Building Committee Meeting April 22, 2019 agenda 1. schedule update 2. regulatory update 3. temp space update 4. exterior finishes 5. interior finishes schedule update Item Schedule Dates 60% Design estimate Due 04/29/29 Reconcile

slide-1
SLIDE 1

Building Committee Meeting April 22, 2019

slide-2
SLIDE 2

agenda

  • 1. schedule update
  • 2. regulatory update
  • 3. temp space update
  • 4. exterior finishes
  • 5. interior finishes
slide-3
SLIDE 3

schedule update

slide-4
SLIDE 4

Item Schedule Dates

60% Design estimate Due 04/29/29 Reconcile estimate 4/30/19 – 5/06/19 Prequalification RFQ issued 05/22/19 Prequalification RFQ due 06/05/19 Prequalified firms notified By 7/02/19 100% CDs (Bid Documents) Due by 7/22/19 Advertisement for bid 7/24/19 FSBs due / GCs due 8/14/19 - 08/28/19 Construction NTP 9/11/19

slide-5
SLIDE 5

regulatory update

slide-6
SLIDE 6

Site Plan Review Hearing

Community Development Board Wednesday, April 24th at 6:00pm Medford City Hall, Room 201

ZBA Hearing

Zoning Board of Appeals Monday, April 29th at 7:30pm Medford City Hall, Room 201

slide-7
SLIDE 7
slide-8
SLIDE 8

item required existing proposed

front yard setback 44’-6” 15’-0” 15’-0” rear yard setback 45’-2” 39’-2” 43’-6” lot coverage 30% max 37.8% 38.9% parking spaces 60 26 39 loading bays 1 1

seeking variances for:

slide-9
SLIDE 9

temp space update

slide-10
SLIDE 10

temp space

200 Boston Avenue

slide-11
SLIDE 11

temp space

200 Boston Avenue

slide-12
SLIDE 12

temp space

200 Boston Avenue

existing

111 High Street staff youth services adult collections

slide-13
SLIDE 13

exterior finishes

slide-14
SLIDE 14

exterior elevations

south east west north

slide-15
SLIDE 15

brick

Morin – College Blend – Norman - Waterstruck

slide-16
SLIDE 16

siding

high pressure laminate rainscreen

slide-17
SLIDE 17

roof

standing seam metal

slide-18
SLIDE 18

interior finishes

slide-19
SLIDE 19

level 1

reflected ceiling plan

slide-20
SLIDE 20

wood-look ceilings

adult collections

slide-21
SLIDE 21

level 2

reflected ceiling plan

slide-22
SLIDE 22

wood-look ceiling

level 2

slide-23
SLIDE 23

adult collections

Lapidus – Mantle – Moonstone

slide-24
SLIDE 24

adult collections – reading room

Color Field – Patina – Copper

slide-25
SLIDE 25

teen’s room

Moraine – Explorer – Orange

slide-26
SLIDE 26

children’s room

Moraine – Explorer – Green

slide-27
SLIDE 27

children’s room

Live Circuit – Current – ProtonEnergy

slide-28
SLIDE 28

teen’s room

Live Circuit – Curret – ProtonEnergy

slide-29
SLIDE 29

children/teen shared study rooms

Live Circuit – Curret – Proton

slide-30
SLIDE 30

lobbies

large format tile
