CNC LATHE ROMI C 420 / C 510 / C 620 / C 680 / C 830 / C 1000 / C 1000BB, C 850H / C 1100H / C 1290H SEV - MF Linha Centur ROMI C 420 / C 510 / C 620 series Illustratives images Equipped with optional Illustrative picture Machines equipped

slide-1
SLIDE 1

CNC LATHE ROMI C 420 / C 510 / C 620 / C 680 / C 830 / C 1000 / C 1000BB, C 850H / C 1100H / C 1290H

SEV - MF

slide-2
SLIDE 2

Linha Centur ROMI C 420 / C 510 / C 620 series

Illustrative picture Machines equipped with optional equipment

Illustratives images Equipped with optional

slide-3
SLIDE 3

Siemens 802 D sl-PLUS CNC

SEV-MF

  • Monitor:
  • 10.4” LCD color with 16 soft keys
  • Comunication Interfaces
  • RS 232
  • Compact Flash Card.
slide-4
SLIDE 4

SEV-MF

This application allows the user to operate the machine in both manual and auto mode (as a typical CNC lathe). There are three levels of

  • peration according to the operator skill:

Manual Mode The operator machines the part as on a conventional lathe using Control Apron. In this mode, manual operations such as Parallel Turning, Taper Turning, Radius Turning, Drilling and Groove can be performed. RMMP - Romi Manual Machining Package (optional)

slide-5
SLIDE 5

SEV-MF

Cycles Mode In this mode the machinist operates the machine in semi automatic mode. He fills in the conversational screen fields for feed, speed and cycle data, then moves the tool to a safe starting point using the Control Apron and then presses the Cycle Start button to perform the cycle. Cycles as Drilling, Tapping, Groove / Parting, Thread and Roughing / Finishing Turning can also be performed. There are fixed cycles and free form for turning. The filling in of the cycles fields are aided by a graphic screen. RMMP - Romi Manual Machining Package (optional)

slide-6
SLIDE 6

SEV-MF

Teach In Mode In this mode the operator saves the

  • perations step by step as he is

machining the first part. The operator can then save these into a program for use on later parts. Both manual

  • perations and cycles operations can

be saved together into the same program and the programs can then be saved in the CNC memory or a compact flash card.

Note: There are also conversational screens for measuring tools and setting work offsets.

RMMP - Romi Manual Machining Package (optional)

slide-7
SLIDE 7

SEV-MF

Fully enclose splash guard, with two front doors and multilayer safety sight window, including tailstock cover and safety electric lock.

ROMI C 420 V4.0

(*) Floor space required (front x side) and net weight (approx.) 0.5 m between centers m (in) 1.0 m between centers m (in) 0.5 m between centers kg (Ibs) 1.0 m between centers kg (Ibs) (*) Without chip conveyour 2,100 (4,630) 2.35 x 1.34 (92.52 x 52.76) 2.85 x 1.34 (112.20 x 52.76) 2,500 (5,512) Illustrative picture

slide-8
SLIDE 8

SEV-MF

Technical Specifications

Capacity Height of centers mm (in) Distance between centers m (in) Swing over bed mm mm (in) Swing over cross slide mm (in) Swing over saddle wings mm (in) Travel (X axis) mm (in) Travel (Z Axis) mm (in) Bed Width mm (in) Height mm (in) Headstock Spindle nose ASA A2-5" A2-6" Spindle hole diameter mm (in) 53 (2.08) 65 (2.55) Speed range rpm 4 ~ 4,000 3 ~ 3,000 Feeds Rapid traverse (Z axis) m/min (ipm) Rapid traverse (X axis) m/min (ipm) Installed power AC Main motor (30 min) hp / kW Total installed power kVA 305 (12.00) 350 (13.77) 10 (393.70) 10 (393.70) 200 (7.87) 400 (15.74) 220 (8.66) 565 / 1,065 (22.24 / 41.92)

C 420

215 (8.46) 0.5 / 1.0 (19.68 / 39.37) 430 (16.92) 10 / 7.5 15

ROMI C 420 V4.0

slide-9
SLIDE 9

SEV-MF

ROMI C 420 V4.0 Power charts

slide-10
SLIDE 10

* ‏)*(

Pneumatic chuck (*) Chuck diameter Hole diameter Ø160 mm Ø39 mm Ø200 mm Ø52 mm ASA A2-6" Ø200 mm Ø52 mm Hydraulic chuck (**) Chuck diameter Hole diameter Ø165 mm Ø42 mm Ø210 mm Ø42 mm ASA A2-6" Ø210 mm Ø51 mm Universal chuck Chuck diameter Hole diameter Ø160 mm Ø42 mm Ø200 mm Ø55 mm ASA A2-6" Ø200 mm Ø55 mm Face plate with 6 T slots Chuck diameter Hole diameter ASA A2-5" Ø400 mm Ø78 mm ASA A2-6" Ø400 mm Ø102 mm (*) Pneumatic chuck with incorporated cylinder (**) Hydraulic chuck with rear cylinder ASA A2-5" ASA A2-5" ASA A2-5"

ROMI C 420 V4.0

SEV-MF

slide-11
SLIDE 11

SEV-MF

Pneumatic chuck Universal chuck Hydraulic chuck

ROMI C 420 V4.0

Illustrative pictures

slide-12
SLIDE 12

Hydraulic tailstock Pneumatic tailstock Manual tailstock

Quill travel mm Quill diameter mm Quill internal taper CM Quill thrust force at 40 bar ( hydraulic ) Kgf TAILSTOCK Body positioning Dragged by the saddle Quill activation Manual (std) Hydraulic (optional) Pneumatic (optional) 180 100 5 948

ROMI C 420 V4.0 Tailstock

Illustrative pictures

slide-13
SLIDE 13

SEV-MF Quick change toolholder (optional) Holders Toolholder size: Square mm (in) Bar (diameter) mm (in) Rear toolholder (optional) Toolholder size: Square mm (in) Bar (diameter) mm (in) Toolholder type gang tools (optional) Toolholder size: Square mm (in) Bar (diameter) mm (in) 8-position Manual square Turret (optional) Toolholder size: Square mm (in) Bar (diameter) mm (in) Number of stations / tools Station-to-station indexing time s Turret indexing time 180° s Toolholder size: Square mm (in) Bar (diameter) mm (in) 8-position disk Type automatic Turret (optional) 25 x 25 (1 x 1) 25 (1) 8 / 8 1 2 25 x 25 (1 x 1) 25 (1) 20 x 20 (1 x 1) 25 (1) 20 x 20 (1 x 1) 25 (1) 25 (1) 2 or 3 25 x 25 (1 x 1)

ROMI C 420 V4.0

slide-14
SLIDE 14

SEV-MF

Illlustrative Image Illlustrative Image

Quick Change Toolholder (optional) 8-Station Disk Type Automatic Electric Turret (optional) Toolholder Type Gang-Tools Plate T-slot based (optional)

ROMI C 420 V4.0

Illlustrative Image

slide-15
SLIDE 15

SEV-MF

ROMI C 420 V4.0

130 liters capacity (34,3 gal) for 500mm between centers and 170 liters capacity (44,9 gal) for 1.000mm between centers

2 bar / 29 PSI Pump

(standard)

Illlustrative Image

Complete coolant system with reservoir and pump

slide-16
SLIDE 16

SEV-MF

ROMI C 420 V4.0

Machine dimensions

slide-17
SLIDE 17

SEV-MF

ROMI C 510 V3.0

Illustrative image Equipped with optional

slide-18
SLIDE 18

SEV-MF

Technical Specifications

Capacity Height of centers mm (in) Distance between centers m (in) Swing over bed mm mm (in) Swing over cross slide mm (in) Swing over saddle wings mm (in) Travel (X axis) mm (in) Travel (Z Axis) mm (in) Bed Width mm mm (in) Height mm mm (in) Headstock Spindle nose ASA A2-6" A2-8" Spindle hole diameter mm (in) 65 (2.55) 80 (3.15) Speed range rpm 3 ~3,000 2 ~ 2,200 Feeds Rapid traverse (Z axis) m/min (ipm) Rapid traverse (X axis) m/min (ipm) Installed power AC Main motor (30 min) hp / kW Total installed power kVA (*) Floor space required (front x side) and net weight (approx.) 1.5 m between centers m (in) 1.5 m between centers kg (Ibs) 3,750 (8,268) 3.75 x 1.68 (147.64 x 66.14) 340 (13.38) 336 (13.22) 10 (393.70) 10 (393.70)

C510

260 (10.23) 1.5 (59.05) 520 (20.47) 255 (10.03) 450 (17.71) 280 (11.02) 1.5 (59.05) 15 / 11 20

ROMI C 510 V3.0

slide-19
SLIDE 19

SEV-MF

ROMI C 510 V3.0 Power charts

slide-20
SLIDE 20

Opened steady rest with bronze tips Follow rest with rollers Closed steady rest with bronze tips

Illustrative images SEV-MF “U” type steady rest

ROMI C 510 V3.0 Steadies

slide-21
SLIDE 21

SEV-MF

  • Follow rest with rollers for Ø15 to Ø80 mm (Ø5/8” to Ø3”)
  • Opened steady rest with bronze tips for Ø8 to Ø80 mm (Ø5/16” to Ø3 1/8”)
  • Closed steady rest with bronze tips for Ø8 to Ø80 mm (Ø5/16” to Ø3 1/8”)
  • Additional set of bronze tips for Ø80 to Ø152 mm (Ø3 1/8” - Ø6”)
  • Additional set of rollers for Ø8 to Ø80 mm (Ø5/16” to Ø3 1/8”)
  • Additional set of rollers for Ø80 to Ø152 mm (Ø3 1/8” - Ø6”)
  • "U” type steady rest with rollers for Ø50 to Ø 250 mm (Ø2” to Ø10”)

ROMI C 510 V3.0 steadies

slide-22
SLIDE 22

SEV-MF

Quick change toolholder (optional) Holders Toolholder size: Square mm (in) Bar (diameter) mm (in) Rear toolholder (optional) Toolholder size: Square mm (in) Bar (diameter) mm (in) WTO Toolholder (VDI-50 Toolholder / DIN 69880-50) (optional) Axial Live tool holder DIN 6499 Radial Live tool holder DIN 6499 Toolholder size: Square mm (in) Bar (diameter) mm (in) Number of stations / tools Station-to-station indexing time s Turret indexing time 180° s Toolholder size: Square mm (in) Bar (diameter) mm (in) 8-position disk Type automatic Turret (optional) 25 x 25 (1 x 1) 32 (1 ¼) 8 / 8 1 2 ER-40 (Ø 4 ~Ø 26 mm) ER-40 (Ø 4 ~Ø 26 mm) 32 x 32 (1 ¼ x 1 ¼) 40 (1 ½) 25 (1) 25 x 25 (1 x 1) 32 (1 ¼) 3 25 x 25 (1 x 1)

ROMI C 510 V3.0 tooling

slide-23
SLIDE 23

SEV-MF VDI-50 Turning tool holder 32 x 32 mm VDI-50 Boring bar holder Ø40 mm VDI-50 Facing tool holder 32 x 32 mm VDI-50 Axial live tool for collets type DIN 6499 - ER-40 (Ø4 a Ø26 mm) VDI-50 Axial live tool for collets type DIN 6499 - ER-40 (Ø4 a Ø26 mm)

WTO TOOL HOLDER (OPTIONAL)

slide-24
SLIDE 24

SEV-MF

Pneumatic chuck Universal chuck Hydraulic chuck

4 jaws independent chuck

ROMI C 510 V3.0 chucks

Illustrative images

slide-25
SLIDE 25

Pneumatic chuck (*) Chuck diameter Hole diameter Ø200 mm Ø51 mm Ø250 mm Ø64 mm ASA A2-8" Ø250 mm Ø64 mm Hydraulic chuck (**) Chuck diameter Hole diameter Ø210 mm Ø51 mm Ø254 mm Ø51 mm ASA A2-8" Ø254 mm Ø64 mm Universal chuck Chuck diameter Hole diameter Ø200 mm Ø55 mm Ø250 mm Ø76 mm ASA A2-8" Ø250 mm Ø76 mm 4 jaws independent chuck Chuck diameter Hole diameter Ø250 mm Ø65 mm Ø315 mm Ø80 mm Ø315 mm Ø80 mm Ø400 mm Ø100 mm (*) Pneumatic chuck with incorporated cylinder (**) Hydraulic chuck with rear cylinder ASA A2-8" ASA A2-6" ASA A2-6" ASA A2-6" ASA A2-6"

ROMI C 510 V3.0 chucks

slide-26
SLIDE 26

SEV-MF

ROMI C 510 V3.0 sheet metal

3 doors making easy the access to the machining area

Illustrative images

slide-27
SLIDE 27

SEV-MF

ROMI C 510 V3.0 sheet metal

slide-28
SLIDE 28

SEV-MF

ROMI C 510 V3.0 sheet metal

slide-29
SLIDE 29

SEV-MF

ROMI C 510 V3.0 Coolant system

2 bar / 29 PSI Pump

(standard)

Illustrative Image

Complete coolant system with reservoir and pump 7 bar / 101,7 PSI Pump (optional)

Illustrative Image

slide-30
SLIDE 30

SEV-MF

ROMI C 510 V3.0

slide-31
SLIDE 31

SEV-MF

ROMI C 620 v3.0

Illustrative image Floor space required (1,000 mm between centers) m (in) (2.000 mm between centers) m (in) Net weight (approx.) (1,000 mm between centers) kg (Ibs) (2,000 mm between centers) kg (Ibs) 5,550 (12,236) 4.85 x 2,075 (190.94 x 81.69) 3.85 x 2,075 (151.57 x 81.69) 5,000 (11,023)

slide-32
SLIDE 32

SEV-MF

Technical Specifications

Capacity Height of centers mm (in) Distance between centers m (in) Swing over bed mm mm (in) Swing over saddle wings mm (in) Swing over cross slide mm (in) Travel (X axis) mm (in) Travel (Z Axis) mm (in) Bed Width (guide face to guide face) mm (in) Height (lower face to prism top) mm (in) Headstock Spindle nose ASA A2-8" A2-8" Spindle hole diameter mm (in) 80 (3.15) 104 (4.09) Transmission Geared (2 ranges) Direct drive 1 ~ 667 2 ~ 2,500 Bearing inner diameter mm (in) 120 (4.72) 150 (5.91) Feeds Rapid traverse (Z axis) m/min (ipm) Rapid traverse (X axis) m/min (ipm) Installed power and Motor AC main motor (S2 - 30 min) kW / cv Total installed power kVA rpm 25 Rotation range 18.5 / 25 7.5 (295.28) 7.5 (295.28) 400 (15.75) 360 (14.17) 1.0 / 2.0 (39.37 / 78.74) 380 (14.96) 1 ~ 1,800 620 (24.41) 540 (21.26) 346 (13.62)

C620

310 (12.2) 1.0 / 2.0 (39.37 / 78.74)

ROMI C 620 v3.0

slide-33
SLIDE 33

SEV-MF

ROMI C 620 V3.0

Geared headstock

ASA A2-8” spindle nose 2 speed ranges

1 a 667 rpm ( 1820 Nm ) 2 a 2500 rpm ( 485 Nm )

Ø80 mm through hole

slide-34
SLIDE 34

SEV-MF

ASA A2-8” spindle nose 1 speed range

1 to 1800 rpm ( 831 Nm )

Ø104 mm through hole

ROMI C 620 V3.0

Direct drive headstock - cartridge type

slide-35
SLIDE 35

ASA A2-8'' SEV-MF ASA A2-8''

Direct drive Geared

ROMI C 620 V3.0

Power charts

slide-36
SLIDE 36

SEV-MF

Rear tool post

ROMI C 620 V3.0

Tooling

Quick change toolpost (optional) Number of faces Toolholder size: Square mm (in) Bar (diameter) mm (in) Rear toolpost (optional) Toolholder size: Square mm (in) Bar (diameter) mm (in) 25 x 25 (1 x 1) 32 (1 1/4) 25 x 25 (1 x 1) 40 (1 1/2) 3

Turning tool holder Boring bar holder

slide-37
SLIDE 37

SEV-MF

4 position electric turret with vertical axis (optional) Number of stations / tools Toolholder size: Square mm (in) Bar (diameter) mm (in) 8 position electric turret with horizontal axis (optional) Number of stations / tools Tool holder fixing Toolholder size: Square mm (in) Bar (diameter) mm (in) 8 position electric turret with horizontal axis for live tools Number of stations / tools Tool holder fixing Toolholder size: Square mm (in) Bar (diameter) mm (in) Live toolholder (axial and radial) DIN 6499 Live tool rotation range rpm 40 (1 1/2) 25 x 25 (1 x 1) 8 / 8 VDI-40 8 / 8 Romi standard or VDI-40 25 x 25 (1 x 1) 25 x 25 (1 x 1) 25 (1) 40 (1 1/2) 4 ~ 4,000 ER 32 (Ø3 ~ Ø20 mm) 8/ago

ROMI C 620 v3.0

slide-38
SLIDE 38

SEV-MF

8 Position electric turret with horizontal axis - Romi std disc 8 Position electric turret with horizontal axis and live tool - VDI-40 std disc 4 position electric turret with vertical axis

ROMI C 620 V3.0

Illustrative pictures of the turrets

slide-39
SLIDE 39

SEV-MF

4 jaws independent chuck Universal chuck Hydraulic chuck

‏)*( ‏)*(

Chuck diam. Chuck hole diam. Thru hole diam. Ø254 mm Ø80 mm Ø64 mm Ø315 mm Ø80 mm Ø64 mm Ø250 mm Ø76 mm (*) Ø315 mm Ø103 mm (*) Ø315 mm Ø80 mm (*) Ø400 mm Ø100 mm (*) Ø500 mm Ø125 mm (*) (*) The spindle hole (Ø80 or Ø104) must be considered to specify the bar capacity. Hydraulic chuck Universal chuck 4 jaws independent chuck

Illustrative pictures

ROMI C 620 V3.0

Chucks

slide-40
SLIDE 40

Drag device

SEV-MF Tailstock Body positioning Quill drive Quill travel mm (in) Quill diameter mm (in) Quill taper hole MT Axial force at 40 bar kgf (lbf) 100 (3.94) 5 948 (2,090) by drag device on carriage 180 (7.09) Manual (standard) Hydraulic (optional)

ROMI C 620 V3.0

Tailstock

slide-41
SLIDE 41

7 bar pump (optional)

Obligatory choice between the 2 or 7 bar options

Wash Gun pump (Optional)

SEV-MF

Steering wheels - easy movment

Oil / coolant separator (oil skimmer) (optional)

ROMI C 620 V3.0

Coolant system

slide-42
SLIDE 42

SEV-MF

ROMI C 620 v3.0

slide-43
SLIDE 43

SEV-MF

ROMI C 680 v3.0

slide-44
SLIDE 44

SEV-MF

ROMI C 680 v3.0

CNC Siemens 802D – sl PRO LCD 14.4” color monitor and control pivoted

  • ver the pendent
  • RS 232
  • 1MB of memory
  • PCMCIA Interface
  • USB Interface
  • Ethernet Interface
  • Thread repair function
slide-45
SLIDE 45

SEV-MF

ROMI C 680 v3.0

  • Geared headstock with coolant and

lubrication system driven by AC motor with pulleys and poli-V belt.

  • Geared headstock, driven by AC motor with

pulleys and poli-V belt.

  • Headstock with two manually selected

speed ranges.

  • high-removal-rate
slide-46
SLIDE 46
  • Distance between centers:

2 and 3 meters

  • Manual tailstock quill diameter

Ø 130 mm e 5 MT.

  • ASA A2-8'' spindle nose Ø 104 mm thru-

hole 1 up to 1800 RPM.

  • ASA A2-11'' spindle nose Ø 172 mm thru-

hole 1 up to 1000 RPM.

  • AC main motor: 40hp/30kW.

ROMI C 680 v3.0

slide-47
SLIDE 47

SEV-MF

ROMI C 830 (V3.0)

Versions: 2.000 (78.7”) between centers 3.000 (118.1”) between centers. 4.000 (157,5”) between centers. 5.000 mm (196.9”) between centers

slide-48
SLIDE 48

ROMI C 1000 (V3.0)

SEV-MF

Length versions: 2.000 (78.7”) between centers 3.000 (118.1”) between centers. 4.000 (157,5”) between centers. 5.000 mm (196.9”) between centers

slide-49
SLIDE 49

SEV-MF

New version - 3.0 ROMI C830 and C 1000

Main changes of the 3.0 version 1) Compliance with the CE standards - sheet metal, electris cabinet, electric switches 2) New headstock:

  • ASA A2-20 spindle with Ø320 mm through hole
  • Benefit: Attend to the petroleum industry (mainly)

4) Increase of the X axis from 450 mm to 520 mm 5) Tailstock drag system through a lock on the table 6) Thread repair software

  • Benefit: Attend to the petroleum industry (mainly)

7) To complement the C series 8) Option of Romi Manual Machine Package

slide-50
SLIDE 50

SEV-MF

Headstock

  • Geared;
  • 2 ranges manually switched
  • ASA A2-11” or ASA A2-20”

Ø 320 mm

slide-51
SLIDE 51
  • Ø 375 mm to attend to the petroleum industry.

SEV-MF

A2-20 headstock - Ø 375mm through hole

slide-52
SLIDE 52

SEV-MF

Power charts

slide-53
SLIDE 53

SEV-MF

Power charts

slide-54
SLIDE 54

SEV-MF1

Door

Version 2.0 Version 3.0

  • External.
  • Bilt-in the sheet metal with door

Centralized lubrication system

slide-55
SLIDE 55

SEV-MF

Hydraulic unit

  • Hydraulic unit for headstock lubrication;
  • Hydraulic unit for chuck cylinder.
slide-56
SLIDE 56

SEV-MF

Coolant pump

Standard: 2 bar coolant pump; *Opcional: 7 bar coolant pump;

  • Tank capacity:
  • 300 liters.
slide-57
SLIDE 57

SEV-MF

Fluorescent worklights

Operator panel arm Internal

slide-58
SLIDE 58

SEV-MF

Rear fixed chip pan

Fixed chip pan Guard cover

  • Removable rear guard covers for chip pan access.
  • Facility to remove the chips and clean the pans
slide-59
SLIDE 59

SEV-MF

Security items - CE compliance

1 – Lock of rear chuck access door; 2 – Lock of front chuck guard door; 3 – Lock of main door;

slide-60
SLIDE 60

Tailstock

SEV-MF1

Version 2.0 Version 3.0

Rack and pinion Dragged by the carriage

slide-61
SLIDE 61

SEV-MF1

Version 2.0 Version 3.0

  • Manual lubrication - one nozzle for each lubrication point.

Manual pump - lubricate all the points MT-5

Tailstock

slide-62
SLIDE 62

SEV-MF1

Version 2.0 Version 3.0

  • Permanent lubrication (grease);
  • New labyrinth design - more efficiency
  • Manual lubrication - oil

Live center cartridge

slide-63
SLIDE 63

Carriage

SEV-MF1

Version 2.0 Version 3.0

Advantages:

  • Increase of the X travel from 450 mm to 520 mm
  • Application of Turcite on the cross slide - increase of the X rapid traverse from 4 to 8 m/min).
  • Cross slide fully supported by the carriage on the both axis limits - more rigidity
slide-64
SLIDE 64

Sheet metal

  • 01 sliding door with displacement through the carriage;
  • 01 sliding door over the chuck;
  • Operator panel arm independent of the door;

SEV-MF

slide-65
SLIDE 65

Sheet metal

SEV-MF

  • The operator panel arm is hinged to make easier the transportation.
slide-66
SLIDE 66

SEV-MF

Electronic package

Full Siemens electronic package

  • CNC
  • Servomotors
  • Motor AC
  • Drives

Drives Servomotors Operator panel

  • Siemens 802D sl-PRO CNC

Benefits:

  • Homogeneous electronic
  • Compatibility
slide-67
SLIDE 67

CNC

  • Ethernet;
  • RS-232;
  • USB;
  • Power outlet;
  • Pendant handwheel.
  • Siemens 802D sl-PRO CNC
slide-68
SLIDE 68

SEV-MF

OPTIONALS

slide-69
SLIDE 69

SEV-MF1

Allow the user to operate the machine in manual mode and automatic mode. There are 3 operation levels according to the operator skills:

  • Manual mode:
  • The operation is similar to a conventional lathe.
  • Fixed cycles mode:
  • The operation is semi-automatic, through filling in

blanks on the CNC screen (conversational screens).

  • Teach In mode:
  • During the first part machining the operations are

recorder step by step as a program, that can be afterward executed.

Romi Manual Machine Package

slide-70
SLIDE 70

SEV-MF

Front chucks

slide-71
SLIDE 71

SEV-MF

Front chucks

Model Diameter [mm] Through hole [mm]

400 136 500 190 550 160 700 171 315 90 400 118 630 252 800 320 4 jaws independant chucks 720 375 3 jaws universal chucks

ASA A2-20" ASA A2-11"

3 jaws universal chucks 4 jaws independant chucks Hidraulic power chuck and hidraulic cylinder with through hole

slide-72
SLIDE 72

SEV-MF

Rear chucks

slide-73
SLIDE 73

SEV-MF

Model Diameter [mm] Through hole [mm]

400 136 500 190 550 160 700 171 630 252 800 320 4 jaws independant chucks 720 375 3 jaws universal chucks

ASA A2-20" ASA A2-11"

3 jaws universal chucks 4 jaws independant chucks

Rear chucks

slide-74
SLIDE 74

SEV-MF1

4 position manual tool post

slide-75
SLIDE 75

SEV-MF1

4 position electric turret

slide-76
SLIDE 76

SEV-MF1

VDI 50 - 8 position electric turret

slide-77
SLIDE 77

SEV-MF1

VDI 50 - 8 position electric turret - live tools

slide-78
SLIDE 78

SEV-MF

Electric turret

8 position (horizontal axis) for driven tools

slide-79
SLIDE 79

SEV-MF

Tailstock with hydraulic driven quill

Hydraulic unit for driven quill

slide-80
SLIDE 80

SEV-MF

U type steady rest

  • 2 ranges:
  • Ø 100 to 305 mm;
  • Ø 292 to 440 mm.
slide-81
SLIDE 81

SEV-MF

Longitudinal chip conveyor

Hinged belt type (TCE)

slide-82
SLIDE 82
  • Ar conditioning for electrical cabinet;
  • Oil Skimmer;
  • Electrical installation for 380V;
  • Rear centralizing ring with Ø 160 mm capacity (ASA A2-11”) and

Ø 375 mm (ASA A2-20”);

  • Compact Flash 1GB;
  • Main spindle indexing with 72 positions (5º);
  • M code external interface with miscellaneous functions (4 M codes);
  • Special colors Munsell or RAL;

SEV-MF

ROMI C 830 / C 1000 / C 1000BB

slide-83
SLIDE 83

SEV-MF

Technical specifications C 830 and C 1000

Technical specifications C 830 C 1000

Capacity

Height of centers mm 435 510 Distance between centers m 2.0 / 3.0 / 4.0 / 5.0 2.0 / 3.0 / 4.0 / 5.0 Swing over bed mm 850 1000 Swing over carriage mm 550 700 Transversal stroke (X axis) mm 520 520 Longitudinal stroke (Z axis) mm 2070 / 3070 / 4070 / 5070 2070 / 3070 / 4070 / 5070

Bed

Width mm 460 460 Height mm 420 420

Headstock - ASA A2-11" version

Spindle nose ASA A2-11" A2-11" Through hole mm 160 160 Speed range rpm 1 a 1038 1 a 1038 Range I rpm 1 a 1038 1 a 1038 Range II rpm 1 a 258 1 a 258

Headstock - ASA A2-20" version

Spindle nose ASA A2-20" A2-20" Through hole mm 375 375 Speed range rpm 1 a 508 1 a 508 Range I rpm 1 a 127 1 a 127 Range II rpm 1 a 508 1 a 508

Feeds

Longitudinal rapid traverse (Z axis - 2.0 and 3.0 m versions) m/mim 8 8 Longitudinal rapid traverse (Z axis - 4.0 and 5.0 m versions) m/mim 5 5 Transversal rapid traverse (X axis - 2.0, 3.0, 4.0 and 5.0 m versions) m/mim 8 8

Manual tailstock

Quill stroke mm 200 200 Quill diameter mm 130 130 Quill inside taper MT 5 5

slide-84
SLIDE 84

SEV-MF

ROMI C 850H / C 1000H / C 1000BB

Dimensões da Máquina

ROMI C 850H / C 1100H / C 1290H

SEV-MF

SEV-MF

Centur 850H / 1000H / 1000BB

Dimensões da Máquina

Dimention of machine

slide-85
SLIDE 85

SEV-MF

ROMI C 850H / C 1100H / C 1290H

slide-86
SLIDE 86

ROMI C 850H / C 1100H / C 1290H

SEV-MF

CNC Siemens 840D sl

  • Display LCD de 10,4''
  • 3 MB de memory
  • Interface RS-232
  • PCMCIA
  • USB
  • Ethernet
  • thread repair
slide-87
SLIDE 87

ROMI C 850H / C 1100H / C 1290H

SEV-MF

Geared headstok with lubrication and cooling system ASA-A2-11'' spindle Ø 142mm, from 1 to 1200 RPM ASA-A2-15” spindle hole Ø 182mm, from 1 to 1000 RPM ASA A2-20'' spindle hole Ø 375mm, 100 to 500 RPM

slide-88
SLIDE 88

ROMI C 850H / C 1100H / C 1290H

SEV-MF

Main motor power : 72 hp Distance between centers: 2,0 / 3,0 / 5,0 / 6,5 / 8,0 e 9,5 m

slide-89
SLIDE 89

ROMI C 850H / C 1100H / C 1290H

SEV-MF

Technical specifications C 850H C 1100H C 1290H

Capacity

Height of centers mm 475 560 675 Distance between centers m 2,0 / 3,5 / 5,0 2.0 / 3.5 / 5.0 / 6.5 / 8,0 / 9,5 3,5 / 5,0 Swing over bed mm 950 1.110 1.330 Swing over wins mm 890 1.055 1.280 Swing over carriage mm 550 720 950 Transversal stroke (X axis) mm 600 600 600 Longitudinal stroke (Z axis) mm 2.140 / 3.665 / 5.190 2070 / 3070 / 4070 / 5070 / 3.665 / 5.190 6.715 / 8.240 / 9.765 Maximum weight permissible between centers to 50 rpm Kg 15.000 15.000 15.000

Bed

Width mm 600 600 600 Height mm 490 490 490

Headstock - ASA A2-15" version

Spindle nose ASA A2-15" A2-15" Through hole mm 260 260 Speed range rpm 1 up to 750 1 up to 750 Range I rpm 1 up to 124 1 up to 124 Range II rpm 1 up to 750 1 up to 750

Headstock - ASA A2-20" version

Spindle nose ASA A2-20" A2-20" Through hole mm 375 375 Speed range rpm 1 - 500 1 - 500 Range I rpm 1 - 142 1 - 142 Range II rpm 1 - 500 1 - 500

slide-90
SLIDE 90

ROMI C 850H / C 1100H / C 1290H

SEV-MF

Power charts

slide-91
SLIDE 91

ROMI C 850H / C 1100H / C 1290H

SEV-MF

slide-92
SLIDE 92

ROMI C 850H / C 1100H / C 1290H

SEV-MF

ROMI C 850H / C 1100H / C 1290H

SEV-MF

slide-93
SLIDE 93

Setor de Engenharia de Vendas – SEV-MF (19) 3455-9500 www.romi.com
