AMCHIP: Backend integration A. Stabile for the AMchip collaboration - PowerPoint PPT Presentation

AMCHIP: Backend integration A. Stabile for the AMchip collaboration FTK review, CERN 09 Nov. 2011 FTK review (CERN) Alberto Stabile 9 Nov. 2011 1 / 29 Project flow The entire chip has been designed with a hybrid approach virtuoso Verilog


  1. AMCHIP: Backend integration A. Stabile for the AMchip collaboration FTK review, CERN 09 Nov. 2011 FTK review (CERN) Alberto Stabile 9 Nov. 2011 1 / 29

  2. Project flow The entire chip has been designed with a hybrid approach virtuoso Verilog netlist geometries SDF time back-annotate time back-annotate timing geometries Design rule check FULL CUSTOM Layout versus schematic calibre DESIGN More repetitive regions have been designed with a full custom approach More complex logics have been designed with a standard cell approach To place and route standard cells, we have used Foundation Flow of Cadence Encounter FTK review (CERN) Alberto Stabile 9 Nov. 2011 2 / 29

  3. The full custom cell At the middle of the design, we have placed peripheral circuitry 2 layers = 1/4 pattern 128 layers + 1 dummy layer in the middle STD CELLS FULL CUSTOM 8 layers 64 pattern vertically The TOP2 block is the larger full custom block designed. It’s composed by an array of 64 × 4 layers FTK review (CERN) Alberto Stabile 9 Nov. 2011 3 / 29

  4. The full custom frame interface A fringe interface in metal 1 has been designed with the same VSS-to-VDD pitch and widths STD cells More repetitive regions have been designed with a full custom approach More complex logics have been designed with a standard cell approach FTK review (CERN) Alberto Stabile 9 Nov. 2011 4 / 29

  5. The LEF file and the bblib file LEF The LEF file is used to describe the geometries of obstacles and pins of our full custom block bblib The bblib file describes the internal timing of full custom block in coarse way : In particular it describes: time arcs between: INIT → ML OUT (3:0) (From init signal to the registered match lines) MLEN → ML OUT (3:0) (From current-source enable signal to the registered match lines) setup time between: BL(3:0) → ML OUT (3:0) (From bit lines to the registered match lines) capacitances of each pin: These values are really important information for Encounter, which is able to choose the correct size buffer for each bitline. FTK review (CERN) Alberto Stabile 9 Nov. 2011 5 / 29

  6. First floorplan: free placing (without constraints) All blocks (macro + standard cells) have been automatically placed by Encounter. The routing algorithm does not converge! FTK review (CERN) Alberto Stabile 9 Nov. 2011 6 / 29

  7. First floorplan: placed without fences User defined positions for TOP2 blocks Automatic placement of other blocks The placement has been done using a flat description of the logic. FTK review (CERN) Alberto Stabile 9 Nov. 2011 7 / 29

  8. First floorplan: placed without fences User defined positions for TOP2 blocks Automatic placement of other blocks The placement has been done using a flat description of the logic. FTK review (CERN) Alberto Stabile 9 Nov. 2011 8 / 29

  9. First floorplan: placed without fences However the congestion (red lines) is too high and routing algorithm does not converge FTK review (CERN) Alberto Stabile 9 Nov. 2011 9 / 29

  10. First floorplan: placed with fences To decrease the routing congestion, we have designed fence areas containing the majority, the fisher tree, and 4 TOP2 macro blocks FTK review (CERN) Alberto Stabile 9 Nov. 2011 10 / 29

  11. First floorplan: placed with fences To decrease the routing congestion, we have designed fence areas containing the majority, the fisher tree, and 4 TOP2 macro blocks FTK review (CERN) Alberto Stabile 9 Nov. 2011 11 / 29

  12. First floorplan: placed with fences However the congestion is still high and routing algorithm do not converge! Solution: Analyze the congestions and re-size the routing channels FTK review (CERN) Alberto Stabile 9 Nov. 2011 12 / 29

  13. Final floorplan full custom full custom macro block macro block full custom full custom macro block macro block full custom full custom macro block macro block full custom full custom macro block macro block full custom full custom macro block macro block size: 3510 µ m × 3985.0 µ m FTK review (CERN) Alberto Stabile 9 Nov. 2011 13 / 29

  14. Pin out configuration FTK review (CERN) Alberto Stabile 9 Nov. 2011 14 / 29

  15. Power routing A ring pads of 208 pads has been placed We have left a space of 30 µ m between the ring pads and the standard cells. This space has been used to place power rings for VDD and VSS just inside the pad frame. The width of each power ring is 10 µ m. The power ring is connected to horizontal strips distributing power inside the chip using metal 1 (width = 330 nm) and vertical strips using metal 6 (width = 1300 nm). After some calculation we found that two layers (metal 1 and 6) are not sufficient for a good power distribution Solution: horizontal power strips in metal 5 (width = 3600 nm). These strips have been placed with a staggered/fringe approach to prevent routing FTK review (CERN) Alberto Stabile 9 Nov. 2011 15 / 29

  16. Routing (metal 1) FTK review (CERN) Alberto Stabile 9 Nov. 2011 16 / 29

  17. Routing (metal 2) FTK review (CERN) Alberto Stabile 9 Nov. 2011 17 / 29

  18. Routing (metal 3) FTK review (CERN) Alberto Stabile 9 Nov. 2011 18 / 29

  19. Routing (metal 4) FTK review (CERN) Alberto Stabile 9 Nov. 2011 19 / 29

  20. Routing (metal 5) FTK review (CERN) Alberto Stabile 9 Nov. 2011 20 / 29

  21. Power routing (metal 5) FTK review (CERN) Alberto Stabile 9 Nov. 2011 21 / 29

  22. Power routing (metal 6) FTK review (CERN) Alberto Stabile 9 Nov. 2011 22 / 29

  23. Number of power pads We have placed a large number of power supply and ground pads. This is done, to guarantee a correct power supply of the core 80 Mmin gnd 70 VDDcore VDDio 60 VDDcore + VDDio gnd + vdd Min number of power pad Current consumption estimated 50 40 30 20 10 0 0 0.5 1 1.5 2 Current consumption of a nominal rating power supply VDD [A] FTK review (CERN) Alberto Stabile 9 Nov. 2011 23 / 29

  24. Signal pad considerations We have chosen bidirectional pads capable of driving a current of 2 mA or 4 mA Even with only 2 mA the estimated pad to output time (including line capacity on PCB for up to 3000 mils) is less than 4 ns. PDDW0204SCDG DS! embedded microstrip PDDW0204SCDG DS embedded microstrip PDDW0408SCDG DS! embedded microstrip PDDW0408SCDG DS embedded microstrip 200 150 number of wire 100 50 0 2 2.2 2.4 2.6 2.8 3 3.2 3.4 3.6 3.8 4 time [ns] FTK review (CERN) Alberto Stabile 9 Nov. 2011 24 / 29

  25. Power consumption The power consumption has been estimated as high as about 70 mW for all full custom blocks and 75 mW for all the standard cells Empty spaces have been filled with decoupling capacitors to filter the power supply The power consumption has been estimated of the IO blocks is 100 mW. Blocks Power consumption Voltage supply Core standard cells ∼ 75 mW 1.2 V Core fullcustom blocks ∼ 70 mW 1.2 V IO cells ∼ 100 mW 3.3 V FTK review (CERN) Alberto Stabile 9 Nov. 2011 25 / 29

  26. Place and route optimized We have used the Foundation Flow (FF) by Cadence Encounter to perform place and route A lot of time was spent to set up the configuration file of the Foundation Flow, because it is important to select compatible libraries The flow contains some important timing optimization steps: pre-cts optimization post-cts optimization post-route optimization We have described the timing constraints in a .sdc file which contains: Setup time for input clocked registers ranges from 0.1 ns to 2.5 ns Hold time after clock for all outputs ranges from 0.1 ns to 2.5 ns The minimum clock period is 10 ns Timing results All the constraints are guaranteed in all optimization steps. FTK review (CERN) Alberto Stabile 9 Nov. 2011 26 / 29

  27. Clock Tree to enhance the timing perfomance Clock tree has been generated and results confirm that the clock distribution is good The maximum clock skew is equal to 400 ps FTK review (CERN) Alberto Stabile 9 Nov. 2011 27 / 29

  28. BackEnd status Completed: TOP2 (macro fullcustom block) designed to have a compatible interface with the STD cell world Pad ring completed: 208 pads have been placed to be compatible with the LAMB routing A study about driving current in the pads has been performed A study about power pad number has been performed Power routing completed: power rings and strips have been placed to obtain a good power distribuition in all regions Floorplan re-designed several times to avoid the routing congestion (stretching of routing channels) A stript has been developed to automatically create a .fp file (floorplan file) with parametric values FTK review (CERN) Alberto Stabile 9 Nov. 2011 28 / 29

  29. BackEnd status In progress: We are running place and route for the new version of FrontEnd logic We are refining the time constraints Future: Solve the issues signal integrity optimization Run DRC and LVS on the final version layout BackEnd simplification for the final user With the Foundation Flow we can easily run the command make postroute to run the script with all place and route instructions FTK review (CERN) Alberto Stabile 9 Nov. 2011 29 / 29
