SLIDE 1

Advancements of the U.S. Egg Industry from 1960 to 2010: Productivity, Resource Utilization, and Environmental Footprint

Hongwei Xin1,2, Nathan Pelletier3, Maro Ibarburu1,2

1 Egg Industry Center; 2 Iowa State University 3 Consultant, Canada

A Presentation to GRA on Agricultural Greenhouse Gases

11 September 2015, Ames, Iowa

SLIDE 2

U.S. & Iowa Egg Industry

2 -

 U.S. human population: 319 M (2014)  U.S. laying hens: 305 M (March 2015), 270 M (June 2015) due to AI outbreak  U.S. eggs production: 87 B/yr  Per-capita egg consumption: 263 eggs/yr

69% shell eggs & 31% processed eggs

 94% of eggs produced in conventional cage housing systems  Iowa laying hens: 59/34.3 M (Mar/Jun’15)  Iowa eggs production: 16.3 B/yr (2014)

SLIDE 3

Presentation Outline

I. Rationale, Objectives, Methodology and Results of the “50-year Study” II. Drivers responsible for the observed changes in environmental footprints

III. Opportunities for further improvement
IV. Summary
3 -

SLIDE 4

I. Rationale, Objectives,

Methodology and Results

f the “50-year Study”
4 -

SLIDE 5

Rationale

Remarkable advancements made in the U.S.

egg production

No assessment of environmental footprint

affected by such advancements

Environmental sustainability is of increasing

socio-economic importance.

An evaluation is warranted.
5 -

SLIDE 6

Objectives

1. Compare 1960 and 2010 U.S. egg production

traits, i.e., HDEP, feed efficiency, pullet and hen BW, mortality, and water use.

2. Characterize supply chain GHG, acidifying and

eutrophying emissions, and energy demand for U.S. egg industry in both periods.

3. Quantify environmental footprint progress

arising from technological advancements over the past 50 years.

6 -

SLIDE 7

Production Systems Compared

Source: “Keeping Chickens in Cages” (by Hartman)

2010 Egg Production vs. 1960 Egg Production

7 -

SLIDE 8

Environmental Footprint Indicators

Global Warming Potential (GWP): a relative measure
f heat trapped by a GHG as compared to CO2 in the

atmosphere, expressed in CO2-eq.

Acidifying emissions (acidification): Emissions (e.g.,

NOx, SO2, NH3) or processes that cause decreased pH in ecological systems (soil/water), in SO2-eq.

Eutrophying emissions (eutrophication): Introduction
f artificial or natural substances, such as nitrates and

phosphates, to aquatic systems (e.g., hypoxia – causing increased growth of algae), in PO4-eq.

Cumulative Energy Demand (CED): life-cycle energy

needs for production of a good or service, in MJ

8 -

SLIDE 9

Methodology: Life Cycle Analysis (LCA) Protocols

Life-cycle environmental impacts calculated

using ISO-compliant LCA methodology and internationally-endorsed methods.

Cradle-to-facility gate system boundaries (i.e.,

all direct and indirect supply chain inputs and emissions).

Impact results examined to identify supply

chain “hot spots” and opportunities for footprint mitigation.

9 -

SLIDE 10

Methodology – LCA Elements

Fertilizers Pesticides Energy Carriers Transport Modes Livestock Production Livestock Processing and Rendering

Ton of Feed Ton of Feed Pullet Baby chick

Hatchery Chick Production

Manure Nutrients

Crop Processing Feed Milling Crop Production Salt, Limestone, Etc Corn, Soybean, Wheat, Etc Production Manure Management Egg Production Pullet Production

10

SLIDE 11

Methodology – Input Data to Models

Data for 1960 models collected from books,

publications, and communication with industry and academic experts.

USDA NASS publications, University extension

pubs, IPCC reference, & peer-reviewed articles.

Data for 2010 models collected via anonymous

surveys with egg companies.

– 57.1 million pullets – 92.5 million laying hens

11 -

SLIDE 12

Methodology – Data Collected

1) Production performance: hen-day egg production, feed use, egg weight, mortality rate, feed efficiency, BW of pullets at transfer to laying house, etc. 2) Manure production, composition and use 3) Feedstuffs production 4) Fertilizer production 5) Energy use: gasoline, diesel, electricity 6) Water use 7) Transportation: distance and modes 8) Other materials used (plastic, paper, etc.)

12 -

SLIDE 13

Pullet Production: 2010 vs. 1960

10.2 11.7 1.7 5.3 3.5 1.2

2 4 6 8 10 12 Feed consumed (kg) Mortality rate (%) Body weight (kg/bird) Year 1960 Year 2010 48%↓ 70%↓

30%↓

Key Findings of 50-Yr Study

13 -

SLIDE 14

Layer/Egg Production: 2010 vs. 1960

59.2 15.8 75.3 6.7 10 20 30 40 50 60 70 80 Egg production (eggs/100 layers/day) Mortality rate (% per year) Layers 1960 Layers 2010

27%↑ 57%↓

14 -

Key Findings of 50-Yr Study

SLIDE 15

Layer/Egg Production: 2010 vs. 1960

12.23 2.48 3.41 9.03 1.45 1.98

2 4 6 8 10 12 14

Feed consumption (kg/100 layers/day) Feed conversion (kg feed/dozen) Feed conversion (kg feed/kg eggs)

Layers 1960 Layers 2010

26%↓ 42%↓

15 -

Key Findings of 50-Yr Study

SLIDE 16

Layer/Egg Production: 2010 vs. 1960

89.7 149.5 77.7 101.7 20 40 60 80 100 120 140 160 Water use (liters/layer/year) Water use (liters/case) Layers 1960 Layers 2010 13%↓ 32%↓

16 -

Key Findings of 50-Yr Study

SLIDE 17

Footprint per Tonne of Egg Production: 2010 vs. 1960

200 70 70 20 50 100 150 200 Acidification (kg SO2 eq) Eutrophication (kg PO4 eq) Eggs 1960 Eggs 2010

65%↓ 71%↓

17 -

Key Findings of 50-Yr Study

SLIDE 18

Footprint per Tonne of Egg Production: 2010 vs. 1960

7.2 17.7 2.1 12.3 2 4 6 8 10 12 14 16 18 GWP (1,000 kg CO2 eq) CED (MJ) Eggs 1960 Eggs 2010

71%↓ 31%↓

18 -

Key Findings of 50-Yr Study

SLIDE 19

Key Findings of 50-Yr Study

 Environmental footprints of GHG, acidification and eutrophication emissions per kg egg output in 2010 are one-third or less of those in 1960. The reductions are equivalent to:

19 -

5.2 million cars

ff the road

(25 million less metric ton CO2-e) Closure of ~59 U.S. coal plants (606,840 less metric ton SO2) 100 million 50-lb bags (10-10-10)

f lawn fertilizer

(233,400 less metric ton PO4)

SLIDE 20

Compared to 1960 hens, 2010 hens have

32% lower water use, equivalent to annual water

savings of

Key Findings of 50-Yr Study

~ 3,700 Olympic swimming pools ~9.3 million m3 or ~2.5 billion gallons per year

20 -

SLIDE 21

Additional resources needed using 1960 technology to produce eggs for 2010:

27% (78 million) more hens
72% (1.3 million acre) more land for corn
72% (1.8 million acre) more land for soybean

Key Findings of 50-Yr Study

2.3 million football fields 3.1 million acres or 1.25 million hectares of land

21 -

SLIDE 22

22 -

While supplying 30% more eggs in 2010, the total environmental footprints are 54% to 63% lower than in 1960 except for CED that is 10% less. Manure management and feed efficiency are the primary “hot spots” for reducing footprint.

Key Findings of 50-Yr Study

SLIDE 23

Relative Footprint Contributions

f Egg Production Components

34.4% 40.1% 71.2% 71.4% 6.1% 17.0% 54.7% 51.1% 13.9% 9.8% 8.9% 8.9% 11.3% 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% Acidification Eutrophication GWP CED Pullets Manure Mgmt Energy Inputs Layer Feed

23 -

Key Findings of 50-Yr Study

SLIDE 24

II. Drivers Responsible for the

Observed Changes

24 -

SLIDE 25

Drivers for the Resultant Changes

1. Background systems
crop yields, energy carriers, fertilizer,

transport modes, etc.

2. Feed composition
3. Animal performance
25 -

SLIDE 26

y = 1.8276x - 3520.9 R² = 0.9499 20 40 60 80 100 120 140 160 180 1910 1960 2010 Yield (bushels/acre) Year

Corn Yield Trend

179% increase

Changes in Background System: Corn Yield

26 -

Source: USDA NASS

SLIDE 27

Changes in Background System: Soybean Yield

27 -

y = 0.3471x - 656.57 R² = 0.9474 5 10 15 20 25 30 35 40 45 50 1910 1960 2010 Yield (bushels/acre) Year

Soybeans Yield Trend

85% increase Source: USDA NASS

SLIDE 28

Changes in Animal Performance: Pullets

28 -

10.2 11.7 1.7 5.3 3.5 1.2

2 4 6 8 10 12 Feed consumed (kg) Mortality rate (%) Body weight (kg/bird) Year 1960 Year 2010 48%↓ 70%↓

30%↓

SLIDE 29

Changes in Animal Performance: Hen Productivity

29 -

y = 0.3188x - 564.81 R² = 0.9671

50 55 60 65 70 75 80 1950 1970 1990 2010

Egg production (eggs/100 layers/day)

Averaging 1.16 extra eggs per hen per year

A hen in 2010 produces 58 extra eggs per year than her counterpart in 1960!

SLIDE 30

7,230 5,797 3,526 2,080 1,000 2,000 3,000 4,000 5,000 6,000 7,000 8,000 Eggs - 1960 Eggs - 1960 (ˠ) Eggs - 1960 (*) Eggs - 2010 kg CO2-e / tonne

GWP per tonne of eggs

28% background systems Percent of the change due to changes in: 44% feed composition 28% animal performance 100% total

(ˠ) Same background system data (i.e., crop yields, energy carriers, fertilizers, transport modes, etc.) as in 2010 model. (*) Same feed composition and background system data as in 2010 model (i.e., only differences in feed conversion, mortalities, emissions from manure management, etc. are considered).

Partitioning of Drivers for Resultant Changes in GHG Emissions

GHG emissions per tonne of eggs

30 -

SLIDE 31

(ˠ) Same background system data (i.e., crop yields, energy carriers, fertilizers, transport modes, etc.) as in 2010 model. (*) Same feed composition and background system data as in 2010 model (i.e., only differences in feed conversion, mortalities, emissions from manure management, etc. are considered). 200 165 126 70 50 100 150 200 250 Eggs – 1960 Eggs - 1960 (ˠ) Eggs – 1960 (*) Eggs – 2010 kg SO2-e / tonne

Acidification per tonne of eggs

27% background systems Percent of the change due to changes in: 30% feed composition 43% animal performance 100% total

31 -

Partitioning of Drivers for Resultant Changes in Acidifying Emissions

Acidifying emissions per tonne of eggs

SLIDE 32

70 55 38 20 10 20 30 40 50 60 70 80 Eggs - 1960 Eggs - 1960 (ˠ) Eggs - 1960 (*) Eggs - 2010 kg PO4-e / tonne

Eutrophication per tonne of eggs

30% background systems Percent of the change due to changes in: 34% feed composition 36% animal performance 100% total

Partitioning of Drivers for Resultant Changes in Eutrophying Emissions

(ˠ) Same background system data (i.e., crop yields, energy carriers, fertilizers, transport modes, etc.) as in 2010 model. (*) Same feed composition and background system data as in 2010 model (i.e., only differences in feed conversion, mortalities, emissions from manure management, etc. are considered).

Eutrophying emissions per tonne of eggs

32 -

SLIDE 33

III. Opportunities for

Further Improvements

33 -

SLIDE 34

Relative Contributions of EGG Production Environmental Footprint

34.4% 40.1% 71.2% 71.4% 6.1% 17.0% 54.7% 51.1% 13.9% 9.8% 8.9% 8.9% 11.3% 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% Acidification Eutrophication GWP CED Pullets Manure Mgmt Energy Inputs Layer Feed

Manure management and feed efficiency are the primary “hot spots”.
34 -

SLIDE 35

Further Improvement: Housing & Manure Management – NH3 Emissions of high-rise vs. manure-belt

AU = animal unit = 500 kg body weight

316 38 100 200 300 400 500 600

High-rise Belt

Layer Housing Type

NH3 ER (g/AU-day)

House

Storage

35 -

SLIDE 36

Further Improvement: U.S. Trend in Hen House Construction

Courtesy of Tom Lippi & Rick VanPuffelen, CTB

36 -

SLIDE 37

37

1% lower CP → 11% reduction in NH3 emission

20 40 60 80 100 January February March April May June July August September October November December Month of 2003 NH3 ER (mg/h-bird)

50
40
30
20
10

10 20 30 Temperature (C)

Standard Low Crude Protein T outside

NH3 ER (g/hen-d) Standard Diet LP Diet 0.90 (0.24-1.58) 0.80 (0.19-1.37)

Liang et al. (2005)

Potential Further Improvement: Dietary Modification

NH3 ER (g/hen-d) Control DDGS EcoCal 0.96 (0.05) 0.82 (0.05) 0.58 (0.05) % ↓ 14 (5) 39 (5)

0.0 0.5 1.0 1.5 2.0 2.5

12 1 2 3 4 5 6 7 8 9 10 11 12 1 2 3 4 5 6 7 8 9 10 11

Month of 2007 - 2009 NH3 ER, g hen -1d-1 Control DDGS EcoCal

EcoCal molting Ctrl molting DDGS molting

Li et al. (2012)

37 -

SLIDE 38

Potential Improvement: Treating Exhaust Air – Vegetative Buffer

38 -
PM reduction: 49±27% (33 d)
NH3 reduction: 46±31% (29 d)
Odor reduction: negligible

Malone et al., (2006) Patterson (2013)

SLIDE 39

3-stage scrubber :

Capital cost: $47-$72/pig
Operation cost: $15-$19/yr

Potential Improvement: Treatment of Exhaust Air – Wet Scrubber

39 -

SLIDE 40

High pressure fogging

at air inlet (~1,000 psi

r ~7,000 kPa)
Retrofitting
40 -

Further Improvement: Better Housing Environment Control

Evaporative cooling pads

at air inlet

New construction
Enhance cooling

efficiency through tunnel ventilation

SLIDE 41

Further Improvement: Better Environmental Control – Impact of

Pad-Fan Cooling on Laying-Hen Mortality

Xin, 2013 (unpublished data)

41 -

SLIDE 42

Hen Mortality vs. Max Indoor Temp

No. of flocks for each daily mean: 51 - 67

Xin, 2013 (unpublished data)

42 -

SLIDE 43

Hen-Day Egg vs. Indoor Temperature

Xin, 2013 (unpublished data)

43 -

SLIDE 44

Summary

Egg production in the United States has advanced dramatically over past 50 years.

Environmental footprints for 1 kg egg output in

2010 are 1/3 or less of those in 1960.

The reductions in environmental footprint are attributable to advancements in:

Background systems (27% – 30%)
Feed composition (30% – 44%)
Animal performance (28% – 43%)

Feed efficiency and manure management are the primary areas for further improvements.

44 -

SLIDE 45

Acknowledgements

American Egg Board, United Egg Allied, U.S.

Poultry and Egg Association, and Egg Industry Center for funding the 50-yr Study.

Participating U.S. egg companies for their

cooperation in providing the essential data.

UEP staff for their support and assistance with

the industry survey.

Mr. Don Bell and Dr. Jim Arthur for their insights

about the 1960 egg production.

45 -
