Cake: : Enabling Hig igh-level SLOs on Shared Sto torage Syste tems

Andrew Wang, Shivaram Venkataraman, Sara Alspaugh, Randy Katz, Ion Stoica University of California, Berkeley SO SOCC CC 20 2012 12

2

 Introduction  Problem And Challenge  Solutions  System Design  Implementation  Evaluation  Conclusion  Future work

Content

Introduction

 Rich web applications

 A single slow storage request can dominate the

• verall response time

 High percentile latency SLOs

 Deal with the latency present at the 95th or

99th percentile

4

Introduction

Datacenter applications

 Latency-sensitive  Throughput-oriented

Accessing distributed storage systems

 Applications don’t share storage systems  Service-level objectives on throughput or latency

5

Introduction

 SLOs

Reflect the performance expectations

 Amazon, Google, and Microsoft have identified

SLO as a major cause of user dissatisfaction

For example

 A web client might require a 99th percentile

latency SLO of 100ms

 A batch job might require a throughput SLO of

100 scan requests per second

6

Problem And Challenge

 Physically separating storage systems

 Need Individual peak load  Segregation of data leads to degraded user

experience

 Operational complexity

• Require additional maintenance staff
• More software bugs and configuration errors

7

Problem And Challenge

 Focusing solely on controlling disk-level resources

 High-level storage SLOs require consideration of

resources beyond the disk

 Disconnect between the high-level SLOs and

performance parameters like MB/s

 Require tedious, manual translation  More programmer or system operator

8

Solutions

Cake ke A coordinated, multi-resource schedule for shared distributed storage environments with the goal of achieving both high throughput and bounded latency.

9

Architecture

System Design

10

System Design

 First-level schedulers as a client

 Provide mechanisms for differentiated

scheduling

 Split large requests into smaller chunks  Limit the number of outstanding device requests

11

System Design

 Cake’s second-level scheduler as a

feedback loop

 While attempting to increase utilization  Continually adjusts resource allocation at each

• f the first-level schedulers

 Maximize SLO compliance of the system

12

First-level Resource Scheduling

Differentiated scheduling

a b

13

First-level Resource Scheduling

Split large requests Control number of outstanding requests

c d

14

Second-level Scheduling

 Multi-resource Request Lifecycle

 Request processing in a storage system

involves far more than just accessing disk

 Necessitating a coordinated, multi-resource

approach to scheduling

15

Second-level Scheduling

 Multi-resource Request Lifecycle

16

Second-level Scheduling

 High-level SLO Enforcement

 Cake’s second-level scheduler

• Satisfy the latency requirements of latency-sensitive

front-end clients

• Maximize the throughput of throughput-oriented

batch clients

 Two phases of second level scheduling

decisions

• For disk in the SLO compliance-based phase
• For non-disk resources in the queue occupancy-

based phase

17

Second-level Scheduling

 The initial SLO compliance-based phase

 Decide on disk allocations based on client performance

 The queue occupancy-based phase

 Balance allocation in the rest of the system to keep the

disk utilized and improve overall performance

18

Implementation

 Chunking Large Requests

19

Implementation

 Number of Outstanding Requests

20

Implementation

 Cake Second-level Scheduler — SLO

Compliance-based Scheduling

21

Implementation

 Cake Second-level Scheduler — Queue

Occupancy-based Scheduling

22

Evaluation

 Proportional Shares and Reservations

When the front-end client is sending low throughput, reservations are an effective way of reducing queue time at HDFS

23

Evaluation

 Proportional Shares and Reservations

When the front-end is sending high throughput,proportional share is an effective mechanism at reducing latency

24

Evaluation

 Single vs Multi-resource Scheduling

CPU contention within HBase when running many concurrent threads and without separate queues and differentiated scheduling

25

Evaluation

 Single vs. Multi-resource Scheduling

Thread-per-request displays greatly increased latency with chunked request sizes

26

Evaluation

 Convergence Time  Diurnal Workload  Spike Workload  Latency Throughput Trade-off  Quantifying Benefits of Consolidation

27

Conclusion

 Coordinating resource allocation across

multiple software layers

 Allowing application programmers to specify

high-level SLOs directly to the storage

 Allowing consolidation of latency-sensitive

and throughput-oriented workloads

28

Conclusion

 Allowing users to flexibly move within the

storage latency vs. throughput trade-off by choosing different high-level SLOs

 Using Cake has concrete economic and

business advantages

29

Future work

 SLO admission control  Influence of DRAM and SSDs  Composable application-level SLOs  Automatic parameter tuning  Generalization to multiple SLOs
