BARCELONA CICLE DE L’AIGUA, SA

1. Introduction 2. Mission 3. Strategic lines 4. Data source 5. Continuous improvement in water management

3 BARCELONA: BUILDING A RESILIENT CITY

3

Sewage system Besòs River Park. Alert System

• Beaches. Alert system

Alternative Water Resources Irrigation system

Drinking fountains. Lakes and fountains

BCASA is a 100% public company created in 2014 by the City Council of Barcelona, attached to the Deputy of Ecology, Urban and Mobility. 101 employee from the Water Cycle Services Direction and CLABSA (Clavegueram de Barcelona, S.A.)

Introduction

BARCELONA CICLE DE L’AIGUA, BCASA

1.

Mission

To manage, coordinate, monitor and optimize with quality, sustainability, participation and mainstreaming the provision of integrated Water Cycle Services:

• Supply
• Sanitation
• Integrated management of the coast
• Other areas of the water cycle

leading all the commitments to improve the environment and fighting climate change, to achieve a sustainable and improved quality of life of citizens.

2.

4

5

3.

Strategic lines

Strategic lines

Water supply

Promote sound policies in order to reduce water consumption

• Ensuring rational use.
• Ensuring the quality of supply.
• Promoting the improvement and development of

the entire water system.

• Collaborate

with

• ther

administrations in the development of hydraulic plans and projects.

3.

6

Sanitation

Promote policies to improve urban drainage

• Improving and extending sewer management.
• Supervising the maintenance of the network.
• Improving

and extending the control and supervision of the work done by others into sewers.

Coast Management

Promote policies to improve the integrated management of the coast

• Promoting a new culture of the beach.
• Coordinating operators.
• Improving the service offered

4.

7

Key data

8

Water supply Dams and reservoirs Desalination plant

Llobregat desalination plant (2009) The largest desalination plant in Europe dedicated to urban supply. Its

• pening made it possible to increase the guarantee and availability of water in

the Barcelona metropolitan area and the area around. This facility can serve 4.5 million inhabitants and can produce up to 60 hm3 of water per year. Furthermore, the start-up of the Llobregat desalination plant has also led to the improved taste and quality of the water supplied to the Barcelona metropolitan area

• 1.666 drinking public fountains.
• 310 ornamental fountains.
• 28 groundwater network operating systems.
• 85 km of groundwater network.
• 3,4 km of regenerated water network.

9

Water supply BCASA management

10

Urban drainage. Coast Management

11

Network magnitudes Network length: 1.800 km Network volume: 3*106 m3 49.500 manholes 72.000 inlets Network typology Combined sewer

30% 15% 35% 10% 10%

Urban drainage. Sewer network

12

Regulation instruments 24 rain gauges 197 limnimeters 49 derivation-retention gates

Urban drainage. Sewer network

Network magnitudes 13 subterranean + 2 opencast stormwater tanks Stormwater tanks volume: 470.000 m3 Volume of regulated water: 145*106 m3 /year

13

Drainage system determinants in Barcelona Llobregat River Besòs River Well-channeled rivers

Mediterranean rain regime: high intensity storms High density of population: 1.6Mhab/98km2 High land imperviousness

Mediterranean Sea

Collserola mountain

Runoff preferred direction Drainage system determinants in Barcelona

Drainage system determinants in Barcelona

WWTP WWTP

Drainage system determinants in Barcelona

WWTP WWTP

Drainage system determinants in Barcelona Low slopes and critical points  FLOODS

Drainage system determinants in Barcelona Combined Sewer Overflows (CSO)

• Total beaches length 4,5 km
• More than 3.800.000 users in summer 2014

Combined Sewer Overflow

19

Integrated Management of the coast

Integrated management of the coast

20

2.554.198 2.281.450 3.670.000 2.490.000 3.446.000 3.752.873 3.802.641 2.000.000 3.000.000 4.000.000 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014

2004 2005 (1) 2006 2008 (2) 2010 2012 2014 MAIG 475.000 190.000 417.000 359.500 135.836 JUNY 722.066 255.217 825.000 500.000 637.000 874.069 892.396 JULIOL 847.522 1.023.167 1.195.000 775.000 1.112.000 1.022.621 1.221.243 AGOST 770.234 733.991 700.000 735.000 937.000 1.167.192 1.079.678 SETEMBRE 214.376 269.075 475.000 290.000 343.000 329.492 473.488 2.554.198 2.281.450 3.670.000 2.490.000 3.446.000 3.752.873 3.802.641

Barcelona beaches, 3,8 millions of visitors in 2014

21

Alternative Water Resource Masterplan. Groundwater network

28 groundwater systems operating Length : 85 km 21 hydrants

22

Alternative Water Resource Masterplan. Water Infrastructure Recovery. Park Güell

Scanner 3D of the water mines at Park Güell

23

Alternative Water Resource Masterplan. Sustainable Urban Drainage Systems (SUDS)

Operative In progress In study Possible location in the future

24

Alternative Water Resource Masterplan. Applicable SUDS to streets in Barcelona

25

SUDS Marina Prat Vermell

26

SUDS Marina Prat Vermell

27

Green roofs & walls – promoting new green spaces in the city – groundwater irrigation

Green Infrastructure and Biodiversity Masterplan

The City of Barcelona is promoting the installation

• f green walls & roofs through the Government

measure 28-10-14

28

Water and urban biodiversity: Protecting aquatic ecosystems

Jardins Mossèn Cinto Verdaguer

Barcelona city promotes since 2008 a program to management ponds and fountains of its parks and gardens with amphibians. The amphibians are the most threatened vertebrates on the planet. In Europe, 23% of species are threatened, according to a study by the

• IUCN. The dependence of two different media, water and land

predisposes them to be very sensitive to deterioration and loss of

• habitats. Protected species:

Common midwife toad –tòtil- (Alytes obstetricans almogavarii) Mediterranean tree frog –reineta- (Hyla meridionalis) Iberian green frog-granota verda- (Pelophylax perezi).

Water and urban biodiversity: Protecting aquatic ecosystems

30

Water and urban biodiversity: Community gardening

Barcelona city promotes since 1997 a program of community gardening for people aged more than 65. The objective is to incorporate them to environmental activities following the ecologic agriculture principles. Nowadays there are 15 gardens between 25 and 40 m2 with seasonal fruit and vegetables, and aromatic plants.

• It has an important social value for its

participants

• It gives the city new green spaces
• Scholars could approach to and practice

agriculture

• It permits coexistence between generations

31

R+D+i programme

ROBOTS FOR THE INSPECTION AND THE CLEARANCE OF THE SEWER NETWORK IN CITIES

RTWQM “Real Time Water Quality Monitoring” The AG “RTWQM” addresses specifically developments that strengthen the interaction between “sensor technologies” and “data analyses & monitoring tools” to safeguard or improve water quality aspects in the different water using sectors following the smart water concept described under 4.7 and 4.9 of the EIP on Water SIP. The essential element of the Industrial Doctorates Plan is the industrial doctorate project, that is, a strategic research project carried out at a company that allows the doctorand to further develop his research training in collaboration with a university, and which is the

• bject of a doctoral thesis.

Industrial Doctorate GIS-platform to improve the hydrogeological knowledge of Barcelona

Continuous improvement in water management

5.

32

Smart water irrigation system

33

• A. Develop and improve the network of groundwater and
• ther water resources alternatives.
• B. Improve irrigation in parks and gardens.
• C. Implement improvements to save water and energy

Installing ornamental fountains recirculation systems, ultrasound equipment for water disinfection, equipment with low energy consumption and equipment for filtering

• D. Promote water conservation in buildings and

municipal services.

Continuous improvement in water management

• 1. Saving measures in parks and gardens

Consumption control and automatic reduction of leakage.

• 1. Flow regulation in public and ornamental fountains

2. Installation of switches and saving systems

• 3. Reduction of tap water consumption for cleaning streets

use of groundwater.

• 4. Promoting water conservation in public buildings
• 5. Reduce the consumption with high efficiency equipment

with meter installation, detection and control of water leaks.

• 6. Saving water in schools

The City Council has promoted the implementation of savings measures in schools and the efficient use of water in the context of Agenda 21.

• 6. Divulgation of advice and practical - Agenda 21

Awareness material to promote the economy and the responsible use of water between citizens and municipal actions: guides, brochures environmental education, websites and exhibitions.

34

Continuous improvement in water management Reduction of water consumption

Continuous improvement in water management Drinking water consumption 1999 – 2015 City of Barcelona.

35

Continuous improvement in water management Municipal Services consumption 1999 - 2015

36

Reduction of consumption of drinking water : 45% Augmentation of consumption of groundwater : 471%. Reduction of consumption of drinking water + groundwater = 28%

Year 2015 Green Spaces Street cleaning Ornamental fountains Sewer network cleaning Other TOTAL %

38,15% 22,66% 27,22% 9,74% 2,24% 100,00%

m3

428.137 327.213 441.276 90.813 135.379 1.422.818 37

Distribution of consumption of groundwater 1999 - 2015 by the Municipal Services

Continuous improvement in water management

38

Continuous improvement in water management Evolution of domestic consumption of drinking water 1995 – 2015 City of Barcelona (l/inhab/day)

Total consumption (domestic, commercial, city council) Domestic consumption
