Big Bang, and the Cosmic Microwave Background Eiichiro Komatsu (Max-Planck-Institut fr Astrophysik, Garching) Celebration for the continuation of the Universe Cluster Deutsches Museum, November 22, 2012 1 Cosmology: The Questions How much

slide-1
SLIDE 1

Big Bang, and the Cosmic Microwave Background

Eiichiro Komatsu (Max-Planck-Institut für Astrophysik, Garching) Celebration for the continuation of the Universe Cluster Deutsches Museum, November 22, 2012

1

slide-2
SLIDE 2

Cosmology: The Questions

  • How much do we understand our Universe?
  • How old is it?
  • How big is it?
  • What shape does it take?
  • What is it made of?
  • How did it begin?

2

slide-3
SLIDE 3

The Breakthrough

  • Now we can observe the physical condition of the

Universe when it was very young.

3

slide-4
SLIDE 4

Cosmic Microwave Background (CMB)

  • Fossil light of the Big Bang!

4

slide-5
SLIDE 5

From “Cosmic Voyage”

slide-6
SLIDE 6

Night Sky in Optical (~0.5µm)

6

slide-7
SLIDE 7

Night Sky in Microwave (~1mm)

7

slide-8
SLIDE 8

Night Sky in Microwave (~1mm)

8

Ttoday=2.725K

COBE Satellite, 1989-1993

slide-9
SLIDE 9

Spectrum of CMB

4K Black-body 2.725K Black-body 2K Black-body Rocket (COBRA) Satellite (COBE/FIRAS) CN Rotational Transition Ground-based Balloon-borne Satellite (COBE/DMR)

Wavelength

3mm 0.3mm 30cm 3m

Brightness, W/m2/sr/Hz

9

(from Samtleben et al. 2007)

slide-10
SLIDE 10

Arno Penzias & Robert Wilson, 1965

10

  • Isotropic
  • Unpolarized
slide-11
SLIDE 11

“For their discovery of cosmic microwave background radiation”

11

slide-12
SLIDE 12
  • P. Roll and D. Wilkinson, 1966

D.Wilkinson (W of WMAP)

12

slide-13
SLIDE 13
  • The spectrum of CMB has a peak at 1.1mm.
  • Let’s compare it with…

–Microwave oven: 12cm –Cellular phone: 20cm –UHF Television: 39-64cm –FM radio: 3m –AM radio: 300m

You can “see” CMB by TV (not by a cable TV of course!). Perhaps you can “hear” CMB by a cell phone?

13

  • Dr. Hiranya Peiris

University College London

slide-14
SLIDE 14

How was CMB created?

  • When the Universe was hot, it was a hot soup made of:
  • Protons, electrons, and helium nuclei
  • Photons and neutrinos
  • Dark matter (DM)
  • DM does not do much, except for providing a a

gravitational potential because ρDM/ρH,He~5

14

slide-15
SLIDE 15

Universe as a hot soup

  • Free electrons can

scatter photons efficiently.

  • Photons cannot go

very far. proton helium electron photon

15

slide-16
SLIDE 16

Recombination and Decoupling

  • [recombination]

When the temperature falls below 3000 K, almost all electrons are captured by protons and helium nuclei.

  • [decoupling] Photons

are no longer

  • scattered. I.e., photons

and electrons are no longer coupled. Time 1500K 6000K

3000K

16

proton helium electron photon

slide-17
SLIDE 17
slide-18
SLIDE 18

COBE/DMR, 1992

  • Isotropic?
  • CMB is anisotropic! (at the 1/100,000

level)

18

Smoot et al. (1992)

1cm 6mm 3mm

slide-19
SLIDE 19

“For their discovery of the blackbody form and anisotropy

  • f the cosmic microwave background radiation”

19

slide-20
SLIDE 20

CMB: The Farthest and Oldest Light That We Can Ever Hope To Observe Directly

  • When the Universe was 3000K (~380,000 years after the Big Bang),

electrons and protons were combined to form neutral hydrogen.

20

slide-21
SLIDE 21

WMAP at Lagrange 2 (L2) Point

  • L2 is a million miles from Earth
  • WMAP leaves Earth, Moon, and Sun

behind it to avoid radiation from them

June 2001: WMAP launched!

February 2003: The first-year data release March 2006: The three-year data release March 2008: The five-year data release January 2010: The seven-year data release

21

used to be September 8, 2010: WMAP left L2

slide-22
SLIDE 22

WMAP at Lagrange 2 (L2) Point

  • L2 is a million miles from Earth
  • WMAP leaves Earth, Moon, and Sun

behind it to avoid radiation from them

June 2001: WMAP launched!

February 2003: The first-year data release March 2006: The three-year data release March 2008: The five-year data release January 2010: The seven-year data release

22

used to be September 8, 2010: WMAP left L2

We are currently working

  • n the final data release!

(nine-year data release)

slide-23
SLIDE 23

WMAP WMAP Spacecraft Spacecraft

thermally isolated instrument cylinder secondary reflectors focal plane assembly feed horns back to back Gregorian optics, 1.4 x 1.6 m primaries upper omni antenna line of sight deployed solar array w/ web shielding medium gain antennae passive thermal radiator warm spacecraft with:

  • instrument electronics
  • attitude control/propulsion
  • command/data handling
  • battery and power control

60K 90K

300K

Radiative Cooling: No Cryogenic System

23

slide-24
SLIDE 24

COBE to WMAP (x35 better resolution)

COBE WMAP

COBE 1989 WMAP 2001

24

slide-25
SLIDE 25

WMAP 7-Year Science Team

  • C.L. Bennett
  • G. Hinshaw
  • N. Jarosik
  • S.S. Meyer
  • L. Page
  • D.N. Spergel
  • E.L. Wright
  • M.R. Greason
  • M. Halpern
  • R.S. Hill
  • A. Kogut
  • M. Limon
  • N. Odegard
  • G.S. Tucker
  • J. L.Weiland
  • E.Wollack
  • J. Dunkley
  • B. Gold
  • E. Komatsu
  • D. Larson
  • M.R. Nolta
  • K.M. Smith
  • C. Barnes
  • R. Bean
  • O. Dore
  • H.V. Peiris
  • L.

Verde

25

slide-26
SLIDE 26

Cosmic Pie Chart: 7-year

  • Standard Model
  • H&He = 4.58% (±0.16%)
  • Dark Matter = 22.9% (±1.5%)
  • Dark Energy = 72.5% (±1.6%)
  • H0=70.2±1.4 km/s/Mpc
  • Age of the Universe = 13.76 billion

years (±0.11 billion years)

“ScienceNews” article on the WMAP 7-year results

26

How did we obtain these numbers?

slide-27
SLIDE 27

23 GHz [unpolarized]

27

slide-28
SLIDE 28

33 GHz [unpolarized]

28

slide-29
SLIDE 29

41 GHz [unpolarized]

29

slide-30
SLIDE 30

61 GHz [unpolarized]

30

slide-31
SLIDE 31

94 GHz [unpolarized]

31

slide-32
SLIDE 32

How many components?

  • 1. CMB: Tν~ν0
  • 2. Synchrotron (electrons going around magnetic

fields): Tν~ν–3

  • 3. Free-free (electrons colliding with protons): Tν~ν–2
  • 4. Dust (heated dust emitting thermal emission): Tν~ν2
  • 5. Spinning dust (rapidly rotating tiny dust grains):

Tν~complicated You need at least five frequencies to separate them!

32

slide-33
SLIDE 33

Galaxy-cleaned Map

33

slide-34
SLIDE 34

Analysis: 2-point Correlation

  • C(θ)=(1/4π)∑(2l+1)ClPl(cosθ)
  • How are temperatures on two

points on the sky, separated by θ, are correlated?

  • “Power Spectrum,” Cl

– How much fluctuation power do we have at a given angular scale? – l~180 degrees / θ

34

θ

COBE WMAP

slide-35
SLIDE 35

COBE/DMR Power Spectrum Angle ~ 180 deg / l

Angular Wavenumber, l

35

~9 deg ~90 deg (quadrupole)

slide-36
SLIDE 36

COBE To WMAP

  • COBE is unable to resolve the

structures below ~7 degrees

  • WMAP’s resolving power is 35

times better than COBE.

  • What did WMAP see?

36

θ

COBE WMAP

θ

slide-37
SLIDE 37

WMAP Power Spectrum

Angular Power Spectrum Large Scale Small Scale about 1 degree

  • n the sky

COBE

37

slide-38
SLIDE 38

The Cosmic Sound Wave

  • “The Universe as a Miso soup”
  • Main Ingredients: protons, helium nuclei, electrons, photons
  • We measure the composition of the Universe by

analyzing the wave form of the cosmic sound waves.

38

slide-39
SLIDE 39

CMB to Baryon & Dark Matter

  • 1-to-2: baryon-to-photon ratio
  • 1-to-3: matter-to-radiation ratio (zEQ: equality redshift)

Baryon Density (Ωb) Total Matter Density (Ωm) =Baryon+Dark Matter

39

slide-40
SLIDE 40

CMB Polarization

  • CMB is (very weakly) polarized!

40

slide-41
SLIDE 41

“Stokes Parameters”

41

Q<0; U=0 North East

slide-42
SLIDE 42

23 GHz [polarized]

Stokes Q Stokes U

42

slide-43
SLIDE 43

23 GHz [polarized]

Stokes Q Stokes U North East

43

slide-44
SLIDE 44

33 GHz [polarized]

Stokes Q Stokes U

44

slide-45
SLIDE 45

41 GHz [polarized]

Stokes Q Stokes U

45

slide-46
SLIDE 46

61 GHz [polarized]

Stokes Q Stokes U

46

slide-47
SLIDE 47

94 GHz [polarized]

Stokes Q Stokes U

47

slide-48
SLIDE 48

How many components?

  • 1. CMB: Tν~ν0
  • 2. Synchrotron (electrons going around magnetic

fields): Tν~ν–3

  • 3. Free-free (electrons colliding with protons): Tν~ν–2
  • 4. Dust (heated dust emitting thermal emission): Tν~ν2
  • 5. Spinning dust (rapidly rotating tiny dust grains):

Tν~complicated You need at least THREE frequencies to separate them!

48

slide-49
SLIDE 49

Physics of CMB Polarization

  • CMB Polarization is created by a local temperature

quadrupole anisotropy.

49

Wayne Hu

slide-50
SLIDE 50

Stacking Analysis

  • Stack polarization

images around temperature hot and cold spots.

  • Outside of the Galaxy

mask (not shown), there are 12387 hot spots and 12628 cold spots.

50

slide-51
SLIDE 51

Radial and Tangential Polarization Patterns around Temp. Spots

  • All hot and cold spots are stacked
  • “Compression phase” at θ=1.2 deg and

“slow-down phase” at θ=0.6 deg are predicted to be there and we observe them!

  • The overall significance level: 8σ

51

slide-52
SLIDE 52

E-mode and B-mode

  • Gravitational potential

can generate the E- mode polarization, but not B-modes.

  • Gravitational

waves can generate both E- and B-modes!

B mode E mode

52

slide-53
SLIDE 53

Gravitational waves are coming toward you... What do you do?

  • Gravitational waves stretch

space, causing particles to move.

53

slide-54
SLIDE 54

Two Polarization States of GW

  • This is great - this will automatically

generate quadrupolar anisotropy around electrons!

54

slide-55
SLIDE 55

From GW to CMB Polarization

55

Electron

slide-56
SLIDE 56

From GW to CMB Polarization

56

Redshift Redshift Blueshift Blueshift R e d s h i f t R e d s h i f t B l u e s h i f t B l u e s h i f t

slide-57
SLIDE 57

From GW to CMB Polarization

57

Gravitational waves can produce both E- and B-mode polarization

slide-58
SLIDE 58

“Tensor-to-scalar Ratio,” r

r = [Power in Gravitational Waves] / [Power in Gravitational Potential]

Theory of “Cosmic Inflation” predicts r <~ 1 – I will come back to this in a moment

58

slide-59
SLIDE 59
  • No detection of B-mode polarization yet.

B-mode is the next holy grail!

Polarization Power Spectrum

59

slide-60
SLIDE 60

Theory of the Very Early Universe

  • The leading theoretical idea about the primordial Universe,

called “Cosmic Inflation,” predicts:

  • The expansion of our Universe accelerated in a tiny

fraction of a second after its birth.

  • Just like Dark Energy accelerating today’s expansion: the

acceleration also happened at very, very early times!

  • Inflation stretches “micro to macro”
  • In a tiny fraction of a second, the size of an atomic nucleus

(~10-15m) would be stretched to 1 A.U. (~1011m), at least.

60

(Guth 1981; Linde 1982; Albrecht & Steinhardt 1982; Starobinsky 1980)

slide-61
SLIDE 61

Cosmic Inflation = Very Early Dark Energy

61

slide-62
SLIDE 62

Origin of Fluctuations

  • OK, back to the cosmic hot soup.
  • The sound waves were created when we perturbed it.
  • “We”? Who?
  • Who actually perturbed the cosmic soup?
  • Who generated the original (seed) ripples?

62

slide-63
SLIDE 63

WMAP Power Spectrum

Angular Power Spectrum Large Scale Small Scale about 1 degree

  • n the sky

COBE

63

slide-64
SLIDE 64

Getting rid of the Sound Waves

Angular Power Spectrum

64

Primordial Ripples

Large Scale Small Scale

slide-65
SLIDE 65

The Early Universe Could Have Done This Instead

Angular Power Spectrum

65

More Power on Large Scales

Small Scale Large Scale

slide-66
SLIDE 66

...or, This.

Angular Power Spectrum

66

More Power on Small Scales

Small Scale Large Scale

slide-67
SLIDE 67

...or, This.

Angular Power Spectrum

67

Small Scale Large Scale

Parametrization: l(l+1)Cl ~ lns–1 And, inflation predicts ns~1

slide-68
SLIDE 68

Theory Says...

  • The leading theoretical idea about the primordial Universe,

called “Cosmic Inflation,” predicts:

  • The expansion of our Universe accelerated in a tiny

fraction of a second after its birth.

  • the primordial ripples were created by quantum

fluctuations during inflation, and

  • how the power is distributed over the scales is

determined by the expansion history during cosmic inflation.

  • Measurement of ns gives us this remarkable information!

68

slide-69
SLIDE 69

Stretching Micro to Macro

Macroscopic size at which gravity becomes important δφ Quantum fluctuations on microscopic scales INFLATION! Quantum fluctuations cease to be quantum, and become observable! δφ

69

slide-70
SLIDE 70

Inflation Offers a Magnifier for Microscopic World

  • Using the power spectrum of primordial fluctuations

imprinted in CMB, we can observe the quantum phenomena at the ultra high-energy scales that would never be reached by the particle accelerator.

  • Measured value: ns = 0.968 ± 0.012 (68%CL)

70

slide-71
SLIDE 71
  • Quantum fluctuations also generate ripples in space-

time, i.e., gravitational waves, by the same mechanism.

  • Primordial gravitational waves generate temperature

anisotropy in CMB, as well as polarization in CMB with a distinct pattern called “B-mode polarization.” h = (Expansion Rate)/(21/2πMplanck) [in natural units] [h = “strain”]

71

(Tensor) Quantum Fluctuations, a.k.a. Gravitational Waves

Starobinsky (1979)

slide-72
SLIDE 72

Probing Inflation (2-point Function)

  • Joint constraint on the

primordial tilt, ns, and the tensor-to-scalar ratio, r.

  • r < 0.24 (95%CL)

72

slide-73
SLIDE 73

Summary

  • CMB is the fossil light of the Big Bang.
  • We could determine the age, composition, expansion

rate, etc., from CMB.

  • We could even push the boundary farther back in time,

probing the origin of fluctuations in the very early Universe: inflationary epoch at ultra-high energies.

  • Next Big Thing: Primordial gravitational waves.
  • The 3-point function: Powerful test of inflation.

73

slide-74
SLIDE 74

Bispectrum

  • Three-point function!
  • Bζ(k1,k2,k3)

= <ζk1ζk2ζk3> = (amplitude) x (2π)3δ(k1+k2+k3)F(k1,k2,k3)

74

model-dependent function

k1 k2 k3 Primordial fluctuation ”fNL”

slide-75
SLIDE 75

MOST IMPORTANT

slide-76
SLIDE 76

Probing Inflation (3-point Function)

  • Inflation models predict that primordial fluctuations are very

close to Gaussian.

  • In fact, ALL SINGLE-FIELD models predict a particular form
  • f 3-point function to have the amplitude of fNL=0.02.
  • Detection of fNL>1 would rule out ALL single-field models!
  • No detection of 3-point functions of primordial curvature
  • perturbations. The 95% CL limits are:
  • –10 < fNL < 74
  • The WMAP data are consistent with the prediction of

simple single-field inflation models: 1–ns≈r≈fNL

76

slide-77
SLIDE 77

Trispectrum

  • Tζ(k1,k2,k3,k4)=(2π)3δ(k1+k2+k3+k4)

{gNL[(54/25)Pζ(k1)Pζ(k2)Pζ(k3)+cyc.] +τNL[Pζ(k1)Pζ(k2)(Pζ(|k1+k3|)+Pζ(|k1+k4|))+cyc.]} The local form consistency relation, τNL=(6/5)(fNL)2, may not be respected – additional test of multi-field inflation! k3 k4 k2 k1

gNL

k2 k1 k3 k4

τNL

77

slide-78
SLIDE 78

The diagram that you should take away from this talk.

  • The current limits

from WMAP 7-year are consistent with single-field or multi- field models.

  • So, let’s play around

with the future.

78

ln(fNL) ln(τNL) 74 3.3x104

(Smidt et

  • al. 2010)
slide-79
SLIDE 79

Case A: Single-field Happiness

  • No detection of

anything after

  • Planck. Single-field

survived the test (for the moment: the future galaxy surveys can improve the limits by a factor of ten). ln(fNL) ln(τNL) 10 600

79

slide-80
SLIDE 80

Case B: Multi-field Happiness

  • fNL is detected. Single-

field is dead.

  • But, τNL is also

detected, in accordance with the Suyama-Yamaguchi inequality, as expected from most (if not all - left unproven) of multi- field models. ln(fNL) ln(τNL) 600

80

30

slide-81
SLIDE 81

Case C: Madness

  • fNL is detected. Single-

field is dead.

  • But, τNL is not

detected, inconsistent with the Suyama- Yamaguchi inequality.

  • (With the caveat that

this may not be completely general) BOTH the single-field and multi-field are gone. ln(fNL) ln(τNL) 30 600

81

slide-82
SLIDE 82

Planck Launched!

  • The Planck satellite was successfully launched from French

Guiana on May 14, 2009.

  • Separation from the Herschell satellite was also successful.
  • Planck has mapped the full sky already - results expected to be

released in December, 2012.

82

slide-83
SLIDE 83

Planck: Expected ClTemperature

  • WMAP: l~1000 => Planck: l~3000

83

slide-84
SLIDE 84

Planck: Expected ClPolarization

  • (Above) E-modes
  • (Left) B-modes (r=0.3)

84
