Auxiloo Background Growing elderly population Projected to double to 98M by 2060 15.7M elderly people have disabilities in the US 67% of them have difficulties walking or climbing $1.35B global market for bathroom and toilet assist
Growing elderly population
○ Projected to double to 98M by 2060
15.7M elderly people have disabilities in the US
○ 67% of them have difficulties walking or climbing
$1.35B global market for bathroom and toilet assist devices
○ Diverse market with 5.6% annual growth
Assistive toilet seat for those with limited physical mobility
Installation Aesthetic Cost Ease of Use Universal Total EZ Access Tilt Aerolet
+
Auxiloo
+ + + +3
Motor torque requirements
○ 2x 40W motors
Rack material requirements
○ Cantilever beam model: 𝝉 = 390 kPa ○ 𝝉y = 215 MPa (stainless steel)
Optimal positioning for mounting/dismounting
○ User observations showed ~45º at the top
45º 350 lbs
Curved rack and pinion design works!
○ But requires strong (and expensive) motors
Constraints are important
○ Compliant materials do not maintain proper alignment ○ Need to increase points of contact to guide racks
Add protective housing to rack/pinion for safety and cleanliness
○ Exposed teeth could cause pinching or jamming
Next Steps
