BROWARD COUNTY, FLORIDA

PUBLIC SAFETY RADIO APCO 25 700MHZ COMMUNICATIONS SYSTEM Proposer Presentations

November 30, 2016

AGENDA

Topic ASTRO P25 System Overview Motorola Approach to Civil Requirements P25 System Transition Plan System Performance – Broward Environment APX Radio Durability Value Added Features CAD Integration Long Term Value Q&A

P25 Radio System

Day to Day Operations

3

ASTRO P25 System Overview

Presented by: Clay Whitehead

4

Explain in more detail your firm’s proposed system for Broward County.

MZC Zone Controllers Network Management

700 MHz Geo-Prime 1 IP Simulcast P25 FDMA/TDMA

Primary Master Core

P25 SYSTEM OVERVIEW

MZC Zone Controllers Network Management

Backup Master Core

700 MHz 11 Simulcast Sites 36 Talkpaths P25 FDMA/TDMA

MCC Dispatch Sunrise AVIAT Microwave Dual Loop Configuration CAD VPI

700 MHz Geo-Prime 2 IP Simulcast P25 FDMA/TDMA

MCC Dispatch Pembroke Pines MCC Dispatch Coconut Creek

700 or 800 MHz Repeater Site P25 FDMA/TDMA Backup 700 MHz 4 Simulcast Sites 12 Talkpaths P25 FDMA/TDMA

WAVE WAVE

MCC7500e DISPATCH CONSOLE

6

FAULT TOLERANT NETWORK DESIGN FAULT TOLERANT NETWORK DESIGN DISPATCH ASSISTANT WINDOW ENHANCED TELEPHONY INTEGRATED INSTANT RECALL RECORDER USES OFF THE SHELF COMPUTER

ISSI 8000 INTEROPERABILITY

P25 Digital Subscribers

BROWARD COUNTY CORE

P25 Digital Subscribers ASTRO 25 Sites ASTRO 25 Sites

MOTOROLA HOSTED CORE

P25 ISSI

Alias Transport Busy Queuing/Callback Fast Start/All Start Fast Auto-Roaming ISSI Data (Location)

MZC Zone Controllers Network Management

WAVE

MZC Zone Controllers Network Management

WAVE

8

Portable operating at 2.5 watts per FCC type acceptance

9

Dual loop configuration; exceeds 99.999% availability

KEY ELEMENTS OF MOTOROLA DESIGN

10

Motorola Design Elements

Fully compliant coverage design Single simulcast cell design simplifies user operation Continued use of SmartX interface to Hosted Master Site for transition Robust microwave dual loop exceeds 99.999% reliability Geo-diversity and site redundancy MCC7500/7500e enables full knowledge transfer for dispatch user experience Unique APX radio to ASTRO infrastructure feature interaction

Logging Recorder

11

Approach to Civil Scope Requirements

Presented by: Blake Smith

12

Please explain your firm’s tower and shelter structures advantages and/or disadvantages.

FULLY COMPLIANT/ TURNKEY CIVIL DESIGN

What does fully compliant mean?

• Motorola meets all coverage requirements
• As directed by the County, all mandatory sites are being utilized
• Motorola meets and exceeds the County Business Enterprise

requirement

What does Turn-Key Civil Design mean?

No Assumptions

• We didn’t assume that we can place antennas or dishes on towers that don’t exist
• We didn’t assume that Broward County wants to engage in costly leases and remediation for

new tower sites

• Constructibility
• Resilient
• No hidden costs

The requirements are the same for all proposers, the differences are in the offerings. Motorola is offering a Broward a complete solution

FULLY COMPLIANT/ TURNKEY CIVIL DESIGN

SITE DEVELOPMENT SUMMARY

CIVIL DESIGN TAKEAWAYS

• It can be built. No guess work.
• No new long term lease costs required
• No need for expensive tower remediation
• Control your schedule
• No Broward County civil costs beyond the proposal
• Opportunity

Full Constructibility

P25 Radio System

Day to Day Operations

17

P25 System Transition

Presented by: Clay Whitehead

18

Describe how your firm will perform a switchover/cutover from the County’s existing system to your firm’s proposed system.

Challenge to Successful Transition Unique Motorola Approach Tower site space Expedite public service move to MOTOTRBO system Base station transition from AC to DC Operational impact Leverage SmartX to support legacy SmartZone users Incorporate T1 loop switch function per RFP System performance Motorola’s intimate knowledge of the existing SmartZone system and Broward County operations enables seamless cutover Interoperability Motorola can support unique functionality between Hosted Master Site and the new Broward County system Training Familiarity with APX radios and Gold Elite consoles

19

UNIQUE MOTOROLA TRANSITION PLAN

MZC Zone Controllers Network Management

Hosted Master Core

CURRENT CONFIGURATION

Gold Elite Dispatch Sunrise Existing Microwave CAD VPI Gold Elite Dispatch Pembroke Pines Gold Elite Dispatch Coconut Creek

Broward County 800 MHz SmartZone Simulcast

• Ft. Lauderdale

800 MHz P25 Simulcast Coral Springs 800 MHz P25 Simulcast Plantation 800 MHz P25 Single Site Hollywood 800 MHz SmartZone Simulcast

MOTOROLA PHASE TRANSITION PLAN

21

Step 1: Replace Gold Elite Consoles at 3 dispatch centers with new MCC 7500 consoles. Step 2: Implement geo-diverse ASTRO 25 IP cores at Sunrise and Coconut Creek. Step 4: Build out new 6/11 GHz MPLS microwave backbone; still support T1 connections. Step 6: Implement first phase channel cutover to P25 TDMA; cutover designated users. Step 7: Implement second phase channel cutover to P25 TDMA and designated users. Step 8: Complete remaining channels cutover to P25 TDMA; cutover remaining users. Step 9: Upgrade system and consoles to current release (7.17 and 7500e). Step 10: Final acceptance testing. Step 5: Implement geo-diverse prime sites at Hard Rock and CORE. Step 3: Implement ISSI connection from Broward County cores to Motorola Hosted Core. Site Construction DC Power Systems

MZC Zone Controllers Network Management

Hosted Master Core

FINAL STEP – UPGRADE SYSTEM AND CONSOLES TO LATEST SYSTEM RELEASE

• Ft. Lauderdale

800 MHz P25 Simulcast

CAD VPI

Coral Springs 800 MHz P25 Simulcast Plantation 800 MHz P25 Single Site Hollywood 800 MHz SmartZone Simulcast

MZC Zone Controllers Network Management

Broward County Core (x2) Geographic Diversity) Sunrise and Coconut Creek

Broward County 700 MHz P25 Simulcast

MCC7500e Dispatch Sunrise MCC7500e Dispatch Pembroke Pines MCC7500e Dispatch Coconut Creek AVIAT Microwave Dual Loop Configuration

Unique Advantage Guarantees Success

Constructible system design approach

YES

Intimate knowledge of current County and municipal systems

YES

Expedite the completion of the County TRBO system

YES

Continued use of SmartX interface to Hosted Master Site

YES

Single rack implementation for new microwave

YES

Followed County instructions in RFP (support T1 connectivity)

YES

Full knowledge transfer for dispatch user experience

YES

23

KEY ADVANTAGES OF MOTOROLA TRANSITION

P25 Radio System

Day to Day Operations

24

System Performance Broward Environment

Presented by: Clay Whitehead

25

Describe how your firm’s proposed system will perform in the County’s environment as compared to other systems for other counties.

PERFORMANCE IN THE BROWARD COUNTY ENVIRONMENT – SIMILAR GEOGRAPHY

26

27

PERFORMANCE IN THE BROWARD COUNTY ENVIRONMENT – SIMILAR SIZE

STATE OF MARYLAND PIMA COUNTY LA-RICS SAN FRANCISCO HARRIS COUNTY HOUSTON STATE OF MISSISSIPPI COBB COUNTY FULTON COUNTY COOK COUNTY NW CENTRAL DISPATCH LOUDON COUNTY PRINCE GEORGES COUNTY LAS VEGAS METRO PD WASHINGTON, DC NJ STATE POLICE STATE OF CT BOSTON STATE OF TENNESSEE

28

PERFORMANCE IN THE BROWARD COUNTY ENVIRONMENT – SIMILAR SIZE

STATE OF MARYLAND PIMA COUNTY LA-RICS SAN FRANCISCO HARRIS COUNTY HOUSTON STATE OF MISSISSIPPI COBB COUNTY FULTON COUNTY COOK COUNTY NW CENTRAL DISPATCH LOUDON COUNTY PRINCE GEORGES COUNTY LAS VEGAS METRO PD WASHINGTON, DC NJ STATE POLICE STATE OF CT BOSTON STATE OF TENNESSEE

P25 Radio System

Day to Day Operations

30

ASTRO System Resilience and Radio Durability

Presented by: Clay Whitehead & Dax Lopez

31

Please expound on the durability of your firm’s equipment.

ASTRO SYSTEM RESILIENCY DESIGN

32

NO SINGLE POINT OF FAILURE

INTERFERENCE LOCATOR

TRIANGULATE TO LOCATE INTERFERERS

• Locate interference to 0.25 sq. Miles
• Enables Customer techs and STs to quickly

locate and remediate Interference

• Improves Simulcast channel availability

(Simulcast Feature)

PROTECTS THE COUNTY’S GRADE OF SERVICE

MISSION CRITICAL PERFORMANCE

A radio is a first responders communication lifeline Its ability for the radio to be easy to use / accessible [Ergonomics], the ability to talk and clearly hear [Audio] the desired information and the ability to do it in more places [Coverage] for many years to come [Durability] are its most important features.

NO COMPROMISES

RELIABILITY = SAFETY

The Endoskeleton Design offers the best

• f both worlds

Ruggedness & Robustness of a metal housing Ergonomics & shock/impact resistance of a plastic

• uter skin

Sealed Endoskeleton for improved Submersible reliability APX does not rely on the polycarbonate outer housing for water sealing

Polycarbonate Alloy “Skin”

High Abrasion Resistance Improved chemical resistance Impact resistance

Sealed High-Strength Aluminum Alloy Endoskeleton High-Impact Resistant Polycarbonate “Skin”

BUILT TO LAST

Gorilla Glass Display technology improves display performance by 5x factor while increasing display size Brightness improves viewing angle to 170 degrees. Eliminates Bi-fringence effect (rainbow effect due to injection molding or polarized sunglasses.

UNCOMPROMISING SPECS

± 72 dB ± 98 dB ± .1 ppm ± 81 dB 1500 mW .211 µV ± 53 dB Spurious Response Audio Distortion Frequency Stability FM Hum and Noise (12.5kHz) Audio Output Intermodulation Sensitivity (Digital 5% BER) 0.9% Selectivity (12.5kHz) ± 48 dB ± .1 ppm 0.6 % FM Hum and Noise Frequency Stability (12.5kHz) Audio Distortion Transmitter Specifications APX Market Leader Coverage Coverage Audio & Coverage Coverage Audio Coverage Audio & Coverage Audio Audio & Coverage Coverage Audio Audio Quality Receiver Specifications APX Market Leader How it affects User Performance… Audio / Coverage

MULTI-MIC NOISE CANCELLING

Maximum Sensitivity Minimum Sensitivity Minimum Sensitivity Minimum Sensitivity Minimum Sensitivity

• BEAM FORMING
• ADAPTIVE NOISE SUPPRESSION
• ADAPTIVE SPEAKER

EQUALIZATION

• ADAPTIVE AGC
• ADAPTIVE WIND PORTING

Logging Recorder

41

Value-Added Features Above the P25 Standard

Presented by: Dax Lopez

42

Highlight features and functions of your firm’s proposed system that will add value for the County compared to the County’s existing

• system. Are there any features that the County will not be able to
• btain? Are there any limitations?

LOCATION ON PTT

ENHANCED COMMAND VISIBILITY

Location sent upon PTT in addition to regular time or distance based updates

• Location updates sent during voice group calls and emergency calls
• Location updates sent even if no data channels are available
• Not available with APX radios on Non-Motorola Infrastructure

LOCATION ON PTT

43

ENHANCED GEO SELECT

DYNAMIC OPERATION BASED ON LOCATION

• Draw a Geo Fence in your Mapping Application and send parameters to the Radio
• Permanent or Dynamic Maps supported
• Can Trigger Channel Selected, Voice Announcements, Color Updates
• Not available with APX radios on Non-Motorola Infrastructure

TALKGROUP TEXT MESSAGING

SIMULTANEOUSLY TEXT / ALERT RADIO USERS

Dispatcher

Talkgroup Text

CORE

• Quick Send a Text to entire Talkgroup.
• Everyone receives the message Simultaneously
• No impact to IV&D
• Not available with APX radios on Non-Motorola

Infrastructure

Talkgroup 1 Talkgroup 1 Talkgroup 1

OTA SOFTWARE UPDATE

SIMULTANEOUSLY UPDATE RADIO FIRMWARE

CORE

FIRMWARE (RXX.XX.XX)

• Simultaneous Update of Firmware to all Radios.
• Radios users have no knowledge of Firmware Updates until

complete.

• Not available with APX radios on Non-Motorola

Infrastructure

(Firmware RXX.XX.XX) Radio Management FIRMWARE (RXX.XX.XX)

ALIAS GROUP DOWNLOAD

RAPID ALIAS UPDATES

CORE

(TX) PTT Radio ID = 12345 (RX) Radio Alias

• Sgt. Smith
• Updates to Alias name in the Provisioning Manager or by

User updates all radios and consoles positions.

• Radio updates performed on PTT over Voice Channel.
• Not available with APX radios on Non-Motorola

Infrastructure

(Radio ID 12345 = “Sgt. Smith”) Provisioning Manager App

Console Demos

49

PremierOne CAD to ASTRO 25 Integration

Presented by: Kynan Stevenson

50

Describe how your firm’s proposed system will interface with the PremierOne CAD system.

51

Motorola Integration Advantage Today

Leverage Existing Investment

YES Functionality since 2012 – Proven integration YES Responder Location – Voice PTT/Emergency, CAD-driven poling YES Advanced Messaging – Incidents, messages, queries, CJIS data YES Radio Console Integration – Assign talkgroup, open channel YES Push-To-Talk Status Monitor – Display unit in CAD YES Emergency Activation Alert – Notify CAD and Mobile users YES

Leverage Existing Investment

YES

PREMIERONE INTEGRATION

No Third Party Integrators Required

Logging Recorder

52

Motorola Solutions Long Term Value

Presented by: Clay Whitehead

53

Discuss long term value to Broward County.

4G LTE INTEGRATION – FIRSTNET READY

54 54

4G LTE INTEGRATION – FIRSTNET READY

55 55

LA-RICS

REGIONAL LTE NETWORK

231 SITE REGIONAL LTE NETWORK COMPLEMENTS NEW P25 PHASE 2 TDMA LMR NETWORK INITIAL DEPLOYMENT OF 1,000 LTE VEHICLE MODEMS

TURNKEY SITE SOLUTION - CONSTRUCTIBLE

56

ASTRO 25 AND PREMIERONE ROADMAP

57

MZC Zone Controllers Network Management

Hosted Master Core

• Ft. Lauderdale

800 MHz P25 Simulcast

CAD VPI

Coral Springs 800 MHz P25 Simulcast Plantation 800 MHz P25 Single Site Hollywood 800 MHz SmartZone Simulcast

MZC Zone Controllers Network Management

Broward County Core (x2) Geographic Diversity) Sunrise and Coconut Creek

Broward County 700 MHz P25 Simulcast

MCC Dispatch Sunrise MCC Dispatch Pembroke Pines MCC Dispatch Coconut Creek AVIAT Microwave Dual Loop Configuration

INTEROPERABILITY WITH BROWARD COUNTY MUNICIPALITIES

MOTOROLA FIELD SERVICE ORGANIZATION

59

94 Technical “Badged” Service Personnel 13 Senior Engineers Over 400 years local experience

Logging Recorder

60

Q&A

Logging Recorder

61

DETAILED CUTOVER PLAN

MZC Zone Controllers Network Management

Hosted Master Core

CURRENT CONFIGURATION

Gold Elite Dispatch Sunrise Existing Microwave CAD VPI Gold Elite Dispatch Pembroke Pines Gold Elite Dispatch Coconut Creek

Broward County 800 MHz SmartZone Simulcast

• Ft. Lauderdale

800 MHz P25 Simulcast Coral Springs 800 MHz P25 Simulcast Plantation 800 MHz P25 Single Site Hollywood 800 MHz SmartZone Simulcast

MZC Zone Controllers Network Management

Hosted Master Core

STEP ONE – REPLACE CONSOLES

MCC Dispatch Sunrise Existing Microwave CAD VPI MCC Dispatch Pembroke Pines MCC Dispatch Coconut Creek

Broward County 800 MHz SmartZone Simulcast

• Ft. Lauderdale

800 MHz P25 Simulcast Coral Springs 800 MHz P25 Simulcast Plantation 800 MHz P25 Single Site Hollywood 800 MHz SmartZone Simulcast

MZC Zone Controllers Network Management

Hosted Master Core

STEP TWO – INSTALL REDUNDANT CORES

Existing Microwave CAD VPI

MZC Zone Controllers Network Management

Broward County Core (x2) Geographic Diversity) Sunrise & Coconut Creek

Broward County 800 MHz SmartZone Simulcast

• Ft. Lauderdale

800 MHz P25 Simulcast Coral Springs 800 MHz P25 Simulcast Plantation 800 MHz P25 Single Site Hollywood 800 MHz SmartZone Simulcast

MCC Dispatch Sunrise MCC Dispatch Pembroke Pines MCC Dispatch Coconut Creek

MZC Zone Controllers Network Management

Hosted Master Core

STEP THREE – BUILD NEW SITES

Existing Microwave CAD VPI

MZC Zone Controllers Network Management

Broward County Core (x2) Geographic Diversity) Sunrise & Coconut Creek

Broward County 800 MHz SmartZone Simulcast

• Ft. Lauderdale

800 MHz P25 Simulcast Coral Springs 800 MHz P25 Simulcast Plantation 800 MHz P25 Single Site Hollywood 800 MHz SmartZone Simulcast

MCC Dispatch Sunrise MCC Dispatch Pembroke Pines MCC Dispatch Coconut Creek

MZC Zone Controllers Network Management

Hosted Master Core

STEP FOUR – REPLACE MICROWAVE

CAD VPI

MZC Zone Controllers Network Management

Broward County Core (x2) Geographic Diversity) Sunrise and Coconut Creek

Broward County 800 MHz SmartZone Simulcast

• Ft. Lauderdale

800 MHz P25 Simulcast Coral Springs 800 MHz P25 Simulcast Plantation 800 MHz P25 Single Site Hollywood 800 MHz SmartZone Simulcast

MCC Dispatch Sunrise MCC Dispatch Pembroke Pines MCC Dispatch Coconut Creek AVIAT Microwave Dual Loop Configuration

MZC Zone Controllers Network Management

Hosted Master Core

STEP FOUR – PHASED CHANNEL TRANSITION

CAD VPI

MZC Zone Controllers Network Management

Broward County Core (x2) Geographic Diversity) Sunrise & Coconut Creek

Broward County 800 MHz SmartZone 700 MHz P25

• Ft. Lauderdale

800 MHz P25 Simulcast Coral Springs 800 MHz P25 Simulcast Plantation 800 MHz P25 Single Site Hollywood 800 MHz SmartZone Simulcast

MCC Dispatch Sunrise MCC Dispatch Pembroke Pines MCC Dispatch Coconut Creek AVIAT Microwave Dual Loop Configuration

MZC Zone Controllers Network Management

Broward County 700 MHz P25 Simulcast

Hosted Master Core

STEP FOUR – COMPLETE CHANNEL TRANSITION

• Ft. Lauderdale

800 MHz P25 Simulcast

CAD VPI

Coral Springs 800 MHz P25 Simulcast Plantation 800 MHz P25 Single Site Hollywood 800 MHz SmartZone Simulcast

MZC Zone Controllers Network Management

Broward County Core (x2) Geographic Diversity) Sunrise & Coconut Creek MCC Dispatch Sunrise MCC Dispatch Pembroke Pines MCC Dispatch Coconut Creek AVIAT Microwave Dual Loop Configuration

MZC Zone Controllers Network Management

Hosted Master Core

STEP FIVE – COMPLETE DC POWER SYSTEMS AT EXISTING SITES

• Ft. Lauderdale

800 MHz P25 Simulcast

CAD VPI

Coral Springs 800 MHz P25 Simulcast Plantation 800 MHz P25 Single Site Hollywood 800 MHz SmartZone Simulcast

MZC Zone Controllers Network Management

Broward County Core (x2) Geographic Diversity) Sunrise and Coconut

Broward County 700 MHz P25 Simulcast

MCC Dispatch Sunrise MCC Dispatch Pembroke Pines MCC Dispatch Coconut Creek AVIAT Microwave Dual Loop Configuration

MZC Zone Controllers Network Management

Hosted Master Core

STEP SIX – CONNECT MCC DISPATCH CONSOLES TO BROWARD CORES

• Ft. Lauderdale

800 MHz P25 Simulcast

CAD VPI

Coral Springs 800 MHz P25 Simulcast Plantation 800 MHz P25 Single Site Hollywood 800 MHz SmartZone Simulcast

MZC Zone Controllers Network Management

Broward County Core (x2) Geographic Diversity) Sunrise and Coconut Creek

Broward County 700 MHz P25 Simulcast

MCC Dispatch Sunrise MCC Dispatch Pembroke Pines MCC Dispatch Coconut Creek AVIAT Microwave Dual Loop Configuration

MZC Zone Controllers Network Management

Hosted Master Core

FINAL STEP – UPGRADE SYSTEM AND CONSOLES TO LATEST SYSTEM RELEASE

• Ft. Lauderdale

800 MHz P25 Simulcast

CAD VPI

Coral Springs 800 MHz P25 Simulcast Plantation 800 MHz P25 Single Site Hollywood 800 MHz SmartZone Simulcast

MZC Zone Controllers Network Management

Broward County Core (x2) Geographic Diversity) Sunrise and Coconut Creek

Broward County 700 MHz P25 Simulcast

MCC Dispatch Sunrise MCC Dispatch Pembroke Pines MCC Dispatch Coconut Creek AVIAT Microwave Dual Loop Configuration

72

73
