SLIDE 1
Broward County Traffic Engineering Programs
- Traffic Signal Coordination
- Hardware and Software Technologies
Broward County Traffic Engineering Programs Broward County Traffic - - PowerPoint PPT Presentation
Broward County Traffic Engineering Programs Broward County Traffic - - PowerPoint PPT Presentation
Broward County Traffic Engineering Programs Broward County Traffic Engineering Programs Traffic Signal Coordination Hardware and Software Technologies Broward County Traffic Engineering Programs Traffic Signal Coordination
SLIDE 2
SLIDE 3
Broward County Traffic Engineering Programs
- Traffic Signal Coordination
- Hardware and Software Technologies
SLIDE 4
County’s Traffic Signal Network
4
- 1,400+ signalized intersections
- 100’s miles of underground copper and fiber-
- ptic communications
SLIDE 5
Traffic Signal Cycle Red-Yellow-Green Phases
5
Minor Street Major Street Left Turns Major Street
SLIDE 6
6
[NORTH]
A Street A Street B Street C Street D Street E Street F Street
TIME
= GREEN PHASE MAJOR STREET = RED PHASE MAJOR STREET
Typical Signal Progression
SLIDE 7
7
[NORTH]
A Street A Street B Street C Street D Street E Street F Street
TIME
= GREEN PHASE MAJOR STREET = RED PHASE MAJOR STREET
Well-Synchronized (Goal)
SLIDE 8
8
Half-Cycling Concept in Downtown Areas
[NORTH]
A Street B Street C Street D Street E Street F Street G Street
TIME
= GREEN PHASE MAJOR STREET = RED PHASE MAJOR STREET
80 SEC 160 SEC
SLIDE 9
9
Half-Cycling Concept in Downtown Areas
[NORTH]
A Street B Street C Street D Street E Street F Street G Street
TIME
= GREEN PHASE MAJOR STREET = RED PHASE MAJOR STREET
WALK WALK WALK WALK
80 SEC 160 SEC
SLIDE 10
Complex Cross-Coordination
Thousands of movements (17,000+), a very large grid, optimized in all directions
10
SLIDE 11
Ongoing Signal Coordination Program
August 2010 – May 2012 Green Lights Phase 1 All Major Corridors Retimed June 2012 – April 2014 Green Lights Phase 2 All Major Corridors Refined N/S and E/W Better Integrated
SLIDE 12
Signal Coordination Benefits
- Fuel Saved: $31 Million/Year
- Carbon Emissions Reduced: 660,000 Metric Tons/Year
= 7% Reduction of Transportation Emissions = 3% Reduction of Total Emissions
12
SLIDE 13
Ongoing Signal Coordination Program
Regularly update, test, refine and adjust signal timing to address changing traffic volumes and patterns
SLIDE 14
Ongoing Signal Coordination Program
Synchronization Adjustments Using GPS Recordings
“After” Travel Time = 199 Seconds “Before” Travel Time = 310 Seconds Travel Time Savings = 111 Sec. (36%)
SLIDE 15
Signal Coordination is Impacted by:
- Railroad crossings and bridge openings
- Emergency vehicle preemptions
- Construction
- School zones
- Crashes
SLIDE 16
Inflow > Outflow = Storage (or Overspill)
18
SLIDE 17
Overcapacity = Congestion
Cannot be overcome by signal timing adjustments
19
SLIDE 18
Broward County Traffic Engineering Programs
- Traffic Signal Coordination
- Hardware and Software Technologies
SLIDE 19
Outdated System Has Been Upgraded
Fully Modernized - July 2015
SLIDE 20
Coordinated Even With Network Interruptions
22
SLIDE 21
Remote Troubleshooting
23
SLIDE 22
Quicker Response Times
24
SLIDE 23
Assists Buses to Maintain Schedules
25
Transit signal priority at 650+ intersections
SLIDE 24
Transit Signal Priority (TSP)
26
- Buses are tracked using GPS (satellite)
- Bus requests “green extension” or “early green
return” of traffic signal to stay on schedule
SLIDE 25
Bike Safety Enhancements
New Technology – Video Bike Detection
SLIDE 26
Bike Safety Enhancements
New Technology – Video Bike Detection
SLIDE 27
Bike Safety Enhancements
New Technology – Video Bike Detection
SLIDE 28
Bike Safety Enhancements
New Technology – Video Bike Detection
SLIDE 29
Bike Safety Enhancements
New Technology – Video Bike Detection
SLIDE 30
Bike Safety Enhancements
New Technology – Video Bike Detection
SLIDE 31
Bike Safety Enhancements Bike Traffic Signal Indications
SLIDE 32
Questions?
Contact us at:
TRAFFIC@Broward.org
34
