An Overview HOLOS2 is compatible with the following Holophane luminaires: Prismatron (remote ballast) Prismpack S ecapsule Prismalume S ecapsule Luminaire Product Features HID Lamp specs for HOLOS2 Lamps available in 250W, 320W,

slide-1
SLIDE 1

An Overview

slide-2
SLIDE 2

HOLOS2 is compatible with the following Holophane luminaires:

  • Prismatron (remote ballast)
  • Prismpack S ecapsule
  • Prismalume S ecapsule
slide-3
SLIDE 3

Luminaire Product Features

slide-4
SLIDE 4
  • Lamps available in 250W, 320W, 350W, 400W
  • Available initial lumens of 25000, 32000, 35000 & 41000
  • Colour temperatures all 4000K
  • Warranted for use in HOLOS by manufacturer
  • Life of over 20000 hours
  • Smooth dimming
  • Less than 10% colour temp variation across the entire

dimming range

HID Lamp specs for HOLOS2

slide-5
SLIDE 5

HOLOS2 works with HID E- Ballast Technology

slide-6
SLIDE 6

Typical Lumen Maintenance vs Time (Metal Halide Lamps)

Electronic Magnetic Multi Vapour

slide-7
SLIDE 7

Results - Extending Lamp Life

  • 400W Metal-Halide Lamp after 8,000 hours

Operating Hours

Tungsten electrodes - Side view

Smart Electronic Ballast for HID with High Frequency MicroStart™ Ignition Conventional magnetic

slide-8
SLIDE 8

Results – Preventing Wall Blackening

Electronic Ballast Magnetic Ballast

400W Metal-Halide Lamp after 8,000 Operating Hours

slide-9
SLIDE 9

Typical Lumen Output vs Time (Metal Halide Lamps)

Lumen Output

slide-10
SLIDE 10

Reduce costs by 40% Extended lamp life 50% faster lamp start up Consistent wattage via controlled system. Faster re-strike

slide-11
SLIDE 11

Even before adding HOLOS2 controls, Holophane’s prismatic and Eballast technologies will reduce both carbon emissions and energy costs, in addition to savings on installation.

slide-12
SLIDE 12

Good HID Typical T5 Prismpack S

£8,794 £8,674 £11,779 Luminaire & Install £4,400 £5,632 £5,702 Yr 1 Energy

(4,000hrs)

£44,000 £56,320 £57,024 Yr 10 Energy

(40,000hrs)

£52,794 £64,994 £68,803

Project Costs

slide-13
SLIDE 13

Summary

– Available now – 250W, 320W, 350W, 400W – Single lamp ballast – Smooth dimming to c25% light output (50% power)

  • 1-10V analogue dimming
  • Digital dimming

– 35°C Ta – Controlled by HOLOS 2

the energy saving Hi-Bay

slide-14
SLIDE 14
  • A one box solution. Utilising all available energy saving

technologies, and with the potential to control all types of lighting

  • A simple solution for maximum control
  • A working system first time round and ‘out of the box’
  • Contractor friendly
  • Future proof
  • Fail safe

HOLOS2 is designed to give lowest total cost of ownership

slide-15
SLIDE 15

HOLOS2...... very easy to install

slide-16
SLIDE 16
  • Integration into BMS
  • Full user documentation
  • Protected programming data
  • Time clock
  • Adaptable
  • Emergency lighting test and record keeping
  • Based on proven technology
  • Multiple control options
  • Safety & access integration
  • Intelligent
  • Safe

Benefits of the HOLOS2 system

slide-17
SLIDE 17
  • Each ballast will report back a variety of data (49 parameters total)

including:

  • Current temperature
  • Maximum temperature achieved
  • Hours run total
  • Dimmed hours run
  • Full power hours run
  • Input power
  • Output power (lamp Watts)
  • Luminaires individually addressed
  • Flash based - no software to buy
  • Email alert system
  • Dynamic addressing

Holophane’s unique solution

Digital system in a nutshell

slide-18
SLIDE 18

Control Schematic for Waverley Street Station, Edinburgh

HOLOS 2 HOLOS 2 Main Trainshed Lighting Concourse Lighting Platforms 8/9 Canopied Lighting Footbridge Lighting Platforms 8/9 Open Lighting CAT 5 Ethernet to Central Control 230V 50Hz Input Ethernet Link Control Input (Photocells/Override) Control Input (Photocells/Override)
slide-19
SLIDE 19

Calculating Savings

slide-20
SLIDE 20

King’s Cross Station

slide-21
SLIDE 21

Burning period from 00:00 to 04:00 Illuminance setting = 50 lux Energy Savings in this period = 49.98 % Average burning hours burning this period 4.00 hours Burning period from 04:00 to 24:00 Illuminance setting = 180 lux Energy Savings in this period = 57.93 % Average burning hours burning this period 9.32 hours Lighting System on for 24.0 hours per day Lamps burning for 13.3 hours per day Overall energy saving 56.61 % Lighting System on for 8,766 hours per year Lamps burning for 4,866 hours per year

King’s Cross Station

slide-22
SLIDE 22

Lighting System on for 24.0 hours per day Lamps burning for 13.3 hours per day Overall energy saving 56.61 % Lighting System on for 8,766 hours per year Lamps burning for 4,866 hours per year Initial load = 68.16kW 24/7 running costs estimated at £60,000 p.a. with annual relamping programme HOLOS 2 controlled system returns an energy cost of £26,400 p.a. with bi-annual relamping

Energy cost saving alone = £33,600 in the first year

HOLOS 2 Control system cost for Kings Cross = £22,000

King’s Cross Station

slide-23
SLIDE 23

H2B

Holos ‘Lite’

slide-24
SLIDE 24
  • Released September 2010
slide-25
SLIDE 25
  • Released September 2010
  • Low cost
slide-26
SLIDE 26
  • Released September 2010
  • Low cost
  • Simple controls - no software front end
slide-27
SLIDE 27
  • Released September 2010
  • Low cost
  • Simple controls - no software front end
  • Small installations
slide-28
SLIDE 28
  • Released September 2010
  • Low cost
  • Simple controls - no software front end
  • Small installations
slide-29
SLIDE 29

HOLOS2 will: Reduce your carbon emissions Reduce energy costs Give lowest total cost of

  • wnership
slide-30
SLIDE 30

Any Questions?
