AMICCOM Electronics Alex Chen Present Who we are? 2005.11 1997.9 Fabless RFIC design house Focus on proprietary RFIC Funding Capital 400 million NTD About 100 employees 70% R&D Key Investors

slide-1
SLIDE 1

AMICCOM Electronics

笙科電 笙科電子

Alex Chen Present

slide-2
SLIDE 2

Who we are?

1997.9 2005.11

  • Fabless RFIC design house
  • Focus on proprietary RFIC
  • Funding Capital 400 million NTD
  • About 100 employees 70% R&D
slide-3
SLIDE 3

亞洲商菱投資顧問股 有限公司 份 亞洲商菱投資顧問股 有限公司 份 (MC Capital Asia Ltd.) (MC Capital Asia Ltd.) 益鼎創業投資管理公司 益鼎創業投資管理公司 (TOP TAIWAN Venture Capital Group) (TOP TAIWAN Venture Capital Group)

Key Investors

22% 17%

slide-4
SLIDE 4

First PHS TRx By CMOS in the World

2004

First LNB Switch By CMOS in the World

2004

GPS Receiver By CMOS

2006

Sub 1GHz TRx 315/433/868/915 MHz

2007

Two VCs join 39% shareholders

2007

Zigbee Silicon Tuner UWB 5.8GHz

2008~2012

MITSUBISHI Top Capital 2.4GHz TRx 3Mbps/1Mbps

2005

Who we are?

slide-5
SLIDE 5
  • 1. Wireless data communication
  • 2. Mobile communication
  • 3. Satellite communication

Our Product

  • Sub 1GHz Family(315/433/868/915)
  • 2.4GHz Family
slide-6
SLIDE 6

Competitors 2.4GHz

Company IC Tx power Tx current Rx sensitivity Rx current VDD Data rate AMICCOM A7105 0dBm 20mA

  • 95dBm@500k

16mA 2.0~3. 6 <=500kbps TI/Chipcon CC2500 0dBm 21.2mA

  • 83dBm@500k

19.6mA 1.8~3. 6 <=500kbps AMICCOM A7125 0dBm 15.7mA

  • 92dBm@1M

16.2mA 2.0~3. 6 <=2Mbps Nordic nRF24L01+ 0dBm 11.3mA

  • 85dBm@1M

13.3mA 1.9~3. 6 <=2Mbps Cypress CYRF6936 0dBm 26.2mA

  • 84dBm@1M

18.4mA 1.8~3. 6 <=1Mbps Atmel ATR2406 4dBm 42mA

  • 93dBm@1152k

57mA 2.9~3. 6 <=1152kbp s EMC EM198810 2dBm 26mA

  • 85dBm@1M

25mA N/A <=1Mbps EMC EM198850 0dBm 20mA

  • 85dBm@1.6M

23mA 2.1~3. 6 <=1.6Mbps Alfaplus ARF2496 0dBm 13mA

  • 85dBm@1M

18mA 1.9~3. 6 <=1Mbps Ubec UM2460 0dBm 15mA

  • 80dBm@1M

18mA N/A <=1Mbps

A7105 -107dBm@2k A7125 -92dBm@1M Extra Sensitive A7121 3M A7130 2M/3M/4M Extra High Throughput A7700 PA+LNA+SW Highly Integrated RF Front End

slide-7
SLIDE 7

Competitors Sub 1GHz

Company IC Tx power Tx current Rx sensitivity Rx current VDD Data rate Ferq. AMICCOM A7102 15dBm 42mA

  • 116dBm@10k

13mA 2.2~3.6 <=150kbps 315/433/868/915 AMICCOM A7128 10dBm 36mA

  • 88dBm@2M

18.5mA 2.3~3.6 <=2Mbps 433/868/915 Nordic nRF905 10dBm 30mA

  • 100dBm@50k

12.5mA 1.9~3.6 <=50kbps 433/868/915 TI/Chipcon CC1101 12dBm 34.2mA

  • 111dBm@1.2k

16mA 1.8~3.6 <=600kbps 315/433/868/915 SiliconLab Si4432 13dBm 30mA

  • 121dBm@2k

18.5mA 1.8~3.6 <256kbps 315/433/868/915 AMICCOM A7103 10dBm 18mA

  • 107dBm@2.4k

9mA 2.0~3.3 <=20kbps 315/433/868/915 NXP UAA3220

  • 103dBm@

4.3mA 2.7~5.5 315/433/868/915 PTC PT4302

  • 112dBm@2k

2.7mA 2.4~5.5 <10k 315/433 PTC TX4915 6dBm 12.5mA 2.2~3.6 <20kbps 315/433/868/915

A7102 Tx=15dBm Rx=-116dBm@10k Extra High Power Extra Sensitive A7128 2M Extra High Throughput Transciever A7108 Tx=20dBm Rx=-114dBm@10k Extra High Power Extra Sensitive

slide-8
SLIDE 8

Applications

A7105(500k) Extra sensitive (-107dBm@2k) A7125(2M)

>2kk per month!!

slide-9
SLIDE 9

A7121(3M) A7130(2M/3M/4M) A7700(PA+LNA+SW) Wireless video

Applications

>85%!!

slide-10
SLIDE 10

Applications

A7125(2M) A7130(2M/3M/4M) A7700(PA+LNA+SW) Wireless audio

slide-11
SLIDE 11

Applications

A7103(TRx) A7201(Rx) A7202(Rx) A7302(Tx) HW control series Low cost RF 315/433/868/915MHz

slide-12
SLIDE 12

Applications

A7102(150k) A7108(250k) 315/433/868/915 Car alarm ,AMR A7533 LNB

slide-13
SLIDE 13

Why Amiccom

Firmware Hardware Mass production

Money Money

slide-14
SLIDE 14

Thank You

www.amiccom.com.tw Alex Chen Present Phone: +886 3 578 5818 ext.181 Mobile:+886 988 654 669 Mobile (China): +86 136 6170 6679 E-mail:slchen@amiccom.com.tw
