

Cleans connectors

  • n back plane and
  • n jumpers
slide-4
SLIDE 4

CONNECTING AT THE SPEED OF LIGHTTM

Match Your Connector Types

CCT Clear Connection Tool 4

1.25mm 2.5mm

MPO

FC SC ST MU LC

Part #CCT-125 Part #CCT-250 Part #CCT-MPO

slide-5
SLIDE 5

CONNECTING AT THE SPEED OF LIGHTTM

How CCT

™ Works

CCT Clear Connection Tool 5

1. Place CCT cleaning tip over connector ferrule 2. Press tool until you hear a “click”

  • Protective CCT shield retracts
  • Fabric comes into contact with ferrule endface
  • Lint-free fabric advances, wiping against

endface

  • 1.25mm and 2.5mm tips rotate for additional

cleaning action

1.25mm 2.5mm

MPO

FC SC ST MU LC

slide-6
SLIDE 6

CONNECTING AT THE SPEED OF LIGHTTM

The Most Connectors Cleaned

CCT Clear Connection Tool 6

FOCCUS CCT Sticklers IBC Tool One Click

Shown: 24 connector bulkhead, 2 connector patch cords

800! 750 525 500

9.3¢ PER CLEANING 11.7¢ PER CLEANING 11¢ PER CLEANING 12.2¢ PER CLEANING

Cost per cleanings based on MSRP

slide-7
SLIDE 7

CONNECTING AT THE SPEED OF LIGHTTM

Is There An Even BETTER Way?

  • Dry cleaning process
  • Mechanical action places a dry cleaning material

in contact with the end face

  • Con: Doesn’t dissolve soil and generates static
  • Wet-To-Dry cleaning process
  • Solvent delivery with a mechanical vacuum

mechanism or other drying means

  • Con: Floods connector, drawing up addition soil

from 5th zone

  • Combination Cleaning™ process
  • Uses minimal quantity of precision

fiber optic cleaner with interactive drying method

  • First-time cleaning without the cons

CCT Clear Connection Tool 7

slide-8
SLIDE 8

CONNECTING AT THE SPEED OF LIGHTTM

CCT

™ With Combination Cleaning ™

CCT Clear Connection Tool 8

1. Lightly wet CCT tip with MX Precision Cleaning Pen tip 2. Place CCT cleaning tip over connector ferrule 3. Press tool until you hear a “click” & repeat 1-2 more times

  • Lightly wetted fabric contacts

endface

  • Solvent breaks down soil
  • As fabric advances, wetted fabric is

replaced with dry fabric, drying remaining cleaner

slide-9
SLIDE 9

CONNECTING AT THE SPEED OF LIGHTTM

Combination Cleaning

TM Process CCT Clear Connection Tool 9

Example #1 – Carbon Black

Before cleaning Dry cleaning (probe tool) Combination CleaningTM

slide-10
SLIDE 10

CONNECTING AT THE SPEED OF LIGHTTM

Combination Cleaning

TM Process CCT Clear Connection Tool 10

Example #2 - Fingerprint

Before cleaning Wet-to-dry (w/IPA) Combination CleaningTM

slide-11
SLIDE 11

CONNECTING AT THE SPEED OF LIGHTTM

Combination Cleaning

TM Process

  • Exceeds IEC 61300-3-35 & IEC TR 62627-1
  • Written into Telcordia GR-2923-CORE
  • Simple, easy to train, repeatable
  • Zone-5 of the end face is never flooded with

excess cleaner

  • Designed to move contamination away from the

initial point of contact

  • Removes the widest range of contamination,

debris and combinations – including static

CCT Clear Connection Tool 11

slide-12
SLIDE 12

CONNECTING AT THE SPEED OF LIGHTTM

Achieve First Time Cleaning…

  • Of the widest range of

debris, contamination and soil

  • From the complete

endface of all connection types

  • Without residual

contamination or re-contamination

CCT Clear Connection Tool 12

slide-13
SLIDE 13

CONNECTING AT THE SPEED OF LIGHTTM

CCT

™ Features

CCT Clear Connection Tool 13

Wrist strap to prevent dropping during field install / maintenance Non-slip surface Extendable cleaning tip for hard-to-reach connectors Protective tip cap tethered for loss prevention Magnet strip – leave on rack during or after datacom install / maintenance Color-coded for connector type Flip-top for cleaning patch cord connectors Remove top for backplane cleaning

slide-14
SLIDE 14

CONNECTING AT THE SPEED OF LIGHTTM

Convenient Packaging

CCT Clear Connection Tool 14

Tool Only

Cleaning Kit

w/ MX Precision Cleaner Pen

Part #’s CCT-125 CCT-250 CCT-MPO Part #’s CCT-125KIT CCT-250KIT CCT-MPO

Detailed Instructions Durable, Water- Resistant Package

slide-15
SLIDE 15

CONNECTING AT THE SPEED OF LIGHTTM

More Combination Cleaning

TM Supplies CCT Clear Connection Tool 15

Precision Cleaners Wipes & Swabs

slide-16
SLIDE 16

CONNECTING AT THE SPEED OF LIGHTTM

More Combination Cleaning

TM Supplies CCT Clear Connection Tool 16

Cleaning Platforms Cleaning Kits

slide-17
SLIDE 17

CONNECTING AT THE SPEED OF LIGHTTM

  • Easy to use for quick and

reliable cleaning

  • Compatible with all major

connector types

  • Effective on a wide variety
  • f soils
  • Use with MX Precision

Cleaning Pen and Combination Cleaning™ process

CCT Clear Connection Tool 17

CCT

™ Clear Connection Tool

Clean Connectors The First Time… Every Time!
