Biosolids Program Evaluation Walworth County Metropolitan (WalCoMet) Sewerage District Tom Foley, P.E. Omkar Ghavi, P.E. BACKGROUND WalCoMet Background Serves 11 entities including Elkorn, Delavan, Darien, Williams Bay 7.0 MGD/ 20.2

slide-1
SLIDE 1

Biosolids Program Evaluation

Walworth County Metropolitan (WalCoMet) Sewerage District

Tom Foley, P.E. Omkar Ghavi, P.E.

slide-2
SLIDE 2

BACKGROUND

slide-3
SLIDE 3

Walworth County Metropolitan Sewerage District

› Serves 11 entities

including Elkorn, Delavan, Darien, Williams Bay

› 7.0 MGD/ 20.2 MGD › Class “B” liquid land

application

WalCoMet Background

slide-4
SLIDE 4

Walworth County Metropolitan Sewerage District

WalCoMet Background

slide-5
SLIDE 5

Existing Biosolids Process

slide-6
SLIDE 6

Existing Biosolids Program

› Biosolids applied to

WalCoMet owned farm (300 ac) or to nearby farm fields ($)

› Approximately

4,000,000 gallons land applied yearly

slide-7
SLIDE 7

Goals

› Analyze existing program

and alternatives

› Develop financial model › Identify low cost solutions › Provide recommendations

slide-8
SLIDE 8

Biosolids Disposal Issues

› Late harvest jeopardizes

fall land application

› Potential future issues:

– Limited land availability – More stringent regulations – Increased solids production – Rising resource costs

slide-9
SLIDE 9

Alternatives

› Continued liquid land application › Dewatering & land application › Dewatering & landfilling › Class “A” sludge production

– Composting – Lime Stabilization – Heat Drying – Thermophilic Digestion – Thermal Hydrolysis

slide-10
SLIDE 10

Financial Modeling Tool

› Input operating cost parameters › Track costs over 20 year planning period › View costs over time for the modeled

alternatives

slide-11
SLIDE 11

FINANCIAL MODEL DEVELOPMENT

slide-12
SLIDE 12

Financial Model

Finan ancial cial Model

Parameters Parameters & More Parameters

slide-13
SLIDE 13

Financial Model Development

› Financial Model Components

– Process – Economics

› Adjustment to Input Parameters

– Compare Scenarios

› Quantity Costs for Alternatives

– Capital Costs – O&M Costs – Present Value Costs

slide-14
SLIDE 14

Financial Model

Sludge Management

  • Sludge Hauling Scenarios
  • Land Application
  • Land Acquisition
  • Landfilling
  • Outside Haulers
  • Class A Biosolids Revenue

Operating Data

  • Sludge
  • Daily Production
  • Handling
  • Stabilization
  • No. of Units
  • Operating Hours
  • Chemicals

Financial Data

  • Planning Parameters
  • Capital Costs
  • O&M Costs
  • Labor
  • Electricity
  • Fuel
  • Chemical
  • Revenue
  • Escalation
slide-15
SLIDE 15

Financial Model

slide-16
SLIDE 16

Process Model

Process Model

Sludge Production Operational Parameters Treatment Performance

Model Output

  • Annual Solids

(Class A/ Class B)

  • Consumables

(Chemicals, Power, Natural Gas, Fuel, etc.)

slide-17
SLIDE 17

Process Model

Mass Balance

slide-18
SLIDE 18

Model Output

slide-19
SLIDE 19

Model Output

slide-20
SLIDE 20

Model Output

slide-21
SLIDE 21

SCENARIOS

slide-22
SLIDE 22

Liquid Land Application

$- $2,000,000 $4,000,000 $6,000,000 $8,000,000 $10,000,000 $12,000,000 $14,000,000 2016 2018 2020 2022 2024 2026 2028 2030 2032 2034 2036 Cumulative Life Cycle Cost

Year

On Farm Haul <5 mi Haul >5 mi Land Acquisition Outside Hauler

1

2 3 4 5 2 3 4

1

5

slide-23
SLIDE 23

Land Acquisition

$- $2,000,000 $4,000,000 $6,000,000 $8,000,000 $10,000,000 $12,000,000 2016 2018 2020 2022 2024 2026 2028 2030 2032 2034 2036 Cumulative Life Cycle Cost Haul 10 miles Land Acquisition

slide-24
SLIDE 24

Land Acquisition

$- $2,000,000 $4,000,000 $6,000,000 $8,000,000 $10,000,000 $12,000,000 2016 2018 2020 2022 2024 2026 2028 2030 2032 2034 2036 Cumulative Life Cycle Cost Haul 15 miles Land Acquisition

slide-25
SLIDE 25

Liquid vs Solid Application

$- $2,000,000 $4,000,000 $6,000,000 $8,000,000 $10,000,000 $12,000,000 $14,000,000 2016 2018 2020 2022 2024 2026 2028 2030 2032 2034 2036 Cumulative Life Cycle Cost Year On Farm Haul <5 mi Haul >5 mi Land Acquisition Dewatering Landfilling

1 1

2 2 3 3 4 5 6 4 5 6

slide-26
SLIDE 26

Liquid vs Solid Application

$- $2,000,000 $4,000,000 $6,000,000 $8,000,000 $10,000,000 $12,000,000 $14,000,000 2016 2021 2026 2031 2036 Cumulative Life Cycle Cost Dewatering Haul/Land Apply on Farm

slide-27
SLIDE 27

Liquid vs Solid Application

$- $2,000,000 $4,000,000 $6,000,000 $8,000,000 $10,000,000 $12,000,000 $14,000,000 2016 2021 2026 2031 2036 Cumulative Life Cycle Analysis Dewatering (2x Fuel) Haul 15 miles (2x Fuel)

slide-28
SLIDE 28

Liquid vs Solid Application

$- $2,000,000 $4,000,000 $6,000,000 $8,000,000 $10,000,000 $12,000,000 $14,000,000 2016 2021 2026 2031 2036 Cumulative Life Cycle Analysis Dewatering (2x Fuel) Haul 15 miles (2x Fuel) Land Acquisition (2x fuel)

slide-29
SLIDE 29

Class “A” Alternatives

$- $2 $4 $6 $8 $10 $12 $14 $16 $18 $20 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Cumulative Life Cycle Cost Millions Year

Option B-1 Liquid Sludge Hauling Option B-2 Dewatering/Solids Hauling Option A-1 Sludge Composting Option A-2 Heat Drying Option A-3 Lime Stabilization Option A-4 Thermophilic Digester Option A-5 Thermal Hydrolysis

B-1 B-2 A-1 A-2 A-3 A-4 A-5

slide-30
SLIDE 30

Recommendations

› Current biosolids program is the lowest cost

and proven option

– Land acquisition and crop rotation will help ensure long term success

› Capital costs of alternatives outweigh

potential savings over a 20 year outlook

› Monitor operation and maintenance costs

using the model to track trends

slide-31
SLIDE 31

› Tom Foley

– tom.foley@clarkdietz.com

› Omkar Ghavi

– omkar.ghavi@clarkdietz.com

Questions?
